Keysight N2786A Probe
Positioner
User’s Guide
The Keysight N2786A 2-legged probe positioner
can be used for quick and stable hands-free
browsing. The positioner has three different-sized
apertures into which various sized probes can be
placed. It supports most Keysight and non-Key-
sight oscilloscope probes. (Refer to the back of this
user’s guide for specific compatibility information.)
N2785-92001_Keysight.fm Page 1 Tuesday, October 21, 2014 11:08 AM

Probe Compatibility
These Keysight probes are compatible with the
N2786A:
•10070C/73C/74C/76A
•N2862A/63A
•1160A/61A/62A/63A/64A/65A
•1156A/57A/58A
•1144A
•10433B/36B/37B/39B/40B/41B/42B
Dimensions
How to Use
To use the positioner, first determine the appropri-
ate aperture for your specific probe. Insert your
probe and then arrange the positioner/probe at the
measuring point. The front of the positioner (the
side with the Keysight logo) must be pointing up
during use.
N2785-92001
Height 91.5 mm
Width 67 mm
Weight 51.5 g
Keysight Part Number N2785-92001
February 2009 - Printed in Germany
