Kenwood TK-290-11B User manual

Document Copyrights
Copyright 2006 by Kenwood Corporation. All rights reserved.
No part of this manual may be reproduced, translated, distributed, or transmitted in any
form or by any means, electronic, mechanical, photocopying, recording, or otherwise, for
any purpose without the prior written permission of Kenwood.
Disclaimer
While every precaution has been taken in the preparation of this manual, Kenwood
assumes no responsibility for errors or omissions. Neither is any liability assumed for
damages resulting from the use of the information contained herein. Kenwood reserves
the right to make changes to any products herein at any time for improvement purposes.

© 2006-7 PRINTED IN JAPAN
B51-8766-00 (N)172
VHF FM TRANSCEIVER
TK-290-11B
SUPPLEMENT
SERVICE MANUAL
This product uses Lead Free solder.
CONTENTS
GENERAL .................................................................. 2
SYSTEM SET-UP ...................................................... 2
CIRCUIT DESCRIPTION ............................................ 3
PARTS LIST ............................................................... 4
EXPLODED VIEW.................................................... 12
ADJUSTMENT ........................................................ 13
PC BOARD VIEWS
FINAL UNIT (X45-3592-71) ................................ 23
CONTROL UNIT (X53-3932-71) ......................... 24
TX-RX UNIT (X57-6132-70) ................................ 28
SCHEMATIC DIAGRAM .......................................... 32
BLOCK DIAGRAM ................................................... 40
LEVEL DIAGRAM .................................................... 42
TECHNICAL DATA .................................................. 43
This product complies with the RoHS directive for the European market.
Helical antenna
(T90-0680-15)
Knob assy (Side key)
(K29-5423-24)
Panel assy
(A62-1100-03)
Knob assy (VOL)
(K29-5283-14)
Knob assy (SEL)
(K29-5282-14)
Plastic cabinet assy
(A02-3865-23)
This service manual (B51-8766-00) applies to products
with 80200001 or subsequent serial numbers.
Refer to the TK-290-11B service manual (B51-8520-00) for
any information which has not been covered in this
manual.
CAUTION
When using an external power connector, please
use with maximum final module protection of
10V.

TK-290-11B
2
INTRODUCTION
SCOPE OF THIS MANUAL
This manual is intended for use by experienced techni-
cians familiar with similar types of commercial grade commu-
nications equipment. It contains all required service informa-
tion for the equipment and is current as of the publication
date. Changes which may occur after publication are covered
by either Service Bulletins or Manual Revisions. These are
issued as required.
ORDERING REPLACEMENT PARTS
When ordering replacement parts or equipment informa-
tion, the full part identification number should be included.
This applies to all parts : components, kits, or chassis. If the
part number is not known, include the chassis or kit number
of which it is a part, and a sufficient description of the re-
quired component for proper identification.
GENERAL
PERSONNEL SAFETY
The following precautions are recommended for person-
nel safety :
•DONOT transmit until all RF connectors are verified se-
cure and any open connectors are properly terminated.
•SHUT OFF and DO NOT operate this equipment near
electrical blasting caps or in an explosive atmosphere.
•This equipment should be serviced by a qualified techni-
cian only.
SERVICE
This radio is designed for easy servicing. Refer to the
schematic diagrams, printed circuit board views, and align-
ment procedures contained within.
SERVICE MANUAL LIST
Title Part No. FINAL UNIT PCB No. CONTROL UNIT PCB No. TX-RX UNIT PCB No.
TK-290-11B B51-8520-00 J72-0654-12 J72-0705-02 J72-0723-02
TK-290-11B B51-8766-00 J79-0071-09 J79-0073-09 J79-0070-09
SUPPLEMENT This service manual
Merchandise received
Transceiver programming
Delivery
Are you using the speaker microphone?
A personal computer (IBM PC or compatible), programming
interface (KPG-36), and programming software (KPG-58D)
are required for programming.
(The frequency, and signaling data are programmed for the
transceiver.)
YES YES
NO NO
With
antenna?
KMC-25
KMC-26
SYSTEM SET-UP
Note:
If sensitivity suppression occurs due to interference with the operating frequency, change the microprocessor clock setting by
checking the Beat Shift-Lower Band or Beat Shift-Upper Band box in the special screen of the KPG-58D.
156MHz±156kHz, 168MHz±168kHz (CH No. 14~23)

TK-290-11B
3
CIRCUIT DESCRIPTION
1. PLL Frequency Synthesizer
The frequency synthesizer consists of the VCXO (X1),
VCO (L800), PLL IC (IC5) and buffer amplifiers. The VCXO
generates a 16.8MHz signal. The frequency stability is within
±2.0ppm (temperature range of –30 to +60°C).
The frequency tuning and modulation of the VCXO are
done to apply a voltage to pin 1 of the VCXO. The output of
the VCXO is applied to pin 9 of the PLL IC.
The VCO of the TK-290 covers the 38MHz spread, setting
frequencies in r1, r2 (receive) and t1, t2 (transmit) with a bias
voltage applied to the –V terminal of the VCO.
A zero (0) volt bias is applied at frequencies lower than r1,
t1. Frequencies r1, t1 through r2, t2 are biased with –3 volts.
Frequencies higher than r2, t2 are biased with –6 volts, and at
174MHz to 178MHz are biased with –9 volts.
The relation of VCO frequency versus PLL lock voltage is
shown in Figure 2.
The output of the VCO is amplified by the buffer amplifier
(Q14) and doubled by Q3, and is then routed to pin 6 of the
PLL IC. The output of the VCO is also amplified by the buffer
amplifier (Q5) and is routed to the next stage according to the
T/R switch (D602, D603).
The PLL IC consists of a prescaler, fractional divider, refer-
ence divider, phase comparator and charge pump. This PLL
IC is a fractional-N type synthesizer and performs in the 80 or
100kHz reference signal which is one eighth of the channel
step (2.5 or 3.125 kHz). The input signal from pin 6 of the PLL
IC is divided down to 80 or 100kHz and compared at the
phase comparator. The pulsed output signal of the phase
comparator is applied to the charge pump and transformed
into a DC signal in the loop filter (LPF). The DC signal is ap-
plied to pin 4 of the VCO and is locked to keep the VCO fre-
quency constant.
PLL data is output from DT (pin 85), CLK (pin 84) and LE
(pin 93) of the microprocessor (IC406). The data is input to
the PLL IC when the channel is changed or when transmis-
sion is changed to reception and vice versa. A PLL lock con-
dition is always monitored by pin 30 (UL) of the microproces-
sor. When the PLL is unlocked, the UL goes low.
r1
t1
r2
t2
174
CV voltage
Frequency
(MHz)
178136
IC6 L800
VCO
CV
IC5
PLL
LPF
DT,CLK,LE
CPU
IC406
Q5 D602,603
Q14
Q3
X1
–VC –V
VCXO
BUFF SW
BUFF
DOUBLER
BPF
to drive amp
to mixer
UL
IC3
IC604
FC
TO
Fig. 1 PLL block diagram
Fig. 2 CV voltage vs frequency

TK-290-11B
4
PARTS LIST
Chip capacitor
Code L W T
Empty 5.6±0.5 5.0±0.5 Less than 2.0
A4.5±0.5 3.2±0.4 Less than 2.0
B4.5±0.5 2.0±0.3 Less than 2.0
C4.5±0.5 1.25±0.2 Less than 1.25
D3.2±0.4 2.5±0.3 Less than 1.5
E3.2±0.2 1.6±0.2 Less than 1.25
F2.0±0.3 1.25±0.2 Less than 1.25
G1.6±0.2 0.8±0.2 Less than 1.0
H 1.0±0.05 0.5±0.05 0.5±0.05
Chip resistor
Code L W T
E3.2±0.2 1.6±0.2 1.0
F2.0±0.3 1.25±0.2 1.0
G1.6±0.2 0.8±0.2 0.5±0.1
H1.0±0.05 0.5±0.05 0.35±0.05
•Rating wattage
Code Wattage Code Wattage Code Wattage
1J 1/16W 2C 1/6W 3A 1W
2A 1/10W 2E 1/4W 3D 2W
2B 1/8W 2H 1/2W
(Less than 10pF)
Code B C D F G
(pF) ±0.1 ±0.25 ±0.5 ±1±2
CAPACITORS
C C 4 5 T H 1 H 2 2 0 J
1234 56
1 = Type ... ceramic, electrolytic, etc. 4 = Voltage rating
2 = Shape ... round, square, etc. 5 = Value
3 = Temp. coefficient 6 = Tolerance
•Temperature coefficient
1st Word C L P R S T U
Color* Black Red Orange Yellow Green Blue Violet
ppm/°C0 –80 –150 –220 –330 –470 –750
•Tolerance (More than 10pF)
Code C D G J K M X Z P No code
(%) ±0.25 ±0.5 ±2±5±10 ±20 +40 +80 +100 More than 10µF : –10~+50
–20 –20 –0 Less than 4.7µF : –10~+75
•Voltage rating
2nd word ABCDEFGHJKV
1st word
01.01.25 1.6 2.0 2.5 3.15 4.0 5.0 6.3 8.0 –
11012.5 16 20 25 31.540 50638035
2100 125 160 200 250 315 400 500 630 800 –
31000 1250 1600 2000 2500 2150 4000 5000 6300 8000 –
•Chip capacitors
(EX) C C 7 3 F S L 1 H 0 0 0 J Refer to the table above.
12345 67 1=Type
(Chip) (CH, RH, UJ, SL) 2 = Shape
3 = Dimension
(EX) C K 7 3 F F 1 H 0 0 0 Z 4 = Temp. coefficient
12345 67 5=Voltage rating
(Chip) (B, F) 6 = Value
7 = Tolerance
RESISTORS
•Chip resistor (Carbon)
(EX) R D 7 3 E B 2 B 0 0 0 J
12345 67
(Chip) (B, F)
•Carbon resistor (Normal type)
(EX) R D 1 4 B B 2 C 0 0 0 J
12345 67
1 = Type 5 = Rating wattage
2 = Shape 6 = Value
3 = Dimension 7 = Tolerance
4 = Temp. coefficient
CC45 Color*
2nd Word G H J K L
ppm/°C±30 ±60 ±120 ±250 ±500
Example : CC45TH = –470±60ppm/°C
•Capacitor value
010 = 1pF 2 2 0 = 22pF
100 = 10pF
101 = 100pF Multiplier
102 = 1000pF = 0.001µF2nd number
103 = 0.01µF1st number
L
W
T
•Dimension

