Kersten UBS Easy 9 G User manual

Original operating
instructions
Hydrostatic Two Wheel Tractor
UBS Easy Models 9 G - 13 GE
Order number: B00013 from machine No: 52361 Rev.: R01 Date: 01.04.2013
Manufactured by Kersten
Arealmaschinen GmbH
Empeler Straße 95
D - 46459 Rees
www.kersten-maschinen.de
Distributed in UK by
Kersten (UK) Ltd Tel. [phone]
Progrees House
39 Boulton Road Reading, RG2 0NH
www.kerstenuk.com - [email protected]

Table of Contents
1
1 INTRODUCTION.........................................................................................................................1
2 ABOUT THESE INSTRUCTIONS ..............................................................................................2
2.1 BEFORE COMMISSIONING.........................................................................................................................................2
2.2 NOTES ON THIS MANUAL .........................................................................................................................................2
3 SAFETY INSTRUCTIONS FOR HYDROSTATIC SINGLE TOWERS............................................... 3
3.1 INTENDED USE............................................................................................................................................................3
3.2 GENERAL SAFETY AND ACCIDENT PREVENTION RULES .....................................................................................3
3.3 PICTOGRAMS USED...................................................................................................................................................7
3.4 WARNINGS AND SAFETY INSTRUCTIONS FOR FILLED LEAD - ACID BATTERIES...............................................8
3.5 INSTRUCTIONS FOR USE FOR STARTER BATTERIES............................................................................................9
4 DISPOSAL........................................................................................................................................ 11
5 GUARANTEED................................................................................................................................. 11
6 RECOMMENDATIONS..................................................................................................................... 11
6.1 LUBRICANT.............................................................................................................................................................. 11
6.2 FUELS....................................................................................................................................................................... 11
6.3 MAINTENANCE AND REPAIR.................................................................................................................................. 11
7 OPERATING THE HYDROSTATIC SINGLE TOWERS .................................................................. 12
7.1 START ENGINE......................................................................................................................................................... 12
7.2 LOADING AND TURNING ON THE PTO................................................................................................................... 12
7.3 DISCONNECTING THE INTERNAL COMBUSTION ENGINE.................................................................................... 13
8 ASSEMBLY....................................................................................................................................... 14
8.1 MOUNTING ATTACHMENT UNIT ............................................................................................................................. 14
8.2 MOUNTING THE HAND PROTECTION..................................................................................................................... 15
9 GENERAL INFORMATION ON LOADING AND TRANSPORT INFORMATION ........................... 16
10 MAINTENANCE................................................................................................................................ 17
10.1 GENERAL MAINTENANCE INSTRUCTIONS............................................................................................................ 17
10.2 DAILY MAINTENANCE.............................................................................................................................................. 17
10.3 MAINTENANCE AFTER 20 HOURS OF OPERATION OR LONGER SERVICE LIFE................................................ 18
10.4 MAINTENANCE AFTER 100 OPERATING HOURS................................................................................................... 18
10.5 STORAGE ................................................................................................................................................................. 18
11 TECHNICAL DATA........................................................................................................................... 19
12 WIRING PLAN - SAFETY DEVICE .................................................................................................. 21
13 MALFUNCTION AND THE RESOLUTION ...................................................................................... 22
14 EC DECLARATION OF CONFORMITY........................................................................................... 25

1
Forewor
d
1 Introduction
Dear Customer,
Thank you for choosing a quality product from Kersten.
This product has been manufactured according to the most up-to-date production methods and extensive
quality assurance measures, because only when you are satisfied with your device, our goal is reached.
Before using this machine or implement for the first time, please read this manual thoroughly and
thoroughly.
If you do not understand any of the information contained in this safety data sheet or the product-specific
installation or operating instructions, please contact your sales representative or the machine
manufacturer directly.
Keep this manual handy. If necessary, you can read important information and handling instructions.
Have fun with your Kersten device wishes you
Dipl.- Ing. (FH) Robert Bosch
Managing Director

