Keysight Technologies E5868A Assembly instructions

E5868A and E5869A Additional Removable
Windows 10 SSDs for 1686x-Series Logic
Analyzers
INSTALLATION AND SETUP GUIDE

Notices
© Keysight Technologies 2023
No part of this manual may be reproduced
in any form or by any means (including
electronic storage and retrieval or transla-
tion into a foreign language) without prior
agreement and written consent from
Keysight Technologies as governed by
United States and international copyright
laws.
Manual Part Number
E5869-97000
Edition
First Edition, September 2023
Printed in Malaysia
Published By:
Keysight Technologies
1900 Garden of the Gods Road
Colorado Springs, CO 80907 USA
Warranty
THE MATERIAL CONTAINED IN THIS
DOCUMENT IS PROVIDED "AS IS," AND IS
SUBJECT TO BEING CHANGED, WITHOUT
NOTICE, IN FUTURE EDITIONS. FURTHER,
TO THE MAXIMUM EXTENT PERMITTED BY
APPLICABLE LAW, KEYSIGHT DISCLAIMS
ALL WARRANTIES, EITHER EXPRESS OR
IMPLIED WITH REGARD TO THIS MANUAL
AND ANY INFORMATION CONTAINED
HEREIN, INCLUDING BUT NOT LIMITED TO
THE IMPLIED WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE. KEYSIGHT SHALL
NOT BE LIABLE FOR ERRORS OR FOR
INCIDENTAL OR CONSEQUENTIAL
DAMAGES IN CONNECTION WITH THE
FURNISHING, USE, OR PERFORMANCE OF
THIS DOCUMENT OR ANY INFORMATION
CONTAINED HEREIN. SHOULD KEYSIGHT
AND THE USER HAVE A SEPARATE
WRITTEN AGREEMENT WITH WARRANTY
TERMS COVERING THE MATERIAL IN THIS
DOCUMENT THAT CONFLICT WITH THESE
TERMS, THE WARRANTY TERMS IN THE
SEPARATE AGREEMENT WILL CONTROL.
Technology Licenses
The hardware and/or software described in
this document are furnished under a
license and may be used or copied only in
accordance with the terms of such license.
U.S. Government Rights
The Software is "commercial computer
software," as defined by Federal Acquisition
Regulation ("FAR") 2.101. Pursuant to FAR
12.212 and 27.405-3 and Department of
Defense FAR Supplement ("DFARS")
227.7202, the U.S. government acquires
commercial computer software under the
same terms by which the software is cus-
tomarily provided to the public. Accord-
ingly, Keysight provides the Software to
U.S. government customers under its stan-
dard commercial license, which is embod-
ied in its End User License Agreement
(EULA), a copy of which can be found at
http://www.key-
sight.com/find/sweula. The license set
forth in the EULA represents the exclusive
authority by which the U.S. government
may use, modify, distribute, or disclose the
Software. The EULA and the license set
forth therein, does not require or permit,
among other things, that Keysight: (1) Fur-
nish technical information related to com-
mercial computer software or commercial
computer software documentation that is
not customarily provided to the public; or
(2) Relinquish to, or otherwise provide, the
government rights in excess of these rights
customarily provided to the public to use,
modify, reproduce, release, perform, dis-
play, or disclose commercial computer
software or commercial computer software
documentation. No additional government
requirements beyond those set forth in the
EULA shall apply, except to the extent that
those terms, rights, or licenses are explic-
itly required from all providers of commer-
cial computer software pursuant to the FAR
and the DFARS and are set forth specifically
in writing elsewhere in the EULA. Keysight
shall be under no obligation to update,
revise or otherwise modify the Software.
With respect to any technical data as
defined by FAR 2.101, pursuant to FAR
12.211 and 27.404.2 and DFARS 227.7102,
the U.S. government acquires no greater
than Limited Rights as defined in FAR
27.401 or DFAR 227.7103-5 (c), as appli-
cable in any technical data. 52.227-14
(June 1987) or DFAR 252.227-7015 (b)(2)
(November 1995), as applicable in any
technical data.
Safety Notices
CAUTION
A CAUTION notice denotes a hazard.
It calls attention to an operating pro-
cedure, practice, or the like that, if
not correctly performed or adhered
to, could result in damage to the
product or loss of important data. Do
not proceed beyond a CAUTION
notice until the indicated conditions
are fully understood and met.
WARNING
A WARNING notice denotes a hazard.
It calls attention to an operating pro-
cedure, practice, or the like that, if
not correctly performed or adhered
to, could result in personal injury or
death. Do not proceed beyond a
WARNING notice until the indicated
conditions are fully understood and
met.
2 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 3
Safety Summary
The following general safety precautions must be observed during all phases of operation
of this product. Failure to comply with these precautions or with specific warnings or
operating instructions in the product manuals violates safety standards of design,
manufacture, and intended use of the instrument. Keysight Technologies assumes no
liability for the customer's failure to comply with these requirements.
General Do not use this product in any manner not specified by the manufacturer. The protective
features of this product may be impaired if it is used in a manner not specified in the
operation instructions.
Before Applying Power Verify that all safety precautions are taken. Make all connections to the product before
applying power.
Do Not Operate in an
Explosive Atmosphere
Do not operate the product in the presence of flammable gases or fumes.
Cleaning Clean the outside of the product with a soft, lint-free cloth. Do not use detergent or
chemical solvents or too much liquid to avoid damaging sensitive electronic components.
Do not attempt to clean internally.
In Case of Damage Products that appear damaged or defective should be made inoperative and secured
against unintended operation. Return the product to a Keysight Sales and Service Office.

