KD-ADA4
KD-ADA4 is a 4 Channel Component/RGBHV Video/Audio Distribution Amplifier,
with capability of allowing cable runs up to 1,000 feet
Up to 1,000 ft. Run
Up to 1,000 ft. Run
Audio
Component
Audio
Audio
Audio
Component
Audio
Component
Component
Plasma/LCD
Plasma/LCD
Plasma/LCD Plasma/LCD
KD-VA5
KD-ADA4
Computer
RGBHV
Component
*KD-VA5 converts
Component to
RGBHV/VGA
Transit/Waiting Area Application
Model: KD-ADA4
Key Digital
®
Exclusive Technologies
4Distributes 1 YPrPb/RGBHV source to 4 YPrPb/RGBHV
outputs/displays
4Supports Left, Right analog stereo, and Coaxial/Digital
(PCM) Audio distribution
4Built-in adjustable video amplifier circuitry allows cable
(RG6) runs up to 1000 ft. without signal degradation for
each channel/output
4Bandwidth of 350 MHz supports all resolutions
up to 1080p
4Can be daisy chained to support additional output
to more displays
4Incorporates 4 Key Digital™Exclusive Technologies
Key Benefits
Key Solutions General Info
Simultaneously distributes a single Video/Audio source up to 4 displays
Is heat resistant and can withstand noisy environments
Built-in video amplifier circuitry allows cable (RG6) runs up to 1000 ft. without
signal degradation
›
›
›
Power: 100VAC to 240VAC,
50Hz and 60Hz, NTSC, PAL
Rack Mount: Yes - 1U
Remote Control: No
Enclosure Type: Metal
Dimensions:
17.5” x 4” x 1.75”
Shipping Carton Dimensions:
24” x 7.5” x 6”
Product Weight: 5 lbs
Shipping Weight: 6 lbs
›
›
›
›
›
›
›
›
Video/Audio Distribution Amps