About this manual
2
2 About this manual
The machine or implement is subject to technical progress. All information, illustrations and
technical data are up-to-date at the time of publication. Changes in the sense of technical
progress are reserved to the manufacturer at any time.
Therefore, no claims can be derived from the information and illustrations in this booklet.
2.1 Before commissioning
Since self-propelled implements and attachments can cause serious accidents or hazards if used
improperly, the first time the Kersten implement is commissioned, it must be instructed by competent
and authorized persons absolutely necessary. The best way to familiarize yourself with its basic
functions and its handling is to choose a free and level terrain for your first trip.
• You reduce the risk of accidents on your part or third parties!
For further information and difficulties of any kind, please contact the dealer, importer or
directly to the manufacturer.
• Be sure to read the safety instructions on the following pages!
• Read the operating instructions before commissioning!
• Pass on all safety instructions to other users!
2.2 Notes on this operating manual
• Enumerations are marked with eye-catching points.
Example:
• Text
• Text
• Instructions are marked according to the order in which they are to be executed.
Example:
1. Text
2. Text

3
Safety instructions
3 Safety instructions for hydrostatic towed tractors
The most important safety instructions in this manual cannot cover all possibilities. It goes without
saying that common sense and caution are factors that are not built into a machine but must be
brought by the person who uses and maintains the machine.
In order to keep the accident risk as low as possible, please observe the following
subchapters.
3.1 Intended use
• The towing vehicle as well as the devices approved by the manufacturer are suitable for the
respective usual or common use and work in the agriculture and forestry, as for example.
• Green area and plant maintenance and built for winter service.
• Any other use is considered improper use. The manufacturer is not liable for damage resulting
from this, the risk being solely borne by the operator.
• Proper use also includes compliance with the operating, maintenance and service conditions
specified by the manufacturer.
• The towing vehicle may only be used, maintained and repaired by persons familiar with it and
aware of the dangers.
• The relevant accident prevention regulations as well as the other generally recognized safety
and occupational health rules must be observed.
• Unauthorized modifications to the machine lead to the exclusion of liability of the manufacturer
for the resulting damage.
3.2 General safety and accident prevention regulations
3.2.1 Basic Rules
•In addition to the instructions in this operating manual, observe the general valid safety and
accident prevention regulations!
•The towing vehicle may not be operated by persons under the age of 16, not even under the
supervision of a
•Adults, be served! Children and adolescents should be instructed not to play with the device.
• Only trained personnel or persons may use this machine!
• When using public traffic routes, observe the relevant regulations!
• The tiller is not approved for public transport.
• The clothing of the user should be tight. Avoid loose-fitting clothing and wear sturdy shoes or safety
shoes!
• Only work in good visibility and light conditions!
• The attached warning and information signs provide important information for safe operation; the
attention serves your safety!
• For transport on motor vehicles or trailers outside the area to be machined, the motor must be
switched off!
• Be careful with rotating tools - safety distance!
• Be careful with trailing tools. Wait for work on these until they stop completely!
• There are crushing and shearing points on driven parts!
•The transportation of persons and objects is prohibited!
• Driving behavior, steering and possibly braking capability as well as tilting behavior are influenced
by mounted or attached devices and load. For this reason, only implements approved by the
manufacturer may be used. The working speed must be adapted to the respective conditions.

4
Safety instructions
• Do not make any changes to the engine's upper idle speed. Too high a speed increases the risk of
accidents.
• Unauthorized conversions that endanger the operational safety of the machine are prohibited!
•Check the machine for operational safety before each use!
3.2.2 Work and danger area
• The user is responsible to third parties in the work area!
• Staying in the danger area of the machine is prohibited!
• Check the near range before starting up. Pay special attention to children and animals. Ensure
sufficient visibility!
• Before starting work, remove foreign objects from the surface to be worked. Pay attention to
other foreign objects during work and eliminate them in good time.
• When working in enclosed areas, the safety distance to the border must be maintained so as not
to damage the tool.
• When working in the immediate vicinity of public roads and paths, these should not be
approached if possible, as there is a risk of injury to third parties due to flying objects.
• When working on public roads and squares or in the immediate vicinity, warning and danger
signs should be set up in order to attract the attention of third parties.
3.2.3 Before starting work
• Before starting work, please familiarize yourself with all the devices and actuators as well as their
function and make sure that all safety devices are properly installed and in the protective position!
It's too late during the assignment!
• Above all, learn how to stop the engine quickly and safely in an emergency.
3.2.4 Starting the machine
• When starting the engine, all drives must be switched off!
• Do not run the engine indoors!
• Do not step in front of the single-axle tractor or the implement to start the engine.
• Do not use jumper fluids when using electric jump start (jumper cable). There is a danger of
explosion!
3.2.5 During operation
• Never leave the operating position on the guide rail while driving!
• Never adjust the operating handle while driving - risk of accident!
• The transport of persons and objects is prohibited!

