Operator’s Manual
Maxi Sneaker 370 Vibratory Plow
Model—Serial Range
25530T—323000000 and Up
3455-524A Original Instructions (EN) *3455-524*A

Disclaimers and Regulatory Information
It is a violation of California Public Resource Code Section 4442 or 4443 to use or operate
the engine on any forest-covered, brush-covered, or grass-covered land unless the engine
is equipped with a spark arrester, as defined in Section 4442, maintained in effective
working order or the engine is constructed, equipped, and maintained for the prevention of
fire.
Because in some areas there are local, state, or federal regulations requiring that a spark
arrester be used on the engine of this machine, a spark arrester is available as an option. If
you require a spark arrester, contact your Authorized Service Dealer. Genuine Toro spark
arresters are approved by the USDA Forestry Service.
The enclosed engine owner's manual is supplied for information regarding the US
Environmental Protection Agency (EPA) and the California Emission Control Regulation of
emission systems, maintenance, and warranty. Replacements may be ordered through the
engine manufacturer.
WARNING
CALIFORNIA
Proposition 65
The engine exhaust from this product contains chemicals known to the State of California to
cause cancer, birth defects, or other reproductive harm.
Battery posts, terminals, and related accessories contain lead and lead compounds, chemicals
known to the State of California to cause cancer and reproductive harm. Wash hands after
handling.
Use of this product may cause exposure to chemicals known to the State of California to cause
cancer, birth defects, or other reproductive harm.
FCC
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired
operation. Changes or modifications not expressly approved by Toro could void the user’s
authority to operate the equipment.
© 2022—The Toro®Company
8111 Lyndale Ave So
Bloomington, MN 55044
Contact us at www.Toro.com
Printed in the USA
All rights reserved

Table of Contents
Disclaimers and Regulatory Information.............................................................................................. 2
Chapter 1: Introduction........................................................................................................................ 1–1
Intended Use ..................................................................................................................................... 1–1
Getting Help....................................................................................................................................... 1–1
Manual Conventions........................................................................................................................ 1–2
Safety Alert Classifications......................................................................................................... 1–2
Chapter 2: Safety.................................................................................................................................. 2–1
General Safety .................................................................................................................................. 2–1
Safety and Instructional Decals .................................................................................................... 2–2
Decal Locations ............................................................................................................................ 2–6
Plow Decal Locations ................................................................................................................ 2–10
Chapter 3: Preparation........................................................................................................................ 3–1
Jobsite Preparation .......................................................................................................................... 3–1
Reviewing the Job Plan............................................................................................................... 3–1
Selecting the Start and End Points........................................................................................... 3–1
Identifying Hazards ...................................................................................................................... 3–2
Locating Utilities............................................................................................................................ 3–2
Classifying the Jobsite................................................................................................................. 3–3
Classified Jobsite Precautions ...................................................................................................... 3–4
Arranging for Traffic Control....................................................................................................... 3–4
Operator Preparation....................................................................................................................... 3–4
Equipment Preparation ................................................................................................................... 3–5
Installing Counterweights ........................................................................................................... 3–5
Mounting the Fire Extinguisher ................................................................................................. 3–5
Chapter 4: Product Overview ............................................................................................................ 4–1
Controls............................................................................................................................................... 4–2
Display ................................................................................................................................................ 4–6
Indicators........................................................................................................................................ 4–6
Indicator Descriptions.................................................................................................................. 4–7
Gauges ........................................................................................................................................... 4–8
Gauges Descriptions ................................................................................................................... 4–8
Keys................................................................................................................................................. 4–9
Keys Descriptions......................................................................................................................... 4–9
Specifications .................................................................................................................................. 4–10
Attachments/Accessories............................................................................................................. 4–11
Chapter 5: Operation ........................................................................................................................... 5–1
Before Operation .............................................................................................................................. 5–1
Before Operation Safety ............................................................................................................. 5–1
Fuel Safety ..................................................................................................................................... 5–2
Fuel .................................................................................................................................................. 5–2
Start Interlock System ................................................................................................................. 5–4
Performing Daily Maintenance.................................................................................................. 5–4
During Operation .............................................................................................................................. 5–4
During Operation Safety ............................................................................................................. 5–4
Slope Safety .................................................................................................................................. 5–7
Adjusting the Roll Bar .................................................................................................................. 5–8
Starting and Shutting Off the Engine ....................................................................................... 5–9
Plow ............................................................................................................................................... 5–10
After Operation................................................................................................................................ 5–12
After Operation Safety............................................................................................................... 5–12
Finishing the Job......................................................................................................................... 5–12
3455-524 A Page 3 Disclaimers and Regulatory Information:

