Site Master™
S331D/S332D
Cable and Antenna Analyzer
User’s Guide
MS2712
MS2712
MS2712
SiteMaster SpectrumMaster CellMaster
MS2711DSpectrumMaster
S331DSiteMaster SiteMaster SpectrumMaster MT8212A CellMaster CellMaster
Color display option shown

WARRANTY
The Anritsu product(s) listed on the title page is (are) warranted against defects in
materials and workmanship for one year from the date of shipment.
Anritsu's obligation covers repairing or replacing products which prove to be defec-
tive during the warranty period. Buyers shall prepay transportation charges for
equipment returned to Anritsu for warranty repairs. Obligation is limited to the origi-
nal purchaser. Anritsu is not liable for consequential damages.
LIMITATION OF WARRANTY
The foregoing warranty does not apply to Anritsu connectors that have failed due to
normal wear. Also, the warranty does not apply to defects resulting from improper or
inadequate maintenance by the Buyer, unauthorized modification or misuse, or op-
eration outside the environmental specifications of the product. No other warranty is
expressed or implied, and the remedies provided herein are the Buyer's sole and
exclusive remedies.
TRADEMARK ACKNOWLEDGMENTS
MS-DOS, Windows, Windows 95, Windows NT, Windows 98, Windows 2000, Win-
dows ME and Windows XP are registered trademarks of the Microsoft Corporation.
Anritsu, FlexCal, InstaCal and Site Master are trademarks of Anritsu Company.
NOTICE
Anritsu Company has prepared this manual for use by Anritsu Company personnel
and customers as a guide for the proper installation, operation and maintenance of
Anritsu Company equipment and computer programs. The drawings, specifications,
and information contained herein are the property of Anritsu Company, and any un-
authorized use or disclosure of these drawings, specifications, and information is
prohibited; they shall not be reproduced, copied, or used in whole or in part as the
basis for manufacture or sale of the equipment or software programs without the
prior written consent of Anritsu Company.
UPDATES
Updates to this manual, if any, may be downloaded from the Anritsu internet site at:
http://www.us.anritsu.com.
October 2004 10580-00079
Copyright ã2003-2004 Anritsu Co. Revision: C

Table of Contents
Chapter 1 - General Information
Introduction ..................................1-1
Description ...................................1-1
Standard Accessories .............................1-1
Printers .....................................1-2
Optional Accessories..............................1-3
Performance Specifications ..........................1-4
Preventive Maintenance ............................1-9
Calibration ...................................1-9
InstaCal Module ..............................1-10
Annual Verification..............................1-10
ESD Precautions ...............................1-10
Mode References ...............................1-10
Chapter 2 - Functions and Operations
Introduction ..................................2-1
Test Connector Panel .............................2-1
Display Overview ...............................2-3
Front Panel Overview .............................2-4
Function Hard Keys ..............................2-5
Keypad Hard Keys ...............................2-6
Soft Keys....................................2-8
T1 Tester Mode Menus (Option 50) .....................2-33
E1 Tester Mode Menus (Option 50) .....................2-36
Transmission Measurement Menus......................2-38
Power Meter Menus (Option 29) .......................2-45
Symbols....................................2-46
Self Test ...................................2-46
Error Messages ................................2-47
Battery Information..............................2-52
Charging a New Battery ..........................2-52
Determining Remaining Battery Life....................2-53
Important Battery Information .......................2-55
Chapter 3 - Getting Started
Introduction ..................................3-1
Power On Procedure ..............................3-1
Cable and Antenna Analyzer Mode ......................3-2
Spectrum Analyzer Mode ..........................3-10
All Modes...................................3-14
Save and Recall a Setup ..........................3-14
Save and Recall a Display .........................3-14
Changing the Units .............................3-15
Changing the Language...........................3-15
i

