Keysight Technologies N6700C Series User manual

Keysight Series N6700C
Low-Profile Modular
Power System
User's Guide
Sie haben Fragen oder wünschen eine Beratung? Angebotsanfrage unter 07121 / 51 50 50 oder über [email protected]
Distributed by:

Legal and Safety Information 7
Legal Notices 7
Safety Symbols 9
Safety Notices 10
1 Quick Reference 13
Introduction to the Instrument 14
Features at a Glance 14
Front Panel at a Glance 16
Rear Panel at a Glance 17
Front Panel Display at a Glance 18
Front Panel Keys at a Glance 20
Front Panel Menu Reference 21
Command Quick Reference 25
Models and Options 38
Model Descriptions 38
Model Differences 39
Options 42
Specifications 43
Supplemental Characteristics N6700C, N6701C, N6702C 43
Dimension Diagrams 45
2 Installation 47
Preliminary Information 48
Check for Items Supplied 48
Inspect the Unit 49
Review Safety Information 49
Observe Environmental Conditions 49
Installing the Mainframe 50
Module Installation 50
Rack Mounting 52
Bench Installation 53
Redundant Ground for 400 Hz Operation 53
Connecting the Power Cord 54
Connecting the Outputs 55
Output Wiring 55
Wire Sizing 56
Keysight N678xA SMU Wiring 58
Multiple Load Wiring 60
Positive and Negative Voltages 60
Load Capacitor Response Times 61
Ferrite Core Installation - for Keysight N6792A only 61
Protecting Sensitive Loads from AC Power Switching Transients 62
Remote Sense Connections 63
Wiring 63
Open Sense Leads 64
Over-Voltage Protection Considerations 64
Output Noise Considerations 64
3 Keysight N6700C Series User's Guide

Parallel and Series Connections 65
Parallel Connections 65
Series Connections 67
Auxiliary Measurement Connections 70
Interface Connections 71
GPIB Connections 71
USB Connections 72
LAN Connections - site and private 72
Digital Port Connections 74
3 Getting Started 77
Using the Front Panel 78
Turn the Unit On 78
Select an Output Channel 78
Set the Output Voltage 79
Set the Output Current 79
Enable the Output 80
Use the Front Panel Menu 80
Remote Interface Configuration 83
USB Configuration 83
GPIB Configuration 83
LAN Configuration 84
Modifying the LAN Settings 85
Using the Web Interface 88
Using Telnet 89
Using Sockets 90
Securing the Interfaces 90
4 Operating the Power System 91
Programming the Output 92
Select a Channel View 92
Select an Output Channel 93
Set the Output Voltage 93
Set the Output Current 93
Set the Output Resistance 94
Set the Output Power 95
Set the Output Mode 96
Set the Slew Rate 96
Enable the Output 97
Sequence Multiple Outputs 98
Program the Output Relays 98
Set the Output Bandwidth 99
Set the Output Turn-Off Mode 100
Programming an Input Short 100
Enable Under-Voltage Inhibit 101
Stepping the Output 102
Synchronizing Output Turn-On 106
Synchronizing Output Turn-On Delays 106
Synchronizing Multiple Mainframes 109
Keysight N6700C Series User's Guide 4

