Kenwood ProTalk tk-3501 User manual

.
TK-3501
.
UHF FM TRANSCEIVER
QUICK REFERENCE GUIDE
ÉMETTEUR-RÉCEPTEUR FM UHF
GUIDE DE RÉFÉRENCE RAPIDE
TRANSCEPTOR FM UHF
GUÍA DE REFERENCIA RÁPIDA
RICETRASMETTITORE FM UHF
GUIDA DI RIFERIMENTO RAPIDO
UHF-FM-TRANSCEIVER
KURZANLEITUNG
UHF FM ZENDONTVANGER
BEKNOPTE HANDLEIDING
UHF FM EL TELSİZİ
HIZLI REFERANS KILAVUZU
ΠΟΜΠΟΔΕΚΤΗΣ FM UHF
ΟΔΗΓΟΣ ΓΡΗΓΟΡΗΣ ΑΝΑΦΟΡΑΣ
TRANSCETOR UHF FM
GUIA DE CONSULTA RÁPIDA
.
© B5A-0020-00 (E)

.

.
TK-3501
UHF FM TRANSCEIVER
QUICK REFERENCE GUIDE
ENGLISH

THANK YOU
We are grateful you have chosen KENWOOD for your PMR446
applications.
This Quick Reference Guide covers only the basic operations of your
PMR446 (Private Mobile Radio). Ask your dealer for information on
any customized features they may have added to your radio. For using
details instruction manual, refer to the following URL.
http://manual2.jvckenwood.com/en_contents/search/
OPERATING CONDITIONS
Open locations (no obstructions) : Up to 9.0 km
Note:
◆
The above range is based on field testing and may vary with your
operating conditions and individual transceiver.

NOTICES TO THE USER
Refer service to qualified technicians only.
Safety: It is important that the operator is aware of, and
understands, hazards common to the operation of any
transceiver.
This equipment complies with the essential requirements of
Directive 1999/5/EC.
Information on Disposal of Old Electrical and Electronic Equipment and
Batteries (applicable for countries that have adopted separate waste
collection systems)
Products and batteries with the symbol (crossed-out wheeled bin)
cannot be disposed as household waste.
Old electrical and electronic equipment and batteries should be recycled
at a facility capable of handling these items and their waste byproducts.
Contact your local authority for details in locating a recycle facility nearest
to you.
Proper recycling and waste disposal will help conserve resources whilst
preventing detrimental effects on our health and the environment.
Notice: The sign “Pb” below the symbol for batteries indicates that this
battery contains lead.
Firmware Copyrights
The title to and ownership of copyrights for firmware embedded in
KENWOOD product memories are reserved for JVC KENWOOD
Corporation.
ⅰ

PRECAUTIONS
●
Do not charge the transceiver and battery pack when they are wet.
●Ensure that there are no metallic items located between the transceiver
and the battery pack.
●Do not use options not specified by KENWOOD.
●If the die-cast chassis or other transceiver part is damaged, do not
touch the damaged parts.
●If a headset or headphone is connected to the transceiver, reduce the
transceiver volume. Pay attention to the volume level when turning the
squelch off.
●Do not place the microphone cable around your neck while near
machinery that may catch the cable.
●Do not place the transceiver on unstable surfaces.
●Ensure that the end of the antenna does not touch your eyes.
●When the transceiver is used for transmission for many hours, the
radiator and chassis will become hot. Do not touch these locations
when replacing the battery pack.
●Do not immerse the transceiver in water.
●Always switch the transceiver power off before installing optional
accessories.
●The charger is the device that disconnects the unit from the AC mains
line. The AC plug should be readily accessible.
WARNING
Turn the transceiver power off in the following locations:
●In explosive atmospheres (inflammable gas, dust particles, metallic
powders, grain powders, etc.).
●While taking on fuel or while parked at gasoline service stations.
●Near explosives or blasting sites.
●In aircraft. (Any use of the transceiver must follow the instructions
and regulations provided by the airline crew.)
●Where restrictions or warnings are posted regarding the use of
radio devices, including but not limited to medical facilities.
●Near persons using pacemakers.
ⅱ

CAUTION
●Do not disassemble or modify the transceiver for any reason.
●Do not place the transceiver on or near airbag equipment while the
vehicle is running. When the airbag inflates, the transceiver may be
ejected and strike the driver or passengers.
●Do not transmit while touching the antenna terminal or if any
metallic parts are exposed from the antenna covering. Transmitting
at such a time may result in a high-frequency burn.
●
If an abnormal odor or smoke is detected coming from the transceiver,
switch the transceiver power off immediately, remove the battery pack
from the transceiver, and contact your KENWOOD dealer.
●Use of the transceiver while you are driving may be against traffic
laws. Please check and observe the vehicle regulations in your
area.
●Do not expose the transceiver to extremely hot or cold conditions.
●Do not carry the battery pack with metal objects, as they may short
the battery terminals.
●Danger of explosion if the battery is incorrectly replaced; replace
only with the same type.
●When attaching a commercial strap to the transceiver, ensure that
the strap is durable. In addition, do not swing the transceiver around
by the strap; you may inadvertently strike and injure another person
with the transceiver.
●If a commercially available neck strap is used, take care not to let
the strap get caught on nearby machine.
●When operating the transceiver in areas where the air is dry, it is
easy to build up an electric charge (static electricity). When using
an earphone accessory in such conditions, it is possible for the
transceiver to send an electric shock through the earphone and to
your ear. We recommend you use only a speaker/microphone in
these conditions, to avoid electric shocks.
ⅲ