Adjusting Markers .............................3-15
Adjusting Limits ..............................3-16
Adjusting the Display Contrast .......................3-17
Adjusting the Backlight Intensity......................3-17
Printing ....................................3-18
Using the Soft Carrying Case.........................3-19
Chapter 4 - Cable and Antenna Analyzer Measurements
Introduction ..................................4-1
Line Sweep Fundamentals ...........................4-1
CW Mode ..................................4-2
Information Required for a Line Sweep ...................4-3
Typical Line Sweep Test Procedures ....................4-3
Chapter 5 - Spectrum Analyzer Measurements
Introduction ..................................5-1
Measurement Fundamentals ..........................5-1
Preamplifier ..................................5-3
Preamplifier Operation............................5-3
Preamplifier Measurement Example.....................5-4
Dynamic Attenuation Control .........................5-6
Frequency Converter Interface (Option 6)...................5-7
Introduction .................................5-7
Bias Tee (Option 10)..............................5-7
Introduction .................................5-7
Selecting the Signal Standard and Channel ..................5-8
Field Strength Measurements ........................5-9
Occupied Bandwidth .............................5-10
Channel Power Measurement........................5-12
Adjacent Channel Power Ratio .......................5-14
Interference Analysis .............................5-16
AM/FM Demodulation ............................5-17
Demodulation Procedure ..........................5-17
Carrier to Interference Ratio (C/I) ......................5-19
Procedure ..................................5-19
Chapter 6 - Power Measurement
Introduction ..................................6-1
Power Measurement ..............................6-1
Chapter 7 - T1 Measurements
Introduction ..................................7-1
T1 Fundamentals................................7-1
Network Equipment ..............................7-2
Testing T1 Circuits...............................7-3
In Service Testing ..............................7-3
Out-Of-Service Testing ...........................7-6
ii

Chapter 8 - E1 Measurements
Introduction ..................................8-1
E1 Fundamentals ...............................8-1
Network Equipment ..............................8-2
Testing E1 Circuits...............................8-3
In Service Testing ..............................8-3
Out-Of-Service Testing ...........................8-8
Chapter 9 - Transmission Measurement
Introduction .................................9-1
Measuring Active Devices ..........................9-1
Calibration ..................................9-1
Transmission Measurement Procedure ...................9-3
Chapter 10 - Handheld Software Tools
Introduction ..................................10-1
Features ...................................10-1
System Requirements.............................10-1
Installation ..................................10-2
Using Handheld Software Tools .......................10-3
Downloading Traces ............................10-3
Plot Capture to the PC ...........................10-4
Plot Upload to the Instrument .......................10-4
Plot Properties ...............................10-4
Appendix A - Reference Data
Coaxial Cable Technical Data.........................A-1
Appendix B - Windowing
Introduction .................................B-1
Examples ..................................B-1
Appendix C - Signal Standards
Introduction .................................C-1
Index
iii/iv

Chapter 1
General Information
Introduction
This chapter provides a description, performance specifications, optional accessories, pre-
ventive maintenance, and calibration requirements for the Site Master™ models S331D and
S332D. Throughout this manual, the term Site Master will refer to the S331D and S332D.
Model Frequency Range
S331D
S332D
Cable and Antenna Analyzer Mode: 25 to 4000 MHz
Cable and Antenna Analyzer Mode: 25 to 4000 MHz
Spectrum Analyzer Mode: 100 kHz to 3000 MHz
Description
The Site Master model S331D is a hand held cable and antenna analyzer. The Site Master
model S332D is a hand held cable, antenna, and spectrum analyzer. Both models include a
keypad to enter data and a liquid crystal display (LCD) to provide graphic indications of
various measurements.
The Site Master is capable of up to 1.5 hours of continuous operation from a fully charged
field-replaceable battery and can be operated from a 12.5 Vdc source. Built-in energy con-
servation features can be used to extend battery life.
The Site Master is designed for measuring SWR, return loss, cable insertion loss and locat-
ing faulty RF components in antenna systems. The Site Master model S332D includes spec-
trum analysis capabilities including carrier-to-interference analysis.
The displayed trace can be scaled or enhanced with frequency markers or limit lines. A
menu option provides for an audible “beep” when the limit value is exceeded. To permit
use in low-light environments, the LCD contrast and backlight intensity can be adjusted.
Standard Accessories
The Handheld Software Tools PC-based software program provides a database record for
storing measurement data. Software Tools can also convert the Site Master display to a
Microsoft Windowsä95/98/NT4/2000/ME/XP workstation graphic. Measurements stored
in the Site Master internal memory can be downloaded to the PC using the included
null-modem serial cable. Once stored, the graphic trace can be displayed, scaled, or en-
hanced with markers and limit lines. Historical graphs can be overlaid with current data,
and underlying data can be extracted and used in spreadsheets or for other analytical tasks.
The Handheld Software Tools program can display measurements made with the Site Mas-
ter (SWR, return loss, cable loss, distance-to-fault, field strength, occupied bandwidth,
channel power, adjacent channel power and interference analysis) as well as providing
other functions, such as converting display modes and Smith charts. Refer to Chapter 9,
Handheld Software Tools, for more information.
1-1

