Key Digital X4x1WUTx User manual

4x1 4K/18G 100m HDBT PoH Wall Plate Switcher with
2x HDMI, DP, USB-C, USB, LAN, ARC, IR, RS-232,
IP Control, CEC Manager
™
. Transmitter Only.
The Experts in Digital Video Technology and Solutions™
Operating Instructions
KD-X4x1WUTx

2
Table of Contents
Quick Setup Guide ............................................................... 2
Integration Options ............................................................... 3
Connections, Buttons, and LEDs...................................................... 9
TCP/IP Commands .............................................................. 14
Specifications .................................................................. 16
Important Product Warnings & Safety Instructions: ....................................... 17
Contacting Key Digital ............................................................ 17
Warranty Information............................................................. 17
Always follow the instructions provided in this Operating Manual.
Please visit www.keydigital.com for the latest product
documentation and software downloads. Product features
and specifications are subject to change without notice.
Introduction
Key Digital®KD-4x1WUTx is an HDBaseT wall-plate transmitter + universal presentation switcher +
soft-codec enabling interface with two HDMI, one Display Port, and one USB-C input, as well as one
USB-A and USB-B connection. KD-X4x1WUTx is ideal for professional video installations in conference
rooms, class rooms, lecture halls, auditoriums, and more. KD-X4x1WUTx is natively received by KD-
X100MRx black box HDBaseT Rx or by KD-UPS52U Presentation Switcher. Both Rx options have audio
de-embedding for ease of integration with audio systems. Additional Key Digital Presentation Switchers
also support integration with KD-X4x1WUTx. KD-X4x1WUTx features push-button or TCP/IP switching
selection of the desired source and is KD-App Ready. Key Digital CEC Manager™enables basic controls
of the connected display for a simplistic all-in-one integration system. KD-X4x1WUTx is HDCP 2.2
compliant and supports 4K/UHD 24/25/30/60 (4:4:4) resolutions with up to 18Gbps bandwidth. 4K/
UHD signals are extended up to 100m / 328ft and 1080p up to 150m / 492ft via single CAT5e/6 cable.
In addition to AV signals, KD-X4x1WUTx extends USB 2.0, IR, RS-232 for controlling remotely located
equipment. The wall-plate unit fits in a standard US three-gang box and is powered by the Rx unit or
Presentation Switcher for convenient installation.
Default IP Address: 192.168.1.239, Port 23

1
Key Features
›Presentation Switching: 2 HDMI, 1 Display Port, and 1 USB-C source selection by push button
or IP control
›Installation: Fits in standard US 3-gang wall box or table and wall AV boxes.
›Rx Options: Native integration with KD-X100MRx black box HDBaseT Rx or KD-UPS52U Presentation
Switcher. Future Rx options may be available.
›Soft-Codec Enabling System: USB Host + Device ports on wall plate and chosen Rx / Presentation
Switch create connectivity hub for professional USB cameras and microphones, audio DSP, keyboard,
mouse, or touchscreen display with connected computer
›Ultra HD/4K: Supports up to 4096x2160 or 3840x2160 24/25/30/60hz at 4:4:4 (signals up to
18Gbps bandwidth)
›Auto-Sensing: Automatic selection of newly detected source and switching from newly disconnected
source when enabled
›CEC Manager™: Power, volume, and muting controls of the connected displays/projectors without
any additional control wiring
›KD-App Ready: Network scan & detect populates pre-built GUI including connected display/projector
controls via CEC Manager™
›Ease of Integration: Complete configuration using Key Digital Management Software™Pro
›HDCP Licensing: Fully licensed and compatible with HDCP 2.2
›HDR10 and Dolby Vision: More life-like images through a greater range of luminance levels
›Power Over HDBaseT: Wall-plate unit powered by Rx/Presentation Switch unit
›Installation: Tx unit designed for installation in standard US three-gang box
›Signal Extension: For resolution and cable quality
»4K/UHD (18G): Up to 100m / 328ft
»1080p: Up to 150m / 492ft
›Deep Color Support: Up to UHD/4K 30Hz 4:4:4/12 bits or 60Hz 4:4:4/8 bit
›Full Buffer System™: Manages TMDS re-clocking / signal re-generation, HDCP authentication to
source & display, EDID Control handshake, and Hot Plug Detection Voltage
›EDID Management: Internal library with 15 internal EDID handshakes including 4K with HDR in
addition to native EDID data copied from the Rx display/device
›IR Sensor: Wall-plate collects line-of-sight IR from remote(s) without external IR wiring
›RS-232: Bi-Directional control to/from Tx and Rx/Presentation Switch unit
›Lossless compressed digital audio: Support for Dolby®TrueHD, Dolby®Digital Plus, Dolby Atmos®,
and DTS-HD Master Audio™
›Control System Support: Fully controllable by all TCP/IP and RS-232 supported control systems via
open API: Compass Control®Pro, AMX®, Crestron®, KNX®, RTI®, Savant, URC®, Leviton®etc.