Synchronization Operation 110
Programming Output Lists 111
Output Lists 111
Program an Output Pulse or Pulse Train 112
Program an Arbitrary List 114
Generating Arbitrary Waveforms 117
Arbitrary Waveform Description 117
Configuring Step Arbs 118
Configuring Pulse Arbs 118
Configuring Ramp Arbs 119
Configuring Trapezoid Arbs 120
Configuring Staircase Arbs 121
Configuring Exponential Arbs 122
Configuring Sinusoid Arbs 122
Configuring Constant-Dwell Arbs 123
Configuring an Arb Sequence 124
Configuring User-Defined Arbs 126
Configuring Steps Common to all Arbs 126
Running the Arb 127
Making Measurements 129
Basic DC Measurements 129
Measurement Ranges 129
Seamless Measurements 130
Simultaneous Measurements 130
Auxiliary Voltage Measurements 130
Using the Digitizer 132
Measurement Types 132
Programming the Digitizer 133
Synchronizing Digitizer Measurements 137
External Data Logging 142
Data Logging Functions 142
Select the Measurement Function and Range 142
Specify the Integration Period 143
Select the Elog Trigger Source 144
Initiate and Trigger the Elog 145
Periodically Retrieve the Data 145
Terminate the Elog 146
Using the Digital Control Port 147
Bi-directional Digital IO 147
Digital Input 148
External Trigger I/O 148
Fault Output 149
Inhibit Input 149
Fault/Inhibit System Protection 150
Output State 151
Using the Protection Functions 152
Protection Functions 152
Set the Over-Voltage Protection 153
5 Keysight N6700C Series User's Guide

Set the Over-Current Protection 153
Set the Over-Power Protection 154
Couple Output Protection 155
Query the Over-Temperature Margin 155
Set the Oscillation Protection 155
Watchdog Timer Protection 156
Clear Output Protection 156
System-Related Operations 157
Self-test 157
Instrument Identification 157
Instrument State Storage 158
Output Groups 158
Front Panel Display 160
Front Panel Keys 161
Password Protection 162
Mainframe Power Allocation 163
Mainframe Power Ratings 163
Mainframe Power Limit 163
Module Power Limit 163
Power Limit Allocation 164
Operating Mode Tutorial 165
Single-Quadrant Operation 165
Multi-Quadrant Operation 166
Keysight N679xA Load Module Operation 169
Index 172
Keysight N6700C Series User's Guide 6

Legal and Safety Information
Legal Notices
Safety Notices
Safety Symbols
Legal Notices
Copyright Notice
© Copyright Keysight Technologies 2017 - 2019
No part of this manual may be reproduced in any form or by any means (including electronic storage
and retrieval or translation into a foreign language) without prior agreement and written consent from
Keysight Technologies Inc. as governed by United States and international copyright laws.
Edition
Edition 2, February 2019
Published By
Keysight Technologies
550 Clark Drive, Suite 101
Budd Lake, New Jersey 07828
USA
Warranty
The material contained in this document is provided "as is," and is subject to being changed, without
notice, in future editions. Further, to the maximum extent permitted by applicable law, Keysight
disclaims all warranties, either express or implied, with regard to this manual and any information
contained herein, including but not limited to the implied warranties of merchantability and fitness for
a particular purpose. Keysight shall not be liable for errors or for incidental or consequential damages
in connection with the furnishing, use, or performance of this document or of any information contained
herein. Should Keysight and the user have a separate written agreement with warranty terms
covering the material in this document that conflict with these terms, the warranty terms in the
separate agreement shall control.
Certification
Keysight Technologies certifies that this product met its published specifications at time of shipment
from the factory. Keysight Technologies further certifies that its calibration measurements are
traceable to the United States National Institute of Standards and Technology, to the extent allowed
by the Institute's calibration facility, and to the calibration facilities of other International Standards
Organization members.
Legal and Safety Information
7 Keysight N6700C Series User's Guide