4 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 5
Contents
1Overview
E5868A and E5869A Additional Removable SSDs 8
When to Use which Removable SSD 8
Handling the E5868A and E5869A SSDs 9
2 Installing the Additional Removable SSD
Step 1. Back up Data for Transfer to the New SSD 11
Step 2. Power Down the 1686x Logic Analyzer 11
Step 3. Remove the Currently Installed SSD 12
Step 4. Install the New SSD 13
Step 5. Power on the 1686x Logic Analyzer 14
Step 6. Perform the first-time Setup Steps 14
Step 7. Restore Data 14
Step 8. Install any Additional Application Software 14
Resolve any Issues with the Installation 14

6 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide
Contents

E5868A and E5869A Additional Removable SSDs for
16860-Series Logic Analyzers
Installation Guide
1Overview
E5868A and E5869A Additional Removable SSDs / 8
Handling the E5868A and E5869A SSDs / 9

8 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide
1 Overview
E5868A and E5869A Additional Removable SSDs
The 1686x-series logic analyzers have a removable Solid State Drive (SSD)
imaged with Windows 10 operating system, Logic and Protocol Analyzer
application software, and any optional application software ordered with
the logic analyzer.
You can remove and replace this SSD with the additional removable SSD
without disassembling the logic analyzer. This guide describes how to
remove and replace the SSD.
When to Use which Removable SSD
The following two models of additional removable SSDs are available for
1686x-series logic analyzers.
E5868A E5869A
E5868A has the drive image required for 1686x-series
logic analyzers with the older M900 motherboard.
E5869A has the drive image required for 1686x-series
logic analyzers with the newer M910 motherboard.
This SSD has a lighter gray color panel with black text. This SSD has a darker gray color panel with white text.
CAUTION
To ensure that you are using the correct model of removable
SSD for your 1686x logic analyzer, match the panel color of
the additional SSD with the panel color of the SSD you are
replacing.

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 9
Overview 1
Handling the E5868A and E5869A SSDs
For the integrity of the data on your hard disk drive, Keysight
recommends that you take the precautions described in this topic
while handling and storing the hard disk drives:
• Store unused SSD in the shipping container.
• Protect the SSD from electrostatic discharge (ESD).
• Protect the SSD from physical shock.
• Protect the SSD Against Contamination of the Edge Connector
CAUTION
Electrostatic discharge can damage electronic
components. Use grounded wrist straps and mats
when handling electronic components.
CAUTION
While operating, do not expose the SSD to more
than 5 to 500 Hz at 0.3 g rms.
CAUTION
The SSD edge connector is sensitive to ESD and
mechanical or material contamination. Take
precautions to protect the edge connector from
contamination during handling and storage.

