KERN DAB-A01 User manual

KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [e-mail]
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Betriebsanleitung Temperatur-Kalibrierset
Operating instruction temperature calibrating set
Mode d’emploi jeu de calibrage de la température
KERN DAB-A01
Version 1.0
07/2015
DAB_A01-BA-def-1510

6 DAB_A01-BA-def-1510
GB
KERN DAB-A01
Version 1.0 07/2015
Operating Instructions
Temperature calibration set
Calibrate / adjust temperature of the heating module
1. Temperature calibration
We recommend performing occasional tests of the instrument’s temperature value,
using the optional temperature calibration set KERN DAB-A01.
Before you do this, allow the device to cool down for at least 3 hours after the last
heating phase.
Preparation:
Switch off moisture analyser
Install temperature calibration set as per illustration
Turn on moisture analyser

DAB_A01-BA-def-1510 7
Set test parameters:
After pressing the first ident number <0> will be displayed.
Using arrow keys select e.g. ident number <1> and confirm by
. The currently set heating profile flashes.
Using arrow keys select heating profile <SOFT> and confirm by
.
The currently set heating profile and switch-off criterion flashes.
Use the arrow keys to select switch-off criterion <MANUAL>.

8 DAB_A01-BA-def-1510
Confirm by , the currently set drying temperature flashes.
Use the arrow keys to enter the desired test temperature. For the
first or the first two digits select a value and confirm by .
Using arrow keys select the desired value for the last digit.
Confirm input by .
Begin temperature calibration:
Switch on temperature calibration set.
Close heating hood and press . The instrument will be automatically heated
to the set temperature. The current temperature and the elapsed time will be in-
dicated in the display.
After approx. 15 minutes finish by . Compare the temperature value of the
moisture analyser with that of the temperature calibration set. At a difference of
±5°C we recommend to adjust the temperature, see following chapter.

DAB_A01-BA-def-1510 9
2. Temperature adjustment
Wird bei der Temperaturkalibrierung die zulässige Abweichung über-/unterschritten
kann die Temperatur des Instruments wie nachfolgend beschrieben justiert werden.
If the admissible deviation is exceeded / not reached during temperature calibration the
temperature of the instrument can be adjusted as described below.
1. Switch off instrument.
2. Press , quickly release, then press and at the same time.
„8.1x“ will be displayed. If not, separate device from power supply and restart
step two.
3. Adjust temperature using arrow keys . Each time you press the but-
ton the temperature will be increased or reduced by 1°C.
4. Confirm input by .
For further information on how to operate the moisture meter please refer to the
operating instructions enclosed with each model.