Information concerning the battery pack:
The battery pack includes flammable objects such as organic
solvent. Mishandling may cause the battery to rupture producing
flames or extreme heat, deteriorate, or cause other forms of
damage to the battery. Please observe the following prohibitive
matters.
DANGER
●Do not disassemble or reconstruct the battery!
The battery pack has a safety function and protection circuit to
avoid danger. If they suffer serious damage, the battery may
generate heat or smoke, rupture, or burst into flame.
●Do not short-circuit the battery!
Do not join the + and – terminals using any form of metal (such as
a paper clip or wire). Do not carry or store the battery pack in
containers holding metal objects (such as wires, chain-necklaces
or hairpins). If the battery pack is short-circuited, excessive current
will flow and the battery may generate heat or smoke, rupture, or
burst into flame. It will also cause metal objects to heat up.
●Do not incinerate or apply heat to the battery!
If the insulator is melted, the gas release vent or safety function is
damaged, or the electrolyte is ignited, the battery may generate
heat or smoke, rupture, or burst into flame.
●Do not leave the battery near fire, stoves, or other heat
generators (areas reaching over 80°C/ 176°F)!
If the polymer separator is melted due to high temperature, an
internal short-circuit may occur in the individual cells and the battery
may generate heat or smoke, rupture, or burst into flame.
●Avoid immersing the battery in water or getting it wet by other
means!
If the battery becomes wet, wipe it off with a dry towel before use.
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
ⅳ

DANGER
●
Do not charge the battery near fire or under direct sunlight!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
●Use only the specified charger and observe charging
requirements!
If the battery is charged in unspecified conditions (under high
temperature over the regulated value, excessive high voltage or
current over regulated value, or with a remodeled charger), it may
overcharge or an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
●Do not pierce the battery with any object, strike it with an
instrument, or step on it!
This may break or deform the battery, causing a short-circuit. The
battery may generate heat or smoke, rupture, or burst into flame.
●Do not jar or throw the battery!
An impact may cause the battery to leak, generate heat or smoke,
rupture, and/or burst into flame. If the battery’s protection circuit is
damaged, the battery may charge at an abnormal current (or
voltage), and an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
●Do not use the battery pack if it is damaged in any way!
The battery may generate heat or smoke, rupture, or burst into
flame.
●Do not solder directly onto the battery!
If the insulator is melted or the gas release vent or safety function
is damaged, the battery may generate heat or smoke, rupture, or
burst into flame.
●Do not reverse the battery polarity (and terminals)!
When charging a reversed battery, an abnormal chemical reaction
may occur. In some cases, an unexpected large amount of current
may flow upon discharging. The battery may generate heat or
smoke, rupture, or burst into flame.
ⅴ

DANGER
●Do not reverse-charge or reverse-connect the battery!
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating
equipment, do not force it; check the polarity of the battery. If the
battery pack is reverse-connected to the charger, it will be reverse-
charged and an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
●Do not touch a ruptured and leaking battery!
If the electrolyte liquid from the battery gets into your eyes, wash
your eyes with fresh water as soon as possible, without rubbing
your eyes. Go to the hospital immediately. If left untreated, it may
cause eye-problems.
WARNING
●Do not charge the battery for longer than the specified time!
If the battery pack has not finished charging even after the regulated
time has passed, stop it. The battery may generate heat or smoke,
rupture, or burst into flame.
●Do not place the battery pack into a microwave or high
pressure container!
The battery may generate heat or smoke, rupture, or burst into
flame.
●Keep ruptured and leaking battery packs away from fire!
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte leaking
from battery can easily catch on fire and may cause the battery to
generate smoke or burst into flame.
●Do not use an abnormal battery!
If the battery pack emits a bad odor, appears to have different
coloring, is deformed, or seems abnormal for any other reason,
remove it from the charger or operating equipment and do not use
it. The battery may generate heat or smoke, rupture, or burst into
flame.
ⅵ

CONTENTS
UNPACKING AND CHECKING EQUIPMENT ......................................... 1
PREPARATION ........................................................................................ 2
ORIENTATION ......................................................................................... 6
CHANNEL LIST ........................................................................................ 8
UNPACKING AND CHECKING EQUIPMENT
Carefully unpack the transceiver. If any of the items listed below
are missing or damaged, file a claim with the carrier immediately.
SUPPLIED ACCESSORIES
●Battery charger/ AC adapter (KSC-35S) ............................. 1
●Li-ion Battery pack (KNB-63L) ............................................ 1
●Cap ..................................................................................... 1
●Belt clip ............................................................................... 1
●Quick Reference Guide ...................................................... 1
Note:
◆
Refer to “PREPARATION” {p. 2} for accessory installation
instructions.
1

