Keystone BFC Series Manual

BACnet Flow Controller for
Fan Filter Units
BFC Series
v001 – Issue Date: 08/30/22
© 2022 Keystone Clean Air Solutions. All rights reserved.
INSTALLATION + SERVICE MANUAL

For more information visit KeystoneCleanAir.com v001
2
BACnet Flow Controller for Fan Filter Units | Table of Contents
Product Overview
General Information ............................................................1
Installation & Mounting Instructions
Typical Wiring.......................................................................2
Input/Output Description ...................................................2
Display Navigation
Initial Startup ........................................................................3
Main Menu ............................................................................4
Service Menu........................................................................5
Service Menu – Fan ............................................................6
Service Menu – Filter..........................................................7
Service Menu – I/O .............................................................8
Service Menu – BACnet .....................................................9
Service Menu – Diagnostics .............................................9
Filter Calibration
Filter Calibration using BFC Interface............................10
Filter Calibration over BACnet.........................................11
Networking & Setup
BACnet Wiring ....................................................................12
Termination ........................................................................12
Electrical Noise ..................................................................12
Network Wire Specications ...........................................13
BACnet Service Menu .......................................................14
BACnet Networking and Setup .......................................15
Setting the Device Instance (Coupled MAC and DI) ...16
Setting the Device Instance (De-coupled MAC and
DI) .........................................................................................17
Network Layout..................................................................18
Package/Component Identication...............................20
Location...............................................................................21
Mounting .............................................................................22
BAS Input Signal ................................................................23
Analog RPM Feedback .....................................................24
Wiring and Cables..............................................................25
Maintenance
Troubleshooting.................................................................26
Specications.....................................................................27
BACnet points list for BFC rmware v3.1.0..................28

For more information visit KeystoneCleanAir.comv001
3
BACnet Flow Controller for Fan Filter Units | Product Overview
General Information
The BACnet Flow Controller (BFC) is a DDC fan controller designed specically for controlling ow through Krown Fan Filter
Units with EC motor technology. The BFC controls an EC motor through a local setpoint which is adjustable using a push
button interface on the BFC, by an analog BAS input voltage, or over BACnet.
In addition to fan control, the BFC can monitor lter pressure drop, lter loading, signal for lter changes, monitor the motor
and lter lifetime in hours, as well as report airow and air temperature over the lter. This information can be viewed from
the LCD screen on the front of the BFC controller, or over BACnet on a building management system.
Back of BFC Controller
Front of BFC Controller
1
34
1
2
3
4
Service Port RJ12 Jack
BACnet Connection RJ45
Jacks
Up and Down arrow buttons
for navigation
Menu button for info
menu and entering Service
menus
22
7
8
4
3
11
5
6
9
10
1
2
Service Port RJ12 Jack
BACnet Connection RJ45
Jacks
24 VAC Power Connection
Pressure Transducer
0-10 VDC Analog Outputs
24 VAC Binary Outputs
Contact Closure
Analog Inputs
Thermistor Input
Motor #1 Jack
BACnet MS/TP Terminals
55
6
12
23
4
10
11
789

For more information visit KeystoneCleanAir.com v001
4
BACnet Flow Controller for Fan Filter Units | Installation Instructions
Typical Wiring
Input/Output Description
Analog Outputs
AO1
Congurable for Unit Pressure, CFM (Air Flow), RPM (Mo-
tor Speed), Filter Load , BAS, *LED Dimming, *LED On/
Off (*for Krown-L w/ BACnet Dimming Control)
AO2
Congurable for Unit Pressure, CFM (Air Flow), RPM (Mo-
tor Speed), Filter Load , BAS, *LED Dimming, *LED On/
Off (*for Krown-L w/ BACnet Dimming Control)
AO3
Congurable for Unit Pressure, CFM (Air Flow), RPM (Mo-
tor Speed), Filter Load , BAS, *LED Dimming, *LED On/
Off (*for Krown-L w/ BACnet Dimming Control)
24 VAC Binary Outputs
BO1 Red LED out
BO3 Green LED out
COM COMMON
Analog Inputs
AI1 Input voltage for remote fan speed control
AI2 Input voltage for LED control (*for Krown-L w/ BACnet Dimming Control)
Inputs
Thermistor Input Analog input for monitoring air over lter
temperature, 10k type J thermistor
Contact Closure Binary input to activate secondary ECM setpoint.