TK-290-11B
5
PARTS LIST
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
L: Scandinavia K:USA P:Canada
Y: PX (Far East, Hawaii) T:England E:Europe
Y:AAFES (Europe) X:Australia M:Other Areas
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
11AA02-3865-23 PLASTIC CABINET ASSY
22B✽A22-2515-45 SUB PANEL
32B✽A62-1100-03 PANEL ASSY
5- B09-0363-03 CAP ACCESSORY
61BB11-1183-14 ILLUMINATION GUIDE (LCD)
71BB38-0786-05 LCD
81AB43-1111-14 BADGE
9- B59-1667-00 SUB-INSTRUCTION MANUAL
10 - ✽B62-1260-10 INSTRUCTION MANUAL
12 2B E23-1102-14 TERMINAL (CONT UNIT)
13 3A E23-1163-04 BATTTERMINAL
14 1B E29-1165-05 INTER CONNECTOR (LCD)
15 - E30-3325-05 CLONING CABLE
16 2B E37-0722-05 ANT COAXIAL CABLE
17 2A ✽E37-1339-05 FLAT CABLE (TX/RX-CONT)
18 1B ✽E37-1350-05 PROCESSED LEAD WIRE (TOGGLE SW)
19 1B ✽E37-1351-05 LEAD WIRE WITH CONNECTOR (SP)
20 3B ✽E58-0528-05 UNIVERSAL CONNECTOR
21 2A ✽E72-0411-04 TERMINAL BLOCK (BATT +)
23 3B F10-2344-04 SHIELDING CASE
25 2A G01-0891-04 COIL SPRING (BATT RELEASE)
26 2A G13-1678-04 CUSHION (TX/RX)
27 - G13-1688-14 CUSHION (CAP)
28 2A,3A ✽G13-1800-04 CUSHION (BATT TERMINAL)
29 2B G53-0822-04 PACKING (CHASSIS)
30 1B G53-0823-04 PACKING (SP)
31 1A G53-0874-03 PACKING (FRONT CABINET)
32 3A ✽G53-1511-04 PACKING (BATT-)
33 3A G53-1621-04 PACKING
35 - H12-3018-02 PACKING FIXTURE
36 - H52-1543-02 ITEM CARTON CASE
38 2A J19-5330-14 HOLDER (BATT RELEASE)
39 1B J21-8328-14 MOUNTING HARDWARE (LCD)
40 2A ✽J21-8329-24 MOUNTING HARDWARE (CONT UNIT)
41 1A J21-8426-04 MOUNTING HARDWARE (PTT)
42 1A J21-8446-04 MOUNTING HARDWARE (PTT)
43 2B J21-8473-04 MOUNTING HARDWARE
44 2B J21-8474-04 MOUNTING HARDWARE
45 - J29-0652-35 CLIP ACCESSORY
46 2B J82-0049-15 FPC (VOLUME/SELECTOR)
47 3A J82-0052-25 FPC (UNIVERSAL CONNECTOR)
48 1A ✽J82-0115-05 FPC (PTT)
49 2B J99-0346-24 ADHESIVE SHEET (TOGGLE SW)
51 2B K29-5282-14 KNOB ASSY (SELECTOR)
52 2B K29-5283-14 KNOB ASSY (VOLUME)
53 1A ✽K29-5423-24 KNOB ASSY (SIDE KEY)
54 2A K29-9250-03 LEVER KNOB (BATT RELEASE)
55 2B K29-9315-02 KEY TOP
56 1A K29-9316-03 KEY TOP (SIDE KEY)
A2B✽N14-0835-04 CIRCULAR NUT (VOLME/SELECTOR)
B2B✽N14-0836-04 CIRCULAR NUT (ANTENNA)
C3AN30-2608-43 PAN HEAD MACHINE SCREW
D2B,3B N67-2606-48 PAN HEAD SEMS SCREW
E1A,2B ✽N78-2030-48 PAN HEAD TAPTITE SCREW
F3AN79-2035-48 PAN HEAD TAPTITE SCREW
G
2A,1B,3B ✽N83-2004-48 PAN HEAD TAPTITE SCREW
H2A✽N83-2005-43 PAN HEAD TAPTITE SCREW
58 - N99-2004-15 SCREW SET ACCESSORY
60 2B ✽R31-0631-15 VARIABLE RESISTOR
62 2B S60-0415-05 CHANNEL SELECTOR
63 1B ✽S72-0411-05 TOGGLE SWITCH
65 1B T07-0349-15 SPEAKER
66 - ✽T90-0680-15 HELICAL ANTENNA ACCESSORY
67 2A T91-0575-05 MIC ELEMENT
69 - W01-0441-05 UNIVERSAL PLUG KIT
C802 CC73GCH1H030C CHIP C 3.0PF C
C803 CC73GCH1H101J CHIP C 100PF J
C804 CK73GB1C104K CHIP C 0.10UF K
C805 CC73GCH1H101J CHIP C 100PF J
C806 CK73GB1C104K CHIP C 0.10UF K
L801 ✽L33-0763-15 SMALL FIXED INDUCTOR
IC801 3B ✽RA07M1317M101 RF POWER MODULE
D102,103 B30-2231-05 LED (Y)
D104 B30-2019-05 LED (RE/GR)
C1-5 CK73GB1H471K CHIP C 470PF K
C6,7 CK73GB1H102K CHIP C 1000PF K
C8 CK73FB1C474K CHIP C 0.47UF K
C10,11 CK73GB1H102K CHIP C 1000PF K
C12 CK73FB1C474K CHIP C 0.47UF K
C14 CK73FB1C104KTD CHIP C 0.10UF K
C15 CK73GB1H471K CHIP C 470PF K
C16 ✽CS77AC1A101M CHIP-TAN 100UF 10WV
C19 CK73FB1C474K CHIP C 0.47UF K
C22 CK73GB1H471K CHIP C 470PF K
C27-29 CK73GB1C104K CHIP C 0.10UF K
C30 CK73FB1C474K CHIP C 0.47UF K
C31 CK73GB1E223K CHIP C 0.022UF K
C32 CK73FB1C474K CHIP C 0.47UF K
C33,34 CK73GB1H471K CHIP C 470PF K
C35 CK73GB1H102K CHIP C 1000PF K
C37 CC73GCH1H101J CHIP C 100PF J
C38 CK73GB1H102K CHIP C 1000PF K
C39 CK73GB1H471K CHIP C 470PF K
C41 CK73GB1H102K CHIP C 1000PF K
TK-290-11B (Y50-5322-70)
FINAL UNIT (X45-3592-71)
CONTROL UNIT (X53-3932-71)
TK-290-11B
FINAL UNIT (X45-3592-71)
CONTROL UNIT (X53-3932-71)
If a part reference number is listed in a shaded box, that part does not come with the PCB.

