Kenwood ProTalk TK-3401D User manual

TK-3401D
UHF DIGITAL TRANSCEIVER
© B5A-0037-00 (E,T)
INSTRUCTION MANUAL

THANK YOU
We are grateful you have chosen KENWOOD for your
dPMR446 applications.
OPERATING CONDITIONS
Open locations (no obstructions) : Up to 9.0 km
Note:
◆The above range is based on field testing and may vary with your
operating conditions and individual transceiver.
◆
Digital technology provides superior clarity in extended coverage.
As RF signal strength weakens with distance, analog reception
becomes increasingly noisy and intermittent. dPMR's low BER
improves reception in fringe areas, thereby “effectively” increasing
coverage as much as twenty percent over analog.
The AMBE+2TM voice coding Technology embodied in this product is protected
by intellectual property rights including patent rights, copyrights and trade
secrets of Digital Voice Systems, Inc. This voice coding Technology is
licensed solely for use within this Communications Equipment. The user of
this Technology is explicitly prohibited from attempting to extract, remove,
decompile, reverse engineer, or disassemble the Object Code, or in any other
way convert the Object Code into a human-readable form. U.S. Patent Nos.
#5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011 and
#5,581,656

i
NOTICES TO THE USER
Refer service to qualified technicians only.
Safety: It is important that the operator is aware of, and
understands, hazards common to the operation of any
transceiver.
This equipment complies with the essential requirements of Directive
1999/5/EC.
Firmware Copyrights
The title to and ownership of copyrights for firmware embedded in
KENWOOD product memories are reserved for JVC KENWOOD
Corporation.
Information on Disposal of Old Electrical and Electronic Equipment and
Batteries (applicable for countries that have adopted separate waste
collection systems)
Products and batteries with the symbol (crossed-out wheeled bin)
cannot be disposed as household waste.
Old electrical and electronic equipment and batteries should be
recycled at a facility capable of handling these items and their
waste byproducts.
Contact your local authority for details in locating a recycle facility
nearest to you.
Proper recycling and waste disposal will help conserve resources
whilst preventing detrimental effects on our health and the
environment.
Notice: The sign “Pb” below the symbol for batteries indicates that
this battery contains lead.

ii
Turn the transceiver power off in the following locations:
• In explosive atmospheres (inflammable gas, dust particles, metallic
powders, grain powders, etc.).
• While taking on fuel or while parked at gasoline service stations.
• Near explosives or blasting sites.
• In aircraft. (Any use of the transceiver must follow the instructions
and regulations provided by the airline crew.)
• Where restrictions or warnings are posted regarding the use of
radio devices, including but not limited to medical facilities.
• Near persons using pacemakers.
PRECAUTIONS
• Do not charge the transceiver and battery pack when they are
wet.
• Ensure that there are no metallic items located between the
transceiver and the battery pack.
• Do not use options not specified by KENWOOD.
• If the die-cast chassis or other transceiver part is damaged, do
not touch the damaged parts.
• If a headset or headphone is connected to the transceiver,
reduce the transceiver volume. Pay attention to the volume level
when turning the squelch off.
• Do not place the microphone cable around your neck while near
machinery that may catch the cable.
• Do not place the transceiver on unstable surfaces.
• Ensure that the end of the antenna does not touch your eyes.
• When the transceiver is used for transmission for many hours,
the radiator and chassis will become hot. Do not touch these
locations when replacing the battery pack.
• Do not immerse the transceiver in water.
• Always switch the transceiver power off before installing optional
accessories.
• The charger is the device that disconnects the unit from the AC
mains line. The AC plug should be readily accessible.

iii
• Do not disassemble or modify the transceiver for any reason.
• Do not place the transceiver on or near airbag equipment while the
vehicle is running. When the airbag inflates, the transceiver may be
ejected and strike the driver or passengers.
• Do not transmit while touching the antenna terminal or if any
metallic parts are exposed from the antenna covering. Transmitting
at such a time may result in a high-frequency burn.
• If an abnormal odor or smoke is detected coming from the
transceiver, switch the transceiver power off immediately,
remove the battery pack from the transceiver, and contact your
KENWOOD dealer.
•
Use of the transceiver while you are driving may be against traffic
laws. Please check and observe the vehicle regulations in your area.
• Do not expose the transceiver to extremely hot or cold conditions.
• Do not carry the battery pack (or battery case) with metal objects,
as they may short the battery terminals.
• Danger of explosion if the battery is incorrectly replaced; replace
only with the same type.
• When attaching a commercial strap to the transceiver, ensure
that the strap is durable. In addition, do not swing the transceiver
around by the strap; you may inadvertently strike and injure
another person with the transceiver.
• If a commercially available neck strap is used, take care not to let
the strap get caught on nearby machine.
• When operating the transceiver in areas where the air is dry, it is
easy to build up an electric charge (static electricity). When using
an earphone accessory in such conditions, it is possible for the
transceiver to send an electric shock through the earphone and to
your ear. We recommend you use only a speaker/microphone in
these conditions, to avoid electric shocks.

