1General Information

1-2 85131C/D/G
General Information
The Cable Sets
The Cable Sets
The Keysight 85131C/D/G semi-rigid cable sets are designed for use with Keysight network
analyzers that have male NMD-3.5 mm test ports.
85131C
The 85131C set contains a single cable. Use it when a DUT is connected, with the appropriate
adapter, directly to the test set test port. See Figure 1-1.
85131D
The 85131D set contains two cables. Each is shorter than the 85131C cable. Use the 85131D
cables when a DUT is connected between cable ends. See Figure 1-1.
Figure 1-1 Cable Configurations
85131G
The 85131G set contains a single cable – the -f- to -m- cable from the 85131D cable set. It is
shorter than the 85131C single cable. See Figure 1-1.
Connector Designators
NMD Connectors
NMD denotes a connector that has larger than standard coupling threads for greater stability.
NMD connectors are used on test cables, test ports, test port adapters, and test port cables.
Female NMD test port connectors are used on the test set end of adapters and cables, and
cannot be connected to standard male connectors.
Male NMD connectors are used on test sets (as test ports), and on the DUT end of adapters
and cables. Male connectors have both the larger threads (for use with test port adapters) and
standard threads (for direct coupling to a DUT).

85131C/D/G 1-3
General Information
Incoming Inspection
PSC Connectors
PSC denotes a precision slotless connector. Precision slotless connectors are metrology grade
connectors that have better electrical performance, better repeatability, and are more durable
than slotted connectors.
Clarifying the Terminology of a Connector Interface
In this document and in the prompts of the PNA calibration wizard, the gender of cable
connectors and adapters is referred to in terms of the center conductor. For example, a
connector or device designated as 1.85 mm –f– has a 1.85 mm female center conductor.
8510-series, 872x, and 875x ONLY: In contrast, during a measurement calibration, the
network analyzer softkey menus label a 1.85 mm calibration device with reference to the sex of
the analyzer’s test port connector—not the calibration device connector. For example, the label
SHORT(F) refers to the short that is to be connected to the female test port. This will be a male
short from the calibration kit.
A connector gage is referred to in terms of the connector that it measures. For instance, a male
connector gage has a female connector on the gage so that it can measure male devices.
Incoming Inspection
Verify that the shipment is complete by referring to Table 4-1 on page 4-4.
If the case or any device appears damaged, or if the shipment is incomplete, notify Keysight.
See “Contacting Keysight” on page 4-3. Keysight will arrange for repair or replacement of
incomplete or damaged shipments without waiting for a settlement from the transportation
company.
When you send the cable set to Keysight, include the following information:
• your company name and address
• the name of a technical contact person within your company, and the person’s complete
phone number
• the model number and serial number of the cable set
Table 1-1 Clarifying the Sex of Connectors: Examples
Terminology Meaning
Short –f– Female short (female center conductor)
Short (f) Male short (male center conductor) to be connected to female port

1-4 85131C/D/G
General Information
Preventive Maintenance
• the part number and serial number of the device
• the type of service required
•adetailed description of the problem
Preventive Maintenance
The best techniques for maintaining the integrity of the cables include:
• routine visual inspection
• cleaning
• proper gaging
• proper connection techniques
• proper storage
All of the above are described in Chapter 3. Failure to detect and remove dirt or metallic
particles on a mating plane surface can degrade repeatability and accuracy and can damage
any connector mated to it. Improper connections, resulting from center conductor values being
out of limits (see Table 2-3 on page 2-4), or from bad connections, can also damage cable
connectors.
Replaceable Parts
See Table 4-1 on page 4-4 for a complete list of cable set contents and their associated part
numbers (you can order a single cable rather than the entire cable set), and for recommended
items not included with the cable set. Refer to “Contacting Keysight” on page 4-3 for
information about communicating with Keysight.