TK-290-11B
6
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C43 CK73GB1H471K CHIP C 470PF K
C45,46 CK73GB1H471K CHIP C 470PF K
C47-49 CC73GCH1H101J CHIP C 100PF J
C103 CK73GB1H102K CHIP C 1000PF K
C104,105 CC73GCH1H101J CHIP C 100PF J
C106 ✽CS77BP1A010M CHIP-TAN 1.0UF 10WV
CN1 ✽E40-6674-05 FLAT CABLE CONNECTOR
CN3 ✽E40-6467-05 FLAT CABLE CONNECTOR
CN4 ✽E41-2539-05 PIN ASSY
CN101 ✽E40-6590-05 FLAT CABLE CONNECTOR
CN501,502 E04-0403-05 PIN SOCKET
L1-4 L92-0470-05 CHIP FERRITE
L6 L92-0149-05 CHIP FERRITE
L7,8 ✽L92-0469-05 CHIP FERRITE
L9 L92-0138-05 CHIP FERRITE
L101 L92-0138-05 CHIP FERRITE
CP1 RK74GA1J473J CHIP-COM 47K J 1/16W
R1 RK73GB2A273J CHIP R 27K J 1/10W
R2 RK73GB2A102J CHIP R 1.0K J 1/10W
R3 RK73GB2A470J CHIP R 47 J 1/10W
R4,5 RK73GB2A473J CHIP R 47K J 1/10W
R6-8 RK73GB2A000J CHIP R 0.0 J 1/10W
R9,10 RK73GB2A562J CHIP R 5.6K J 1/10W
R11 RK73GB2A000J CHIP R 0.0 J 1/10W
R12 RK73GB2A102J CHIP R 1.0K J 1/10W
R13 RK73GB2A473J CHIP R 47K J 1/10W
R14 RK73GB2A104J CHIP R 100K J 1/10W
R15 RK73GB2A222J CHIP R 2.2K J 1/10W
R17,18 RK73GB2A473J CHIP R 47K J 1/10W
R22,23 RK73GB2A102J CHIP R 1.0K J 1/10W
R26-28 RK73GB2A103J CHIP R 10K J 1/10W
R29,30 RK73GB2A223J CHIP R 22K J 1/10W
R32 RK73GB2A680J CHIP R 68 J 1/10W
R33 RK73GB2A223J CHIP R 22K J 1/10W
R34 RK73GB2A182J CHIP R 1.8K J 1/10W
R35 RK73GB2A103J CHIP R 10K J 1/10W
R36 RK73GB2A182J CHIP R 1.8K J 1/10W
R43,44 RK73GB2A473J CHIP R 47K J 1/10W
R45-49 RK73GB2A102J CHIP R 1.0K J 1/10W
R56 RK73GB2A153J CHIP R 15K J 1/10W
R57 RK73GB2A000J CHIP R 0.0 J 1/10W
R59 RK73GB2A102J CHIP R 1.0K J 1/10W
R60 RK73GB2A101J CHIP R 100 J 1/10W
R63,64 RK73GB2A000J CHIP R 0.0 J 1/10W
R101 RK73GB2A104J CHIP R 100K J 1/10W
R102-104 RK73GB2A103J CHIP R 10K J 1/10W
R105 RK73GB2A471J CHIP R 470 J 1/10W
R106 RK73GB2A274J CHIP R 270K J 1/10W
R107 RK73GB2A472J CHIP R 4.7K J 1/10W
R108 RK73GB2A100J CHIP R 10 J 1/10W
R502 RK73GB2A102J CHIP R 1.0K J 1/10W
D2 UDZS3.9B ZENER DIODE
D12,13 MA2S111-F DIODE
D15 MA2S111-F DIODE
D16 IMN10 DIODE
D19,20 MA2S111-F DIODE
D101 1SS373F DIODE
IC1 TDA7053AT BI-POLAR IC
IC2 BU4094BCFV MOS-IC
IC3 NJM2904V-ZB MOS-IC
IC4-6 TC7SH08FU-F MOS-IC
IC10 ✽TC7W04FU-F MOS-IC
IC101 LC75824W MOS-IC
Q5 2SC4617(S) TRANSISTOR
Q6 ✽2SB798AZ(DLDK TRANSISTOR
Q7,8 2SK1824-A FET
Q14 UMC4N TRANSISTOR
Q15 2SK1824-A FET
C1 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C2 CK73HB1A104K CHIP C 0.10UF K
C5 CK73GB1H102K CHIP C 1000PF K
C6 CS77AA0J100M CHIP-TAN 100UF 6.3WV
C8-10 CK73GB1H102K CHIP C 1000PF K
C11 C92-0588-05 CHIP-TAN 1.5UF 16WV
C13 CK73HB1H102K CHIP C 1000PF K
C14,15 C92-0588-05 CHIP-TAN 1.5UF 16WV
C16 CK73HB1A104K CHIP C 0.10UF K
C17 CK73HB1H102K CHIP C 1000PF K
C18 C92-0588-05 CHIP-TAN 1.5UF 16WV
C20 CK73GB1C104K CHIP C 0.10UF K
C21 CC73HCH1H560J CHIP C 56PF J
C23 CC73GCH1H101J CHIP C 100PF J
C24 C92-0588-05 CHIP-TAN 1.5UF 16WV
C25 CC73GCH1H180J CHIP C 18PF J
C26 CC73GCH1H270J CHIP C 27PF J
C27 CK73GB1C104K CHIP C 0.10UF K
C28 CK73GB1C333K CHIP C 0.033UF K
C29 CC73GCH1H130G CHIP C 13PF G
C30 CC73GCH1H270J CHIP C 27PF J
C31 CK73GB1H471K CHIP C 470PF K
C32 CS77CA1VR22M CHIP-TAN 0.22UF 35WV
C33 CC73GCH1H150G CHIP C 15PF G
C34 CC73GCH1H331J CHIP C 330PF J
C35 CC73GCH1H130G CHIP C 13PF G
C36 CC73GCH1H100D CHIP C 10PF D
C37 CK73GB1H471K CHIP C 470PF K
C38 CC73GCH1H060B CHIP C 6.0PF B
C39 CK73GB1H102K CHIP C 1000PF K
C40 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C41 CK73GB1H471K CHIP C 470PF K
C42 CC73GCH1H150G CHIP C 15PF G
C43 CS77AA0J4R7M CHIP-TAN 4.7UF 6.3WV
C44 CC73GCH1H680J CHIP C 68PF J
C45 CC73GCH1H150G CHIP C 15PF G
C46 CK73GB1H102K CHIP C 1000PF K
C47 CK73GB1H471K CHIP C 470PF K
C48 CK73GB1H102K CHIP C 1000PF K
C49,50 CK73GB1H471K CHIP C 470PF K
C52 CK73GB1H102K CHIP C 1000PF K
C53-57 CK73GB1H471K CHIP C 470PF K
C58 CC73GCH1H101J CHIP C 100PF J
C59 CC73GCH1H680J CHIP C 68PF J
C60-62 CK73GB1H471K CHIP C 470PF K
C63 CC73GCH1H101J CHIP C 100PF J
C64 CK73GB1H471K CHIP C 470PF K
TX-RX UNIT (X57-6132-70)
CONTROL UNIT (X53-3932-71)
TX-RX UNIT (X57-6132-70)

TK-290-11B
7
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C66,67 CK73GB1H471K CHIP C 470PF K
C69 CC73GCH1H070D CHIP C 7.0PF D
C70 CC73GCH1H101J CHIP C 100PF J
C71 CK73FB1C474K CHIP C 0.47UF K
C73 C92-0588-05 CHIP-TAN 1.5UF 16WV
C76 CC73GCH1H101J CHIP C 100PF J
C78 CK73GB1H103K CHIP C 0.010UF K
C79 CK73FB1C474K CHIP C 0.47UF K
C81 CK73GB1H102K CHIP C 1000PF K
C82 CC73GCH1H680J CHIP C 68PF J
C83 CC73GCH1H200J CHIP C 20PF J
C84,85 CK73GB1H102K CHIP C 1000PF K
C86 CC73GCH1H220J CHIP C 22PF J
C87 CC73GCH1H680J CHIP C 68PF J
C88 CC73GCH1H120J CHIP C 12PF J
C89 CC73GCH1H090D CHIP C 9.0PF D
C90 CC73GCH1H270J CHIP C 27PF J
C91 CC73GCH1H100D CHIP C 10PF D
C92 CC73GCH1H120J CHIP C 12PF J
C93 CC73GCH1H100D CHIP C 10PF D
C95 CK73GB1H103K CHIP C 0.010UF K
C97 CC73HCH1H080B CHIP C 8.0PF B
C98 CK73GB1C683K CHIP C 0.068UF K
C99 CK73GB1H102K CHIP C 1000PF K
C100 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C101 CK73FB1C105K CHIP C 1.0UF K
C102 CC73GCH1H150G CHIP C 15PF G
C103 CK73GB1H102K CHIP C 1000PF K
C105 CK73HB1H102K CHIP C 1000PF K
C106 CK73HB1A104K CHIP C 0.10UF K
C107 CK73GB1H103K CHIP C 0.010UF K
C108 CK73GB1H102K CHIP C 1000PF K
C109 CK73HB1C103K CHIP C 0.010UF K
C110 CK73GB1H102K CHIP C 1000PF K
C111 CK73HB1H102K CHIP C 1000PF K
C112 CK73HB1A104K CHIP C 0.10UF K
C113-115 CC73HCH1H101J CHIP C 100PF J
C117-119 CK73HB1H102K CHIP C 1000PF K
C120 CK73HB1C103K CHIP C 0.010UF K
C202 CC73GCH1H060D CHIP C 6.0PF D
C204 CK73GB1H102K CHIP C 1000PF K
C205 CC73GCH1H030C CHIP C 3.0PF C
C206,207 CK73GB1H102K CHIP C 1000PF K
C209,210 CK73GB1H102K CHIP C 1000PF K
C212,213 CK73GB1H102K CHIP C 1000PF K
C214 CC73GCH1H060D CHIP C 6.0PF D
C215 CC73GCH1H030C CHIP C 3.0PF C
C216 CC73GCH1H010C CHIP C 1.0PF C
C217 CK73GB1H102K CHIP C 1000PF K
C219 CC73GCH1H060D CHIP C 6.0PF D
C222 CC73GCH1H151J CHIP C 150PF J
C223 CC73GCH1H070D CHIP C 7.0PF D
C224 CK73GB1H471K CHIP C 470PF K
C225 CC73GCH1H151J CHIP C 150PF J
C226-228 CK73GB1H471K CHIP C 470PF K
C229,230 CK73GB1C104K CHIP C 0.10UF K
C232 CC73GCH1H151J CHIP C 150PF J
C233 CK73GF1A105Z CHIP C 1.0UF Z
C234 CK73GB1H102K CHIP C 1000PF K
C237,238 CK73GB1H102K CHIP C 1000PF K
C240 CC73GCH1H060D CHIP C 6.0PF D
C242 CK73GF1A105Z CHIP C 1.0UF Z
C300 CK73GB1H472K CHIP C 4700PF K
C301,302 CC73GCH1H221J CHIP C 220PF J
C303 CK73GB1C104K CHIP C 0.10UF K
C304 CK73GB1H102K CHIP C 1000PF K
C305 CK73GB1H103K CHIP C 0.010UF K
C306-308 CK73GB1H102K CHIP C 1000PF K
C309 ✽CS77BP1A010M CHIP-TAN 1.0UF 10WV
C310,311 CK73GB1C104K CHIP C 0.10UF K
C312 CK73GB1C333K CHIP C 0.033UF K
C313,314 CC73GCH1H220J CHIP C 22PF J
C315 CK73GB1H102K CHIP C 1000PF K
C316 CC73GCH1H820J CHIP C 82PF J
C317 CK73GB1H102K CHIP C 1000PF K
C318 CK73GB1C104K CHIP C 0.10UF K
C319 CK73GB1H103K CHIP C 0.010UF K
C320 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C321 CK73GB1C104K CHIP C 0.10UF K
C323 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C327 CK73GB1H103K CHIP C 0.010UF K
C331,332 CK73GB1H103K CHIP C 0.010UF K
C333 CK73HB1H102K CHIP C 1000PF K
C334 CK73HB1A104K CHIP C 0.10UF K
C335 CK73HB1H102K CHIP C 1000PF K
C336 CK73GB1A224K CHIP C 0.22UF K
C337 CK73FB1C334K CHIP C 0.33UF K
C400,401 CC73GCH1H101J CHIP C 100PF J
C403-411 CC73GCH1H101J CHIP C 100PF J
C413 CK73GB1H471K CHIP C 470PF K
C414 CK73GB1H103K CHIP C 0.010UF K
C415 CK73FB1C105K CHIP C 1.0UF K
C416,417 CK73GB1H471K CHIP C 470PF K
C419 CS77AB20J470M CHIP-TAN 47UF 6.3WV
C420 C92-0702-05 CHIP ELE 47UF 6.3WV
C421 CK73GB1H471K CHIP C 470PF K
C422 CK73FB1C105K CHIP C 1.0UF K
C423,424 CK73GB1H471K CHIP C 470PF K
C425 CK73GB1H103K CHIP C 0.010UF K
C426 CK73GB1H471K CHIP C 470PF K
C427 CK73GB1H103K CHIP C 0.010UF K
C428 CS77CA1C010M CHIP-TAN 1.0UF 16WV
C429 CK73GB1H102K CHIP C 1000PF K
C430 CK73FB1C105K CHIP C 1.0UF K
C431 CK73GB1H471K CHIP C 470PF K
C432 CK73FB1C105K CHIP C 1.0UF K
C433 C92-0698-05 CHIP ELE 47UF 16WV
C434,435 CK73GB1H471K CHIP C 470PF K
C436 CK73FB1C105K CHIP C 1.0UF K
C437 CK73GB1H472K CHIP C 4700PF K
C438 CK73GB1H103K CHIP C 0.010UF K
C439 CK73GB1E103K CHIP C 0.010UF K
C440 CK73GB1C273K CHIP C 0.027UF K
C441,442 CK73GB1H102K CHIP C 1000PF K
C443 CK73GB1H222K CHIP C 2200PF K
C444 CC73GCH1H070D CHIP C 7.0PF D
C445,446 CK73GB1H222K CHIP C 2200PF K
C447,448 CC73GCH1H180J CHIP C 18PF J
C449 CK73GB1H103K CHIP C 0.010UF K
C450 CS77CP0J100M CHIP-TAN 10UF 6.3WV
TX-RX UNIT (X57-6132-70)