Chapter 6: Transport............................................................................................................................ 6–1
Hauling the Machine ........................................................................................................................ 6–1
Trailer Requirements ................................................................................................................... 6–1
Loading the Machine ................................................................................................................... 6–2
Tie-Down Points............................................................................................................................ 6–3
Tying Down the Machine ............................................................................................................ 6–3
Unloading the Machine ............................................................................................................... 6–4
Retrieving the Machine ................................................................................................................... 6–5
Chapter 7: Maintenance ..................................................................................................................... 7–1
Maintenance Safety ......................................................................................................................... 7–1
Recommended Maintenance Schedule...................................................................................... 7–2
Lubrication.......................................................................................................................................... 7–4
Greasing the U-Joint.................................................................................................................... 7–4
Engine Maintenance........................................................................................................................ 7–4
Engine Safety ................................................................................................................................ 7–4
Engine Oil Specifications............................................................................................................ 7–4
Changing the Air Filter................................................................................................................. 7–5
Checking the Engine Oil ............................................................................................................. 7–6
Changing the Engine Oil............................................................................................................. 7–6
Checking the Exhaust Clamp .................................................................................................... 7–6
Checking the Exhaust System .................................................................................................. 7–6
Fuel System Maintenance.............................................................................................................. 7–7
Checking the Fuel Lines ............................................................................................................. 7–7
Changing the Fuel Filter.............................................................................................................. 7–7
Draining the Fuel/Water Separator .......................................................................................... 7–7
Electrical System Maintenance..................................................................................................... 7–8
Electrical System Safety ............................................................................................................. 7–8
Checking the Battery ................................................................................................................... 7–8
Charging the Battery.................................................................................................................... 7–9
Drive System Maintenance .......................................................................................................... 7–11
Tire Specifications ...................................................................................................................... 7–11
Changing the Axle Oil................................................................................................................ 7–11
Gearbox Specifications ............................................................................................................. 7–12
Checking the Gearbox Oil ........................................................................................................ 7–12
Changing the Gearbox Oil........................................................................................................ 7–13
Cooling System Maintenance...................................................................................................... 7–13
Cooling System Safety.............................................................................................................. 7–13
Coolant Specifications............................................................................................................... 7–13
Checking the Engine Coolant Level....................................................................................... 7–13
Changing the Engine Coolant ................................................................................................. 7–14
Checking the Radiator Hoses.................................................................................................. 7–14
Belt Maintenance............................................................................................................................ 7–14
Checking the Drive Belt Tension............................................................................................. 7–14
Adjusting the Drive Belt............................................................................................................. 7–15
Replacing the Drive Belt ........................................................................................................... 7–15
Controls Maintenance ................................................................................................................... 7–16
Adjusting the Parking Brake..................................................................................................... 7–16
Adjusting the Neutral Position ................................................................................................. 7–16
Cleaning the Controls Linkage Assembly............................................................................. 7–17
Hydraulic System Maintenance .................................................................................................. 7–17
Hydraulic System Safety........................................................................................................... 7–17
Hydraulic Fluid Specifications ................................................................................................. 7–17
Checking the Hydraulic Fluid Level........................................................................................ 7–18
Disclaimers and Regulatory Information: Page 4 3455-524 A

Changing the Hydraulic Fluid .................................................................................................. 7–18
Changing the Hydraulic Filter .................................................................................................. 7–20
Checking the Hydraulic Lines .................................................................................................. 7–20
Plow Maintenance.......................................................................................................................... 7–20
Checking the Plow Vibrator Oil................................................................................................ 7–20
Checking the Plow Blade.......................................................................................................... 7–21
Changing the Plow Blade ......................................................................................................... 7–21
Changing the Plow Skid Shoes............................................................................................... 7–21
Checking the Plow Mounting Bolts......................................................................................... 7–22
ROPS Maintenance ....................................................................................................................... 7–22
ROPS Notice ............................................................................................................................... 7–22
Checking the Roll Bar................................................................................................................ 7–22
Checking the Seat Belt.............................................................................................................. 7–23
Cleaning............................................................................................................................................ 7–23
Removing Debris ........................................................................................................................ 7–23
Chapter 8: Storage............................................................................................................................... 8–1
Storage Safety .................................................................................................................................. 8–1
Preparing the Machine for Storage Over 30 Days.................................................................... 8–1
Decommission the Machine........................................................................................................... 8–1
California Proposition 65 Warning Information
3455-524 A Page 5 Disclaimers and Regulatory Information:

Chapter 1
Introduction
Intended Use
This machine is an articulating, hydrostatic, four-wheel drive, ride-on vibratory plow
designed to install cable and pipe in a variety of soils. Optional trenching, drilling, and reel
carrier attachments are available. Using this product for purposes other than its intended
use could prove dangerous to you and bystanders. Do not modify the machine or
attachments.
This machine should be operated, serviced, and repaired only by professionals familiar with
its characteristics and acquainted with the relevant safety procedures.
Operate this machine in ambient temperatures from -12° to 46°C (10° to 115°F). Contact
your Authorized Service Dealer for provisions required for operating this machine in extreme
temperatures.
Read this information carefully to learn how to operate and maintain your product properly
and to avoid injury and product damage. You are responsibility for operating the product
properly and safely.
Getting Help
G402348
Visit www.Toro.com for product safety and
operation training materials, accessory
information, help finding a dealer, or to register
your product.
Whenever you need service, genuine Toro parts,
or additional information, contact an Authorized
Service Dealer or Toro Customer Service and have
the model and serial numbers of your product
ready. These numbers are located on the serial
plate on your product . Write the numbers in the
space provided.
IMPORTANT
With your mobile device, you can scan the QR code on the serial number decal (if
equipped) to access warranty, parts, and other product information.
Model
Number:
Serial
Number:
Introduction Page 1–1 3455-524 A

Manual Conventions
This manual identifies potential hazards and has safety messages identified by the safety-
alert symbol, which signals a hazard that may cause serious injury or death if you do not
follow the recommended precautions.
G405934
This manual uses 2 words to highlight information. Important calls attention to special
mechanical information and Note emphasizes general information worthy of special
attention.
Safety Alert Classifications
The safety-alert symbol shown in this manual and on the machine identifies important safety
messages that you must follow to prevent accidents.
Safety-alert symbol appears above information that alerts you to unsafe actions or situations
and is followed by the word DANGER,WARNING, or CAUTION.
DANGER
Danger indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
Warning indicates a potentially hazardous situation which, if not avoided, could result
in death or serious injury.
CAUTION
Caution indicates a potentially hazardous situation which, if not avoided, may result
in minor or moderate injury.
3455-524A Page 1–2 Introduction: Manual Conventions

Chapter 2
Safety
General Safety
WARNING
Contacting underground utilities can cause death or serious injury.
Locate and verify underground utilities before digging or drilling.
• Before operating any equipment, review emergency procedures and check that all safety
precautions have been taken.
• Read and understand the content of this Operator’s Manual before starting the engine.
Always follow all safety instructions to avoid serious injury or death.
• Keep bystanders out of the operating area. Mark the job site clearly. Stop the machine if
a bystander enters the area.
• Do not operate the machine where flammable gas may be present.
• Slopes are a major factor related to loss-of-control and tip-over accidents, which can
result in severe injury or death. Operating the machine on any slope or uneven terrain
requires extra caution.
WARNING
Crushing can cause death or serious injury
Follow the procedure in Operator's Manual. Drive cautiously.
To help avoid injury:
• Operate at slow speed when on rough terrain.
• Avoid driving across slopes.
• Never jerk control levers. Use a steady, even motion.
• Always operate with heavy end uphill.
• Always drive with attachment low to the ground.
Safety Page 2–1 3455-524 A

Safety and Instructional Decals
Safety decals and instructions are easily visible to the operator and are located near any area
of potential danger. Replace any decal that is damaged or missing.
Decal Part: 147-5630
decal147-5630
Hydraulic fluid; Read the
Operator’s Manual.
Decal Part: 147-5634
decal147-5634
Forward
Fast
Turn right
Rearward
Slow
Turn left
3455-524A Page 2–2 Safety: Safety and Instructional Decals

Decal Part: 147-5637
decal147-5637
Lower the trencher; raise the plow.
Raise the trencher; lower the plow.
Decal Part: 147-5638
decal147-5638
Vibration
Fast
Neutral
Decal Part: 147-5642
decal147-5642
Oil level
Safety: Safety and Instructional Decals Page 2–3 3455-524 A