The following items are supplied with the basic hardware:
·Soft Carrying Case
·Rechargeable Battery
·AC-DC Adapter
·Automotive Cigarette Lighter 12 Volt DC Adapter
·Handheld Software Tools CDROM
·Serial Interface Cable (null modem type)
·One year Warranty (includes battery, firmware, and software)
·User's Guide
Printers
·2000-1214 HP DeskJet Printer, Model 450 w/Interface Cable, Black Print
Cartridge, and U.S. Power Cable
·2000-1215 Color Print Cartridge for HP450 DeskJet
·2000-1216 Black Print Cartridge for HP450 DeskJet
·2000-1217 Rechargeable Battery Pack for HP450 DeskJet
·2000-1218 Power Cable (U.K.) for DeskJet Printer
·2000-663 Power Cable (Europe) for DeskJet Printer
·2000-664 Power Cable (Australia) for DeskJet Printer
·2000-667 Power Cable (S. Africa) for DeskJet Printer
·2000-753 Serial-to-Parallel Converter Cable, DB9 (f) to Centronics (m)
·1091-310 Cable Adapter, Centronics (f) to DB25 (f)
1-2
Chapter 1 General Information

Optional Accessories
1-3
Chapter 1 General Information
Part Number Description
10580-00100 S33xD Programming Manual (available on disk or at www.us.anritsu.com)
10580-00101 S331D Maintenance Manual
10580-00102 S332D Maintenance Manual
760-229 Transit Case
633-27 Rechargeable Battery, NiMH
2000-1029 Battery Charger with universal power supply, NiMH only
48258 Soft Carrying Case
40-163 AC-DC Adapter Power Supply
806-62 Automotive Cigarette Lighter 12 Volt DC Adapter
800-441 Serial Interface Cable Assembly
551-1691 USB Adapter Cable
2300-347 Handheld Software Tools CD
FCN4760 4.7 GHz to 6 GHz Frequency converter for S332D only
ICN50 InstaCal™ Calibration Module, 50W, 2 MHz to 4 GHz, N (m)
OSLN50LF Anritsu Precision N (m) Open/Short/Load, 42 dB
OSLNF50LF Anritsu Precision N (f) Open/Short/Load, 42 dB
22N50 Anritsu Precision N (m) Short/Open
22NF50 Anritsu Precision N (f) Short/Open
SM/PL Anritsu Precision N (m) Load, 42 dB
SM/PLNF Anritsu Precision N (f) Load, 42 dB
2000-767 7/16 (m) Precision Open/Short/Load
2000-768 7/16 (f) Precision Open/Short/Load
34NN50A Adapter, Precision N (m) to N (m) 18 GHz
34NFNF50 Adapter, Precision N (f) to N (f) 18 GHz
510-90 Adapter, 7/16 (f) to N (m) 7.5 GHz
510-91 Adapter, 7/16 (f) to N (f) 7.5 GHz
510-92 Adapter, 7/16 (m) to N (m) 7.5 GHz
510-93 Adapter, 7/16 (m) to N (f) 7.5 GHz
510-96 Adapter, 7/16 DIN (m) to 7/16 DIN (m) 7.5 GHz
510-97 Adapter, 7/16 DIN (f) to 7/16 DIN (f) 7.5 GHz
1091-27 Adapter, Type-N male to SMA(f) adapter
1091-26 Adapter, Type-N male to SMA(n) adapter
15NNF50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to N (f) 6 GHz
15NNF50-3.0C Armored Test Port Extension Cable, 3.0 meter, N (m) to N (f) 6 GHz
15NNF50-5.0C Armored Test Port Extension Cable, 5.0 meter, N (m) to N (f) 6 GHz
15NN50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to N (m) 6 GHz
15NN50-3.0C Armored Test Port Extension Cable, 3.0 meter, N (m) to N (m) 6 GHz
15NN50-5.0C Armored Test Port Extension Cable, 5.0 meter, N (m) to N (m) 6 GHz
15NDF50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to 7/16 DIN (f) 6 GHz
15ND50-1.5C Armored Test Port Extension Cable, 1.5 meter, N (m) to 7/16 DIN (m) 6 GHz
2000-1030 Portable Antenna SMA (m), 50W, 1.71 to 1.88 GHz
2000-1031 Portable Antenna SMA (m), 50W, 1.85 to 1.99 GHz
2000-1032 Portable Antenna SMA (m), 50W, 2.4 to 2.5 GHz
2000-1035 Portable Antenna SMA (m), 50W, 896 to 941 MHz
2000-1200 Portable Antenna SMA (m), 50W, 806 to 866 MHz
2000-1361 Portable Antenna SMA(m), 50W, 5725-5825 MHz
806-16 Bantam Plug to Bantam Plug
806-116 Bantam Plug to BNC
806-117 Bantam “Y” Plug to RJ48
1030-86 Band Pass Filter, 806-869 MHz, 1.7 dB loss, N(m) to SMA(f), 50W
1030-87 Band Pass Filter, 902-960 MHz, 1.7 dB loss, N(m) to SMA(f), 50W
1030-88 Band Pass Filter, 1.85-1.99 GHz, 1.8 dB loss, N(m) to SMA(f), 50W
1030-89 Band Pass Filter, 2.4-2.5 GHz, 1.4 dB loss, N(m) to SMA(f), 50W