TK-290-11B
8
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
C451,452 CK73GB1H102K CHIP C 1000PF K
C454 CC73GCH1H101J CHIP C 100PF J
C456-477 CC73GCH1H101J CHIP C 100PF J
C478 CK73GB1C104K CHIP C 0.10UF K
C479 CC73GCH1H271J CHIP C 270PF J
C480 CC73GCH1H221J CHIP C 220PF J
C481 CK73FB1C105K CHIP C 1.0UF K
C482 CK73GB1C104K CHIP C 0.10UF K
C483 CK73GB1H102K CHIP C 1000PF K
C484 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C485 CK73GB1H102K CHIP C 1000PF K
C487 CK73GB1C104K CHIP C 0.10UF K
C488 CS77AA1A6R8M CHIP-TAN 6.8UF 10WV
C600 CK73GB1C473K CHIP C 0.047UF K
C601 CS77CA1ER47M CHIP-TAN 0.47UF 16WV
C602 CK73GB1C104K CHIP C 0.10UF K
C603 CK73GB1C683K CHIP C 0.068UF K
C604 CK73GB1H103K CHIP C 0.010UF K
C606 CK73GB1H222K CHIP C 2200PF K
C607 CC73GCH1H101J CHIP C 100PF J
C608 CK73GB1H103K CHIP C 0.010UF K
C609 CC73GCH1H121J CHIP C 120PF J
C610 CK73GB1H103K CHIP C 0.010UF K
C611 CK73GB1E123K CHIP C 0.012UF K
C612 CS77CP0J4R7M CHIP-TAN 4.7UF 6.3WV
C613 CK73GB1H103K CHIP C 0.010UF K
C619 CC73GCH1H331J CHIP C 330PF J
C621 CK73GB1C104K CHIP C 0.10UF K
C626 CK73GB1C104K CHIP C 0.10UF K
C627 CK73GB1H122J CHIP C 1200PF J
C628-630 CK73GB1H103K CHIP C 0.010UF K
C631,632 CK73GB1C104K CHIP C 0.10UF K
C633 CK73GB1H103K CHIP C 0.010UF K
C634,635 CK73GB1H562J CHIP C 5600PF J
C636 CK73GB1C333K CHIP C 0.033UF K
C637 CK73GB1H562J CHIP C 5600PF J
C638 CK73GB1H272J CHIP C 2700PF J
C639 CC73GCH1H090D CHIP C 9.0PF D
C640,641 CK73GB1H272J CHIP C 2700PF J
C642 CC73HCH1H151J CHIP C 150PF J
C643 CK73HB1H122K CHIP C 1200PF K
C644 CK73HB1H102K CHIP C 1000PF K
C645 CC73GCH1H090D CHIP C 9.0PF D
C646 CS77CP0J100M CHIP-TAN 10UF 6.3WV
C647 CK73HB1A104K CHIP C 0.10UF K
C648 CC73HCH1H101J CHIP C 100PF J
C650,651 CK73HB1A104K CHIP C 0.10UF K
C652 CS77CP0J4R7M CHIP-TAN 4.7UF 6.3WV
C655 CC73HCH1H101J CHIP C 100PF J
C656 CK73FB1H563K CHIP C 0.056UF K
C657 CS77CP0J4R7M CHIP-TAN 4.7UF 6.3WV
C659 CK73GB1C104K CHIP C 0.10UF K
C660 CS77AA0J100M CHIP-TAN 10UF 6.3WV
C661 CK73GB1C104K CHIP C 0.10UF K
C663 CK73HB1H102K CHIP C 1000PF K
C664 CK73HB1A104K CHIP C 0.10UF K
C665 CK73GB1C333K CHIP C 0.033UF K
C668 CK73GB1H102K CHIP C 1000PF K
C669 CC73GCH1H101J CHIP C 100PF J
C670 CK73HB1A104K CHIP C 0.10UF K
C671 CK73HB1H222K CHIP C 2200PF K
C672 CC73HCH1E221J CHIP C 220PF J
C673 CK73HB1H681K CHIP C 680PF K
C674 CK73GB1A224K CHIP C 0.22UF K
C675 CK73HB1C103K CHIP C 0.010UF K
C678 CK73HB1A104K CHIP C 0.10UF K
C679 CK73GB1C104K CHIP C 0.10UF K
C681 CK73GB1E103K CHIP C 0.010UF K
C682 CK73GB1C104K CHIP C 0.10UF K
CN400 ✽E40-6589-05 FLAT CABLE CONNECTOR
CN401 ✽E40-6674-05 FLAT CABLE CONNECTOR
CN403 E40-6453-05 FLAT CABLE CONNECTOR
CN404,405 E23-1293-05 TEST TERMINAL
F400 ✽F53-0325-05 FUSE
CD300 L79-1072-05 CERAMIC DISCRI
CF300,301 L72-0916-05 CERAMIC FILTER
L1 L92-0138-05 CHIP FERRITE
L2 L40-2775-92 SMALL FIXED INDUCTOR (27NH)
L3 L40-2775-57 SMALL FIXED INDUCTOR (27.0NH)
L5 L40-3981-37 SMALL FIXED INDUCTOR (0.390UH)
L6 L40-1885-92 SMALL FIXED INDUCTOR (180NH)
L7 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L8 ✽L40-5675-72 SMALL FIXED INDUCTOR (56NH)
L9 L40-1085-92 SMALL FIXED INDUCTOR (100NH)
L10,11 L92-0149-05 CHIP FERRITE
L12 ✽L33-0763-15 SMALL FIXED INDUCTOR
L13 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L14 ✽L33-0765-15 SMALL FIXED INDUCTOR
L15,16 ✽L33-1226-15 SMALL FIXED INDUCTOR
L17 L41-1092-44 SMALL FIXED INDUCTOR (1UH)
L18 L40-4791-86 SMALL FIXED INDUCTOR (4.7UH)
L19 L40-4775-92 SMALL FIXED INDUCTOR (47NH)
L20 L92-0140-05 CHIP FERRITE
L22 ✽L40-8275-72 SMALL FIXED INDUCTOR (82NH)
L23 L92-0138-05 CHIP FERRITE
L24 L40-1278-67 SMALL FIXED INDUCTOR (12NH)
L25 L40-3378-67 SMALL FIXED INDUCTOR (33NH)
L26 L40-1278-67 SMALL FIXED INDUCTOR (12NH)
L201 ✽L34-4820-05 COIL
L202 ✽L34-4821-05 COIL
L204 ✽L41-6885-33 SMALL FIXED INDUCTOR (0.68UH)
L205 ✽L34-4821-05 COIL
L206 ✽L34-4820-05 COIL
L207 ✽L40-8275-72 SMALL FIXED INDUCTOR (82NH)
L208 ✽L40-5675-72 SMALL FIXED INDUCTOR (56NH)
L209,210 ✽L40-8275-72 SMALL FIXED INDUCTOR (82NH)
L211,212 L39-1272-15 TOROIDAL COIL
L213 L92-0138-05 CHIP FERRITE
L214 L39-1272-15 TOROIDAL COIL
L215 ✽L40-8275-72 SMALL FIXED INDUCTOR (82NH)
L300 L41-1095-33 SMALL FIXED INDUCTOR (1.0UH)
L301 L40-3391-37 SMALL FIXED INDUCTOR (3.300UH)
L400 L92-0136-05 CHIP FERRITE
L401 L92-0138-05 CHIP FERRITE
L404 L40-1001-37 SMALL FIXED INDUCTOR (10.00UH)
L800 ✽L78-0487-15 VCO
L905 L92-0138-05 CHIP FERRITE
X1 L77-1969-05 TCXO (16.8MHZ)
X300 L77-1742-05 CRYSTAL RESONATOR (45.305MHZ)
TX-RX UNIT (X57-6132-70)

