Keysight Technologies N99xxA Series User manual

THANK YOU
N99xxA/B FieldFox Handheld Analyzer
Quick Start Guide
Congratulations, with this instrument you will achieve fast, accurate results with condence.
IMPORTANT!
FULLY charge the FieldFox battery before using the FieldFox for the rst time (i.e, The battery will
be fully charged in about 4 hours).
When setting FieldFox on a surface, it is recommended to operate it with the kickstand open. The
cooling is less effective when FieldFox is placed lying down at on the instrument’s back.
keysight.com
Find a Manual • Register Your Instrument
Browse Application Notes
Request Repair or Calibration
View Discussion Forums • Updates
-Learn more or for questions: Download the
N9927-90001 or N9938-90003 User’s Guide.
-See also, www.keysight.com/nd/eldfox.
Keysight.com
2. Insert the supplied AC/DC adapter (15-19 VDC) into the power connector and
into an electrical outlet (AC/DC adapter is not shown).
- N9912A and N9923A models: The power connector is located on the right side,
under the middle hinged door.
- All other models: The power connector is located on the LEFT side, under the
bottom hinged cover.
Step 1
1. Install the battery pack into the FieldFox
battery compartment. The battery door is
located on the lower-right side of the FieldFox
(i.e., Press and slide the door down to open).
For more, see Step 3.
Step 2
Battery door
Kickstand
LED
Power button
Power connector
Audio jack
DC VoltageSource
Step 3
3. Extend the
kickstand and
press the power
button.

This information is subject to change
without notice.
© Keysight Technologies 2014-2019
Edition 1, August 2019
www.keysight.com
