Keysight Technologies N6700C Series User manual

Front and Rear Panels at a Glance
5991-3422
*5991-3422*
www.keysight.com
© Keysight Technologies 2016
Edition 1, October 2016
Printed In Malaysia
Built-in instrument help
Press the key and scroll to the Help item.
Press Enter. Select a Help item from the menu.
Documentation for mobile devices
A manual for mobile devices is
available by scanning the following:
Additional Information
Documentation on the Web
Product documentation is available on the Web at
http://www.keysight.com/find/N6700.
Firmware updates
Install the latest firmware updates from the Web at
http://www.keysight.com/find/N6700firmware.
1 - Display - Turns off after 1 hour of inactivity.
Press any key to restore the display.
2- Navigation keys - Move the cursor to a menu item.
Press Select to select the highlighted item.
3- Output keys - Turns the output on or off.
Enter voltage and current settings.
Output Connectors at a Glance
Connectors
have local
sense jumpers
installed
1. Remove the
blower cover.
Remove the screws
from the top and side
of the blower cover.
Power Module Installation at a Glance
2. Install the
power
modules.
Align the module
over the pins and
push it down onto
the connector.
3. Install the
blower cover.
Carefully fit the spring
clips under the lip of
the power modules.
Install the screws
at each end of the
power module.
Menu
4 - On/Off switch and LED - LED indicates power is on.
Green: norrmal operation. Amber: screen saver mode.
5- System keys - Toggle between 1- and 4- channel view.
Access front panel menu. Select an output channel.
6- Numeric entry keys – Enter numeric values. Arrow keys
increment and decrement voltage and current settings.
1 - GPIB - GPIB interface connector.
2- Ground - Mchassis ground binding post.
3- AC input - Requires a ground conductor.
4 - Output connector – Includes +/- output and
+/- sense terminals.
5 - Digital Connector - Pins functions are user-configurable.
6- USB – USB interface connector.
7- LAN – 10/100 Base-T.
Left LED indicated activity
Right LED indicates link intergrity.
++S +LS -LS -S
50A SENSE
50 A CONNECTOR
LOCKING
SCREW
12 A & 20 A
CONNECTOR
+S + -S
− − G + + +S G -S
8A CONNECTOR

Front Panel Menu Reference
Menu