For more information visit KeystoneCleanAir.comv001
5
BACnet Flow Controller for Fan Filter Units | Display Navigation
Initial Startup
When the BFC controller is powered up with 24VAC it will display the following information.
KEYSTONE
ELECTRONICS Start–up screen
BFC
VERSION Displays rmware version
CURR
PRESSURE Displays the current static pressure in in. w.g.
ECM SETPOINT Displays ECM setpoint in % motor speed
UNIT STATUS Displays current unit status (Off, Low Pressure, Normal, Filter Loaded)
CONTROL MODE Displays the current control mode (BACnet, BAS, Local Control)
CURRENT CFM Displays the current airow (only visible with the Constant Flow motor program)
*LCD display will cycle between Curr Pressure, ECM Setpoint, Unit Status, Control Mode, and Current CFM during normal
operation.
Change ECM motor setpoint using and arrow keys
LOCAL ECM
58% Setpoint will save after being adjusted with arrow keys
NOTE: Local setpoints are stored to EEPROM and will remain set after power failures.

For more information visit KeystoneCleanAir.com v001
6
BACnet Flow Controller for Fan Filter Units | Display Navigation
Main Menu
From the Home Screen press the Menu button to enter this menu. Use Up and Down arrow buttons to navigate through.
FILTER LOAD Read Only - Displays % of lter loading based on new, clean lter pressure drop
ECM SPEED Read Only - Displays the current RPM of the motor
LOCAL ECM Displays local ECM Setpoint.
Press the Menu button then use the arrow keys to change the ECM Setpoint. Press menu again to save.
LOCAL DIMMING Displays local LED Dimming Setpoint (for Krown-L w/ BACnet Dimming Control).
Press the Menu button then use the arrow keys to change the Dimming Setpoint. Press Menu again to save.
MAC ADDRESS Read Only - Displays device MAC Address
DEVICE INST Read Only - Displays device Instance
PRESS MENU
TO EXIT
NOTE: Local setpoints are stored to EEPROM and will remain set after power failures.

For more information visit KeystoneCleanAir.comv001
7
BACnet Flow Controller for Fan Filter Units | Display Navigation
Service Menu
Hold down Menu button for 5 seconds, display will show ‘Passcode’. Use Up and Down arrow buttons to enter this sequence:
Down, Up, Up, Down.
SERVICE MENU
FAN
Allows you to see or adjust:
Current CFM
CFM Offset
CFM Tweak
ECM Setback
Fan Type
Unit Size ie. 2X2
Wheel Type
Voltage Type
Motor Runtime (in hours)
Reset Motor Runtime
SERVICE MENU
FILTER
Filter Load
Load Trip
Current Pressure
Filter Type
Filter Runtime (in hours)
Reset Filter
SERVICE MENU
I/O
Analog In 1 (BAS ECM SP)
Analog In 2 (BAS LED SP)
Analog Out 1 (Present Value)
Analog Out 1 (AO1 Usage)
Analog Out 2 (Present Value)
Analog Out 2 (AO2 Usage)
Analog Out 3 (Present Value)
Analog Out 3 (AO3 Usage)
SERVICE MENU
BACNET
MAC Address
Device Instance
Baud Rate
RS-485 Termination
BACnet Reset
SERVICE MENU
DIAGNOSTICS
Restore Defaults
Total Device Reset
Factory Conguration Reset

For more information visit KeystoneCleanAir.com v001
8
BACnet Flow Controller for Fan Filter Units | Display Navigation
Service Menu – Fan
Press Menu button to enter this menu. Use Up and Down arrow buttons to navigate through.
CURRENT CFM
XXXX CFM Read Only
UNIT STYLE Supply, Exhaust
NOTE: Must match actual conguration of Krown Fan Filter Unit
UNIT SIZE
2X2
Displays the ECM motor calibration for Krown Fan Filter Unit nominal size (2x2)
Selectable sizes are: 2’ x 2’, 2’ x 3’, 2’ x 4’
NOTE: Must match actual conguration of Krown Fan Filter Unit.
WHEEL TYPE
XXX
Adjust unit wheel type from FC to BC. Read only varying on fan type and unit size
The wheel type is factory set, but it can be adjusted only under the Constant Torque setting. From there, you
can set the wheel type to BC on 2’ x 3’ and 2’ x 4’ units only.
NOTE: BC wheel type is for Constant Torque only.
VOLTAGE TYPE
XXX Adjust unit voltage type from 115/240/277.
MOTOR PROGRAM
XXX
Adjust fan type from Constant Volume to Constant Torque. Airow (CFM) will be hidden if fan type is constant
torque
MOTOR RUNTIME
0 HRS Read Only – Displays number of hours on motor since last reset
RESET MOTOR
RUNTIME Resets Motor Runtime
CFM OFFSET
0 CFM
Adjust airow reading +/- up to 500 CFM to coincide with balancer measured airow
Example: ow hood reads 550 CFM
Airow reading on BFC is 500 cfm
Adjust CFM offset to +50 CFM
CFM TWEAK
100 %
Adjust airow reading between 50 to 200%
Example: ow hood reads 550 CFM
Airow reading on BFC is 500 cfm
Adjust CFM tweak to +110%
ECM SETBACK Secondary setpoint for use in turndown or night setback applications. This is activated upon contact closure.
PRESS MENU
TO EXIT