5
Safety instructions
• If, for example, the attachment has caught a foreign object and blocked it, stop the engine and clean
the attachment with a suitable tool! Always switch off the engine when handling or cleaning the
implement!
• Do not leave the operating station until all tools of the attachment have come to a standstill!
• In the event of damage to the self-propelled implement or attachment, stop the engine immediately
and have the damage repaired.
• If the steering fails, stop the self-propelled implement immediately and stop the engine. Have the
fault rectified immediately.
• If there is a risk of slipping on sloping ground, the implement carrier must be secured by an escort
with a pole or a rope. The escort must be located above the vehicle at a sufficient distance from the
work tools! For the helper, it is recommended to wear crampons.
• If possible, always drive across (horizontally) to the slope!
• Only drive on rough and dry ground on steep slopes! Moisture and rain increase the risk of slipping
out and slipping.
• On steep slopes, lattice wheels or sprockets must be used to prevent the tractors from slipping off.
• In emergency situations, if, for example, the machine slips sideways in the slope, always release the
handles! You as an operator do not manage with their physical strength to prevent the Never move
the operating handle while driving - accident risk!
• The transport of persons and objects is prohibited!
• If, for example, the attachment has caught a foreign object and blocked it, stop the engine and clean
the attachment with a suitable tool! Always switch off the engine when handling or cleaning the
implement!
• Do not leave the operating station until all tools of the attachment have come to a standstill!
• In the event of damage to the self-propelled implement or attachment, stop the engine immediately
and have the damage repaired.
• If the steering fails, stop the self-propelled implement immediately and stop the engine. Have the
fault rectified immediately.
• If there is a risk of slipping on sloping ground, the implement carrier must be secured by an escort
with a pole or a rope. The escort must be located above the vehicle at a sufficient distance from the
work tools! For the helper, it is recommended to wear crampons.
• If possible, always drive across (horizontally) to the slope!
• Only drive on rough and dry ground on steep slopes! Moisture and rain increase the risk of slipping
out and slipping.
• On steep slopes, lattice wheels or sprockets must be used to prevent the tractors from slipping off.
• In emergency situations, if, for example, the machine slips sideways in the slope, always release the
handles! You as an operator do not manage with their physical strength to prevent the
Einachsschlepper on slipping and are otherwise carried away

6
Safety instructions
3.2.6 Leaving the machine
• When stopping the machine, close the fuel cock (if present)!
• By using wheel chocks or, if necessary, by applying the parking brake, secure the machine from
rolling away when leaving the vehicle.
• Secure the device against unauthorized use!
• Switch off the engine and, if present, remove the ignition key or the spark plug connector!
• Never leave the machine unattended while the engine is still in operation!
3.2.7 Screw connections and tires
• When working on the wheels, make sure that the device is safely parked and secured against rolling
away!
• Regularly check nuts and bolts for tightness and retighten if necessary.
• Repair work on the tires must only be carried out by qualified personnel and with suitable mounting
tools!
• If the tire pressure is too high, there is a risk of explosion!
• Check the air pressure regularly!
3.2.8 Coupling and uncoupling attachments
• Attach and remove attachments only when the engine is off, and the PTO is off.
• When replacing attachments and their parts, use suitable tools and
• Wear gloves.
• When mounting and dismounting, bring the required support equipment into the respective position
and ensure sufficient stability.
• Secure the rear-mounted tow tractor with an attachment to prevent it from rolling (parking brake,
wheel chocks).
• When attaching attachments, there is a risk of injury (crushing). Special care is necessary.
• Attach implements according to regulations and fix in the prescribed places
3.2.9 Maintenance, cleaning and repair work
• Do not carry out maintenance and cleaning work on the running engine!
• Always remove the spark plug connector when working on the engine.
• If guards and working tools are subject to wear, they must be checked regularly and replaced if
necessary.
• Damaged cutting tools must be replaced.
• When replacing cutting tools, use suitable tools and wear protective gloves.
• Only use original spare parts from the manufacturer, as these comply with the technical
requirements and thus the risk of accidents is minimized!