Performance Specifications
Performance specifications are provided in Table 1-1. All specifications apply when cali-
brated at ambient temperature after a five minute warm up. Typical values are given for ref-
erence, and are not guaranteed.
1-4
Chapter 1 General Information
Cable and Antenna Analyzer
Frequency Range: 25 MHz to 4000 MHz
Frequency Accuracy: £±75 ppm @ +25°C
Frequency Resolution: 100 kHz
Output Power: < 0 dBm (–10 dBm nominal)
Immunity to Interfering Signals: on-channel +17 dBm
on-frequency –5 dBm
Measurement speed: £3.5 msec / data point (CW ON)
Number of data points: 130 or 259 or 517
Return Loss:
Range: 0.00 to 60.00 dB
Resolution: 0.01 dB
VSWR:
Range: 1.00 to 65.00
Resolution: 0.01
Cable Loss:
Range: 0.00 to 30.00 dB
Resolution: 0.01 dB
Measurement Accuracy: > 42 dB corrected directivity after calibration
Distance-To-Fault
Vertical Range:
Return Loss: 0.00 to 60.00 dB
VSWR: 1.00 to 65.00
Horizontal Range: 0 to (# of data pts –1) x Resolution to a maximum of
1197m (3929 ft)
# of data pts = 130 or 259 or 517
Horizontal Resolution (rectangular windowing):
Resolution (meters) = (1.5 x 108) x (Vp)/DF
Where Vp is the relative propagation velocity of the cable and DF is the stop frequency minus the
start frequency (in Hz).
Table 1-1. Performance Specifications (1 of 5)

1-5
Chapter 1 General Information
Spectrum Analyzer (S332D only)
Frequency Range: 100 kHz to 3000 MHz (tunable to 9 kHz)
Frequency Reference (internal timebase):
Aging: ± 1 ppm/yr
Accuracy: ± 2 ppm
Frequency Span: 10 Hz to 2.99 GHz in 1, 2, 5 step selections in auto mode,
plus zero span
Sweep Time: £1.1 seconds, full span;
£50 mseconds to 20 seconds, zero span
Resolution Bandwidth (–3 dB): 100 Hz to 1 MHz in 1-3 sequence ± 5% Accuracy
Video Bandwidth (–3 dB): 3 Hz to 1 MHz in 1-3 sequence ± 5% Accuracy
SSB Phase Noise (1 GHz)
@ 30 kHz Offset: £–75 dBc/Hz
Spurious Responses: £–45 dBc
Spurious Residual Responses: £–90 dBm >10 MHz, £–80 dBm £10 MHz
(10 kHz RBW, pre-amp on)
Amplitude
Total Level Accuracy: ± 1 dB typical (±1.5 dBm), ³10MHz to 3 GHz
± 2 dB, typical <10 MHz
for input signal levels ³–60 dBm
(excludes input VSWR mismatch)
Measurement Range: +20 dBm to –135 dBm
Input Attenuator Range: 0 to 51 dB, selected manually or automatically coupled to
the reference level. Resolution in 1 dB steps.
Displayed Average Noise Level: £–135 dBm typical, ³10 MHz (preamp on)
£–115 dBm typical, <10 MHz (preamp on) for input terminated,
0 dB attenuation, RMS detection, 100 Hz RBW
Dynamic Range: >65 dB
Display Range: 1 to 15 dB/division, in 1 dB steps, 10 divisions displayed
Scale Units: dBm, dBV, dBmV, dBmV, V, W
RF Input VSWR: 1.5:1 typical (10 MHz to 2.4 GHz with ³20 dB attenuation),
10 MHz to 2.4 GHz)
Table 1-1. Performance Specifications (2 of 5)