U.S. Government Rights
The Software is "commercial computer software," as defined by Federal Acquisition Regulation (“FAR”) 2.101.
Pursuant to FAR 12.212 and 27.405-3 and Department of Defense FAR Supplement (“DFARS”) 227.7202, the U.S.
government acquires commercial computer software under the same terms by which the software is customarily
provided to the public. Accordingly, Keysight provides the Software to U.S. government customers under its
standard commercial license, which is embodied in its End User License Agreement (EULA), a copy of which can
be found at http://www.keysight.com/find/sweula. The license set forth in the EULA represents the exclusive
authority by which the U.S. government may use, modify, distribute, or disclose the Software. The EULA and the
license set forth therein, does not require or permit, among other things, that Keysight: (1) Furnish technical
information related to commercial computer software or commercial computer software documentation that is
not customarily provided to the public; or (2) Relinquish to, or otherwise provide, the government rights in excess of
these rights customarily provided to the public to use, modify, reproduce, release, perform, display, or disclose
commercial computer software or commercial computer software documentation. No additional government
requirements beyond those set forth in the EULA shall apply, except to the extent that those terms, rights, or
licenses are explicitly required from all providers of commercial computer software pursuant to the FAR and the
DFARS and are set forth specifically in writing elsewhere in the EULA. Keysight shall be under no obligation to
update, revise or otherwise modify the Software. With respect to any technical data as defined by FAR 2.101,
pursuant to FAR 12.211 and 27.404.2 and DFARS 227.7102, the U.S. government acquires no greater than Limited
Rights as defined in FAR 27.401 or DFAR 227.7103-5 (c), as applicable in any technical data
Declaration of Conformity
Declarations of Conformity for this product and for other Keysight products may be downloaded from
the Web. Go to http://www.keysight.com/go/conformity and click on "Declarations of Conformity".
You can then search by product number to find the latest Declaration of Conformity.
Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC
This product complies with the WEEE Directive 2002/96/EC marketing requirement. The affixed
product label (see below) indicates that you must not discard this electrical/electronic product in
domestic household waste.
Product Category: With reference to the equipment types in the WEEE directive Annex 1, this product
is classified as "Monitoring and Control instrumentation" product.
Do not dispose in domestic household waste.
To return unwanted products, contact our local Keysight office, or see
http://www.keysight.com/environment/product for more information.
Keysight N6700C Series User's Guide 8
Legal and Safety Information

Safety Symbols
A WARNING notice denotes a hazard. It calls attention to an operating procedure, practice, or the
like that, if not correctly performed or adhered to, could result in personal injury or DEATH. Do not
proceed beyond a WARNING notice until the indicated conditions are fully understood and met.
A CAUTION notice denotes a hazard. It calls attention to an operating procedure, practice, or the
like that, if not correctly performed or adhered to, could result in damage to the product or loss of
important data. Do not proceed beyond a CAUTION notice until the indicated conditions are fully
understood and met.
Direct current
Alternating current
Frame or chassis terminal
Standby supply. Unit is not completely disconnected from AC mains when switch is off.
Risk of electric shock
Refer to accompanying documents
Earth ground terminal
The CE mark is a registered trademark of the European Community.
The ETL mark is a registered trademark of Intertek.
The RCM mark is a registered trademark of the Spectrum Management Agency of Australia.
South Korean Class A EMC Declaration
This equipment has been conformity assessed for use in business environments. In a residential environment this
equipment may cause radio interference. This EMC statement applies to the equipment only for use in business
environments.
Contains one or more of the 6 hazardous substances above the maximum concentration value (MCV), 40 Year
EPUP.
ISM1-A This text indicates that the instrument is an Industrial Scientific and Medical Group 1 Class A product (CISPER
11, Clause 4).
ICES/NMB-001 This text indicates product compliance with the Canadian Interference- Causing Equipment Standard (ICES-
001).
Legal and Safety Information
9 Keysight N6700C Series User's Guide

Safety Notices
The following general safety precautions must be observed during all phases of operation of this
instrument. Failure to comply with these precautions or with specific warnings or instructions
elsewhere in this manual violates safety standards of design, manufacture, and intended use of the
instrument. Keysight Technologies assumes no liability of the customer’s failure to comply with the
requirements.
General
Do not use this product in any manner not specified by the manufacturer. The protective
features of this product may be impaired if it is used in a manner not specified in the
operating instructions.
Environmental Conditions
Never use the instrument outside of the specified environmental conditions described in
the Environmental Characteristics of the specifications.
Ground the Instrument
This product is provided with protective earth terminals. To minimize shock hazard, the
instrument must be connected to the AC mains through a grounded power cable, with
the ground wire firmly connected to an electrical ground (safety ground) at the power
outlet. Any interruption of the protective (grounding) conductor or disconnection of the
protective earth terminal will cause a potential shock hazard that could result in injury
or death.
Before Applying Power
Verify that all safety precautions are taken. All connections must be made with the unit
turned off, and must be performed by qualified personnel who are aware of the hazards
involved. Improper actions can cause fatal injury as well as equipment damage. Note
the instrument's external markings described under "Safety Symbols".
Some power modules generate voltages exceeding 60 VDC
Ensure that instrument connections, load wiring, and load connections are either
insulated or covered so that no accidental contact with lethal output voltages can
occur.
Do Not Operate in an Explosive Atmosphere
Do not operate the instrument in the presence of flammable gases or fumes.
Do Not Remove the Instrument Cover
Only qualified, service-trained personnel who are aware of the hazards involved should
remove instrument covers. Disconnect the power cable and any external circuits before
removing instrument covers.
Keysight N6700C Series User's Guide 10
Legal and Safety Information