iv
Information concerning the battery pack:
The battery pack includes flammable objects such as organic
solvent. Mishandling may cause the battery to rupture
producing flames or extreme heat, deteriorate, or cause other
forms of damage to the battery. Please observe the following
prohibitive matters.
• Do not disassemble or reconstruct battery!
The battery pack has a safety function and protection circuit to
avoid danger. If they suffer serious damage, the battery may
generate heat or smoke, rupture, or burst into flame.
• Do not short-circuit the battery!
Do not join the + and – terminals using any form of metal (such
as a paper clip or wire). Do not carry or store the battery pack in
containers holding metal objects (such as wires, chain-necklaces or
hairpins). If the battery pack is short-circuited, excessive current will
flow and the battery may generate heat or smoke, rupture, or burst
into flame. It will also cause metal objects to heat up.
• Do not incinerate or apply heat to the battery!
If the insulator is melted, the gas release vent or safety function is
damaged, or the electrolyte is ignited, the battery may generate
heat or smoke, rupture, or burst into flame.
• Do not leave the battery near fire, stoves, or other heat
generators (areas reaching over 80°C/ 176°F)!
If the polymer separator is melted due to high temperature, an
internal short-circuit may occur in the individual cells and the
battery may generate heat or smoke, rupture, or burst into flame.
• Avoid immerse the battery in water or get it wet by other
means!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
• Do not charge the battery near fire or under direct sunlight!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.

v
• Use only the specified charger and observe charging
requirements!
If the battery is charged in unspecified conditions (under high
temperature over the regulated value, excessive high voltage or
current over regulated value, or with a remodeled charger), it may
overcharge or an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
• Do not pierce the battery with any object, strike it with an
instrument, or step on it!
This may break or deform the battery, causing a short-circuit. The
battery may generate heat or smoke, rupture, or burst into flame.
• Do not jar or throw the battery!
An impact may cause the battery to leak, generate heat or smoke,
rupture, and/or burst into flame. If the battery’s protection circuit
is damaged, the battery may charge at an abnormal current (or
voltage), and an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
• Do not use the battery pack if it is damaged in any way!
The battery may generate heat or smoke, rupture, or burst into
flame.
• Do not solder directly onto the battery!
If the insulator is melted or the gas release vent or safety function
is damaged, the battery may generate heat or smoke, rupture, or
burst into flame.
• Do not reverse the battery polarity (and terminals)!
When charging a reversed battery, an abnormal chemical reaction
may occur. In some cases, an unexpected large amount of current
may flow upon discharging. The battery may generate heat or
smoke, rupture, or burst into flame.
• Do not reverse-charge or reverse-connect the battery!
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating
equipment, do not force it; check the polarity of the battery. If the
battery pack is reverse-connected to the charger, it will be reverse-
charged and an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.

vi
• Do not touch a ruptured and leaking battery!
If the electrolyte liquid from the battery gets into your eyes, wash
your eyes with fresh water as soon as possible, without rubbing
your eyes. Go to the hospital immediately. If left untreated, it may
cause eye-problems.
• Do not charge the battery for longer than the specified time!
If the battery pack has not finished charging even after the
regulated time has passed, stop it. The battery may generate heat
or smoke, rupture, or burst into flame.
• Do not place the battery pack into a microwave or high
pressure container!
The battery may generate heat or smoke, rupture, or burst into
flame.
• Keep ruptured and leaking battery packs away from fire!
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte leaking
from battery can easily catch on fire and may cause the battery to
generate smoke or burst into flame.
• Do not use an abnormal battery!
If the battery pack emits a bad odor, appears to have different
coloring, is deformed, or seems abnormal for any other reason,
remove it from the charger or operating equipment and do not use
it. The battery may generate heat or smoke, rupture, or burst into
flame.

1
CONTENTS
UNPACKING AND CHECKING EQUIPMENT.......................... 1
PREPARATION .......................................................... 2
ORIENTATION ........................................................... 8
BASIC OPERATIONS .................................................. 10
CHANNEL SETUP MODE.............................................. 11
KEY ASSIGNMENT MODE ............................................ 20
BACKGROUND OPERATIONS ........................................ 24
VOICE OPERATED TRANSMISSION (VOX) ......................... 25
ALL RESET MODE ..................................................... 26
TROUBLESHOOTING GUIDE ......................................... 27
UNPACKING AND CHECKING EQUIPMENT
Carefully unpack the transceiver. If any of the items listed
below are missing or damaged, file a claim with the carrier
immediately.
SUPPLIED ACCESSORIES
• Battery charger/ AC adapter (KSC-35S) ................................1
• Li-ion Battery pack (KNB-45L)................................................ 1
• Cap.........................................................................................1
• Locking bracket.......................................................................1
• Belt clip (KBH-10)...................................................................1
• Screw (M3 x 8 mm) ................................................................ 2
• Quick Reference Guide .......................................................... 1
Note:
◆Refer to “PREPARATION” {p.2} for accessory installation
instructions.