For more information visit KeystoneCleanAir.comv001
9
BACnet Flow Controller for Fan Filter Units | Display Navigation
Service Menu – Filter
Press Menu button to enter this menu. Use Up and Down arrow buttons to navigate through.
FILTER TYPE
XXX
Adjust lter type, BTR, RSR.
BTR = Bench Top Removable RSR = Room Side Removable
FILTER LOAD
XX % Read Only - Displays % of lter loading based on new, clean lter pressure drop
LOAD TRIP
1.50
This read only value represents the ratio between clean and loaded lter pressure. It is factory set for 1.5
times the clean lter pressure and is not eld adjustable.
Example: If the lter calibrated pressure is 0.16 in. w.g., the loaded lter pressure will be 0.24 in. w.g.
FILTER RUNTIME
0 HRS Read Only – Displays number of hours on lter since last reset
RESET
FILTER
Resets Filter Runtime.
Activate this to calibrate lter pressure during initial setup or lter replacement.
PRESS MENU
TO EXIT

For more information visit KeystoneCleanAir.com v001
10
BACnet Flow Controller for Fan Filter Units | Display Navigation
Service Menu – I/O
Press Menu button to enter this menu. Use Up and Down arrow buttons to navigate through.
BAS (AI1)
0 VDC Read Only – Displays current input BAS voltage for motor speed control
AI2 (BAS LED)
0 VDC Read Only – Displays input voltage to Analog Input 2 for LED control (UFFU w/ BACnet Dimming Control only)
CONTACT CLOSURE Displays current state of binary contacts used for night setback / secondary ECM setpoint (open / closed)
AO1 USAGE
FILTER LOAD
(DEFAULT)
Congure Analog Output 1 for:
Unit Press - Unit Pressure; Range (0 in. w.g. to 2 in.w.g.)
CFM - Airow; Range (0 - 5000 CFM)
RPM - Range (0 - 2500 RPM). See page 11 for RPM details.
Filter Load - Range (0 - 100%)
BAS - 0-10VDC signal to BAS
LED Dimming (0 - 100%)
LED On/Off (Changes autonomously Based on LED Dimming value)
Disabled
AO1 PRESVAL
0 VDC Read Only - Present Value for Analog Output 1
AO2 USAGE
UNIT PRESSURE
(DEFAULT) Congure Analog Output 2 same as AO1 options shown above.
AO2 PRESVAL
0 VDC Read Only - Present Value for Analog Output 2
AO3 USAGE
BAS (DEFAULT) Congure Analog Output 3, same as AO1 options shown above.
AO3 PRESVAL
0 VDC Read Only - Present Value for Analog Output 3
PRESS MENU
TO EXIT

For more information visit KeystoneCleanAir.comv001
11
BACnet Flow Controller for Fan Filter Units | Display Navigation
Service Menu – BACnet
MAC ADDRESS
1
Sets unit’s MAC address
NOTE: the MAC address (range 1-99) is added to the device instance.
Example: MAC address = 1, device instance = 100, total address for this BFC would be 101
DEVICE INST
0, 000, 101
This is the ‘software’ BACnet address and must be unique to your building site.
Range: 1 – 4,194,303
BAUD RATE
76800
BAUD RATE
This sets the BACnet MS/TP baud rate
9600 baud (all BACnet devices must at least support this speed) – slowest
19200 baud
38400 baud
76800 baud (default baud rate for Keystone products) - fastest
RS-485 TERM,
DISABLED Enable and disable RS-485 termination on MS/TP segment.
RESTORE BACNET
DFLTS Reset MAC Address, Device Instance, and BAUD rate to default values.
PRESS MENU
TO EXIT
Service Menu – Diagnostics
RESTORE
TTLDEV RESET
Full device reset, removes all order information including unit conguration. Does not change any BACnet
settings.
RESTORE
FACTORY CONFIG Resets device to factory settings without changing any BACnet settings.
PRESS MENU
TO EXIT