7
Safety instructions
• Cleaning with the high-pressure cleaner should be carried out so that the water jet is not held directly
in bearings, turned parts, grease nipples, shaft seals, wheel hubs, etc. After each cleaning with the
high-pressure device, the lubrication points must be re-greased. In the case of infringement, the right
to guarantee expires!
• Check the moving parts for ease of movement and regrease if necessary!
• After maintenance and cleaning work, be sure to replace the guards and put them in the protective
position!
• To avoid the risk of fire, keep the machine clean!
• Regularly check nuts and bolts for tightness and retighten if necessary.
• When carrying out maintenance, cleaning and repair work on the lifted device, always make sure
that it is protected by suitable support elements!
• Before carrying out any repairs, make sure that the hydraulic system is depressurised, because
fluids under pressure can penetrate the skin and cause serious injuries! There fore See a doctor
immediately - danger of infection!
• Repairs may only be carried out by qualified personnel.
• When working on the electrical system, always remove the earth strap from the battery!
• Check the hydraulic hose lines for damage and aging at regular intervals and replace if necessary.
• When welding the tractor or mounted equipment, disconnect the battery.
• Repair work such as welding, grinding, drilling etc. must not be carried out on load-bearing and other
safety-related parts such as frames, axles, etc.!
3.2.10 Engine, fuel and oil
• Before refueling, switch off the engine and remove the ignition key (if available)!
• Do not top up with fuel and do not spill fuel (use a suitable refilling aid). If necessary, take up
spilled fuel immediately.
• Dispose of oils, fuels and filters separately and properly!
• When handling fuel, caution is required, increased risk of fire. Never refuel near open flames, hot
engine parts, and sparks when flying. Do not smoke when refueling!
3.2.11 Electrical system and battery
• When working on the electrical system, always disconnect the battery (negative pole) (if present).
• Make sure the connection is correct - first positive pole and then negative pole!
• Be careful with battery gases - Explosive!
• Avoid sparks and open flame near batteries.
• Take care when handling battery acid - corrosive!
• Always provide the positive pole with the intended cover or terminal protection cap.
• Caregivers of pacemakers must not touch the live parts of the ignition system while the engine is
running!

8
Safety instructions
3.3 Pictograms used
Explanation of the pictograms used:
Before commissioning read and observe the
operating instructions and safety instructions.
Switch off the engine and remove the spark plug
connector before carrying out any repair, maintenance
or cleaning work.
Never open or remove protective devices while the
engine is running!
Touch machine parts only when they have come to a
complete stop.
Danger from passing parts while the engine is running -
keep safety distance.
Follow the instructions in the technical manual.
Smudge!

9
Safety instructions
3.4 Warnings and safety instructions for filled lead - acid batteries
• Follow the instructions on the battery and in the operating instructions.
• Use eye protection.
• Keep children away from acid and battery.
Explosion hazard:
• When charging batteries, a highly explosive bang mixture is produced, so please
note the following:
• Fire, sparks, open light and smoking prohibited.
• Avoid sparking when handling cables and electronic devices, as well as through
electronic charging.
• Avoid short circuits
Burn Hazards:
• Battery acid is highly corrosive, therefore:
• Wear protective gloves and eye protection.
• Do not tip the battery, acid can escape from the degassing openings.
First aid:
• Acid splash in the eye; immediately rinse with clear water for several minutes. Then
seek medical attention immediately.
• Acid splashes on the skin or clothing; Immediately neutralize with an acid converter or
soapy water and rinse with plenty of clear water.
• In case of drunk acid, consult a doctor immediately.
Warnings:
• Do not expose batteries to direct daylight unprotected.
• Discharged batteries can freeze, therefore store frost-free.
Disposal:
• Hand over used batteries at a collection point.
• During transport, the following instructions for use must be observed.
• Never dispose of old batteries in the household waste.