E5868A and E5869A Additional Removable Windows 10
SSDs for 16860-Series Logic Analyzers
Installation Guide
2Installing the Additional
Removable SSD
Step 1. Back up Data for Transfer to the New SSD / 11
Step 2. Power Down the 1686x Logic Analyzer / 11
Step 3. Remove the Currently Installed SSD / 12
Step 4. Install the New SSD / 13
Step 5. Power on the 1686x Logic Analyzer / 14
Step 6. Perform the first-time Setup Steps / 14
Step 7. Restore Data / 14
Step 8. Install any Additional Application Software / 14
CAUTION
Electrostatic discharge can damage electronic components. Use
grounded wrist straps and mats when handling electronic components.

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 11
Installing the Additional Removable SSD 2
Step 1. Back up Data for Transfer to the New SSD
Before removing the existing SSD from your logic analyzer, ensure that you
back up the data such as license files which can later be transferred to the
new SSD.
1ClosetheKeysight Logic and Protocol Analyzer application software.
2 Back up data using LAN, USB flash drive, writable CDs, etc.
3 Back up license files. License files have the extension “.lic”.
Keysight recommends floating licenses for logic analyzers with
removable disks such as the 1686x-series logic analyzers.
Server License Files
If the license server is on the logic analyzer, back up the server license
files which are located in the “LicenseFiles” folder under the license
server’s installation directory. The default location is: C:\Program Files\
Keysight Technologies\LicenseServer\LicenseFiles\
Node-locked License Files
You can also use node-locked licenses. However, because the logic
analyzer host ID changes with the SSD, you must have separate
licenses on each SSD. Node-locked license files are located in the
“License” folder under the Keysight Logic and Protocol Analyzer
application’s installation directory. The default location is: C:\Program
Files\Keysight Technologies\Logic Analyzer\License\
Step 2. Power Down the 1686x Logic Analyzer
WARNING
Hazardous voltages exist on the power supply. To avoid electrical shock,
disconnect the power from the instrument before performing the
following procedures. After disconnecting the power, wait at least six
minutes for the capacitors on the power supply board to discharge
before servicing the instrument.
CAUTION
Damage can occur to electronic components if you remove or replace
assemblies when the instrument is on or when the power cable is
connected. Never attempt to remove or install any assembly with the
instrument on or with the power cable connected.

12 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide
2 Installing the Additional Removable SSD
1 Power down the logic analyzer system using one of the methods
explained below.
•Using the Windows Shutdown - On the logic analyzer desktop, click
Start > Shut Down or if you are running remote desktop, click Start >
Settings > Windows Security > Shut Down.
•Using a Short Press of the Power Button - Press the power button
on the logic analyzer for a short time (less than 2 seconds).
•Using a Long Press of the Power Button - Press the power button for
more than 4 seconds. This powers down the system abruptly. Use
this method only when other methods have not responded because
Any data that has not been written to the disk will be lost. Also, if the
system does not boot, the hard disk drive will need to be re-imaged.
2 Remove the power cord.
Step 3. Remove the Currently Installed SSD
1 Loosen both thumb screws that hold the hard disk drive in place.
Thumb Screws
Removable SSD

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 13
Installing the Additional Removable SSD 2
2 Pull the drive tray out to remove the disk drive.
Step 4. Install the New SSD
1 Slide the new SSD into the drive bay.
2 Gently press the drive tray all the way in to seat the disk drive
connectors.
Removable SSD pulled out

14 E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide
2 Installing the Additional Removable SSD
3 Tighten both thumb screws to hold the hard disk drive in place.
Step 5. Power on the 1686x Logic Analyzer
Turn on the logic analyzer.
Step 6. Perform the first-time Setup Steps
If you are using the replacement SSD as an additional bootable drive, the
replacement disk is pre-configured with the Windows 10 operating
system, frame drivers, and Logic and Protocol Analyzer software (just like
the original 1686x SSD as shipped from the factory).
The next step is to perform the first-time setup procedures described in
the 16860-Series Logic Analyzers Installation Guide shipped with the
16860 logic analyzer.
Step 7. Restore Data
Restore the data and license files you backed up in “Step 1. Back up Data for
Transfer to the New SSD" on page 11.
Step 8. Install any Additional Application Software
Resolve any Issues with the Installation
If you have any questions, go to www.keysight.com/find/contactus for
help.

E5868A and E5869A Additional Removable SSDs for 16860-Series Logic Analyzers Installation Guide 15

This information is subject to
change without notice.
© Keysight Technologies 2023
First Edition, September 2023
*E5869-97000*
www.keysight.com