TK-290-11B
9
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
X400 L77-1863-05 CRYSTAL RESONATOR (12.0MHZ)
X600 L77-1708-05 CRYSTAL RESONATOR (3.579545MHZ)
XF301 L71-0588-05 MCF (44.85MHZ)
CP419-436 R90-0741-05 MULTIPLE RESISTOR
R4 RK73GB2A000J CHIP R 0.0 J 1/10W
R5 RK73GB2A104J CHIP R 100K J 1/10W
R6 ✽RK73GH2A473D CHIP R 47K D 1/10W
R7 RK73GB2A104J CHIP R 100K J 1/10W
R8 RK73GB2A683J CHIP R 68K J 1/10W
R9 RK73HB1J221J CHIP R 220 J 1/16W
R10 RK73HB1J100J CHIP R 10 J 1/16W
R11 RK73HB1J220J CHIP R 22 J 1/16W
R12 RK73GB2A100J CHIP R 10 J 1/10W
R13 RK73GB2A104J CHIP R 100K J 1/10W
R14 RK73GB2A184J CHIP R 180K J 1/10W
R15 RK73GB2A561J CHIP R 560 J 1/10W
R16 RK73GB2A000J CHIP R 0.0 J 1/10W
R17 RK73GB2A394J CHIP R 390K J 1/10W
R18 RK73GB2A152J CHIP R 1.5K J 1/10W
R19 ✽RK73GH2A513D CHIP R 51K D 1/10W
R20,21 RK73HB1J103J CHIP R 10K J 1/16W
R22,23 RK73HB1J473J CHIP R 47K J 1/16W
R24 RK73GB2A101J CHIP R 100 J 1/10W
R25 RK73GB2A124J CHIP R 120K J 1/10W
R26 RK73HB1J221J CHIP R 220 J 1/16W
R27 RK73GB2A472J CHIP R 4.7K J 1/10W
R28 RK73GB2A223J CHIP R 22K J 1/10W
R29 RK73GB2A104J CHIP R 100K J 1/10W
R30 RK73HB1J220J CHIP R 22 J 1/16W
R31 RK73GB2A471J CHIP R 470 J 1/10W
R32 RK73GB2A122J CHIP R 1.2K J 1/10W
R33 RK73GB2A103J CHIP R 10K J 1/10W
R34 RK73GB2A223J CHIP R 22K J 1/10W
R35 RK73EB2ER39K CHIP R 0.39 K 1/4W
R36 RK73GB2A000J CHIP R 0.0 J 1/10W
R37 RK73EB2ER39K CHIP R 0.39 K 1/4W
R38 RK73GB2A222J CHIP R 2.2K J 1/10W
R39 RK73EB2ER39K CHIP R 0.39 K 1/4W
R40 RK73GB2A822J CHIP R 8.2K J 1/10W
R41,42 RN73GH1J154D CHIP R 150K D 1/16W
R43 RK73GB2A180J CHIP R 18 J 1/10W
R44,45 RN73GH1J154D CHIP R 150K D 1/16W
R46 RK73GB2A101J CHIP R 100 J 1/10W
R47,48 RN73GH1J154D CHIP R 150K D 1/16W
R49 RK73GB2A101J CHIP R 100 J 1/10W
R50 RK73GB2A470J CHIP R 47 J 1/10W
R51 RK73GB2A000J CHIP R 0.0 J 1/10W
R52 RK73GB2A103J CHIP R 10K J 1/10W
R53 RK73GB2A560J CHIP R 56 J 1/10W
R54,55 RK73GB2A152J CHIP R 1.5K J 1/10W
R56 RK73GB2A473J CHIP R 47K J 1/10W
R57 RK73GB2A104J CHIP R 100K J 1/10W
R58 RK73GB2A105J CHIP R 1.0M J 1/10W
R59 RK73GB2A104J CHIP R 100K J 1/10W
R60 RK73GB2A221J CHIP R 220 J 1/10W
R61 RK73GB2A000J CHIP R 0.0 J 1/10W
R63 RK73HB1J103J CHIP R 10K J 1/16W
R65 RK73GB2A392J CHIP R 3.9K J 1/10W
R66 RK73HB1J101J CHIP R 100 J 1/16W
R67 RK73GB2A102J CHIP R 1.0K J 1/10W
R68 RK73HB1J101J CHIP R 100 J 1/16W
R69-71 RK73GB2A561J CHIP R 560 J 1/10W
R73 RK73GB2A223J CHIP R 22K J 1/10W
R75 RK73GB2A102J CHIP R 1.0K J 1/10W
R76 RK73GB2A101J CHIP R 100 J 1/10W
R77 RK73HB1J000J CHIP R 0.0 J 1/16W
R78 RK73HB1J101J CHIP R 100 J 1/16W
R79 RK73GB2A104J CHIP R 100K J 1/10W
R80 RK73GB2A221J CHIP R 220 J 1/10W
R82,83 RK73GB2A000J CHIP R 0.0 J 1/10W
R85,86 RK73GB2A000J CHIP R 0.0 J 1/10W
R88 RK73GB2A274J CHIP R 270K J 1/10W
R89 RK73GB2A270J CHIP R 27 J 1/10W
R90,91 RK73GB2A000J CHIP R 0.0 J 1/10W
R200 RK73GB2A473J CHIP R 47K J 1/10W
R201 RK73GB2A104J CHIP R 100K J 1/10W
R202,203 RK73GB2A103J CHIP R 10K J 1/10W
R204 RK73GB2A121J CHIP R 120 J 1/10W
R205 RK73GB2A104J CHIP R 100K J 1/10W
R206 RK73GB2A473J CHIP R 47K J 1/10W
R207 RK73GB2A100J CHIP R 10 J 1/10W
R208 RK73GB2A821J CHIP R 820 J 1/10W
R209 RK73GB2A100J CHIP R 10 J 1/10W
R210,211 RK73GB2A104J CHIP R 100K J 1/10W
R212 RK73GB2A222J CHIP R 2.2K J 1/10W
R213 RK73GB2A271J CHIP R 270 J 1/10W
R214 RK73GB2A101J CHIP R 100 J 1/10W
R215,216 RK73GB2A000J CHIP R 0.0 J 1/10W
R219 RK73GB2A000J CHIP R 0.0 J 1/10W
R222 RK73GB2A000J CHIP R 0.0 J 1/10W
R226 RK73GB2A100J CHIP R 10 J 1/10W
R301 RK73GB2A102J CHIP R 1.0K J 1/10W
R303 RK73GB2A274J CHIP R 270K J 1/10W
R304 RK73HB1J182J CHIP R 1.8K J 1/16W
R305 RK73GB2A183J CHIP R 18K J 1/10W
R306 RK73GB2A271J CHIP R 270 J 1/10W
R307 RK73GB2A223J CHIP R 22K J 1/10W
R308-310 RK73GB2A000J CHIP R 0.0 J 1/10W
R313 RK73GB2A331J CHIP R 330 J 1/10W
R318 RK73HB1J102J CHIP R 1.0K J 1/16W
R319 RK73GB2A123J CHIP R 12K J 1/10W
R320 RK73GB2A152J CHIP R 1.5K J 1/10W
R321 RK73GB2A102J CHIP R 1.0K J 1/10W
R329 RK73GB2A104J CHIP R 100K J 1/10W
R330 RK73GB2A000J CHIP R 0.0 J 1/10W
R331 RK73GB2A104J CHIP R 100K J 1/10W
R332 RK73GB2A224J CHIP R 220K J 1/10W
R333 RK73GB2A000J CHIP R 0.0 J 1/10W
R334 RK73GB2A100J CHIP R 10 J 1/10W
R335 RK73GB2A681J CHIP R 680 J 1/10W
R336 RK73HB1J334J CHIP R 330K J 1/16W
R337 RK73GB2A332J CHIP R 3.3K J 1/10W
R339 RK73GB2A473J CHIP R 47K J 1/10W
R341 RK73GB2A473J CHIP R 47K J 1/10W
R400 RK73GB2A102J CHIP R 1.0K J 1/10W
R401 RK73GB2A272J CHIP R 2.7K J 1/10W
R402 RK73GB2A332J CHIP R 3.3K J 1/10W
R403 RK73GB2A473J CHIP R 47K J 1/10W
R404 RK73GB2A182J CHIP R 1.8K J 1/10W
TX-RX UNIT (X57-6132-70)