Do Not Modify the Instrument
Do not install substitute parts or perform any unauthorized modification to the product.
Return the product to a Keysight Sales and Service Office for service and repair to
ensure that safety features are maintained.
Fuses
The instrument contains an internal fuse, which is not customer accessible.
Cleaning
To prevent electric shock, always unplug the unit before cleaning. Use a dry cloth or
one slightly dampened with water to clean the external case parts. Do not use
detergent or chemical solvents. Do not attempt to clean internally.
In Case of Damage
Instruments that are not functioning correctly, appear damaged or defective should be
made inoperative and secured against unintended operation until they can be repaired
by qualified service personnel.
Legal and Safety Information
11 Keysight N6700C Series User's Guide

Keysight N6700C Series User's Guide
1
Quick Reference
Legal and Safety Information
Introduction to the Instrument
Front Panel Menu Reference
Command Quick Reference
Models and Options
Specifications and Characteristics
This document includes user, service, and programming information for the
Keysight N6700C Series Modular Power System .
Documentation and Firmware Revisions
You can download the latest version of this document at
www.keysight.com/find/n6700-doc. The latest version is also available for
mobile devices at www.keysight.com/find/n6700-mobilehelp. If you have
feedback on this document, please contact Keysight at
www.keysight.com/find/n6700-docfeedback.
This document describes firmware revision E.02.01 and up. For the latest
firmware revision go to Firmware Updates in the Keysight N6700C Series
Operating and Service Guide.
Contacting Keysight Technologies
Use www.keysight.com/find/assist for information on contacting Keysight
worldwide, or contact your Keysight Technologies representative.
© Copyright Keysight Technologies 2017 - 2019

Introduction to the Instrument
Features at a Glance
Front Panel at a Glance
Front Panel Display at a Glance
Front Panel Keys at a Glance
Rear Panel at a Glance
Features at a Glance
The Keysight N6700 Modular Power System is a configurable, one rack- unit (1U) platform that lets
you mix and match power modules to create a power system optimized for your test system
requirements.
Keysight N6700–N6702 MPS mainframes are available in power levels of 400 W, 600 W, and 1,200 W.
Up to four power modules can be installed in each mainframe. Power modules come in power levels of
20 W through 500 W, have various voltage and current combinations, and provide the following
performance features:
lN673xB, N674xB, and N677xA DC Power Modules provide programmable voltage and current,
measurement, and protection features, making these economical models suitable for powering
the device-under-test or system resources such as fixture controls.
lN675xA High-Performance, Autoranging DC Power Modules provide low noise, high accuracy, fast
programming times, and advanced programming and measurement capabilities to speed test
throughput.
lN676xA Precision DC Power Modules provide precise control and measurements in the milli- and
micro-ampere region with the ability to simultaneously digitize voltage and current and capture
those measurements into an oscilloscope-like data buffer.
lN678xA Source/Measure Units (SMU) have a multiple-quadrant power mesh with separate
voltage and current priority source modes. These models are optimized for applications such as
battery drain analysis and functional testing.
lN6783A Application-Specific DC Power Modules are two-quadrant low-wattage models spe-
cifically designed for battery charging/discharging and mobile communications applications.
lN679xA Electronic Load Modules are single-quadrant 100 W and 200 W models having constant
current, constant voltage, constant power, and constant resistance operating capabilities. They
also provide many of the existing measurement and protection features of the other power mod-
ules.
1 Quick Reference
14 Keysight N6700C Series User's Guide

