Introduction
Key Digital®Phantom Series™ HDMI/DVI Distribution Ampliers are designed and engineered
to offer the best in quality, performance, and reliability while providing a cost effective HDMI/
DVI distribution solution. The KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro HDMI
Distribution Ampliers provide single input to multiple output distribution and maintain
crystal-clear, pristine picture and sound quality. Phantom Series™ Distribution Ampliers are
a transparent solution for all digital video/audio distribution applications and support all HD
and SD video standards, including 1080p/60. KD-HDDA Pro Distribution Ampliers feature
status-monitoring LEDs and are capable of separating HDMI Audio.
About the KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro
›Distribution of one HDMI input to multiple (2, 3, or 4) HDMI outputs
›Supports all SD, HD, and VESA (VGA, SVGA, XGA, WXGA, SXGA, UXGA) resolutions up to
1080p (60Hz & 50Hz)
»SD & HD: 480i, 480p, 720p, 1080i, 1080p
»VESA: From 640x480p up to 1920x1200p
›EDID and HDCP Transparency between source and displays
›Can be used to strip audio from the HDMI input and send it to external digital or analog audio
outputs
›Supports signal rates up to 10.2 Gb per second
›Supports HDMI and DVI-D
›Compliant with all HDMI
®
versions and HDCP copyright protection
›Input and Output status indicated by LED lights
›Firmware upgradable
›Rack mountable
Advanced HDMI®Features
›3D – Capability to pass 3D stereoscopic signal formats
Accessories
›External power supply: 5V 2A
›HDMI Lacing Clips
›Rack Ears
›Operating Instructions
›Warranty Card

2
Quick Setup Guide
›Step 1: Find a safe and convenient location to mount or place your KD-HDDA Pro unit
›Step 2: Begin with the KD-HDDA Pro unit and all input/output devices turned off with
power cables removed
›Step 3: Connect your HDMI or DVI-D source device to the input port of your KD-HDDA Pro unit
›Step 4: Connect your HDMI or DVI-D displays to the output port of your KD-HDDA Pro unit
›Step 5: Be sure the Operation Mode Switch is set to the “Normal” position
›Step 6: Connect power to the KD-HDDA Pro unit
›Step 7: Power on input/output devices
Audio
Audio
Audio
Audio
Audio
HDMI
Audio
CAT6/STP
Audio
Audio
Audio
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
Audio
CAT6/STP
Audio
CAT6/STP
DVI Video*
DVI Video*
DVI Video*
DVI Video*
HDMI
HDMI
HDMI
HDMI
HDMI
HDMI
CAT6/STP
CAT6/STP
Up to 400’
with Key Digital
®
KD-CAT6STP1X
KD-CATHD500Pro
KD-CATHD500Pro
CAT6/STP
CAT6/STP
Up to 600’
with Key Digital
®
KD-CAT6STP1X
KD-CATHD500FW
KD-CATHD500FW
CAT6/STP
CAT6/STP
Up to 600’
with Key Digital
®
KD-CAT6STP1X
KD-CATHD500FW
KD-CATHD500FW
KD-HDDA1x4Pro
EDID Control
RS-232
KD-HDDA1x4Pro
EDID Control
RS-232
KD-HDDA1x4Pro
EDID Control
RS-232
Speakers
Speakers
Sub-Woofer
Cable Box
Display 4
Display 3
Display 2
Display 1
Audio Rcvr.
Speakers
Speakers
Sub-Woofer
Cable Box
Display 4
Display 3
Display 2
Display 1
Audio Rcvr.
Display 4
Display 3
Display 2
Display 1
DVI
DVI Video* DVI Video*
Desktop PC
Note: No signal conversion is done on the KD-HDDA1x2Pro; KD-HDDA1x3Pro; KD-HDDA1x4Pro.
If input signal is HDMI output signal will be HDMI. If input signal is DVI output signal will be DVI.