1-6
Chapter 1 General Information
T1 Analyzer (Option 50, S331D only)
Line Coding: AMI, B8ZS
Framing Modes: D4 (Superframe), ESF (Extended Superframe)
Connection Configurations: Terminate (100W)
Bridge (³1000W)
Monitor (Connect via 20 dB pad in DSX)
Receiver Sensitivity: 0 to –36 dBdsx
Transmit Level: 0 dB, –7.5 dB, and –15 dB
Clock Sources: External
Internal: 1.544 MHz ± 30 ppm
Pulse Shapes: Conform to ANSI T1.403
Pattern Generation & Detection: PRBS: 2-9, 2-11, 2-15, 2-20, 2-23 Inverted and non-inverted,
QRSS, 1-in-8 (1-in-7), 2-in-8, 3-in-24, All ones, All zeros,
T1-Daly, User defined (£32 bits)
Circuit Status Reports: Carrier present, Frame ID and Sync., Pattern ID and Sync.
Alarm Detection: AIS (Blue Alarm), RAI (Yellow Alarm)
Error Detection: Frame Bits, Bit, BER, BPV, CRC, Error Sec
Error Insertion: Bit, BPV, Framing Bits, RAI, AIS
Loopback Modes: Self loop, CSU, NIU, user defined, In-band or Data Link
Level Measurements: Vp-p (± 5%), dBdsx
Data Log: Continuous, up to 48 hrs
E1 Analyzer (Option 50, S331D only)
Line Coding: AMI, HDB3
Framing Modes: PCM30, PCM30CRC, PCM31, PCM31CRC
Connection Configurations: Terminate (75W, 120W)
Bridge (³1000W)
Monitor (Connect via 20 dB pad in DSX)
Receiver Sensitivity: 0 to –43 dB
Clock Sources: External
Internal, 2.048 MHz ± 30 ppm
Pulse Shapes: Conform to ITU G.703
Pattern Generation and Detection:
PRBS: 2-9, 2-11, 2-15, 2-20, 2-23 Inverted and
non-inverted, QRSS, 1-in-8 (1-in-7), 2-in-8, 3-in-24,
All ones, All zeros, T1-Daly, User defined (£32 bits)
Circuit Status Reports: Carrier present, Frame ID and Sync., Pattern ID and Sync.
Alarm Detection: AIS, RAI, MMF
Error Detection: Frame Bits, Bit, BER, BPV, CRC, E-Bits, Error Sec
Error Insertion: Bit, BPV, Framing Bits, RAI, AIS
Table 1-1. Performance Specifications (3 of 5)

1-7
Chapter 1 General Information
Loopback Modes: Self loopback
Level Measurements: Vp-p (± 5%), dBdsx
Data Log: Continuous, up to 48 hrs
FCN4760 Frequency Converter (S332D only)
Frequency Range 4.7 GHz to 6.0 GHz
Frequency Resolution* 10 Hz
Frequency Reference Aging: ±1 ppm/yr
Accuracy: ±2 ppm
SSB Phase Noise £–65 dBc/Hz
(6 GHz) @ 30 kHz Offset
Spurious Responses £–45 dBc
Input Related
Spurious Residual £–90 dBm
Responses*
Measurement Range –40 dBm to –100 dBm
Sensitivity* (displayed £–100 dBm
average noise level)
Accuracy ±1.75 dBm typ. (±2.25 dBm max.)*
Maximum Input Level –5 dBm
without damage
Input and Output Ports:
RF In Type N, female, 50W
RF Out Type N, male, 50W
Electromagnetic Meets European community requirements for CE marking
Compatibility
Safety Conforms to EN 61010-1 for Class 1 portable equipment
Temperature:
Operating –10°C to 50°C, 85% humidity or less
Storage –50°C to +80°C
Power Dissipation 850 mW maximum
Dimensions
WxHxD 6.6cmx10.9 cm x 3.3 cm
(2.6 in x 4.3 in x 1.3 in)
Weight <0.45 kg (< 1 lb.)
* Specifications apply when connected to the Site Master.
Table 1-1. Performance Specifications (4 of 5)

