Kenwood KTC-V300N User manual

© B64-3320-00/00 (KV)
KTC-V300N
TV TUNER 3page 2 - 8
INSTRUCTION MANUAL
SYNTONISEUR TV 3page 10 - 16
MODE D'EMPLOI
SINTONIZADOR TV 3página 18 - 24
MANUAL DE INSTRUCCIONES
SINTONIZADOR TV 3página 26 - 32
MANUAL DE INSTRUÇÕES
Take the time to read through this instruction manual.
Familiarity with installation and operation procedures will help you obtain the best
performance from your new TV Tuner.
For your records
Record the serial number, found on the back of the unit, in the spaces designated on the
warranty card, and in the space provided below. Refer to the model and serial numbers
whenever you call upon your Kenwood dealer for information or service on the product.
Model KTC-V300N Serial number
US Residence Only
Register Online
Register your Kenwood product at
www.kenwoodusa.com
B64-3320-000001Eng.indd1B64-3320-000001Eng.indd1 06.1.124:00:09PM06.1.124:00:09PM

2|English
Accessories
1
..........1
2
..........1
3
(4.0m) ..........1
4
(5.5m) ..........1
5
..........6
6
(3.0m) ..........1
7
..........2
8
(M4x8mm) ..........4
9
(ø4x16m) ..........4
0
..........1
■Securing to audio board
Use screws (Accessory 8and 9) to fix TV Tuner onto an audio board or another.
Installation the TV Tuner Unit
Accessory 9
Accessory 8
Accessory 7
B64-3320-000001Eng.indd2B64-3320-000001Eng.indd2 06.1.124:00:09PM06.1.124:00:09PM

English |3
Installing the Antenna
■Before installing the antenna
2WARNING
• Mounting and wiring this product requires skills and
experience. For safety's sake, leave the mounting
and wiring work to professionals.
2CAUTION
• Incar antennas have a lower reception sensitivity
than antennas intended for outside mounting. The
picture may not appear or may be disturbed if the
signal in your area is weak.
• The film antennas are designed specially for use in
car.
• Do not attach the film antennas in the following
places:
– A place where the driver’s view is blocked
– A place where safety parts such as an airbag are prevented
from operating normally
– On the surface of a glass such as a rear hatch glass which
is frequently moved.
• The reception sensitivity lowers in the following
places:
– A place where a heat reflection glass or mirror-type glass
film is affixed
– A place where the film antenna of the factory-supplied
radio already exists
– On the window where the heating wire already exists
– On the side of the vehicle (door, front quarter window,
etc.)
– On the rear window
– On a glass (heat reflecting glass, heat insulating glass, etc.)
that blocks radio waves
• Using the cleaner (Accessory 0), remove oil and dirt
from the glass surface to which the film antennas
are to be affixed.
• If the ambient temperature is low, warm the glass
before starting the work.
• Before starting the work, confirm well the places
where the film antennas (Accessory 1and 2) and
the cables (Accessory 3and 4) are to be installed.
Once peeled off, the film antennas and double-stick
tape lose adhesion.
• Do not fold or damage the film antennas.
• Noise generated by the air conditioner or monitor
can cause poor TV reception.
• The film antennas cannot be installed depending on
the vehicle model.
• The reception sensitivity can vary with the
windshield wiper operation depending on the
vehicle model.
• The reception sensitivity can vary depending on the
relationship between the traveling direction of the
vehicle (the pointing direction of the antennas) and
the location of the broadcast station.
B64-3320-000001Eng.indd3B64-3320-000001Eng.indd3 06.1.124:00:10PM06.1.124:00:10PM

4|English
Installing the Antenna
• To prevent short circuits, remove the key from the ignition and disconnect the -terminal of the battery.
• Make sure to ground the unit to a negative 12V DC power supply.
• After the unit is installed, check whether the brake lamps, blinkers, wipers, etc. on the car are working
properly.
• Thoroughly wipe away oil and other dirt from the installation surface. Please avoid installation on uneven
surfaces.
■System connection
TV ANTENNA INPUT
TO MONITOR UNIT
Both the left and right cable connectors are
adhesive-backed.
TV antenna cable
(Accessory 3and 4)
Monitor cable
(Accessory 6)
• Insert the connector with the
hook aligned until it clicks.
• Release the hook when
disconnecting the connector.
Hook
TV tuner (KTC-V300N)
Control unit
To film antenna To film antenna
B64-3320-000001Eng.indd4B64-3320-000001Eng.indd4 06.1.124:00:10PM06.1.124:00:10PM

English |5
■Wiring example
Select either one of the following wiring routes depending on the situation.
TV antenna cables (Accessory 3and Accessory 4) are different in length. Use them appropriately to fit the
wiring of the vehicle you are working on.
Film antenna
(Accessory 1)
Film antenna
(Accessory 2)TV antenna cable
(Accessory 3and 4)
Monitor cable
(Accessory 6)TV Tuner
(KTC-V300N)
Film antenna
(Accessory 1)
Film antenna
(Accessory 2)TV antenna cable
(Accessory 3or 4)
Monitor cable
(Accessory 6)TV Tuner
(KTC-V300N)
TV antenna cable
(Accessory 3or 4)
Example A
This example shows a case where the cables are routed on the passenger’s seat side. For the right-hand-drive
car, route the cables on the left side passenger’s seat.
Example B
This example shows a case where it is difficult to route the cables near the rearview mirror.
B64-3320-000001Eng.indd5B64-3320-000001Eng.indd5 06.1.124:00:10PM06.1.124:00:10PM