TK-290-11B
10
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
R405 RK73GB2A332J CHIP R 3.3K J 1/10W
R406 RK73GB2A100J CHIP R 10 J 1/10W
R407 RK73GB2A102J CHIP R 1.0K J 1/10W
R408 RK73GB2A104J CHIP R 100K J 1/10W
R409 RK73GB2A102J CHIP R 1.0K J 1/10W
R410 RK73GB2A272J CHIP R 2.7K J 1/10W
R411 RK73GB2A821J CHIP R 820 J 1/10W
R412 RK73GB2A182J CHIP R 1.8K J 1/10W
R413 RK73GB2A473J CHIP R 47K J 1/10W
R414 RK73GB2A000J CHIP R 0.0 J 1/10W
R415 RK73GB2A471J CHIP R 470 J 1/10W
R416 RK73GB2A104J CHIP R 100K J 1/10W
R418,419 RK73GB2A104J CHIP R 100K J 1/10W
R420 RK73GB2A103J CHIP R 10K J 1/10W
R421 RK73GB2A223J CHIP R 22K J 1/10W
R422 RK73GB2A103J CHIP R 10K J 1/10W
R423 RK73GB2A473J CHIP R 47K J 1/10W
R424 RK73GB2A103J CHIP R 10K J 1/10W
R425 RK73GB2A102J CHIP R 1.0K J 1/10W
R426,427 RK73GB2A103J CHIP R 10K J 1/10W
R428 RK73GB2A472J CHIP R 4.7K J 1/10W
R429 RK73GB2A103J CHIP R 10K J 1/10W
R430 RK73GB2A473J CHIP R 47K J 1/10W
R431 RK73GB2A102J CHIP R 1.0K J 1/10W
R432,433 RK73GB2A473J CHIP R 47K J 1/10W
R434 RK73GB2A103J CHIP R 10K J 1/10W
R435,436 RK73GB2A102J CHIP R 1.0K J 1/10W
R437 RK73GB2A473J CHIP R 47K J 1/10W
R438-441 RK73GB2A102J CHIP R 1.0K J 1/10W
R442 RK73GB2A152J CHIP R 1.5K J 1/10W
R443 RK73GB2A821J CHIP R 820 J 1/10W
R444 RK73FB2B000J CHIP R 0.0 J 1/8W
R445 RK73GB2A000J CHIP R 0.0 J 1/10W
R446 RK73GB2A472J CHIP R 4.7K J 1/10W
R447 RK73GB2A473J CHIP R 47K J 1/10W
R448 RK73GB2A102J CHIP R 1.0K J 1/10W
R449-451 RK73GB2A473J CHIP R 47K J 1/10W
R452-455 RK73GB2A104J CHIP R 100K J 1/10W
R456-459 RK73GB2A473J CHIP R 47K J 1/10W
R460-462 RK73GB2A000J CHIP R 0.0 J 1/10W
R464 RK73GB2A473J CHIP R 47K J 1/10W
R466 RK73GB2A000J CHIP R 0.0 J 1/10W
R467,468 RK73GB2A473J CHIP R 47K J 1/10W
R469 RK73GB2A102J CHIP R 1.0K J 1/10W
R470-472 RK73GB2A000J CHIP R 0.0 J 1/10W
R474 RK73GB2A103J CHIP R 10K J 1/10W
R475-477 RK73GB2A101J CHIP R 100 J 1/10W
R478 RK73GB2A471J CHIP R 470 J 1/10W
R479 RK73GB2A473J CHIP R 47K J 1/10W
R480 RK73GB2A472J CHIP R 4.7K J 1/10W
R481 RK73GB2A000J CHIP R 0.0 J 1/10W
R482 RK73GB2A102J CHIP R 1.0K J 1/10W
R483 RK73GB2A473J CHIP R 47K J 1/10W
R484 RK73GB2A102J CHIP R 1.0K J 1/10W
R485,486 RK73GB2A473J CHIP R 47K J 1/10W
R487 RK73GB2A102J CHIP R 1.0K J 1/10W
R488 RK73HB1J000J CHIP R 0.0 J 1/16W
R489 RK73GB2A103J CHIP R 10K J 1/10W
R490 RK73GB2A104J CHIP R 100K J 1/10W
R491 RK73GB2A000J CHIP R 0.0 J 1/10W
R493 RK73GB2A100J CHIP R 10 J 1/10W
R494 RK73GB2A473J CHIP R 47K J 1/10W
R495 RK73GB2A471J CHIP R 470 J 1/10W
R601 RK73GB2A153J CHIP R 15K J 1/10W
R602 RK73GB2A223J CHIP R 22K J 1/10W
R603 RK73GB2A000J CHIP R 0.0 J 1/10W
R605,606 RK73GB2A000J CHIP R 0.0 J 1/10W
R607 RK73GB2A153J CHIP R 15K J 1/10W
R608 RK73GB2A103J CHIP R 10K J 1/10W
R609 RK73GB2A154J CHIP R 150K J 1/10W
R610 RK73GB2A563J CHIP R 56K J 1/10W
R611 RK73GB2A184J CHIP R 180K J 1/10W
R612 RK73GB2A334J CHIP R 330K J 1/10W
R614 RK73GB2A184J CHIP R 180K J 1/10W
R615,616 RK73GB2A103J CHIP R 10K J 1/10W
R617 RK73GB2A000J CHIP R 0.0 J 1/10W
R618 RK73GB2A683J CHIP R 68K J 1/10W
R619 RK73GB2A101J CHIP R 100 J 1/10W
R621 RK73GB2A103J CHIP R 10K J 1/10W
R622 RK73GB2A223J CHIP R 22K J 1/10W
R623 RK73GB2A334J CHIP R 330K J 1/10W
R624 RK73GB2A333J CHIP R 33K J 1/10W
R626 RK73GB2A104J CHIP R 100K J 1/10W
R628 RK73GB2A334J CHIP R 330K J 1/10W
R629 RK73GB2A223J CHIP R 22K J 1/10W
R631 ✽RK73GB2A204J CHIP R 200K J 1/10W
R633 RK73GB2A154J CHIP R 150K J 1/10W
R634 RK73GB2A153J CHIP R 15K J 1/10W
R635 RK73GB2A393J CHIP R 39K J 1/10W
R639 RN73GH1J913D CHIP R 91K D 1/16W
R640 RN73GH1J683D CHIP R 68K D 1/16W
R641 RN73GH1J913D CHIP R 91K D 1/16W
R642 RN73GH1J333D CHIP R 33K D 1/16W
R643 RK73GB2A564J CHIP R 560K J 1/10W
R645 RN73GH1J274D CHIP R 270K D 1/16W
R647 RK73GB2A000J CHIP R 0.0 J 1/10W
R648 RN73GH1J913D CHIP R 91K D 1/16W
R649 RN73HH1J682D CHIP R 6.8K D 1/16W
R651 RK73GB2A155J CHIP R 1.5M J 1/10W
R652 RK73HB1J473J CHIP R 47K J 1/16W
R653 RK73HB1J184J CHIP R 180K J 1/16W
R654 RN73HH1J683D CHIP R 68K D 1/16W
R655 RK73HB1J474J CHIP R 470K J 1/16W
R656 RN73HH1J682D CHIP R 6.8K D 1/16W
R657 RK73GB2A101J CHIP R 100 J 1/10W
R658 RK73HB1J224J CHIP R 220K J 1/16W
R659 RK73HB1J103J CHIP R 10K J 1/16W
R660 RK73HB1J223J CHIP R 22K J 1/16W
R661 RK73HB1J393J CHIP R 39K J 1/16W
R662 RK73HB1J470J CHIP R 47 J 1/16W
R663 RK73HB1J220J CHIP R 22 J 1/16W
R665,666 RK73GB2A000J CHIP R 0.0 J 1/10W
R668 RK73GB2A334J CHIP R 330K J 1/10W
R669 RK73GB2A000J CHIP R 0.0 J 1/10W
R670-673 RK73GB2A472J CHIP R 4.7K J 1/10W
R674 RK73HB1J104J CHIP R 100K J 1/16W
R675 RK73HB1J473J CHIP R 47K J 1/16W
R677 RK73GB2A333J CHIP R 33K J 1/10W
R679 RK73GB2A000J CHIP R 0.0 J 1/10W
R680-683 RK73HB1J104J CHIP R 100K J 1/16W
TX-RX UNIT (X57-6132-70)