2
Included Accessories
›USB-A to USB Micro Data Cable
›Aluminum decora plate (qty 1) + Decora mounting screws with flat head (qty 6)
›Gang-box mounting screws (qty 6)
›3-pin phoenix terminal (qty 1)
›2-pin phoenix terminal (qty 1)
Quick Setup Guide
Rx UNITS SOLD SEPARATELY. Go to Presentation Solutions section for compatible Rx models.
CONNECT:
Begin with the KD-UPS52U unit, KD-X100MRx, KD-X4x1WUTx, USB camera (sold separately), all
input/output devices, and audio system powered off.
1. Connect HDMI, Display Port, and USB-C sources to the input ports of Tx unit
2. (Optional) Connect HDMI, Display Port, USB-C, VGA sources to presentation switcher (sold
separately). Port connectivity varies by presentation switcher model.
3. Connect HDMI displays / projectors to the HDMI output port of the RX unit / presentation switcher
4. Connect USB devices into desired USB A ports and USB host computer to desired USB B ports at
wall plate transmitter, HDBaseT Rx, or presentation switcher.
»a. Note: When using KD-UPS52U presentation switcher the connection location of the USB
devices and host is determined by the USB mode selection switch. Please refer to KD-UPS52U
Quick Setup Guide for more information.
5. Connect CAT5e/6 cabling to Tx and Rx unit / presentation switch. Use 568-B standard termination
on both ends. Avoid couplers and excess CAT cable length.
6. To send the selected audio source into audio systems, connect from the analog or digital audio de-
embed outputs of the Rx unit / presentation switcher
7. Connect control system or PC to LAN port of the KD-X4x1WUTx or the Rx for network connectivity
8. Connected monitors are controlled by CEC Manager
™
on the HDMI connection. Alternatively,
connect IR/RS-232 wiring from control system into pass-thru ports of KD-X4x1WUTx and IR/RS-232
ports of the Rx unit / Presentation Switch
9. Screw-in power supply to the KD-UPS52U or KD-X100MRx unit, and then connect power to outlets.
10. Power on HDMI sources and displays, audio systems, connected computers, USB devices and hosts

3
Integration Options
Integration with KD-X100MRx Receiver:
Amplifier
KD-X100MRx
KD-X4x1WUTx
Presentation Switcher KD-PS42 with KD-AMP220
WiFi Router
WiFi
TCP/IP
KEY DIGITAL
APP READY
USB
KD-CAMUSB
DSP/Mixer
DisplayPort
HDMI HDMI
USB-C
USB
USB
HDMI
Audio
Audio
Audio
KD-AMP220
Input Control Vol
Mic Mute Line BassL/R PCM
12
Treble
KD-AMP220
HDBT

