Keysight U1231A/U1232A/
U1233A Handheld Multimeter
Quick Start Guide

Verify that you received the following items in the shipment of
your multimeter:
✔One pair of red and black test leads
✔Four 1.5 V AAA alkaline battery
✔Printed copy of the U1231A/U1232A/U1233A
Quick Start Guide
If any item is missing or damaged, keep the shipping materials
and contact the nearest Keysight Sales Office.
NOTE
The descriptions and instructions in this guide apply to the
U1231A, U1232A, and U1233A handheld multimeters.
The model U1233A appears in all illustrations.
All related documents and software are available for download
at www.keysight.com/find/hhTechLib.
Quick Start Guide
Keysight
U1231A/U1232A/U1233A
Handheld Multimeter

U1231A/U1232A/U1233A Handheld Multimeter
Install the Batteries
2 U1231A/U1232A/U1233A Quick Start Guide
Install the Batteries
Your multimeter is powered by four 1.5 V AAA alkaline batter-
ies (included with the shipment).
1Turn the multimeter OFF and remove the test
leads from the terminals.
2Loosen the screw on the battery cover with a
suitable Phillips screwdriver.
3Remove the battery cover and observe the
polarity markings.
4Insert the batteries and replace the battery
cover and screw.
Turn On the Multimeter
To power ON your multimeter,
turn the rotary switch to any
other position.
Controlling the Multimeter Remotely
Your multimeter is capable of
remote data logging.
To use this feature, you will
need a PC running a Windows
operating system, an IR-USB
cable (U1173A, purchased sepa-
rately), and the Keysight GUI
Data Logger Software.
The Keysight GUI Data Logger software is downloadable for
free from www.keysight.com/find/hhTechLib.
To PC (host)

U1231A/U1232A/U1233A Handheld Multimeter
The Multimeter at a Glance
U1231A/U1232A/U1233A Quick Start Guide 3
The Multimeter at a Glance
Vsense indicator
Keypad
Rotary switch
LED flashlight
Battery cover
Tilt stand
Display screen
Input terminals
Test lead/probe holders
IR communication port
(U1233A only)

U1231A/U1232A/U1233A Handheld Multimeter
Understanding the Rotary Switch
4 U1231A/U1232A/U1233A Quick Start Guide
Understanding the Rotary Switch
NOTE
Some rotary switch positions have a shifted function printed in
orange. Press to switch between the shifted and regular
function.
Legend Functions shown in the primary display
Low input impedance — VZLOW Auto (AC or DC)/
VZLOW DC V/VZLOW AC V for eliminating ghost voltages
AC V/Frequency
DC V
Resistance/Short continuity/Open continuity[1]
Diode
Capacitance/Temperature (U1233A only)
Capacitance/Auxiliary Temperature (U1232A only)
Capacitance (U1231A only)
DC or AC A/Frequency
DC or AC μA/Frequency
Clamp-on AC or DC A/Frequency (U1231A only)
Auxiliary Temperature (U1231A only)
[1] Open continuity option must be enabled through the multimeter’s Setup
( > ). Open continuity is disabled by default.
WARNING
Remove the test leads from the measuring source or
target before changing the rotary switch position.
Refer to the U1231A/U1232A/U1233A User’s Guide for a
complete list and description of all rotary switch labels for
each separate multimeter model.
Shift
Esc
Hz
AUX
Hz
Hz
AUX
Hz
AUX

U1231A/U1232A/U1233A Handheld Multimeter
Understanding the Keypad
U1231A/U1232A/U1233A Quick Start Guide 5
Understanding the Keypad
Understanding the Input Terminals
Legend Key response when pressed for:
Less than 1 second More than 1 second
Sets the null/relative mode Enters the Hold-Log Recall
menu
Starts the MaxMin recording Stops the MaxMin recording
Sets a manual range Enables autoranging
Freezes and stores the present
reading in the
display
Automatically freezes the pres-
ent reading
once the reading is stable
Turns the LCD backlight on or
off.
Turns the LED flashlight on or
off.
Switches between the regular
and shifted (icons printed in
orange) functions
U1233A only: Enables the
non-contact voltage detector
(Vsense).
Null
Recall
Max
Min
Auto
Range
Auto
TriHold
g
Log
Shift
Esc
Rotary position for
U1232A and U1233A Input terminals Overload protection
600 Vrms
600 Vrms for
short circuit <0.3 A
11 A/1000 V,
fast-acting fuse
Hz
AUX
Hz
Hz

U1231A/U1232A/U1233A Handheld Multimeter
Understanding the Input Terminals
6 U1231A/U1232A/U1233A Quick Start Guide
Non-contact voltage detector (Vsense)
WARNING
Voltage could still be present even if there is no alert
indication. Do not rely on the Vsense detector with
shielded wire. Never touch live voltage or conductor
without the necessary insulation protection.
The Vsense detector may be affected by differences in
socket design, insulation thickness, and insulation type.
2
AC
Voltage source
Shift
Esc
1
> 1 s
3
NOTE
Press to change the Vsense detector’s sensitivity from
Hi.SE (high sensitivity) to Lo.SE (low sensitivity).
Auto
Range

U1231A/U1232A/U1233A Handheld Multimeter
Performing Measurements
U1231A/U1232A/U1233A Quick Start Guide 7
Performing Measurements
AC voltage measurements
DC voltage measurement
AC
4
1
3
Voltage source
2
Hz
2
DC
3
Voltage source

U1231A/U1232A/U1233A Handheld Multimeter
Performing Measurements
8 U1231A/U1232A/U1233A Quick Start Guide
Resistance measurement
Continuity test
4
1
3
Resistor
2
Shift
Esc
2
ON
(closed)
OFF
(open)
3
Press again to switch
between testing for shorted ( ) or
open ( ) contacts.
Shift