1-8
Chapter 1 General Information
Power Meter (Option 29)
Frequency Range: 10 MHz to 3000 MHz
Detection Range: –80 dBm to +80 dBm
Offset Range: 0 to +60 dB
Accuracy: ± 1 dB typical (± 1.5 dBm max), ³10 MHz to 3 GHz
±2 dB, typical, 3 MHz to <10 MHz
VSWR: 1.5:1 typical (Pin> –30 dBm, 10 MHz to 2.4 GHz)
Maximum Input Power
without damage: +43 dBm without external attenuator
General
Language Support: English, Spanish, French, German, Chinese, Japanese
Internal Trace Memory: Up to 200 traces
Setup Configurations: S331D: 25 setups (VNA-10, T1-5, E1-5, Power Meter-5),
S332D: 20 setups (VNA-10, SPA-5, Power Meter-5)
Display: VGA, standard monochrome or optional color LCD with
adjustable backlight
Inputs and Outputs Ports:
RF Out: Type N, female, 50W
Maximum Input without Damage: +23 dBm, ± 50 VDC
RF In: Type N, female, 50W
Maximum Input without Damage: +43 dBm (Peak), ± 50 VDC
Ext. Trig In: BNC, female (5 V TTL)
Ext. Freq Ref In (2 to 20 MHz): Shared BNC, female, 50W, (–15 dBm to +10 dBm)
Serial Interface: RS-232 9 pin D-sub, three wire serial
Electromagnetic Compatibility: Meets European Community requirements for CE marking
Safety: Conforms to EN 61010-1 for Class 1 portable equipment
Temperature:
Operating: -10°C to 55°C, humidity 85% or less
Non-operating: –51°C to +71°C (recommend battery stored separately
between 0°C and +40°C for any prolonged non-operating
storage period)
Power Supply:
External DC Input: +12.5 to +15 volt dc, 3A maximum
Internal: NiMH battery: 10.8 volts, 1800 mAh
Dimensions:
Size (wxhxd): 25.4 cm x 17.8 cm x 6.1 cm (10.0 in x 7.0 in x 2.4 in)
Weight: < 2.28 kg (< 5 lbs) including battery
Table 1-1. Performance Specifications (5 of 5)

Preventive Maintenance
Site Master preventive maintenance consists of cleaning the unit and inspecting and clean-
ing the RF connectors on the instrument and all accessories.
Clean the Site Master with a soft, lint-free cloth dampened with water or water and a mild
cleaning solution.
CAUTION: To avoid damaging the display or case, do not use solvents or abra-
sive cleaners.
Clean the RF connectors and center pins with a cotton swab dampened with denatured alco-
hol. Visually inspect the connectors. The fingers of the N (f) connectors and the pins of the
N (m) connectors should be unbroken and uniform in appearance. If you are unsure whether
the connectors are good, gauge the connectors to confirm that the dimensions are correct.
Visually inspect the test port cable(s). The test port cable should be uniform in appearance,
not stretched, kinked, dented, or broken.
Calibration
The Site Master is a field portable unit operating in the rigors of the test environment. An
Open-Short-Load (OSL) calibration, InstaCal calibration, FlexCal calibration with
open-short-load, or FlexCal calibration with an InstaCal module should be performed prior
to making a measurement in the field (see Calibration, page 3-2). A built-in temperature
sensor in the Site Master advises the user when the internal temperature has exceeded a
measurement accuracy window, and the user is advised to perform another calibration in or-
der to maintain the integrity of the measurement.
NOTES:
For best calibration results—compensation for all measurement uncertain-
ties—ensure that the Open/Short/Load is at the end of the test port or optional
extension cable; that is, at the same point that you will connect the antenna or
device to be tested.
For best results, use a phase stable Test Port Extension Cable (see Optional
Accessories). If you use a typical laboratory cable to extend the Site Master test
port to the device under test, cable bending subsequent to the OSL calibration
will cause uncompensated phase reflections inside the cable. Thus, cables
which are NOT phase stable may cause measurement errors that are more pro-
nounced as the test frequency increases.
For optimum calibration, Anritsu recommends using precision calibration com-
ponents.
1-9
Chapter 1 General Information