4
Integration with KD-UPS52U:
USB
AppleTV Signage
(USB-C)
PC (DisplayPort)
KD-X100MRx
KD-X4x1WUTx
Presentation Switcher KD-PS42 with KD-AMP220
DSP/Mixer
Cable/Satellite
USB-C
DisplayPort
HDMI
HDMI
USB-C
USB
USB
HDMI
HDMI
HDMI
HDMI
WiFi Router
RS-232
RS-232
WiFi
Audio
KD-AMP220
Input Control Vol
Mic Mute Line BassL/R PCM
12
Treble
KD-AMP220
KEY DIGITAL
APP READY
TCP/IP
HDBT
HDBT
TCP/IP
KD-UPS52U
KD-CAMUSB
DisplayPort

5
CONFIGURE:
Configure and control your KD-X4x1WUTx via Key Digital Management Software™Pro (KDMS™Pro)
that can be downloaded here: KDMS™Pro Download
1. Connect to KD-X4x1WUTx from your PC using the USB micro port on the face
of the unit
2. Open KDMS
™
Pro software and perform a USB Device scan (fig. 1a-1b)
3. Choose the device from the Devices window (fig. 2a)
4. Set the desired Device Name in the KD-X4x1WUTx Information window (fig. 2b)
5. In the Network Settings section of the Properties window, enter the desired IP settings (fig. 2c)
»a. IP Address (default is 192.168.1.239)
»b. Subnet Mask (default is 255.255.255.0)
»c. Gateway (default is 192.168.1.1)
»d. Port (default is 23)
»i. Note: If using KD-App, please do not change the port number.
6. Save (fig. 2d)

6
7. If using KD-App or KDMS for control, set the desired Input/Output names by entering the Input/
Output Settings section of the properties window, and selecting the Change Input/Output Name
button (fig. 3a), selecting the desired input/output and entering the name (fig. 3b)
3a
3b
8. Set the EDID rotary to position “A” for 4K video with 2ch audio. Choose setting “4”
for 1080p video with 2ch audio. Refer to the Connections, Buttons, and LEDs
section for more options and information.
9. Set the Forced HPD to the ON position to fix a high HPD state to connected displays.
10. Additional settings may be adjusted in the KDMS software. Full access to all
settings/commands is achieved via terminal session using Tera Term or PuTTy
software.
11. Ensure that CEC is enabled on your displays/projectors. Depending on the
manufacturer, HDMI-CEC may be given a different name. View THIS article for a list
of CEC names and how to enable CEC on popular displays.
12. Your unit is now ready to control from the KDMS Control Panel, KD-App, or by professional
control system.

7
CONTROL:
Option 1: Control via Push Button
1. Display Control via CEC Manager
™
»a. Requires CEC supported display with CEC enabled
2. Input Select
»a. Advances through inputs 1, 2, 3 and 4 respectively
»b. Press and hold for 5 seconds to active Auto switching. Solid illumination of the button’s
backlighting indicates mode has been set
Option 2: Control via KD-App, Key Digital Management Software™
›KD-X4x1WUTx is controllable by:
»Key Digital’s user-friendly iOS App (downloadable in the App Store)
»Key Digital Management Software (downloadable here).
›Configuration Steps:
»Connect and configure KD- X4x1WUTx as described in this Quick Setup Guide.
»Download and open KD-App and/or KDMS
»Ensure the iOS device and/or PC computer are on the same network with KD-X4x1WUTx
»Perform a network scan in the KD-App/KDMS
»Select and control the selected KD-X4x1WUTx

8
Option 3: Control via professional control system
KD-X4x1WUTx allows control over TCP/IP interface for bi-directional communication. You may connect to
the LAN port of the KD-X4x1WUTx, KD-X100MRx, or KD-UPS52U to deliver network connectivity to the Key
Digital devices.
Default IP Address: 192.168.1.239, Port 23
›For TCP/IP control, the default static IP address is 192.168.1.239, with port 23
›RS-232 connection is used for control pass-thru to connected devices, not for unit control of the
KD-X4x1WUTx
›For the past 10 years, most Key Digital switches have supported a standard audio+video switching
command. KD-X4x1WUTx is also controllable by this command, so if you have previously integrated
Key Digital switches by third-party control systems you may have success using the same driver/
module.
»Switching – Video + Audio together (two commands supported)
»SPO01SIyy - yy = input number (01-02)
»SPOSIyy - yy = input number (01-02)