PREPARATION
INSTALLING/ REMOVING THE BATTERY PACK
CAUTION
◆
Do not short the battery terminals or dispose of the battery by fire.
◆
Never attempt to remove the casing from the battery pack.
◆
Install the battery pack after cleaning the battery pack contacts and
the transceiver terminals.
.
1To install the battery pack, align the
base of the battery pack with the
transceiver, then press the battery
pack into place until the lock lever is
secure.
.
2To remove the battery pack, push the
lock lever up, then pull the battery
pack away from the transceiver.
Lock lever
Lock lever
2

INSTALLING THE BELT CLIP
.
1Remove the battery pack. {p. 2}
2To install the belt clip, align the guides
of the belt clip with the grooves on the
rear of the battery pack, then slide the
belt clip into place until the lock lever
is secure.
.
3To remove the belt clip, push the
lock lever towards the transceiver
while sliding the belt clip up.
.
Belt clip
Lock lever
INSTALLING THE CAP OVER THE SPEAKER/
MICROPHONE JACKS
.
If you are not using a speaker/ microphone
or Headset, install the cap over the
speaker/ microphone jacks using the
supplied M3 x 6 mm screws.
Note:
◆
To keep the transceiver water resistant, you
must cover the speaker/ microphone jacks
with the supplied cap.
Cap
3

CHARGING THE BATTERY PACK
The battery pack is not charged at the factory; charge it before
use.
Average battery pack life (calculated using 5% transmit time, 5%
receive time, and 90% standby time) is 14 hours.
ATTENTION:
◆
Always switch OFF a transceiver equipped with a battery pack before
inserting the transceiver into the charger.
.
1Plug the AC adapter cable into the
jack located on the rear of the
charger.
2Plug the AC adapter into an AC
outlet.
.
3Slide a battery pack or a
transceiver equipped with a
battery pack into the charging
slot of the charger.
●Make sure the metal contacts of
the battery pack mate securely
with the charger terminals.
●The indicator lights red and
charging begins.
4When charging is completed,
the indicator lights green.
Remove the battery pack or the
transceiver from the charging
slot of the charger.
●It takes approximately 3 hours to
charge the battery pack.
●When the charger will not be
used for a long time, unplug the
AC adapter from the AC outlet.
Indicator
Charging slot
4

Note:
◆
When an abnormality occurs during charging, the indicator performs
as follows:
Blinks Red: The battery pack is either defective or the battery pack
contacts are not properly mated with those of the charger.
Alternates Flashing Green and Orange: The battery pack has not
satisfied the charging start temperature. Remove the battery pack
from the charger and wait until it reaches a normal temperature before
charging it again.
◆
The ambient temperature should be between 5°C and 40°C while
charging is in progress. Charging outside this range may not fully
charge the battery.
◆
The battery pack life is over when its operating time decreases even
though it is fully and correctly charged. Replace the battery pack.
◆
While operating the transceiver using a Li-ion battery pack in areas
of an ambient temperature of –10°C and lower, operating time may
be shortened.
◆
Attention should be drawn to the environmental aspects of battery
pack disposal.
5

ORIENTATION
Battery
pack
Antenna
AChannel selector
Rotate to change the operating channel.
●If enabled by your dealer, setting the Channel selector
to the “S” position begins Scan.
BLED indicator
Refer to the LED indicator status. {p. 7}
CPower switch/ Volume control
Turn clockwise to switch the transceiver ON. To switch the
transceiver OFF, turn counterclockwise until a click sounds.
Rotate to adjust the volume level.
DPTT (Push To Talk) switch
Press and hold, then speak into the microphone to transmit.
ESide key
Press and hold this key to hear background noise.
Release the key to return to normal operation (Squelch Off
Momentary).
6

FSpeaker/ microphone jacks
Insert the Speaker/ microphone or Headset plug into this jack.
LED Indicator Status
Indicator Color Meaning
Lights red Transmitting
Lights green Receiving a call
Blinks red Battery power is low
Blinks green Scanning
Blinks red/orange The selected channel has not been programmed
and cannot be used.
7

CHANNEL LIST
This transceiver allows you to reprogram each of the channels
with different frequencies and QT (Quiet Talk)/ DQT (Digital Quiet
Talk) settings. The table below lists the default channel settings.
Channel Number Frequency (MHz) QT/DQT Setting
1446.00625 94.8 Hz
2446.09375 88.5 Hz
3446.03125 103.5 Hz
4446.06875 79.7 Hz
5446.04375 118.8 Hz
6446.01875 123.0 Hz
7446.08125 127.3 Hz
8446.05625 85.4 Hz
9446.00625 107.2 Hz
10 446.09375 110.9 Hz
11 446.03125 114.8 Hz
12 446.06875 82.5 Hz
13 446.04375 D132N
14 446.01875 D155N
15 446.05625 D134N
16 446.08125 D243N
8