Decal Part: 147-5646
decal147-5646
Warning—Read the Operator’s
Manual before starting the machine.
Decal Part: 147-5652
decal147-5652
Parking brake
3455-524A Page 2–4 Safety: Safety and Instructional Decals

Decal Part: 147-5639
decal147-5639
Hydraulic fluid filter
Hydraulic fluid
Engine air filter
Engine air filter
Fuel filter
Fuel filter
Belt
Engine oil filter
Transmission oil
Lubrication
Vibrator box oil level
Read the Operator’s Manual.
Decal Part: 147-5805
decal147-5805
Throttle
Fast
Slow
Safety: Safety and Instructional Decals Page 2–5 3455-524 A

Decal Locations
G414366
147-5647
147-5627
147-5645
147-5629
147-5650
147-5651
147-5641
147-5648
147-5644
Decal Part: 147-5647
decal147-5647
Crushing hazard—stay away form
articulated joints.
3455-524A Page 2–6 Safety: Safety and Instructional Decals

Decal Locations (continued)
Decal Part: 147-5627
decal147-5627
Explosion hazard—Do not use starting fluid.
Decal Part: 147-5645
decal147-5645
Engine—Off
Engine—Run
Engine—Start
Decal Part: 147-5629
decal147-5629
Explosion hazard—Call before you
dig.
Safety: Safety and Instructional Decals Page 2–7 3455-524 A

Decal Locations (continued)
Decal Part: 147-5650
decal147-5650
Tipping hazard—Raise and lock
the roll bar and wear a seatbelt.
Decal Part: 147-5651
decal147-5651
Burn hazard—keep away from hot
surfaces.
3455-524A Page 2–8 Safety: Safety and Instructional Decals

Decal Locations (continued)
Decal Part: 147-5641
decal147-5641
Tie down
Decal Part: 147-5648
decal147-5648
Cutting hazard of the hand—Keep
your hands away from the machine.
Decal Part: 147-5644
decal147-5644
Warning—Wear hearing protection
Safety: Safety and Instructional Decals Page 2–9 3455-524 A

Plow Decal Locations
G414368
147-5649 147-5641
Decal Part: 147-5649
decal147-5649
Cutting hazard of the hand—Keep
bystanders away.
3455-524A Page 2–10 Safety: Safety and Instructional Decals

Plow Decal Locations (continued)
Decal Part: 147-5641
decal147-5641
Tie down
Safety: Safety and Instructional Decals Page 2–11 3455-524 A

Chapter 3
Preparation
Jobsite Preparation
A successful job begins before working. The first step in planning is reviewing information
already available about the job and jobsite.
Reviewing the Job Plan
Review the blueprints or other plans. Check for information about existing or planned
structures, elevations, or proposed work that may be taking place at the same time.
Selecting the Start and End Points
Select an end to use as a starting point. Consider the following when selecting a starting
point:
• Always park the equipment on a level site. Consider how the slope will affect setup
and operation. Assess the risks on each slope to determine if factors affecting risks
create an unsafe condition for working.
• Check that the starting and ending points allow enough space for working.
• Consider how shade, wind, fumes, and other site features will affect operator
comfort.
3455-524 A Page 3–1 Preparation

Identifying Hazards
Inspect the jobsite before transporting equipment; check for the following:
• Overall grade or slope
• Changes in elevation such as hills or open trenches
• Obstacles such as buildings, railroad crossings, or streams
• Signs of utilities
– “Buried utility” notices
– Gas or water meters
– Drop boxes
– Manhole covers
– Utility facilities without overhead lines
– Junction boxes
– Light poles
– Sunken ground
• Traffic
• Access
• Soil type and condition
• Loose material such as fencing or cable
Locating Utilities
1. Notify One-Call Services; mark the proposed path with white paint and have the
underground utilities located before working.
• In the US or Canada, call 811 (US) or 888-258-0808 (US and Canada). Also contact
any local utilities that do not participate in One-Call service.
• In countries that do not have a One-Call service, contact all local utility companies to
have underground utilities located.
2. Verify underground utilities; have an experienced locating equipment operator sweep
the area within 6 m (20 ft) to each side of the proposed excavation to verify previously
marked line and cable locations. Mark the location of all buried utilities and obstructions.
3. Locate overhead lines; note the location and height of all overhead lines in the jobsite
and ensure that the equipment maintains a proper distance from live lines.
Preparation: Jobsite Preparation Page 3–2 3455-524 A