InstaCal Module
The Anritsu InstaCal module can be used in place of discrete components to calibrate the
Site Master. The InstaCal module can be used to perform an Open, Short and Load (OSL)
or a FlexCal calibration procedure. Calibration of the Site Master with the InstaCal takes
approximately 45 seconds (see Calibration, page 3-2). Unlike a discrete calibration compo-
nent, the InstaCal module can not be used at the top of the tower to conduct load or inser-
tion loss measurements. The module operates from 2 MHz to 4 GHz and weighs eight
ounces.
Anritsu recommends annual verification of the InstaCal module to verify performance with
precision instrument data. The verification may be performed at a local Anritsu Service
Center or at the Anritsu factory.
Annual Verification
Anritsu recommends an annual calibration and performance verification of the Site Master
and the OSL calibration components and InstaCal module by local Anritsu service centers.
Anritsu service centers are listed in Table 1-2 on the following page.
The Site Master itself is self-calibrating, meaning that there are no field-adjustable compo-
nents. However, the OSL calibration components are crucial to the integrity of the calibra-
tion and therefore, must be verified periodically to ensure performance conformity. This is
especially important if the OSL calibration components have been accidentally dropped or
over-torqued.
ESD Precautions
The Site Master, like other high performance instruments, is susceptible to ESD damage.
Very often, coaxial cables and antennas build up a static charge, which, if allowed to dis-
charge by connecting to the Site Master, may damage the Site Master input circuitry. Site
Master operators should be aware of the potential for ESD damage and take all necessary
precautions. Operators should exercise practices outlined within industry standards like
JEDEC-625 (EIA-625), MIL-HDBK-263, and MIL-STD-1686, which pertain to ESD and
ESDS devices, equipment, and practices.
As these apply to the Site Master, it is recommended to dissipate any static charges that
may be present before connecting the coaxial cables or antennas to the Site Master. This
may be as simple as temporarily attaching a short or load device to the cable or antenna
prior to attaching to the Site Master. It is important to remember that the operator may also
carry a static charge that can cause damage. Following the practices outlined in the above
standards will insure a safe environment for both personnel and equipment.
Mode References
The term “VNA” in reference to the Site Master denotes cable and antenna analyzer modes.
The term “SPA” in reference to the Site Master denotes Spectrum Analyzer mode. All other
modes are referenced individually.
1-10
Chapter 1 General Information

1-11/1-12
Chapter 1 General Information
UNITED STATES
ANRITSU COMPANY
490 Jarvis Drive
Morgan Hill, CA 95037-2809
Telephone: [phone]
1-800-ANRITSU
FAX: [phone]
FRANCE
ANRITSU S.A
9 Avenue du Quebec
Zone de Courtaboeuf
91951 Les Ulis Cedex
Telephone: [phone]
FAX: [phone]
KOREA
ANRITSU CORPORATION LTD.
Service Center:
8F Hyunjuk Building
832-41, Yeoksam Dong
Kangnam-Gu
Seoul, South Korea 135-080
Telephone: [phone]
FAX: [phone]
ANRITSU COMPANY
10 New Maple Ave., Unit 305
Pine Brook, NJ 07058
Telephone: [phone]
1-800-ANRITSU
FAX: [phone]
GERMANY
ANRITSU GmbH
Grafenberger Allee 54-56
D-40237 Dusseldorf, Germany
Telephone: [phone]
FAX: [phone]
SINGAPORE
ANRITSU (SINGAPORE) PTE LTD.
10, Hoe Chiang Road
#07-01/02 Keppel Towers
Singapore 089315
Telephone: [phone]
FAX: [phone]
ANRITSU COMPANY
1155 E. Collins Blvd
Richardson, TX 75081
Telephone: 1-800-ANRITSU
FAX: [phone]
INDIA
MEERA AGENCIES PVT. LTD.
23 Community Centre
Zamroodpur, Kailash Colony Extension,
New Delhi, India 110 048
Phone: [phone]
FAX : [phone]
SOUTH AFRICA
ETECSA
12 Surrey Square Office Park
330 Surrey Avenue
Ferndale, Randburt, 2194
South Africa
Telephone: [phone]
FAX: [phone]
AUSTRALIA
ANRITSU PTY. LTD.
Unit 3, 170 Foster Road
Mt Waverley, VIC 3149
Australia
Telephone: [phone]
FAX: [phone]
ISRAEL
TECH-CENT, LTD.
4 Raul Valenberg St
Tel-Aviv 69719
Telephone: [phone]
FAX: [phone]
SWEDEN
ANRITSU AB
Fagelviksvagen 9A
145 84 Stockholmn
Telephone: [phone]
FAX: [phone]
BRAZIL
ANRITSU ELECTRONICA LTDA.
Praia de Botafogo, 440, Sala 2401
CEP22250-040, Rio de Janeiro, RJ
Brasil
Telephone: [phone]
FAX: [phone]
ITALY
ANRITSU Sp.A
Roma Office
Via E. Vittorini, 129
00144 Roma EUR
Telephone: [phone]
FAX: [phone]
TAIWAN
ANRITSU CO., INC.
7F, No. 316, Section 1
NeiHu Road
Taipei, Taiwan, R.O.C.
Telephone: [phone]
FAX: [phone]
CANADA
ANRITSU INSTRUMENTS LTD.
700 Silver Seven Road, Suite 120
Kanata, Ontario K2V 1C3
Telephone: [phone]
FAX: [phone]
JAPAN
ANRITSU CUSTOMER SERVICE LTD.
1800 Onna Atsugi-shi
Kanagawa-Prf. 243 Japan
Telephone: [phone]
FAX: [phone]
UNITED KINGDOM
ANRITSU LTD.
200 Capability Green
Luton, Bedfordshire
LU1 3LU, England
Telephone: [phone]
FAX: [phone]
CHINA
ANRITSU ELECTRONICS (SHANGHAI)
CO. LTD.
2F, Rm B, 52 Section Factory Building
No. 516 Fu Te Rd (N)
Shanghai 200131 P.R. China
Telephone:[phone],
58680228
FAX: [phone]
Table 1-2. Anritsu Service Centers