9
Connections, Buttons, and LEDs
Front Connections and LEDs
›HDMI Inputs: Using an HDMI cable, connect your HDMI sources.
»Supports up to UHD/4K @ 50/60 fps [4:4:4], 18Gbps
»See Supported Standard 4K Video Formats table below
»Supports HDR10 and Dolby Vision
»Compliant with HDCP 2.2 and previous
»Supports lossless compressed audio formats including
Dolby®TrueHD, Dolby®Digital Plus, DTS-HD Master Audio™,
and Dolby®Atmos
»Does not support CEC pass through from display connected to Rx unit
/ presentation switch
›Display Port Input: Using a Display Port cable, connect your source.
»Supports up to UHD/4K @ 50/60 fps [4:4:4], 18Gbps
»Supports HDR
»Supports Display Port version 1.3 and previous
»Compliant with HDCP 2.2 and previous
›USB-C Input: Using a USB-C cable, connect your source.
»Supports up to UHD/4K @ 50/60 fps [4:4:4], 18Gbps
»Supports HDR
»Cable must be USB-C 3.2 Gen 2 to support AV at the
needed bandwidth
»Utilizes Display Port over USB-C alt mode
»Supports Display Port version 1.3 and previous
»Compliant with HDCP 2.2 and previous
Supported standard 4K Video Formats:
Resolution Bandwidth
1 4K@24/25/30 [4:4:4] 8bit < 10.2Gbps
2 4K@24/25/30 [4:2:2] 8/10/12bit < 10.2Gbps
3 4K@50/60 [4:2:0] 8bit < 10.2Gbps
4 4K@24/25/30 [4:4:4] 10/12bit < 18Gbps
5 4K@50/60 [4:2:2] 8/10/12bit < 18Gbps
6 4K@50/60 [4:2:0] 10/12bit < 18Gbps
7 4K@50/60 [4:4:4] 8bit < 18Gbps

10
›Power, Link, Video LEDs: Indicate system connectivity status
»Power (red) illuminates solid with proper powering from local
connection / presentation switch
»Link (blue) illuminates solid from healthy HDBaseT connectivity with
Rx unit / presentation switch
»Video (green) illuminates solid with active HDMI signal
›USB Device Port
»Supports USB2.0 and previous
»Used for connecting USB endpoints (ie KD-CAMUSB, keyboard, mouse)
»Not used for connecting USB hosts (ie computer)
»Supports connectivity to USB hubs but may not exceed 15 endpoint
devices
»Provides 5V 500mA power
»Use USB toggle switch to determine if KD-X4x1WUTx will be used to connect a USB host (USB-B
port) or USB device (USB-A port). Both host and device are not simultaneously possible.
›USB Host Port
»Supports USB2.0 and previous
»Used for connecting USB host (ie computer)
»Not used for connecting USB hosts (ie KD-CAMUSB, keyboard, mouse)
»Use USB toggle switch to determine if KD-X4x1WUTx will be used to
connect a USB host (USB-B port) or USB device (USB-A port).
Both host and device are not simultaneously possible.
›LAN Port
»Default static IP address is 192.168.1.239, port 23
»Used to connect with Network Switch and peripheral devices needing
network connectivity and/or TCP/IP control
»Unit configuration, control, and firmware updates are most commonly
achieved with Key Digital Management Software™Pro, download at
KDMS™
Pro Download
›Reset Pin
»Push and hold for approximately 10 seconds to restore all settings to
default
»Front LEDs will turn off and restore during bootup process to indicate
the reset has completed.

