KD-CDA12
KD-CDA12 is a 12 Channel Component/RGBHV Video/Audio Distribution Amplifier
Audio
Audio
KD-CDA12
HDTV Cable Box
DVD Player
Component
Component
Audio
Component
Audio
Component
Audio
Component
Audio
Component
Audio
Component
Audio
Component
*All Component sources can
be substituted with RGBHV
Plasma/LCD
Plasma/LCD
Retail Environment Application
Model: KD-CDA12
4Distributes 1 or 2 YPrPb/RGBHV sources to
12 YPrPb/RGBHV outputs/displays
4Can support 2 inputs to 6 outputs on each side or
1 input to 12 outputs on both sides
4Supports Left, Right analog stereo, and Coaxial/Digital
(PCM) Audio distribution
4Bandwidth of 350 MHz supports all resolutions
up to 1080p
4Each channel/output can support cable runs up to 300 ft.
4Can be daisy chained to support additional output
to more displays
4Incorporates 3 Key Digital™Exclusive Technologies
Key Benefits
Key Solutions General Info
Simultaneously distributes a one or two Video/Audio source up to 12 displays
Is heat resistant and can withstand noisy environments
Built-in video amplifier circuitry allows cable (RG6) runs up to 300 ft.
without signal degradation
›
›
›
Power: 100VAC to 240VAC,
50Hz and 60Hz, NTSC, PAL
Rack Mount: No
Remote Control: No
Enclosure Type: Metal
Dimensions:
12.5” x 6” x 1.75”
Shipping Carton Dimensions:
16” x 9” x 6”
Product Weight: 4 lbs
Shipping Weight: 6 lbs
›
›
›
›
›
›
›
›
Key Digital
®
Exclusive Technologies
Video/Audio Distribution Amps