2
PREPARATION
INSTALLING/ REMOVING THE BATTERY PACK
◆
Do not short the battery terminals or dispose of the battery by fire.
◆Never attempt to remove the casing from the battery pack.
◆Install the battery pack after cleaning the battery pack contacts
and the transceiver terminals.
1Align the battery pack with the back
of the transceiver, then press the
battery pack and transceiver firmly
together until the release latch on
the base of the transceiver locks.
2To remove the battery pack, lift the
safety catch on the base of the
transceiver, then press the release
latch underneath the safety catch.
3While pressing the release latch,
pull the battery pack away from the
transceiver.

3
Indicator
• Make sure the metal contacts of
the battery pack mate securely
with the charger terminals.
• The indicator lights red and
charging begins.
4When charging is completed, the indicator lights green.
Remove the battery pack or the transceiver from the
charging slot of the charger.
• It takes approximately 3 hours to charge the battery pack.
• When the charger will not be used for a long time, unplug the
AC adapter from the AC outlet.
Note:
◆When an abnormality occurs during charging, the indicator performs
as follows:
Blinks Red: The battery pack is either defective or the battery pack
contacts are not properly mated with those of the charger.
Alternates Flashing Green and Orange: The battery pack has not
satisfied the charging start temperature. Remove the battery pack
from the charger and wait until it reaches a normal temperature before
charging it again.
◆The ambient temperature should be between 5°C and 40°C while
charging is in progress. Charging outside this range may not fully
charge the battery.
CHARGING THE BATTERY PACK
The battery pack is not charged at the factory; charge it before
use.
ATTENTION:
◆Always switch OFF a transceiver equipped with a battery pack
before inserting the transceiver into the charger.
1Plug the AC adapter cable into the jack located on the rear
of the charger.
2Plug the AC adapter into an AC outlet.
3Slide a battery pack or a transceiver equipped with a
battery pack into the charging slot of the charger.

4
INSTALLING THE BELT CLIP
Do not use glue which is designed to prevent screw loosening when
installing the belt clip, as it may cause damage to the transceiver. Acrylic
ester, which is contained in these glues, may crack the transceiver’s back
panel.
Belt clip
If necessary, attach the belt clip using
the two supplied M3 x 8 mm screws.
Note:
◆If the belt clip is not installed, its
mounting location may get hot during
continuous transmission or when left
sitting in a hot environment.
◆The battery pack life is over when its operating time decreases even
though it is fully and correctly charged. Replace the battery pack.
◆While operating the transceiver using a Li-ion battery pack in areas of
an ambient temperature of –10°C and lower, operating time may be
shortened.
BATTERY LIFE
The operating times listed in the table below are measured
under the following cyclic conditions:
Calculated using 5% transmit time, 5% receive time, and 90%
standby time.
Battery Type
Operating Time/ Hours (Approx.)
Digital Mode Analog Mode
Battery Saver
On
Battery Saver
Off
Battery Saver
On
Battery Saver
Off
KNB-45L
Supplied battery 16 H 14H 18H 14H
KNB-69L
Optional battery 22 H 18H 24H 18H

5
INSTALLING THE CAP OVER THE SPEAKER/
MICROPHONE JACKS
Install the cap over the speaker/ microphone jacks when not
using an optional speaker/ microphone or headset.
Note:
◆To keep the transceiver water resistant, you must cover the
speaker/ microphone jacks with the supplied cap.
1Place the cap over the jacks so that the locking
tabs insert into the transceiver grooves.
2While holding the cap in place, push it towards
the bottom of the transceiver until the tabs on
the cap click into place.
• To remove the cap, hold the top of the cap in
place with your finger while inserting a 2 mm or
smaller flat blade screwdriver under the bottom
of the cap. Slowly slide the screwdriver in until its
tip touches the tab inside the cap, then gently pry
the cap up (handle of screwdriver moving away
from the transceiver) to remove the cap.

6
INSTALLING THE OPTIONAL SPEAKER/ MICROPHONE
(OR HEADSET)
Note:
◆The transceiver is not fully water resistant when using a speaker/
microphone or headset.
1Insert the speaker/ microphone (or
headset) plugs into the speaker/
microphone jacks of the transceiver.
2Place the locking bracket over the
speaker/ microphone (or headset)
plugs so that the locking tabs insert
into the transceiver grooves.
• Push down on the locking bracket to
slide it into place.
3While holding the locking bracket in
place, push it towards the bottom of
the transceiver until the tabs on the
bracket click into place.
• To remove the locking bracket, push
the bracket up from the base.