3
Installation and Operation
Before permanently securing the unit for nal installation of cabling behind walls or ceilings, test for
proper operation of the unit and the cables in your system.
It is recommended that you leave enough ventilation space to provide sufcient airow and
cooling, especially if you are going to leave the unit powered at all times.
An optional HDMI cable clip (included) enables a method for securing HDMI cables the HDMI
connectors on the back of the units and helps defeat intermittent or complete signal loss due to
poor connection.
Active Input / Output LED Indicators
›The front LEDs indicate that a valid HDMI / DVI-D connection is made between the KD-HDDA Pro
unit and each Input / Output.
DVI Applications for KD-HDDA Pro Series
KD-HDDA Pro Distribution Ampliers can also be used with DVI-D sources and displays. For
these applications, use DVI to HDMI (Key Digital model number KD-MFHDMI or KD-FMHDMI)
adapters. Note that while HDMI supports both video and audio over an HDMI cable, DVI-D
supports only video.
Audio
Audio
Audio
Audio
Audio
HDMI
Audio
CAT6/STP
Audio
Audio
Audio
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
HDMI/DVI*
Audio
CAT6/STP
Audio
CAT6/STP
DVI Video*
DVI Video*
DVI Video*
DVI Video*
HDMI
HDMI
HDMI
HDMI
HDMI
HDMI
CAT6/STP
CAT6/STP
Up to 400’
with Key Digital®
KD-CAT6STP1X
KD-CATHD500Pro
KD-CATHD500Pro
CAT6/STP
CAT6/STP
Up to 600’
with Key Digital®
KD-CAT6STP1X
KD-CATHD500FW
KD-CATHD500FW
CAT6/STP
CAT6/STP
Up to 600’
with Key Digital®
KD-CAT6STP1X
KD-CATHD500FW
KD-CATHD500FW
KD-HDDA1x4Pro
EDID Control
RS-232
KD-HDDA1x4Pro
EDID Control
RS-232
KD-HDDA1x4Pro
EDID Control
RS-232
Speakers
Speakers
Sub-Woofer
Cable Box
Display 4
Display 3
Display 2
Display 1
Audio Rcvr.
Speakers
Speakers
Sub-Woofer
Cable Box
Display 4
Display 3
Display 2
Display 1
Audio Rcvr.
Display 4
Display 3
Display 2
Display 1
DVI
DVI Video* DVI Video*
Desktop PC

4
EDID Control Settings
At times, your HDMI sources and display may not synchronize properly.
This is when EDID* control should be utilized. KD-HDDA Pro
Distribution Amps feature an internal library of EDID settings to ensure
your HDMI source’s output is compatible with the display devices.
Please reset the unit by either unplugging and plugging the HDMI
connections, or via a power cycle for the new settings to take effect.
Rotary EDID Settings:
KD-HDDA1x2Pro
EDID Settings
0Copy EDID from
HDMI Output 1
11080i, 2Ch Audio
21080i, Dolby/DTS 5.1
31080i, 2ch Audio
41080p, Dolby/DTS 5.1
51080p, HD Audio
61080p, 2ch Audio
73D, 2ch Audio
83D, Dolby/DTS 5.1
93D, HD Audio
A1280x1024 DVI
B1920x1080 DVI
C1920x1200 DVI
D1080p, 2Ch Audio
E1080p, 2Ch Audio
FCopy EDID from
HDMI Output 2
KD-HDDA1x3Pro
EDID Settings
0Copy EDID from
HDMI Output 1
11080i, 2Ch Audio
21080i, Dolby/DTS 5.1
31080i, 2ch Audio
41080p, Dolby/DTS 5.1
51080p, HD Audio
61080p, 2ch Audio
73D, 2ch Audio
83D, Dolby/DTS 5.1
93D, HD Audio
A1280x1024 DVI
B1920x1080 DVI
C1920x1200 DVI
D1080p, 2Ch Audio
ECopy EDID from
HDMI Output 3
FCopy EDID from
HDMI Output 2
KD-HDDA1x4Pro
EDID Settings
0Copy EDID from
HDMI Output 1
11080i, 2Ch Audio
21080i, Dolby/DTS 5.1
31080i, 2ch Audio
41080p, Dolby/DTS 5.1
51080p, HD Audio
61080p, 2ch Audio
73D, 2ch Audio
83D, Dolby/DTS 5.1
93D, HD Audio
A1280x1024 DVI
B1920x1080 DVI
C1920x1200 DVI
DCopy EDID from
HDMI Output 4
ECopy EDID from
HDMI Output 3
FCopy EDID from
HDMI Output 2
Example of EDID Auto Select:
If one of your system’s displays supports 1080p and the second display only supports up to
1080i (does not support 1080p), then the highest common EDID format supported is 1080i. By
choosing the Auto Select EDID Setting, your KD-HDDA Pro unit will inform your source device to
output 1080i in order to ensure all displays receive a supported signal.
Rotary EDID Control Switch
* EDID (Extended display identication data) is a data structure provided
by a display to describe its capabilities to a source device.

