Kettler Henley Installation and operation manual

Nov 2016
IMPORTANT
PLEASE KEEP THIS BOOKLET FOR FUTURE REFERENCE.
THIS IS IMPORTANT INFORMATION REGARDING THE USE AND
CARE OF YOUR GARDEN FURNITURE.
Henley Gazebo
08321

Parts List
Helpful advice before you begin:
1. We suggest you spend a short time reading through this leaet and then follow the simple
step by step instructions.
2. Do not discard any of the packaging until you have checked that you have all the parts and
the pack of ttings.
3. Assemble this product on a soft surface.
4. To ensure an easier assembly, we strongly advise that all ttings are only nger tightened
during initial assembly. Only upon completion of the assembly should all xing points
be fully tightened.
5. Keep ttings out of children’s reach.
6. Do not use any other tools other than those recommended to build this product.
7. Please do not use substitute parts. Use only additional or replacement parts supplied by Kettler.
8. In the unlikely event that this product has missing or damaged parts, please visit our website
www.kettler.co.uk
Do not discard any of the packaging until you have checked that you have all
the parts and the pack of xings.
x 4 x 4 x 1 x 4
x 4 x 8 x 4 x 4 x 4
x 1x 4x 1x 1x 16x 8
x 4
AB DC
E F HG I
ONMLKJ
P

1M
2M
3M
3M
Overview
Assembly
This product requires a minimum of 2 people to assemble. Working at
height should only be done by a competent person. Please read the
assembly instructions thoroughly before assembly. Assemble all xings
nger tight and only tighten fully when all assembly stages complete.
We recommend this product is secured to the oor (xings not included).

Framework Assembly
A
B
When assembling please
make sure the hole is
facing outside.
5
1
4
2
3
Main Frame
Insert A into B ensuring both
end xing plates are facing
downwards (see step 3) and
screw hole facing outwards
(required at a later stage).
Repeat 4 times.
1

Framework Assembly
Insert A/B into E and repeat
4 times whilst supporting frame.
F
3
JK
E
2
E
A
FJ
K
4
E
H
I
5
C
P
D
Insert F into E rst and secure with J & K.
Then secure F into A/B with J & K.
Slide I up E rst. Fix H to underside of E.
Insert C into D ensuring end xing plates
are facing downwards (see step 6).

Roof Framework
Once step 6 is complete, remove
roof nial, loosely hang canopy,
ret nial. Continue to step 7.
6
6
7
7
EE
N
M
G
O
D
Securing Canopy
Fit plate (N), making sure it is the right way
round, pull canopy tight using (M) and
secure with nial (G). Repeat 4 times. And
then Velcro to underside of A/B.

Curtain / Side Rail Assembly
1
1
2
2
B
A
E
C
DA
Curtain/Side Rail Parts List
x 4
x 4
x 4 x 4 x 16
A
B
C D E

• This product may only be used for its intended purpose as furniture for residential properties.
• Check all components regularly for correct function, damage and loose connections especially
at the start of the season and at 1-2 month intervals dependent on use.
• Damaged components may endanger your safety or shorten the life of the product. Replace all
damaged parts immediately. Use only spare parts manufactured by Kettler. Should you wish to
purchase spare parts, they can be ordered directly from: www.kettler.co.uk/shop
• Kettler will not be responsible for damaged caused by improper use.
For Your Safety
Attention
• Whilst assembling this product keep out of the reach of children. (Choking hazard –
contains small parts)
• Ensure that your working area is free of possible sources of danger, for example don’t
leave any tools lying around.
• Always dispose of packaging material in such a way that it may not cause any danger.
There is always a risk of suocation if children play with plastic bags!
• We reserve the right to make changes for technical reasons.
Kettler GB Limited,
Merse Road, North Moons Moat,
Redditch, Worcestershire,
B98 9HL
www.kettler.co.uk
Warranty For Home Use