The output and system features are described in the following sections. Not all output features are
available on every power module. The Model Differences section describes the features that apply
only to specific power modules.
Output features
lProgrammable voltage, current, power, or resistance - Full programming capability is provided for
the entire range of output voltage and current for all power modules. Power and resistance pro-
graming is available on Keysight N679xA load modules.
lLow output noise - Available on Keysight N676xA and N675xA power modules. Output noise is less
than 4.5 mV peak-to-peak, which is comparable to linear supplies.
lArbitrary waveform generation - This allows the output to act as a DC bias transient generator or
an arbitrary waveform generator.
lFast up/down programming - Available on Keysight N675xA, N676xA, and N678xA SMU power
modules. Response time is less than 1.5 millisecond from 10% to 90% of the output rating.
lFast transient response - Available on Keysight N675xA, N676xA, and N678xA SMU power mod-
ules. Transient response is less than 100 μs.
lOutput autoranging capability - Available on Keysight N676xA and N675xA power modules. Autor-
anging supplies the maximum rated power over a continuous range of voltage and current settings
lOutput On/Off sequencing - A turn-on/turn-off delay capability for each output allows output
on/off sequencing.
lRemote voltage sensing - Two remote sensing terminals are provided for each output. When
shipped, the remote sense jumpers are included in a separate bag. See Items Supplied.
lOutput protection - Each output has over-voltage, over-current, and over-temperature protection.
Over-voltage and over-current protection are programmable.
lMultiple-Quadrant operation - Available on Keysight N678xA SMU and N6783A power modules.
2- quadrant operation provides source and sink output capability. Keysight model N6784A offers
4- quadrant output operation.
lElectronic Load operation - Available on Keysight N679xA load modules. 100 W and 200 W input
ratings are available.
Measurement features
lMultiple-output/Single-output meter display - Switch between a 4-output summary view and a 1-
output detailed view of power system information. All power modules display real-time output
voltage and current measurements as well as status information.
lSeamless measurement autoranging - Available on Keysight N678xA SMU power modules. Out-
put measurements seamlessly autorange between ranges – however, the 10 μA current range
must be selected manually.
Keysight N6700C Series User's Guide 15
1 Quick Reference

lMicroampere current measurements - Available on Keysight N6761A, N6762A, and N678xA SMU
power modules. Current measurement can be made as low as 1 μA in the 10 μA range.
lFast Digitizing Available on Keysight N678xA SMU power modules. 5.12 μs/sample for one para-
meter; 10.24 μs/sample for two parameters.
System features
lChoice of three interfaces - GPIB (IEEE-488), LAN, and USB remote programming interfaces are
built in.
lBuilt-in Web server - A built-in Web server lets you control the instrument directly from an internet
browser on your computer.
lSCPI language - The instrument is compatible with the Standard Commands for Programmable
Instruments (SCPI).
lFront panel I/O setup - Menus let you set up GPIB and LAN parameters from the front panel.
lReal-time status information - The front panel indicates the status of each output. It also indicates
when a protection shut-down has occurred.
lModule identification - Each module has identifying data stored in non-volatile memory. Inform-
ation includes model number, serial number, and options.
lUniversal AC input - Mainframes have universal input voltage capability with active power factor
correction.
Front Panel at a Glance
1. Display - Turns off after 1 hour of inactivity. Press any key to restore the display.
2. Navigation keys - Move the cursor to a menu item. Select the highlighted menu item.
3. Output keys - Turn the outputs on or off. Enter voltage or current.
4. On/Off switch and LED - LED indicates power is on. Green indicates normal operation. Amber indic-
ates display is in screen-saver mode.
1 Quick Reference
16 Keysight N6700C Series User's Guide