1
0
Safety instructions
3.5 Instructions for Use for Starter Batteries
1. Removal and installation of the battery
• Before removing the battery, switch off the engine and all power consumers.
• Avoid short circuits due to tools.
• When removing, first disconnect the negative pole (-), then the positive pole (+).
• Clean battery terminals and pole terminals and treat with acid-free grease.
• Clean the footprint / support before installing the battery.
• Tighten the battery firmly.
• When installing, first connect positive pole (+), then negative pole (-).
• Make sure that the pole terminals are secure.
• Leave at least one gas outlet unlocked.
• This also applies to the return transport of used batteries.
2. External loading
• Read and follow the operating instructions of the charger manufacturer!
• Check electrolyte level before charging and level if necessary.
• Disconnect the battery cable and remove the battery from the vehicle.
• Ensure good room ventilation.
• Use only suitable DC chargers.
• Connect the positive pole (+) of the battery to the plus output of the charger. Connect negative
pole (-) accordingly.
• Only switch on the charger after the battery has been connected and switch off the charger
after charging.
• Charging current should be 1/10 Ah of battery capacity.
• Interrupt the charge if the acid temperature exceeds 55 ˚C.
• Battery is fully charged if charging voltage does not increase within 2 hours.
3. Maintenance
• Keep the battery clean and dry.
• Do not use any improvers.
• Do not open the battery.
• If the starting power is insufficient, recharge the battery.
4. Start Help
• Use only standardized jump leads and observe their instructions for use.
• Use only batteries of the same nominal voltage.
• Switch off the engine from the helping vehicle.
• First connect both positive terminals (+) with the red jumper cable. Then connect a pole tongs
to the negative pole (-) of the dispenser battery. Then clamp the second pole on one of the
bare spots of the needy single-axle tractor.
• Start the helping vehicle, then max. The engine of the auxiliary towing vehicle max. Start 15
seconds.
• Disconnect the cable in reverse order.

Safety instructions
10
5. Decommissioning
• Store the battery in a cool place.
• When decommissioning, disconnect the negative pole (-).
• Regularly check the charge status of the battery and recharge if necessary.

11
Disposal and warranty
4 Disposal
The equipment must be disposed of in accordance with local, state, or local regulations.
Depending on the material, you can dispose of the parts as residual waste, special waste or
recycling. The company Kersten Arealmaschinen GmbH assumes no disposal.
5 Warranty
The device is accompanied by a sales message, which among other things determines the time for
the start of the warranty period. When selling the device, please complete the sales message
completely and send it back to us within 14 days. If warranty claims are asserted without us having
a sales message, no warranty service will be provided.
Warranty claims should be submitted promptly, but no later than six weeks after the occurrence of
the damage, giving details of the purchase data, otherwise no warranty service will be provided.
Complaints must be confirmed by the company Kersten Arealmaschinen GmbH. Wear parts are
excluded from the warranty. Furthermore, the warranty expires due to improper operation, when
performing no or incorrect maintenance work, when using inadmissible equipment and when using
non-original spare parts.
6 Recommendations
6.1 Lubricants
For engine and gearbox, use the specified lubricants (see under "Technical data").
For "open" lubrication points or nipple points we recommend to use biolubricant oil or biolubricant
grease. With the use of biolubricants you act ecologically correct, protect the environment and
promote the health of people, animals and plants.
6.2 Fuels
The built-up B & S or Honda engine can be easily operated with commercial unleaded normal and
premium gasoline and leaded premium gasoline.
Do not add oil to the gasoline.
If unleaded petrol is used for the environment, engines that are to be decommissioned for more than 30
days should have their fuel drained completely to avoid resin residues in the carburettor, fuel filter and
tank, or to add a fuel stabilizer to the fuel.
6.3 Maintenance and repair
Your dealer has trained mechanics who perform proper maintenance and repair. You should only
carry out major maintenance work and repairs yourself if you have the appropriate tools and
knowledge of machines and internal combustion engines.