11
›EDID Rotary
»EDID authentication is provided from the unit to the connected
inputs/sources.
»The EDID file (AKA “handshake”) is selected using the EDID rotary on
the unit and provides a list of compatible video and audio formats as
well as digital data, informing the source device what it should output.
»Most sources will comply with a new EDID file without a power-cycle,
but devices do behaves differently
»Adjustments may speed up sync time during source selection.
Position EDID Handshake Description EDID Rotary
0Copy EDID from HDMI Output 1
Note: Default position
is “A”
11080i, 2CH AUDIO
21080i, DOLBY/DTS 5.1
31080i, HD AUDIO
41080p, 2CH AUDIO
51080p, DOLBY/DTS 5.1
61080p, HD AUDIO
74Kx2K@60, 10.2G, HDR, 2CH AUDIO
84Kx2K@60, 10.2G, HDR, DOLBY/DTS 5.1
94Kx2K@60, 10.2G, HDR, HD AUDIO
A4Kx2K@60, 18G, HDR, 2CH AUDIO
B4Kx2K@60, 18G, HDR, DOLBY/DTS 5.1
C4Kx2K@60, 18G, HDR, HD AUDIO IMPORTANT: Please
apply light pressure
to the EDID rotary
when making your
selection.
D1280x720p@60 DVI (no audio)
E1920x1080p@60 DVI (no audio)
F4Kx2K@30, 10.2G, HDR, 2CH AUDIO
›Forced HPD Switch: Troubleshooting tool
»When ON, Hot Plug Detection voltage is fixed on to the connected
sources
»Standard HPD passthrough from display to source when set to OFF
position

12
›Firmware Load Switch:
»Used to select the firmware load location
»IMPORTANT: Consult with Key Digital tech support before updating
firmware
›Service USB Port:
»Used for configuration and control from PC via KDMS Pro, KDMS, or
third-party control terminal
»Used for firmware updates (consult with Key Digital tech support
before updating firmware)
»Supports USB driver for Windows 10, 7, XP, Mac, Linux
»Will register as “Prolific USB-to-Serial Comm Port in Device Manager
»Can be used as RS-232 control port. Baud rate is 57,600
›Display Control Buttons
»Sends CEC Power Toggle, Volume Up, Volume Down, and Mute Toggle
commands to Display connected to RX unit / Presentation Switcher
»Requires CEC supported display with CEC enabled
»Future updates may enable additional control options without
programming needed

13
›Input Select Button
»Advances through inputs 1, 2, 3 and 4 respectively
»LED display indicates selected source
»Press and hold for 5 seconds to active Auto switching. Solid
illumination of the button’s backlighting indicates mode has been set
»Note: Auto switching is disabled when a manual push button
switching is executed. A fixed auto switching mode may be set
via command string or through KDMS Pro software.
›IR Sensor
»Used to collect line-of-sight IR from remote control
»Receives signals from a 90° angle at up to 30ft away
»Signal is output on Rx unit / presentation switch’s IR Out port
»KD-X4x1WUTx is NOT controllable via IR
»IR and RS-232 supported simultaneously
Rear Connections
›HDBaseT Output: Connect a CAT5e/6 cable to the
Rx unit / presentation switch at the port labeled “HDBaseT In”
»4K/UHD (18G): Up to 100m / 328ft
»1080p: Up to 150m / 492ft
»Must connect with KD-UPS52U, KD-X100MRx, or KD-PS42
»Has been verified some third-party HDBaseT Rx / projectors.
Contact Key Digital Technical Support for more information.
»Power over HDBaseT from Rx
›IR In: Connect to the IR In terminals from a control system or an IR
connecting block.
»Signal is output on Rx unit / presentation switch’s IR Out port
simultaneously as any IR input collected by the IR Sensor
»KD-X4x1WUTx is not controllable via IR
›RS-232 Terminal: Connect with control system for pass-thru of
bi-directional RS-232 signals to/from controlled device.
»Supports baud rate up to 115,200bps
»KD-X4x1WUTx is not controllable via RS-232