5. System keys - Toggle between single-channel and multiple-channel view. Access front panel com-
mand menu. Select an output channel to control.
6. Numeric Entry keys - Enter values. Arrow keys increment or decrement numeric settings.
Rear Panel at a Glance
1. GPIB - GPIB interface connector.
2. Ground - Chassis ground binding post.
3. IEC 320 connector - AC input connector. Power cord requires a ground conductor.
4. Output connector - Includes +/−output and +/− sense terminals.
5. Digital connector - Pin functions are user-configurable.
6. USB - USB interface connector.
7. LAN - 10/100/1000 Base-T Left LED indicates activity. Right LED indicates link integrity.
SHOCK HAZARD
The power cord provides a chassis ground through a third conductor. Be certain that
your power outlet is of the three-conductor type with the correct pin connected to earth
ground.
Keysight N6700C Series User's Guide 17
1 Quick Reference

Front Panel Display at a Glance
Voltage & Current View Voltage measurement Bar indicates output polar-
ity is reversed
Current measurement
Press
to toggle between views
Operating status
(CV = constant voltage)
Voltage and current set-
tings
Interface status
(IO = activity on interface)
Voltage, Current, &
Power View
Voltage measurement Current measurement and power
measurement
Press
to toggle between views
4-Channel View Voltage and Current measurements
Press
to toggle between views
The highlighted channel is the active channel
1 Quick Reference
18 Keysight N6700C Series User's Guide

Grouped-Channel View Channels 2 through 4 are connected in parallel and have been configured or grouped to actas a
single, higher-power channel
Refer to Output Groups for more
information
Grouped channels are addressed using the channel number of the lowest channel in the group
Double-Wide View Channel 2 is a double-wide power module that occupies two channel locations in the mainframe
Operating status
indicators
OFF = the output is off
CV = the output is in constant voltage mode
CC = the output is in constant current mode
CP+ = the output is limited (or disabled) by the positive power limit
CP– = the output is limited (or disabled) by the negative power limit
VL+/– = the output is in positive or negative voltage limit mode
CL+/– = the output is in positive or negative current limit mode
OV = the output is disabled by the over-voltage protection
OV– = the output is disabled by the negative over-voltage protection
OC = the output is disabled by the over-current protection
OT = the over-temperature protection has tripped
PF = the output is disabled by a power-fail condition
OSC = the output is disabled by the oscillation protection
INH = the output is disabled by an external inhibit signal
UNR = the output is unregulated
PROT = the output is disabled by a condition from a coupled channel
SH = the load input terminals are shorted (N679xA)
UVI = an under-voltage inhibit condition occurred (N679xA)
Interface status
indicators
Err = an error has occurred (press Error key to display error message)
Lan = the LANis connected and has been configured
IO = there is activity on one of the remote interfaces
Keysight N6700C Series User's Guide 19
1 Quick Reference

Front Panel Keys at a Glance
Meter returns the display to metering mode.
Menu accesses the command menu.
Channel selects or highlights a channel to control.
Back backs out of a menu without activating any changes.
Help accesses information about the displayed menu control.
Error displays any error messages in the error queue.
Arrows let you move around in the command menus.
Select lets you make a selection in the command menus. It also lets you enter editmode for
editing the numeric parameters.
On/Off controls the selected output (or all outputs when All is lit). This key is only active in
Single- channel or Multiple-channel view.
Voltage lets you change the voltage setting.
Current lets you change the current setting.
The 0 through 9 keys enter numbers.
The (.) key is the decimal point.
The – key is used to enter a minus sign.
The ÇÈ arrow keys increment or decrement voltage or current settings.They also select
letters in alphabetic entry fields.
The E key enters an exponent. Add the value to the right of the E.
The Åback arrow key deletes digits as it backspaces over them.
The Enter key enters a value. If you exit a field without pressing the Enter key, the value is
ignored.
1 Quick Reference
20 Keysight N6700C Series User's Guide