12
Operation of the hydrostatic single-axle tractor
1
Illustration 7.1
7 Operation of the hydrostatic tow tractor
7.1 Start the engine
• To start the engine, the drive lever (Fig. 7.1, Pos. 6) in the recess of the shift gate and the
mechanical auxiliary drive lever (Fig. 7.1, Pos. 4) must be in the "Off" position. In addition, the
lower lever for the hydraulic drive (Fig. 7.1, Pos. 3), which is located below the right-hand handle,
must not be actuated.
If the levers are not in the position described above, the ignition of the engine is interrupted,
and the engine does not start.
• During the starting process it is forbidden to operate the deadman switch (Fig. 7.1, item 1)!
• To start the engine, the respective operating instructions of the engine manufacturer must be
observed.
7.2 Starting and switching on the auxiliary drive
You are best acquainted with the basic functions of the single-axle tractor by choosing a free and
level terrain for your first trip.
• Press the throttle lever (Fig. 7.1, Pos. 7) approx. 1/3.
• Press down the deadman switch (Fig. 7.1, item 1) and keep it pressed. Likewise, the lower lever
(Fig. 7.1, Pos. 2), which is located below the left handgrip and whose function resembles a
conventional "drive clutch", pull and hold.
• Select the direction of travel using the lever (Fig. 7.1, Pos. 6).
• Make sure that nobody is in front of and behind the machine!
• After selecting the direction of travel, slowly release the lever (Fig. 7.1, item 2). The faster the lever
is released, the faster the machine starts to move. To spare the components, a jerky start should
be avoided.
• To stop the machine, first pull the lever (Fig. 7.1, Pos. 2) and then the lever for the direction of travel
(Fig. 7.1, Pos. 6) back into the recess. Afterwards the levers (Fig. 7.1, Pos. 1 and 2) can be
released.

13
Operation of the hydrostatic single-axle tractor
• The required travel speed is set on the rotary knob (Fig. 7.1, item 5).
The setting of the driving speed and the preselection of the direction of travel may only be
carried out when the single-axle tractor is at a standstill!
• Use the throttle lever (Fig. 7.1, Pos. 7) to regulate the engine speed and thus also the driving
speed. Always try to drive with the lowest speed required, this protects material and the
environment.
• The hydraulically driven attachment machine is switched on with the lever (Fig. 7.1, Pos. 3), which
is located below the right-hand grip. Jerky switch-on is prohibited, so u.a. Uncontrolled reactions
of the implement are avoided. The lever has a self-holding feature (Fig 7.1, Pos. 8), which can be
inserted at a longer duty cycle. The latching automatically disappears when the lever (Fig. 7.1,
Pos. 3) is pulled again.
• The mechanically driven attachment machine is switched on with the lever (Fig.7.1, item 4) by a
gentle clockwise movement. Jerky switch-on is prohibited, so u.a. Uncontrolled reactions of the
implement are avoided.
• Switching on the implement is only permitted on a free or already worked area!
• It is not permitted to switch on the implement outside the working area!
• Never operate the attachment when children or animals are in the work area.
• If, when turning on the attachment, you notice that the tool is not turning up and you hear a noise
from slipping V-belts, you must switch off the attachment immediately. If the tool is engaged, the
initial torque is too high. If possible, switch on the machine without load. If necessary, check the
tension of the tension spring on the Bowden cable.
7.3 Switching off the internal combustion engine
• Before switching off the internal combustion engine, make sure that the drive lever (Fig. 7.1, item
6) is in the recess and the lever for the mechanical drive (Fig. 7.1, item 4) is in the "off" position,
In addition, the lever (Fig. 7.1, Pos. 3) for the hydraulic power take-off may not be pulled by the
self-holding.
• Place the throttle lever (Fig. 7.1, item 7) in the neutral position and allow the engine to idle for
approximately one ½ minute.
• Turn the engine off switch located on the internal combustion engine to the "0" position.
• Close the fuel tap
• Secure the towing vehicle against unauthorized use and, if necessary, remove the ignition key.
• When leaving, secure the device against rolling away, by using wheel chocks or, if necessary, by
applying the parking brake.
Tip:
In case of prolonged downtime, do not stop the engine with the "Engine off switch", but close the
fuel cock and let the engine run until it comes to a standstill by itself. Thus, the carburettor is empty
and no gumming can occur. This procedure must not be carried out in confined spaces, otherwise
there is danger of suffocation. Basically, pay attention to adequate ventilation!