TK-290-11B
11
PARTS LIST
Ref. No. Address Parts No. Description Desti-
nation
New
parts
Ref. No. Address Parts No. Description Desti-
nation
New
parts
R684 RK73HB1J473J CHIP R 47K J 1/16W
R685 RK73HB1J394J CHIP R 390K J 1/16W
R686 RK73HB1J000J CHIP R 0.0 J 1/16W
R687 RK73HB1J223J CHIP R 22K J 1/16W
R688 RK73HB1J000J CHIP R 0.0 J 1/16W
R689 RK73GB2A103J CHIP R 10K J 1/10W
R690 RK73GB2A271J CHIP R 270 J 1/10W
R691 RK73GB2A103J CHIP R 10K J 1/10W
R922 RK73GB2A103J CHIP R 10K J 1/10W
R923,924 RK73HB1J000J CHIP R 0.0 J 1/16W
D4 MA2S111-F DIODE
D5 ✽1SS360-F DIODE
D6 MA2S111-F DIODE
D7 1SS388F DIODE
D8 DA221 DIODE
D9 HZU4CLL ZENER DIODE
D10 MA4PH633 DIODE
D11 MA77 DIODE
D12,13 ✽MA2S077-F DIODE
D200 HSM88AS-E DIODE
D201-208 ✽1SV273-F VARIABLE CAPACITANCE DIODE
D300 MA3J742 DIODE
D400 1SR154-400 DIODE
D401 MA2S111-F DIODE
D402,403 ✽NNCD6.8G-A ZENER DIODE
D404 1SS301F DIODE
D408 1SS301F DIODE
D409 MA2S111-F DIODE
D601 MA3J742 DIODE
D602,603 ✽MA2S077-F DIODE
IC2 LMC7101BIM5 MOS-IC
IC3 ✽M62354GPDF0J MOS-IC
IC4 ✽MAX865EUA+T MOS-IC
IC5 LMX2352TMX/NP ANALOGUE IC
IC6 LMC7101BIM5 MOS-IC
IC7 ✽NJM2904V-ZB MOS-IC
IC200 GN2011(Q) MOS-IC
IC300 TA31136FNG MOS-IC
IC301 TC7S66FUF MOS-IC
IC400 BU4094BCFV MOS-IC
IC401,402 TK11250CMCL-G BI-POLAR IC
IC403-405 BU4094BCFV MOS-IC
IC406 ✽784214AGC150A MICROPROCESSOR IC
IC409 PST9132NR MOS-IC
IC412 AT24C08A10SU18 ROM IC
IC413 TC75W51FUF MOS-IC
IC414 AT29C02090TU ROM IC
IC415 ✽TC7S02F-F MOS-IC
IC600 LC73872M MOS-IC
IC601 TC75W51FUF MOS-IC
IC602 TA75W01FUF MOS-IC
IC603 M62364FP-F MOS-IC
IC604,605 TC75W51FUF MOS-IC
IC607 ✽TC35453FG MOS-IC
IC608,609 ✽TC7W53FU-F HYBRID IC
IC610 TC75W51FUF MOS-IC
Q1 DTA114EE DIGITAL TRANSISTOR
Q2 ✽2SJ144-GR(F) FET
Q3 2SC5108(Y)F TRANSISTOR
Q4 2SC4617(S) TRANSISTOR
Q5 2SC4649(N,P) TRANSISTOR
Q6 ✽2SC5110-F(O) TRANSISTOR
Q7 DTC114EE DIGITAL TRANSISTOR
Q8 ✽2SC4988-E TRANSISTOR
Q9 DTA144EE DIGITAL TRANSISTOR
Q10 DTC144EE DIGITAL TRANSISTOR
Q13 2SK1824-A FET
Q14 2SC5108(Y)F TRANSISTOR
Q200 ✽3SK274✽J-F FET
Q301 2SC4617(S) TRANSISTOR
Q302 ✽2SK1215-E(E) FET
Q400 UMG3N TRANSISTOR
Q401 ✽UPA572T-A FET
Q402 FP210 TRANSISTOR
Q403 2SJ243-A FET
Q404 DTC144EE DIGITAL TRANSISTOR
Q405 UMG3N TRANSISTOR
Q406 DTA123JE DIGITAL TRANSISTOR
Q407 ✽2SC4215-F(Y) TRANSISTOR
Q408-410 2SC4617(S) TRANSISTOR
Q411 2SB1132(Q,R) TRANSISTOR
Q412 2SK1824-A FET
Q413 HN1L02FU(F) FET
Q414 2SK1824-A FET
Q415 ✽2SJ517-E FET
Q601,602 2SK1824-A FET
TH301 157-104-65001 THERMISTOR
TX-RX UNIT (X57-6132-70)

TK-290-11B
12
EXPLODED VIEW
Parts with the exploded numbers larger than 700 are not supplied.
If a part reference number is listed in a box on the exploded view of the PCB, that part does not come with the PCB. These parts must be ordered separately.
3
2
1
BA
53
41
42
5648
1
8
31
38
25 25
54
Ex2
67x2
40
17
26x2
21
Gx2
Control unit
(A/6)
Control
unit
(E/6)
Control
unit (D/6)
Control
unit (B/6)
Control
unit
(F/6)
Hx2
H
Gx7
12
28
28
13
13
32
F
F
47 20
33
Cx2
701
700
702
703
30
19
65
G
39
7
14
6
18
49
63
E
43
44
55
51
52
A
2A
A
AB
3
Ex5
16
46
29
60
62
D
D
23
IC801
G
G
A:N14-0835-04
B:N14-0836-04
C M2.6 x 8 : N30-2608-43
D M2.6 x 6 : N67-2606-48
E M2 x 3 : N78-2030-48
F M2 x 3.5 : N79-2035-48
G M2 x 4 : N83-2004-48
H M2 x 5 : N83-2005-43
TX-RX unit
Final unit

TK-290-11B
13
ADJUSTMENT
Test Equipment Required for Alignment
No. Test Equipment Major Specifications
1Standard Signal Generator Frequency Range Maximum 600MHz or more.
(SSG) Modulation Frequency modulation and external modulation.
Output –133dBm/0.05µV to 7dBm/501mV
2Power Meter Input Impedance 50Ω.
Operation Frequency Up to 600MHz.
Measurement Range Full scale of 10W or so.
3Deviation Meter Frequency Range 100 to 200MHz.
4 Digital Volt Meter Measuring Range FS=18V or so.
(DVM) Accuracy High input impedance for minimum circuit loading.
5Oscilloscope DC through 30MHz.
6 High Sensitivity Frequency Range Up to 1GHz or so.
Frequency Counter Frequency Stability 0.2ppm or less.
7Ammeter 5A.
8AF Volt Meter Frequency Range 50Hz to 1MHz.
(AF VTVM) Voltage Range 1mV to 10V.
9 Audio Generator (AG) Frequency Range 100Hz to 100kHz or more.
Output 0 to 1V.
10 Distortion Meter Capability 3% or less at 1kHz.
Input Level 50mV to 10Vrms.
11 16ΩDummy Load Approx. 16Ω, 5W.
12 Regulated Power Supply 5V to 10V, approx. 5A
Useful if ammeter equipped.
13 Spectrum Analyzer Measuring Range DC to 1GHz or more.
14 Tracking Generator Center Frequency 50kHz to 600MHz.
Frequency Deviation ±35MHz.
Output Voltage 100mV or more.
■The following parts are required for adjustment
1. Antenna connector adapter
The antenna connector of this radio uses an SMA termi-
nal.
Use an antenna connector adapter [SMA(f) – BNC(f) or
SMA(f) – N(f)] for adjustment. (The adapter is not provided as
an option, so buy a commercially-available one.)
Note
When the antenna connector adapter touches the knob,
draw out the knob to mount the connector.
2. Universal connector
Use the interface cable (KPG-36) for PC tuning or the lead
wire with plug (E30-3287-28) and screw (N08-0535-08) for
panel tuning. Connect the plug to the universal connector of
the radio and tighten the screw.
The lead wire with plug (E30-3287-28) and screw (N08-
0535-08) terminals are as follows. Numbers are universal
connector terminal numbers.
Caution
1. When connecting the plug to the universal connector of
the radio, a short circuit may occur. To provent this, be
sure to turn the radio POWER switch off.
2. Since the RX AF output is a BTL output, there is a DC com-
ponent. Isolate this with a capacitor or transformer as
shown in the figure.
3. Do not connct an instrument between red or black and
GND.
•Universal connector
1: SSW
3: SP–
5: EMC
7: PTT
9: NC
11: 5M
13: RXD
2: SP+
EXT/INT RF SW
4: MSW
6: ME
8: PF
10: E
12: TXD
14: NC

TK-290-11B
14
•Panel tuning
ADJUSTMENT
•PC tuning
Connect the wires to the PCB in the connector case of
interface cable.
For output the wires out of the connector case, need to
process the connector case.
Repair Jig (Chassis)
Use jig (part No.: A10-1399-03) for repairing the trans-
ceiver Place the TX-RX unit on the jig and fit it with 7 screws.
Note: Supply power from an external power supply (Battery
terminal : +, jig (chassis) : –)
11: GREEN (5M)
TUBE
SCREW
8: YELLOW (PF SW)
2: RED (RX AF OUTPUT)
3: BLACK (RX AF OUTPUT)
10: BROWN (GND)
6: BROWN (MIC GND)
5: WHITE (MIC INPUT)
7: BLUE (PTT SW) GND →ON
RED (2)
BLK (3)
100µ10V
100µ10V
16Ω
WHT
(5)
BRN (6)
BLU (7)
BRN (10)
PTT SW
+
+
+
To Radio
AF
Voltmeter
Audio
generator
10µ10V
Connector case
KPG-36
Remove the
screw
PCB layout
Shield
AF
voltmeter
Audio
generator
100 µ10 V
100 µ10 V
10 µ10 V
+
+
+
16Ω
Battery terminal (+)
(CN405)
TX-RX unit
Jig

