KERN&SOHN TAB-BA-e-2014 User manual

KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
email: [e-mail]
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
Instruction Manual
Pocket scale
KERN TAB
Version 1.4
2020-02
GB
TAB-BA-e-2014
Importør:
Impex Produkter AS
Gamle Drammensvei 107
1363 Høvik
www.impex.no
[email protected]
Tel.: [phone]

TAB-BA-e-2014
2
GB
KERN TAB
Version 1.4 2020-02
Instruction Manual
Pocket scale
Contents
1Technical data ................................................................................................ 3
2B as ic Information (General).......................................................................... 4
2.1 Proper use................................................................................................................................. 4
2.2 Improper Use ............................................................................................................................ 4
2.3 Warranty .................................................................................................................................... 4
2.4 Monitoring of Test R esources ................................................................................................. 4
3B as ic S afety Precautions .............................................................................. 5
3.1 P ay attention to the ins tructions in the Operation Manual .................................................. 5
3.2 Personnel training .................................................................................................................... 5
4Trans portation & S torage.............................................................................. 5
4.1 Testing upon acceptance ........................................................................................................ 5
4.2 Packaging.................................................................................................................................. 5
5Appliance overview ....................................................................................... 6
6Unpacking, S etup and C ommis s ioning ....................................................... 7
6.1 Ins tallation S ite, L oc ation of Us e ............................................................................................ 7
6.2 Unpacking ................................................................................................................................. 7
6.2.1 Scope of delivery........................................................................................................................ 7
6.3 Battery operation and change................................................................................................. 8
6.4 Initial Commis s ioning .............................................................................................................. 8
6.5 Adjus tment................................................................................................................................ 8
6.6 Adjus ting ................................................................................................................................... 8
7Operation Mode.............................................................................................. 9
7.1 K eyboard overview................................................................................................................... 9
7.2 Operation................................................................................................................................. 10
7.2.1 Weighing................................................................................................................................... 10
7.2.2 Taring........................................................................................................................................ 11
7.2.3 External weighing units............................................................................................................. 12
7.3 Dis play background illumination .......................................................................................... 12
8S ervice, maintenance, dis pos al.................................................................. 13
8.1 Cleaning .................................................................................................................................. 13
8.2 Service, maintenance............................................................................................................. 13
8.3 Disposal................................................................................................................................... 13
9Instant help................................................................................................... 14
10 Declaration of Conformity ........................................................................... 14

TAB-BA-e-2014
3
1 Technical data
KERN
TAB 20-3
Weighing range (max) 20 g
Readability (d) 0.001 g
Recommended adjustment weight,
added 10 g
(F2)
Weighing Units ct, g, gn
Stabilization time (typical) 3 sec.
Operating temperature + 10° C …. + 30° C
Humidity of air 15 % - 80 % (non-condensing)
Dimensions of the housing
(W x D x H) [mm] 95 x 133 x 33
Weighing plate [mm] Ø 18
Weight (net) 200 g

TAB-BA-e-2014
4
2 Basic Information (General)
2.1 Proper use
The balance you purchased is intended to determine the weighing value of material
to be weighed. It is intended to be used as a “non-automatic“ balance, i.e. the
material to be weighed is manually and carefully placed in the centre of the weighing
plate. As soon as a stable weighing value is reached the weighing value can be read.
2.2 Improper Use
Do not use balance for dynamic weighing. In the event that small quantities are
removed or added to the material to be weighed, incorrect weighing results can be
displayed due to the “stability compensation“ in the balance. (Example: Slowly
draining fluids from a container on the balance.)
Do not leave permanent load on the weighing plate. This may damage the measuring
system.
Impacts and overloading exceeding the stated maximum load (max) of the balance,
minus a possibly existing tare load, must be strictly avoided. Balance may be
damage by this.
Never operate balance in explosive environment. The serial version is not explosion
protected.
The structure of the balance may not be modified. This may lead to incorrect
weighing results, safety-related faults and destruction of the balance.
The balance may only be used according to the described conditions. Other areas of
use must be released by KERN in writing.
2.3 Warranty
Warranty claims shall be voided in case
•Our conditions in the operation manual are ignored
•The appliance is used outside the described uses
•The appliance is modified or opened
•Mechanical damage and damage caused by media, liquids
•natural wear and tear
•The appliance is improperly set up or incorrectly electrically connected
•The measuring system is overloaded
2.4 Monitoring of Test Resources
In the framework of quality assurance the measuring-related properties of the
balance and, if applicable, the testing weight, must be checked regularly. The
responsible user must define a suitable interval as well as type and scope of this test.
Information is available on KERN’s home page (www.kern-sohn.com) with regard to
the monitoring of balance test substances and the test weights required for this. In
KERN’s accredited DKD calibration laboratory test weights and balances may be
calibrated (return to the national standard) fast and at moderate cost.