Chapter 2
Functions and Operations
Introduction
This chapter provides a brief overview of the Site Master functions and operations, provid-
ing the user with a starting point for making basic measurements. For more detailed infor-
mation, refer to the specific chapters for the measurements being made.
The Site Master is designed specifically for field environments and applications requiring
mobility. As such, it is a lightweight, handheld, battery operated unit which can be easily
carried to any location, and is capable of up to 1.5 hours of continuous operation from a
field replaceable battery for extended time in the field. Built-in energy conservation fea-
tures allow battery life to be further extended. The Site Master can also be powered by a
12.5 Vdc external source. The external source can be either the Anritsu AC-DC Adapter
(P/N 40-163) or 12.5 Vdc Automotive Cigarette Lighter Adapter (P/N 806-62). Both items
are standard accessories.
Test Connector Panel
The connectors and indicators located on the test panel (Figure 2-1) are listed and described
below. The illustration depicts an S331D with Option 50, T1/E1 installed.
12.5-15VDC
(3A)
12.5 to 15 Vdc @ 3A input to power the unit or for battery charging.
WARNING
When using the AC-DC Adapter, always use a three-wire power cable connected
to a three-wire power line outlet. If power is supplied without grounding the equip-
ment in this manner, there is a risk of receiving a severe or fatal electric shock, or
damaging the equipment.
2-1
Spectrum Analyzer
RF Out /
T1/E1
Ext Freq Ref / Ext Trigger
RECEIVE TRANS MIT
RF In 50Reflection 50
+43 dBm MAX 50 VDC M AX
Serial
Interface
External Power
12.5 - 15V DC
(1350 mA)
Battery Charging
+23 dBm MAX 50 VDC M AX
CAUTION
AVOID STATIC
DISCHARGE
S
ERIAL INTERFA
C
E
EXTERNAL POWER
EXTERNAL FREQ REF /
EXT TRIGGER
EXTERNAL POWER LED
BATTERY
CHARGING
LED
RF IN
T1/E1
RF
OU
T
!
Figure 2-1. S331D Test Connector Panel (with Option 50)

Battery
Charging
Illuminates when the battery is being charged. The indicator automatically shuts
off when the battery is fully charged.
External
Power
Illuminates when the Site Master is being powered by the external charging unit.
Serial
Interface
RS232 DB9 interface to a COM port on a personal computer (for use with the
Anritsu Handheld Software Tools program) or to a supported printer.
RF Out/
Reflection 50W
RF output, 50 Wimpedance, for reflection measurements. Maximum input is
+23 dBm at ±50 Vdc.
Spectrum
Analyzer
RF In 50W
RF input, 50 Wimpedance, for spectrum analysis measurements. Maximum in-
put is +43 dBm at ±50 Vdc.
Ext Freq
Ref/Ext Trigger
Input for an external reference signal or trigger in Spectrum Analyzer mode.
T1/E1
Receive/
Transmit
Transmit and Receive connectors for T1 and E1 measurements (Option 50,
S331D only)
Frequency
Converter
Interface
(Option 6)
Ten pin D-style connector providing an interface to control and communicate
with an Anritsu frequency conversion module.
Headphone
Jack
Provides audio output for the built-in AM/FM demodulator for testing and trou-
bleshooting wireless communication systems.
2-2
Chapter 2 Functions and Operations

Display Overview
Figure 2-2 illustrates some of the key information areas of the S331D display.
Figure 2-3 illustrates some of the key information areas of the S332D display.
Chapter 2 Functions and Operations
2-3
TITLE BAR
DATA
POINTS
SWEEP
TIME
CALIBRATION
STATUS
ME
SS
A
G
EAREA
CURRENT
MENU
Figure 2-2. S331D Display Overview
TITLE BAR
SWEEP
MODE
DETECTION
METHOD
PREAMPLIFIER
STATE
ME
SS
A
G
EAREA
CURRENT
MENU
Figure 2-3. S332D Display Overview