7
SWITCHING THE AUDIO OUTPUT
It is necessary to switch the audio output if you listen only
through the earphone (2.5).
1Switch the transceiver power OFF.
2Press and hold the PTT switch and Side 2 key while turning
the transceiver power ON.
3Continue to hold the PTT switch and Side 2 key until a
beep sounds.
• Repeat steps 1 to 3 to switch the audio output.
• When the audio output is switched to earphone, you will hear
the beep from the earphone; and a beep will sound from the
speaker when the audio output is switched to built-in speaker.

8
ORIENTATION
Battery pack
Selector
Rotate to change the operating channel.
• To change the operating frequency, Common ID or QT/DQT
settings of a channel, refer to “CHANNEL SETUP MODE”
{p.11}.
• Channel Annunciation: When changing channels, the
transceiver will announce the newly selected channel number.
LED indicator
Refer to the LED indicator status. {p.9}
Power switch/ Volume control
Turn clockwise to switch the transceiver ON. To switch the
transceiver OFF, turn counterclockwise until a click sounds.
Rotate to adjust the volume level.
PTT (Push to Talk) switch
Press and hold, then speak into the microphone to transmit.
Antenna
Microphone Speaker

9
Side 1 key
Press to activate its programmable function.
The default setting is [Zone].
• For function descriptions and details on how to change the
function of the Side 1 key, refer to “KEY ASSIGNMENT MODE”
{p.17}.
Side 2 key
Press to activate its programmable function.
The default setting is [Squelch Off Momentary].
• For function descriptions and details on how to change the
function of the Side 2 key, refer to “KEY ASSIGNMENT MODE”
{p.17}.
Speaker/ microphone jacks
Insert the Speaker/ microphone or Headset plug into this
jack.
LED Indicator Status
Indicator Color Meaning
Flashes blue Digital mode
Flashes orange Analog mode
Lights red Transmitting
Lights green Receiving a call
Blinks red Battery power is low
Blinks green Scanning
Blinks red/orange The selected channel has not been
programmed and cannot be used.

10
BASIC OPERATIONS
1Turn the Power switch/ Volume control
clockwise to switch the transceiver power
ON.
• A beep will sounds.
2Press the key programmed with the
[Monitor] or [Squelch Off] (Side 2 key
default) function to hear background noise,
then rotate the Power switch/ Volume
control to adjust the volume.
3Rotate the Selector to select your desired
channel.
• When you receive an appropriate signal, you
will hear audio from the speaker.
4To make a call, press and hold the PTT
switch, then speak into the microphone
using your normal speaking voice.
• Hold the microphone approximately 3 to 4 cm
(1.5 inches) from your lips.
5Release the PTT switch to receive.
Note:
◆When the battery pack voltage becomes too low, transmission will
stop and an alert tone will sound.

11
CHANNEL SETUP MODE
This transceiver allows you to reprogram each of the channels
with different frequencies and Common ID (Digital)/ QT/DQT
(Analog) settings. The table below lists the default channel
settings.
Zone type Digital
Channel Number Frequency Common ID
1446.103125 MHz 1
2446.109375 MHz 2
3446.115625 MHz 3
4446.121875 MHz 4
5446.128125 MHz 5
6446.134375 MHz 6
7446.140625 MHz 7
8446.146875 MHz 8
9446.153125 MHz 9
10 446.159375 MHz 10
11 446.165625 MHz 11
12 446.171875 MHz 12
13 446.178125 MHz 13
14 446.184375 MHz 14
15 446.190625 MHz 15
16 446.196875 MHz 16

12
Zone type Analog
Channel Number Frequency QT/DQT
1446.00625 MHz 94.8 Hz
2446.09375 MHz 88.5 Hz
3446.03125 MHz 103.5 Hz
4446.06875 MHz 79.7 Hz
5446.04375 MHz 118.8 Hz
6446.01875 MHz 123.0 Hz
7446.08125 MHz 127.3 Hz
8446.05625 MHz 85.4 Hz
9446.00625 MHz 107.2 Hz
10 446.09375 MHz 110.9 Hz
11 446.03125 MHz 114.8 Hz
12 446.06875 MHz 82.5 Hz
13 446.04375 MHz D132N
14 446.01875 MHz D155N
15 446.05625 MHz D134N
16 446.08125 MHz D243N
Note:
◆You must first select an operating frequency for a channel before
you can select a Common ID (Digital)/ QT/DQT (Analog) setting
for that same channel.
