Configuration 1
1Remove both rubber bumpers from the E5810B.
2Using a Torx screwdriver, attach the rackmount bracket - half rack (B) to the E5810B with three
panhead screws, M4X10 (E).
3Plug the E5810B power adapter (D) into the DC power port of the E5810B. Place the power
adapter into the power adapter holder (C).
4Using a Torx screwdriver, attach the rackmount bracket - side (A) to the E5810B and the power
adapter holder (C) with five panhead screws, M4X10 (E).
Item Part number Description Quantity Item Part number Description Quantity
AE5810-00031 Rackmount bracket[a] -
side
[a] Rackmount bracket is also known as a rack ear.
1E0515-0380 Panhead screw, M4X10 8
BE5810-00022 Rackmount bracket[a] -
half rack 1F0515-0440 Machine screw 4
CE5810-00035/
E5810-00045 Power adapter holder 1 G0535-1156 Machine nut 4
D0950-6484 Power adapter 1 H3050-2222 Plastic washer 8
NOTE Effective September 2022, the power adapter holder (either part number
E5810-00035 or E5810-00045) will be included in the rackmount kit.

6 Keysight E5810B Rackmount Installation Guide (Option 200)

Keysight E5810B Rackmount Installation Guide (Option 200) 7
5Using a Torx screwdriver, attach the rack ears to the rack with four machine screws (F), four
machine nuts (G), and eight plastic washers (H).

8 Keysight E5810B Rackmount Installation Guide (Option 200)
Configuration 2
1Remove both rubber bumpers from the E5810B.
2Plug the E5810B power adapter (C) into the DC power port of the E5810B. Place the power
adapter into the power adapter holder (B).
3Using a Torx screwdriver, attach the ATH manipulator mounting bracket (A) to the E5810B and
the power adapter holder (B) with five panhead screws, M4X10 (D) and three panhead screws,
M5X10 (E).
Item Part number Description Quantity Item Part number Description Quantity
AE5810-00032 ATH manipulator
mounting bracket 1D0515-0380 Panhead screw, M4X10 5
BE5810-00035/
E5810-00045 Power adapter holder 1 E0515-0386 Panhead screw, M5X10 3
C0950-6484 Power adapter 1
NOTE Effective September 2022, the power adapter holder (either part number
E5810-00035 or E5810-00045) will be included in the rackmount kit.

Keysight E5810B Rackmount Installation Guide (Option 200) 9

10 Keysight E5810B Rackmount Installation Guide (Option 200)
Configuration 3
1Remove both rubber bumpers from the E5810B.
2Plug the E5810B power adapter (C) into the DC power port of the E5810B. Place the power
adapter into the power adapter holder (B).
3Using a Torx screwdriver, attach the CTH manipulator mounting bracket (A) to the E5810B and
the power adapter holder (B) with five panhead screws, M4X10 (D).
Item Part number Description Quantity Item Part number Description Quantity
AE5810-00033 CTH manipulator
mounting bracket 1D0515-0380 Panhead screw, M4X10 5
BE5810-00035/
E5810-00045 Power adapter holder 1 E0515-4303 HD Cap Hex socket screw, M6X10 4
C0950-6484 Power adapter 1 F3050-2305
Washer flat metallic
6.4 mm ID 12 mm OD
1.6 mm THK
4
NOTE Effective September 2022, the power adapter holder (either part number
E5810-00035 or E5810-00045) will be included in the rackmount kit.

Keysight E5810B Rackmount Installation Guide (Option 200) 11
4Using an Allen key, attach the CTH manipulator mounting bracket to the rack with four HD Cap
Hex socket screws, M6X10 (E) and four washers (F).

12 Keysight E5810B Rackmount Installation Guide (Option 200)
Configuration 4
1Remove both rubber bumpers from the E5810B.
2Plug the E5810B power adapter (C) into the DC power port of the E5810B. Place the power
adapter into the power adapter holder (B).
3Using a Torx screwdriver, attach the ATH cart mounting bracket (A) to the E5810B and the power
adapter holder (B) with two panhead screws, M4X10 (E) and three 90° flat head screws, M4X10
(F).
Item Part number Description Quantity Item Part number Description Quantity
AE5810-00034 ATH cart mounting
bracket 1D0515-0386 Panhead screw, M5X10 2
BE5810-00035/
E5810-00045 Power adapter holder 1 E0515-0380 Panhead screw, M4X10 2
C0950-6484 Power adapter 1 F0515-1269 90° flat head screw,
M4X10 3
NOTE Effective September 2022, the power adapter holder (either part number
E5810-00035 or E5810-00045) will be included in the rackmount kit.

Keysight E5810B Rackmount Installation Guide (Option 200) 13
4Using a Torx screwdriver, attach the ATH cart mounting bracket to the rack with two panhead
screws, M5X10 (D).