14
TCP/IP Commands
KD-X4x1WUTx allows bi-directional control over TCP/IP connection made at KD-X4x1WUTx, KD-UPS52U,
or KD-X100MRx.
›Default static IP address is 192.168.1.239, port 23
Notes:
»Commands are not case-sensitive
»Commands require a carriage return following each string
»Spaces are shown for clarity; commands should NOT have any spaces
»After a new command is received, a prompt should be sent back
Help Command (H). Returns entire API in readable format:
-------------------------------------------------------------------------
-- Key Digital Systems HELP --
-------------------------------------------------------------------------
-- KD-X4x1WUTx F/W Version : 1.14 --
-- --
-- H : Help --
-- STA : Show Global System Status --
-- --
-- Video Output Setup Commands: xx = [01,A=All], yy = [01-04,U,D] --
-- ( yy : 01=HDMI1, 02=HDMI2, 03=USB C, 04=DisplayPort[DP] ) --
-- SPO SI yy : Set Output to Video Input yy --
-- SPO xx SI yy : Set Output to Video Input yy --
-- SPO xx ON/OFF : Set Output xx ON/OFF --
-- SPO xx VM E/D : Set Output xx Video Mute Enable/Disable --
-- SPO xx DBG ON/OFF : Set Output xx Debug Mode ON/OFF --
-- SPO xx LRM ON/OFF : Set HDBT Output xx Long Range Mode ON/OFF --
-- --
-- Display Control Commands: xx = [01,A=All] --
-- SPO xx TV ON/OFF : Set Display xx ON/OFF (Turn TV On/OFF) --
-- SPO xx AV U/D : Set Display xx Volume Up/Down --
-- SPO xx AM E/D/T : Set Display xx Audio Mute Enabled/Disabled/Toggle--
-- --
-- Input/Output/Device Naming Commands [xx=01-04] (c=Max. 16 Chars) --
-- SPI xx WN cccccccccccccccc : Write Input xx Name --
-- SPI xx RN : Read Input xx Name --
-- SPO xx WN cccccccccccccccc : Write Output xx Name --
-- SPO xx RN : Read Output xx Name --
-- SPC WN cccccccccccccccc : Write Device Name --
-- SPC RN : Read Device Name --
-- --
-- Network Setup, ( xxx=[000-255], zzzz=[0001~9999] ) --
-- SPCETIPA xxx.xxx.xxx.xxx : Set Host IP Address to xxx.xxx.xxx.xxx --
-- SPCETIPM xxx.xxx.xxx.xxx : Set Net Mask to xxx.xxx.xxx.xxx --
-- SPCETIPR xxx.xxx.xxx.xxx : Set Route IP Address to xxx.xxx.xxx.xxx --
-- SPCETIPP zzzz : Set TCP/IP Port to zzzz --
-- SPCETIPB : Apply New Network Cong --
-- --

15
-- System Control Setup Commands: --
-- SPC AS x : Set Auto Sense Mode x = [0=OFF,1=AUTO,2=FORCED ON] --
-- SPC FB E/D : Enable/Disable Front Panel Buttons --
-- SPC RSB z : Set USB RS232 Baud Rate to z bps, z=[0-5] --
-- [0:115200, 1:57600, 2:38400, 3:19200, 4:9600, 5:4800] --
-- SPC DF : Reset to Factory Defaults --
-- SPC DF00 : Reset to Factory Defaults without Network Reset --
-------------------------------------------------------------------------
Status Command (STA). Returns unit status and settings in readable format:
-------------------------------------------------------------------------
-- Key Digital Systems STATUS --
-------------------------------------------------------------------------
-- Model: KD-X4x1WUTx, Device Name: X4x1WUTx_0001 --
-- Main F/W Ver: 1.14, CEC Ver: 1.02 --
-- --
-- USB(RS232): Baud Rate=115200bps, Data=8bit, Parity=None, Stop=1bit --
-- Front Panel Button : Enabled --
-- --
-- Network Setting(Web Server/TCP Control) Status --
-- MAC Address = 26:5F:78:24:E7:45 --
-- Host IP Address = 192.168.001.239 --
-- Net Mask = 255.255.255.000 --
-- Router IP Address = 192.168.001.001 --
-- TCP Port = 0023 --
-- --
-- Video Input Status --
-- EDID = DEFAULT 10, FORCED HPD = OFF, AUTO SENSE = OFF --
-- 01 : HDMI1, LINK = OFF --
-- 02 : HDMI2, LINK = OFF --
-- 03 : USB C, LINK = OFF --
-- 04 : DP , LINK = OFF --
-- --
-- Video Output Status (D=Disable, E=Enable) --
-- HDBT Output : IN = 01, OUT = ON , V/MUTE = D, LINK = OFF, DBG = OFF --
-- LRM = OFF --
-- --
-- Display Output Status (CEC Control) --
-- HDBT Output : TV = ON , A/V MUTE = Disable, A/MUTE = Disable --
-------------------------------------------------------------------------