14
Montage
8 Montage
8.1 Mounting attachment
• To mount an attachment, the attachment and attachment tube on the drive unit must be clean and
well-lubricated (see Figure 8.1).
• The coupling of the attachment and the receiving tube of the drive unit must be at the same height
to allow them to be pushed together. For this purpose, parking supports are available on some
attachments, where the appropriate height can be adjusted.
• When assembling, it is important to note that the coupling driver (red plastic star) is located in one
of the two coupling halves.
• Pull up the locking lever (Fig.8.1) and fold the locking lever upwards.
• If the attachment of the attachment can not be pushed completely into the pick-up tube, then the
teeth of the two coupling halves may be opposite each other. By switching on the power take-off
and by slowly pulling on the starter cable of the engine, the drive shaft continues to rotate, allowing
the further drive in.
• Lower the locking lever again and check that the locking pin is fully engaged.
Illustration 8.1
Clutch takeaway
Grease nipple
Locking lever

15
Montage
8.2 Assembly of the hand guard
The installation of the handguard is described in more detail below and illustrated in Figure 8.2.
1. To install the left-hand guard, place the supplied drilling template (Fig. 8.2, item 1) on the hand spar
(Fig. 8.2, item 2) and drill two 6.5 mm holes.
2. Screw on the left mounting bracket (Fig. 8.2, Pos. 3) with 2 M 6 x 20 screws, 2 body washers and 2
lock nuts.
3. Fasten the hand guard with 2 M6 x 20 screws, 2 large washers and 2 lock nuts.
4. Perform the same steps for mounting the right-hand guard.
1
3
2
Illustration 8.2

16
General instructions for load securing and transport
9 General instructions for load securing and transport
• Pay attention to the trailer load of the towing vehicle and the permissible total weight of the
trailer!
• Suitable loading ramps with sufficient load-bearing capacity must be used for loading the
machine.
• The ramps must be secured against slipping.
• The machine must be secured against rolling during transport.
• There are ring eyes on the handlebar pockets of the single-axle tractor (Fig. 9.1, item 1) and on
various attachments (Fig. 9.2, item 1), which can be used for lashing.
1 1
• If present, apply the parking brake so that the drive wheels are locked.
• Switch off the engine and close the fuel tap.
• Before unloading the machine, make sure there is no obstacle immediately before the ramps on the
ground, otherwise there is a risk of collision. When unloading several machines, these are far
enough to drive out of the loading zone.
Illustration 9.1
Illustration 9.2

17
Maintenance
10 Maintenance
10.1 General maintenance instructions
• Personal injury or damage to the machine may occur.
• Check all safety-related parts before every use of the machine.
• Oil change intervals must be carried out according to the recommendations of the respective engine
manufacturer.
• Check the hydraulic connections for leaks before each use.
• High pressure leaking fluids (such as hydraulic oil and diesel fuel) can penetrate the skin
and cause serious injury! Therefore, seek medical attention immediately - risk of infection!
• The hydrostatic tiller is operated with biodegradable oil.
• The machine must be regularly serviced.
• Dispose of oils, fuels and filters separately and properly!
• When working on the electrical system, disconnect the earth connection from the battery!
• Repairs, maintenance and cleaning work as well as the elimination of malfunctions must always be
carried out with the drive switched off and the engine stationary. Remove ignition key or spark plug
connector! After carrying out this work, replace all protective devices!
• If the machine is transported in a different way than with its own drive, this must be done with the
motor switched off!
• Regularly check nuts and bolts for tightness and retighten if necessary.
• When carrying out electrical welding work on the tractor and attached equipment, disconnect the
cables at the generator and at the battery!
• Only use original spare parts from the manufacturer!
• After the first 5 hours of operation, check all screw and bolt connections.
• Lubricate or lubricate all moving parts regularly.
• Check hydraulic connections for the first time after 5 operating hours, retighten if necessary.
Only tightening has no success!
Release a leaking hydraulic fitting first, then move the hose or fitting, and then retighten the
fitting.
10.2 Daily maintenance
• Before each use, the safety elements and moving parts must be checked for wear.
• Check the hydraulic oil level before each use. To do this, unscrew the cap from the tank and visually
check whether the oil in the tank easily covers the horizontally arranged plate.
• Check the engine oil level before each use.
• Inspect the air pre-filter (if present) and air filter cartridge for dirt if it is very dirty or damaged.
• Check hydraulic connections and lines for leaks and damage.
• Check the air pressure of the drive wheels.
• Carry out a test run before each use.
• Clean the unit after each use.