5
External Audio Outputs
Analog audio output via 3.5mm stereo phone jack
›2 channel analog audio output from the selected HDMI
input source
›Converts only 2 ch. PCM audio from the HDMI input to
2 channel analog audio output
›Only supports 2 ch. PCM audio, not multi-channel PCM,
Dolby, DTS, HD audio
Digital audio output via Coax/RCA
›Digital audio output from the selected HDMI input source
›Uses SPDIF format
›Supports PCM, Dolby, DTS; does not support multi-channel PCM or HD audio
Digital audio output via Optical
›Digital optical audio output from the HDMI input
›Uses SPDIF format
›Supports PCM, Dolby, DTS; does not support multi-channel PCM or HD audio
RS-232 Commands and Protocol
›KD-HDDA Pro units are compatible with all Control Systems, such as Compass Control
®
, AMX
®
,
Control4
®
, Crestron
®
, RTI
®
, Universal
®
›Connect your Control System’s Master Controller to the KD-HDDA Pro unit using the RS-232
port. Follow all instructions provided with your control system.
›RS-232 Protocol:
»Baud Rate = 57600 bits per second
»Data Bits = 8 / Stop Bits = 1
»Parity = None
»Flow Control = None
RS-232 Command Description
H Help
PF Power Off
PN Power ON
Video Output Setup Commands: xx = [01-02/03/04] (A=All)
SPO xx ON/OFF Set Output xx ON/OFF
Audio Output Setup Commands: [E=Enable, D=Disable]
SPO AA E/D Enable/Disable External Analog Audio Output
SPO DA E/D Enable/Disable External Digital Audio Output
System Address Setup Command: xx = [00-99], 00 = Single
SPC Axx Set System Address to xx
SPC DF Reset to Factory Defaults
›All RS-232 commands must be in
lower case letters
›Command must be terminated with
a carriage return

6
Mechanical / Technical Specifications
Inputs 1 HDMI Connector
Outputs 4/3/2 HDMI Connectors
Analog L/R Audio Output (3.5mm Stereo Phone Jack)
Digital Audio Output (Coax; 1 RCA Jack + TOSLINK)
Digital Audio Output (Optical: 1RCA Jack + TOSLINK)
Bandwidth TMDS bandwidth 10.2 Gb/s
Compliance With
HDMI Standard
All HDMI versions and HDCP.
Link Single Link: 1080p/60, 12 bit color depth, 1920x1200 max
Deep Color Support Supports digital video formats in Deep Color Mode at up to 12 bits/
color
Lossless
Compressed Digital
Audio
Supports lossless compressed digital audio
(Dolby
®
TrueHD, Dolby
®
Digital Plus and DTS
™
-HD Master Audio)
DDC Signal (Data) Input DDC Signal: 5 Volts p-p (TTL)
HDMI Video/Audio
Signal
Input Video Signal: 1.2 Volts p-p
HDMI Connector HDMI Connector: Type A, 19 Pin Female
I2C Communication EDID and HDCP Bi-Directional Transparency from Display to Source
EDID Control 16 Available EDID Settings
Power Source 5 Volt DC @ 2 Amp, 100-240 VAC, 50-60 Hz
Dimensions W=8.5”, H=1.75”, D=4”
Weight 2 Lbs

7
Important Product Warnings:
1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including ampliers) that produce heat.
7. Only use attachments/accessories specied by the manufacturer.
8. Refer all servicing to qualied service personnel. Servicing is required when the device has
been damaged in any way including:
»Damage to the power supply or power plug
»Exposure to rain or moisture
Power Supply Use:
You MUST use the Power Supply provided with your unit or you VOID the
Key Digital®Warranty and risk damage to your unit and associated equipment.

8
How to Contact Key Digital
®
System Design Group (SDG)
For system design questions please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Key Digital Trainings
For questions about Key Digital
®
Trainings please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Customer Support
For customer support questions please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Technical Support
For technical questions about using Key Digital
®
products, please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Marketing and Public Relations:
For marketing and public relations information, please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Repairs and Warranty Service
Should your product require warranty service or repair, please obtain a Key Digital
®
Return Material
Authorization (RMA) number by contacting us at:
›Phone: [phone]
›E-mail: [email protected]
Feedback
Please email any comments/questions about the manual to:
›E-mail: [email protected]
Warranty Information
All Key Digital
®
products are built to high manufacturing standards and should
provide years of trouble-free operation. They are backed by a limited three-year
parts and labor warranty.

9

Key Digital®Systems :: 521 East 3rd Street :: Mount Vernon, NY 10553
Phone : [phone] Fax : [phone] Web : www.keydigital.com
Key Digital®, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high quality video imaging is important. Key Digital®
is at the forefront of the video industry for Home Theater
Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers.
Rev 0 – March 2013