6|English
■Installation Precedure
Installing the Antenna
1
23
4 4
3
Ceramic line
Cable connector Viewed from inside the vehicle
Slit
Film antenna
(Accessory 1)
Release paper 1
Film antenna
Slit
Slit
1. Confirm the installation place.
• Affix the film antennas and cable
connectors to the front windshield
following the laws and regulations of
your country.
• Affix each film antenna so that it does
not overlap the ceramic line. Affixing
the antenna on the ceramic line will
lose the adhesion force.
2. Using the cleaner (Accessory
0), wipe dirt off the antenna
installation surface.
3. Affix each film antenna.
1) Peel off the release paper (half-
transparent sheet) 1starting at the
slit, and then affix the film antenna to
the windshield.
• Once peeled off, the remaining
portions of the antenna cannot be
affixed again. Confirm the installation
place again.
2) Peel off the release paper 2starting
at either slit, and affix the film
antenna to the windshield.
3) Peel off the release paper 3and
release paper 4and affix the film
antenna to the windshield in the
same manner as above.
• Either the left or right side of the film
antenna can be affixed first.
• Inserting the release paper 1under
the corner of the film antenna as
shown on the right allows you to
peel off other sheets of release paper
easily.
B64-3320-000001Eng.indd6B64-3320-000001Eng.indd6 06.1.124:00:11PM06.1.124:00:11PM

English |7
Rubbing directions and places
4. Rub a rubber spatula against the
transparent sheet to affix the
antenna element to the windshield
tightly. If the rubber spatula is
not available, use a small board
wrapped with cloth.
5. Slowly peel off the transparent
sheet along the element line.
6. Make sure that the antenna element
has been affixed tightly, and then
affix the cable connector to the
element terminal.
7. Route the cable and secure it
with the supplied cable clamps
(Accessory 5).
Cable connector
(Accessory 3and 4)
Inside the
vehicle
Outside the vehicle
Peel-off direction
Antenna element
Windshield
Element terminal
Affix the cable connector
in such a manner that
the bare portions of the
antenna element are
aligned with the line
shape protrusions of the
cable connector.
Inside the
vehicle
Outside the vehicle
Antenna element
Windshield
Peel-off direction
B64-3320-000001Eng.indd7B64-3320-000001Eng.indd7 06.1.124:00:11PM06.1.124:00:11PM

8|English
Specifications
TV Tuner section
Colour system
: NTSC
Channel selection system
: PLL frequency synthesiser system
Television system
: M
Channel converge
VHF : 2 - 13 ch
UHF : 14 - 69 ch
Demodulation system
: Split carrier system
Antenna input
: 4-ch diversity (3.5 ø miniplug)
General
Operating voltage
: 14.4 V DC (11 V - 16 V)
Current consumption
: 305 mA
Dimensions (W×H×D)
: 188 × 30 × 144 mm
7-3/8 × 1-3/16 × 5-11/16 inch
Operational temperature range
: -10 °C - +60 °C
Storage temperature range
: -30 °C - +85 °C
Weight
: 680 g
1.5 lbs
TV Antenna
Output impedance
: 75 Ω / 3.5 ø minijack
Operating voltage
: 8 V DC
Current consumption
: 85 mA
Cable length
: 4.0 m, 5.5 m
Film antenna element size (W×H)
: 345 × 94 mm
13-9/16 × 3-11/16 inch
Weight
: 375 g
0.8 lbs
Specifications subject to change without
notice.
FCC WARNING
This equipment may generate or use radio frequency energy.
Changes or modifications to this equipment may cause
harmful interference unless the modifications are expressly
approved in the instruction manual. The user could lose
the authority to operate this equipment if an unauthorized
change or modification is made.
NOTE
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment may cause harmful
interference to radio communications, if it is not installed and
used in accordance with the instructions. However, there is
no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
receiver.
• Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician
for help.
B64-3320-000001Eng.indd8B64-3320-000001Eng.indd8 06.1.124:00:12PM06.1.124:00:12PM

B64-3320-000001Eng.indd9B64-3320-000001Eng.indd9 06.1.124:00:12PM06.1.124:00:12PM

10 |Français
Accessoires
1
..........1
2
..........1
3
(4,0m) ..........1
4
(5,5m) ..........1
5
..........6
6
(3,0m) ..........1
7
..........2
8
(M4x8mm) ..........4
9
(ø4x16mm) ..........4
0
..........1
■Fixation de la carte audio
Utilisez les vis (Accessoire 8et 9) pour fixer le tuner TV sur une carte audio ou autre.
Installation du tuner TV
Accessoire 9
Accessoire 8
Accessoire 7