16
Specifications
Technical:
»Inputs: 2 HDMI, 1 Display Port, 1 USB-C, 1 IR Sensor, 1 Serial IR, 1 Bi-Directional RS-232
»Outputs: 1 HDBaseT RJ45, 1 Bi-Directional RS-232
»DDC Signal (Data): Input DDC Signal: 5 Volts p-p (TTL)
»HDMI Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
»Display Port Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
»USB-C Video/Audio Signal: Input Video Signal: 1.2 Volts p-p
»RJ45 Connector: Shielded Link Connector, HDBaseT
»IR Connectors: 1 IR Sensor, 1 2-pin phoenix terminal
»RS-232 Connector: 3-pin phoenix terminal
General:
»Regulation: CE, RoHS, WEEE, EAC
»Wallplate: Standard 3-gang Wallplate
»Enclosure: Faceplate - Silver Brushed Metal, Body - Texturized Silver Metal
»Product Dimensions: 5.5 x 4.1 x 1.43” (141 x 105 x 36.4mm)
»Product Weight: Weight: 1.3 lbs
»Packaging Dimensions: 11” x 7.9” x 2.1” (280 x 200 x 55 mm)
»Packaging Weight; Weight: 2.1 lbs
»Accessories:
»USB-A to USB Micro Data Cable
»Aluminum decora plate (qty 1) / Decora mounting screws with flat head (qty 6)
»Gang-box mounting screws, (qty 6)
»3-pin phoenix terminal (qty 1)
»2-pin phoenix terminal (qty 1)
Important Product Warnings:
1. Connect all cables before providing power to the unit.
2. Test for proper operation before securing unit behind walls or in hard to access spaces.
3. If installing the unit into wall or mounting bracket into sheet-rock, provide proper screw support
with bolts or sheet-rock anchors.

17
Safety Instructions:
Please be sure to follow these instructions for safe operation of your unit.
1. Read and follow all instructions.
2. Heed all warnings.
3. Do not use this device near water.
4. Clean only with dry cloth.
5. Install in accordance with the manufacturer’s instructions.
6. Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
7. Only use attachments/accessories specified by the manufacturer.
8. Refer all servicing to qualified service personnel. Servicing is required when the device has been
damaged in any way including:
»Damage to the power supply or power plug
»Exposure to rain or moisture
Power Supply Use:
You MUST use the Power Supply PROVIDED with your unit or you VOID the Key Digital®Warranty
and risk damage to your unit and associated equipment.
Contacting Key Digital
®
Technical Support
For technical questions about using Key Digital®products, please contact us at:
›Phone: [phone]
›E-mail: [email protected]
Repairs and Warranty Service
Should your product require warranty service or repair, please obtain a Key Digital®Return Material
Authorization (RMA) number by contacting us at:
›Phone: [phone]
›E-mail: [email protected]
Warranty Information
All Key Digital®products are built to high manufacturing standards and should provide years of trouble-free
operation. They are backed by a Key Digital Limited 3 Year Product Warranty Policy.

18
Key Digital®, led by digital video pioneer Mike Tsinberg,
develops and manufactures high quality, cutting-edge
technology solutions for virtually all applications where
high-end video and control are important. Key Digital®
is at the forefront of the video industry for Home
Theater Retailers, Custom Installers, System Integrators,
Broadcasters, Manufacturers, and Consumers.
Rev 1 – Sept 2021
Key Digital®:: 521 East 3rd Street :: Mount Vernon, NY 10553
Phone : [phone] Fax : [phone] Web : www.keydigital.com
© 2020 Key Digital, Inc. All rights reserved.