TAB-BA-e-2014
5
3 Basic Safety Precautions
3.1 Pay attention to the instructions in the Operation Manual
Carefully read this operation manual before setup and
commissioning, even if you are already familiar with KERN
balances.
Versions in other languages are non-binding translations.
The only binding version is the original document in German.
3.2 Personnel training
The appliance may only be operated and maintained by trained personnel.
4 Transportation & Storage
4.1 Testing upon acceptance
When receiving the appliance, please check packaging immediately, and the
appliance itself when unpacking for possible visible damage.
4.2 Packaging
Keep all parts of the original packaging for a possibly
required return.
Only use original packaging for returning.
Prior to dispatch disconnect all cables and remove
loose/mobile parts.
Reattach possibly supplied transport securing devices.
Secure all parts such as the glass wind screen, the
weighing platform, power unit etc. against shifting and
damage.

TAB-BA-e-2014
6
5 Appliance overview
1
Wind screen / hinged cover serving as pressure and dust protection
2
Adjustment weight
3
Weighing surface with weighing vessel

TAB-BA-e-2014
7
6 Unpacking, Setup and Commissioning
6.1 Installation Site, Location of Use
The balances are designed in a way that reliable weighing results are achieved in
common conditions of use.
You will work accurately and fast, if you select the right location for your balance.
Therefore, observe the following for the installation site:
•Place the balance on a firm, level surface;
•Avoid extreme heat as well as temperature fluctuation caused by installing
next to a radiator or in the direct sunlight;
•Protect the balance against direct draughts due to open windows and doors;
•Avoid jarring during weighing;
•Protect the balance against high humidity, vapours and dust;
•Do not expose the device to extreme dampness for longer periods of time.
Non-permitted condensation (condensation of air humidity on the appliance)
may occur if a cold appliance is taken to a considerably warmer environment.
In this case, acclimatize the appliance for ca. 2 hours at room temperature.
•Avoid static charge of goods to be weighed and weighing container.
The occurrence of electromagnetic fields, electrostatic charging as well as instable
power supply may result in considerable display variations (incorrect weighing
results). In that case, the location must be changed.
6.2 Unpacking
Carefully remove the balance from the packaging, remove plastic cover and setup
balance at the intended workstation.
6.2.1 Scope of delivery
Serial accessories:
•Pocket scale
•Batteries
•Instruction Manual
•Adjustment weight

TAB-BA-e-2014
8
6.3 Battery operation and change
In order to save the battery, the balance switches automatically off after 30 seconds
without weighing.
If the balance is not used for a longer time, take out the batteries and store them
separately. Leaking battery liquid could damage the balance.
6.4 Initial Commissioning
The warm-up period after the start stabilises the measured values.
The accuracy of the balance depends on the local acceleration of gravity.
Strictly observe hints in chapter “Adjustment”.
6.5 Adjustment
As the acceleration value due to gravity is not the same at every location on earth,
each balance must be coordinated - in compliance with the underlying physical
weighing principle - to the existing acceleration due to gravity at its place of location
(only if the balance has not already been adjusted to the location in the factory). This
adjustment process must be carried out during the initial start-up, after change in
location and variation of surrounding temperature. To receive accurate measuring
values it is also recommended to adjust the balance periodically in weighing
operation.
6.6 Adjusting
With an adjustment weight, the weighing accuracy can be checked and re-adjusted
at any time.
Procedure when adjusting:
Observe stable environmental conditions.
Switch on scale by and wait for “0.0“ to appear
on the screen
Press and hold until “ZERO“ appears flashing
Confirm by pressing and the value of the
adjustment weight will be shown flashing
Position the adjustment weight; after a while “PASS“
appears; this concludes the adjustment process.
Afterwards the scale switches off automatically.

TAB-BA-e-2014
9
7 Operation Mode
7.1 Keyboard overview
Key Description Function
Short key pressing
CAL-key •
Adjusting (Press and hold key for a long time)
•Backlighting ON/OFF
UNIT-key
•Weighing units switch-over
TARE button
•Tare = Return display to zero
ON/OFF-switch •Turn on/off

TAB-BA-e-2014
10
7.2 Operation
7.2.1 Weighing
Start balance by pressing
The balance shows for approx. 3 seconds
„HELLO“ in the display and then goes to „0.0“.
Now it is ready for operation.

If display does not show ”0“, press .
Put on items to be weighed,
weighed value is displayed.
(Example)
If the material to be weighed is heavier than the
weighing range, the display will show „OVER"
(=Overload).