TK-290-11B
15
Panel Test Mode
This mode is used for making transceiver connection tests
and clearing the memory.
To set Panel test mode, turn on the power with [Tone 2]
and [PTT] are still held down and then first release [PTT]. This
mode cannot be set when disabled with the FPU.
In Panel test mode, when channel or signaling is selected,
the signaling that was most recently used is displayed.
Key operations in Panel test mode are as follows.
[Selector switch] : Use to select the test channel.
[PTT] : For transmit.
[SW A] : For down signaling.
[SW B] : For up signalling.
[Tone 1] : For setting Panel tuning mode.
[Tone 2] : For switching power between Hi/Low.
Enter the LCD all lamp mode if held
down for 1 second.
[Monitor] : For monitoring.
[Toggle] : No function.
Frequency (MHz)
CH RX TX
1155.100 (Center) 155.000 (Center)
2136.100 (Low) 136.000 (Low)
3173.900 (Hi) 173.975 (Hi)
4155.000 155.000
5155.200 155.200
6155.400 155.400
Signaling
No. Encode tone Decode tone
1None None
2QT 67.0Hz QT 67.0Hz
3QT 250.3Hz QT 250.3Hz
4DQT 023N DQT 023N
5None None
6DTMF (9) DTMF (159)
7MSK PN pattern None
8100Hz square wave None
9Tone 1 1750Hz None
10 Tone 2 2135Hz None
•LCD all lamp mode
Channel Signaling
How to Remove the Flat Cable
1. Gently draw out both sides of the connector lever uni-
formly in the direction of the arrow with tweezers.
(CN101, CN400)
2. Gently rise up the connector lever in the direction of the
arrow with a fine regular screwdriver or tweezers.
(CN1, CN3, CN401, CN403)
Note: Gently push both sides of the connector lever, when
put in the flat cable.
ADJUSTMENT
Tweezers
Flat cable
Lever
Regular screwdriver
Flat cable
Lever
•Clear function
Pressing [PTT] while holding down [Monitor] in Panel test
mode, triggers the clear function which clears all transceiver
data settings.
Panel test mode
LCD all lamp mode
[Tone 2]
holding about 1 sec.

TK-290-11B
16
•Panel tuning mode
Press [Tone 1] in Panel test mode to set Panel tuning
mode.
Varicap shift voltage (Mid)
Varicap shift voltage (High)
Voltage change frequency (Low-Mid)
Voltage change frequency (Low-Mid)
Voltage change frequency (Mid-High)
Voltage change frequency (Mid-High)
Frequency tune
RF high power
RF low power
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[PTT]
[Monitor] : Write data
[Tone 2]
[Tone 2] [Tone 2]
[Tone 2]
[Tone 2]
[Monitor]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
[Tone 2]
VSWM 75 VCO –3V adj.
VSWH146 VCO –6V adj.
VCO –3V shift RX frequency
VCO –3V shift TX frequency
VCO –6V shift RX frequency
VCO –6V shift TX frequency
FREQ160 TX frequency adj.
POW 78
[Monitor]
RF high power (Low)
POW 86
L
High power adj. (Low edge)
RF high power (Cen)
POW 78
C
High power adj. (Center)
RF high power (Hi)
POW 82
H
POW 55
LO
High power adj. (Hi edge)
Low power adj.
Function name Display Remarks
Max deviation
[Tone 2] [Tone 2]
[Tone 2]
[Tone 2]
[Monitor]
[Tone 2]
MDV 50
[Monitor]
Max deviation (Low)
MDV 73
L
Deviation adj. (Low edge)
Max deviation (Cen)
MDV 50
C
Deviation adj. (Center)
Max deviation (Hi)
MDV 35
H
Deviation adj. (Hi edge)
Deviation balance BLNC 75
QT deviation QTDV 67
DQT deviation DQDV 48
DTMF deviation DTDV150
MSK deviation MSDV 87
SQ T233
Sensitivity
SNS 75
MON
Squelch tight
SQ O186
Squelch open
BATT– – –
BATT153
END
Battery level
[Tone 2]
[Tone 2]
[Tone 2]
[Monitor]
[Tone 2]
[Monitor]
Sensitivity (Low)
SNS 17
L MON
Deviation adj. (Low edge)
Sensitivity (Cen)
MDV 75
C MON
Deviation adj. (Center)
Sensitivity (Hi)
MDV 191
H MON
Deviation adj. (Hi edge)
153.0000
r1
166.0000
r2
165.0000
t2
154.0000
t1
Note: Different sample displays are shown.
ADJUSTMENT

TK-290-11B
17
Item Condition
Measurement Adjustment
Specifications/Remarks
Test-
equipment Unit Terminal PartsUnit Method
ADJUSTMENT
1. Varicap shift 1) Set panel tuning mode DC VTVM TX-RX TP2 Panel SW A/ –3V ±0.1V
voltage Push Tone 2 to select SW B
Mid VSWM ∗∗
High 2) Push Tone 2 to select –6V ±0.1V
VSWH∗∗∗
2. Voltage change 1) Set panel tuning mode TP1 4.15V ±0.05V
frequency Push Tone 2 to select
Low–Mid ∗∗∗ . ∗∗∗∗
RX r1
TX 2) Push Tone 2 to select 4.15V ±0.05V
∗∗∗ . ∗∗∗∗
t1
Mid–Hi 3) Push Tone 2 to select 4.15V ±0.05V
RX ∗∗∗ . ∗∗∗∗
r2
TX 4) Push Tone 2 to select 4.15V ±0.05V
∗∗∗ . ∗∗∗∗
t2
1. Frequency 1) Set panel test mode
Power meter Panel ANT Panel SW A/ 155.000MHz ±50Hz
adjustment CH No. : 1 f. counter SW B
Signaling No. : 1
Select FRQ ∗∗∗
in panel tuning mode
PTT : ON
2. Maximum 1) Set panel test mode Power meter Panel ANT Check 5.0W or more
power CH No. : 3
check Signaling No. : 1 Ammeter
BATT terminal voltage : 7.5V
Select POW 255
in panel tuning mode
PTT : ON
Caution: When adjusting transmit power and sensitivity, connect the cable to the SMA antenna connector on the top panel. At this time,
use the antenna-less type jig connector (E30-3287-28) in the universal connector.
Item Condition
Measurement Adjustment
Specifications/Remarks
Test-
equipment Unit Terminal PartsUnit Method
Common Section
Transmitter Section

TK-290-11B
18
Item Condition
Measurement Adjustment
Specifications/Remarks
Test-
equipment Unit Terminal PartsUnit Method
ADJUSTMENT
3. TX high 1) Set panel test mode Power meter Panel ANT Panel SW A/ 4.50W ±0.1W
power CH No. : 3 SW B 2.3A or less
adjustment Signaling No. : 1 Ammeter
Select POW ∗∗∗
in tuning mode
Push Monitor to 3 point
adjustment mode
Select POW ∗∗∗
L
PTT : ON
2) Push Tone 2 to select
POW ∗∗∗
C
PTT : ON
3) Push Tone 2 to select
POW ∗∗∗
H
PTT : ON
4. TX high 1) Set panel test mode Check 3.7W~5.2W
power CH No. : 1 2.3A or less
check Signaling No. : 1
PTT : ON
2) CH No. : 2
Signaling No. : 1
PTT : ON
3) CH No. : 3
Signaling No. : 1
PTT : ON
5. TX low 1) Set panel test mode Panel SW A/ 1.0W ±0.1W
power CH No. : 3 SW B 1.2A or less
adjustment Signaling No. : 1
Select POW ∗∗∗
LO
PTT : ON
6. TX low 1) Set panel test mode Check 0.5W~1.5W
power CH No. : 1 1.2A or less
check Signaling No. : 1
Set low power (Push Tone 2)
PTT : ON
2) CH No. : 2
Signaling No. : 1
Set low power (Push Tone 2)
PTT : ON
3) CH No. : 3
Signaling No. : 1
Set low power (Push Tone 2)
PTT : ON

TK-290-11B
19
Item Condition
Measurement Adjustment
Specifications/Remarks
Test-
equipment Unit Terminal PartsUnit Method
ADJUSTMENT
7. Maximum 1) Set panel test mode Power meter Panel ANT Panel SW A/ 3.2kHz ±0.05kHz
deviation CH No. : 3 Deviation SW B (According to the
adjustment Signaling No. : 1 meter larger +, –)
Select MDV ∗∗∗ Oscilloscope
in panel tuning mode
Push Monitor to 3 point AG Side
Universal
adjustment mode AF VTVM
Select MDV ∗∗∗
L
AG : 1kHz/100mV
Deviation meter filter setting
LPF : 15kHz
HPF : OFF
PTT : ON
2) Push Tone 2 to select
MDV ∗∗∗
C
PTT : ON
3) Push Tone 2 to select
MDV ∗∗∗
H
PTT : ON
8. DQT balance 1) Set panel test mode Make the demodu-
adjustment CH No. : 3 lation waves into
Signaling No. : 1 square waves.
Select BLNC∗∗∗
in panel tuning mode
Deviation meter filter setting
LPF : 3kHz
HPF : OFF
PTT : ON
9. MIC 1) Set panel test mode Check 1.4kHz~2.9kHz
sensitivity CH No. : 3
check Signaling No. : 1
AG : 1kHz/10mV
Deviation meter filter setting
LPF : 15kHz
HPF : OFF
PTT : ON
10. QT 1) Set panel tuning mode Panel SW A/ 0.6kHz ±0.05kHz
deviation CH No. : 3 SW B
adjustment Signaling No. : 1
MIC input : OFF
Select QTDV∗∗∗
in panel tuning mode
Deviation meter filter setting
LPF : 3kHz
HPF : 50Hz
De-emphasis : 750µs
PTT : ON