For more information visit KeystoneCleanAir.com v001
12
BACnet Flow Controller for Fan Filter Units | Filter Calibration
Filter Calibration
To properly track lter loading, the BFC must be calibrated with the clean lter pressure. Before proceeding, ensure the unit is
operating at the desired airow. Any changes to the airow will change the unit pressure and therefore require the lter status
to be reset. For further information on airow balancing please refer to the Krown Fan Filter Unit Manual. Filter calibration
can be performed either directly through the BFC interface or over BACnet. Each method is described below.
Using the BFC Interface
Step 1: To calibrate clean lter pressure drop, scroll through the ‘Service Menus’ until reaching ‘Filter’. Select this menu by
pressing the ‘Enter/Menu’ button (far right).
NOTE: To enter the Service Menu, hold down the ‘Enter/Menu’ button for 5 seconds. Display will show ‘Passcode’. Use
the Up and Down arrow buttons to enter this sequence:
Down, Up, Up, Down.
Step 2: Scroll through the ‘Filter’ menu until reaching ‘Reset Filter’, select by pressing the ‘Enter/Menu’ button.NOTE: Make
sure the area directly beneath and around the unit is clear of any personnel or equipment as this can affect the
reading of the clean lter static pressure.
Step 3: Press the ‘Enter/Menu’ button to conrm reset of lter; this will begin calibration. This will take approximately 2
minutes.
After lter calibration is complete, LCD will display:
‘RESET COMPLETED’.
Filter Reset Screen Filter Calibration Screen

For more information visit KeystoneCleanAir.comv001
13
BACnet Flow Controller for Fan Filter Units | Filter Calibration
Via BACnet
The steps below require the BFC to be congured and set up on a BACnet front-end system.
For further information on BFC BACnet setup, see Networking & Setup section.
Step 1: Ensure that BACnet point AV2 – Filter Runtime is being pulled in (see table below).
Step 2: Write a value of 0 to AV2 – Filter Runtime. This will initiate a calibration cycle. The current unit pressure (AI5) will be
automatically be copied to the Filter Calibrated Pressure (AV5). This process takes approximately 2 minutes.
NOTE: Filter loading can subsequently be monitored using BACnet point: AV1 – Filter Load (from 0% clean to 100%
loaded).
Object Name Units Default Range Description R/W
AI5 Unit Pressure in. w.g. Dynamic Dynamic Current differential pressure measured across the lter R
AV1 Filter Load % 0 0-100% Current percent of lter loading based on new, clean lter
pressure drop R
AV2 Filter Runtime Hours 0 0-99999 Current number of hours on lter since last reset. Enter value
of zero after lter has been replaced to perform calibration. R/W
AV3 Motor Runtime Hours 0 0-99999 Current number of hours on motor since last reset R
AV4 Airow cfm N/A 0-9999 Current airow R
AV5 Filter Calibrated
Pressure in. w.g. N/A Dynamic Unit pressure when lter was calibrated R
AV6 Filter Trip Pressure in. w.g. 0 Dynamic Filter trip pressure R
AV7 Filter Loading Trip
Point Numeric 1.5 1-3 Factory set lter loading trip point R

For more information visit KeystoneCleanAir.com v001
14
BACnet Flow Controller for Fan Filter Units | Networking & Setup
From Previous
Device
To Next
Device
BACnet Wiring
BACnet Wiring
The Keystone BACnet Flow Controller (BFC) has the
option of using a CAT 5 cable to run BACnet MS/TP, or
cable hardwired into a pluggable terminal block (see
next page if using hardwired BACnet connections). The
RJ-45 jacks for use with the supplied BACnet cables
are directly tied to the pluggable terminal block, and
so any combination of supplied cables and hardwired
connections can be used on a single network segment.
BACnet networks must be run in a daisy chain
conguration, meaning there is only one main cable and
each network device is connected directly along its path,
with no more than 30 devices per segment, and MS/TP
segment lengths must not exceed 1050 feet.
Termination
BACnet MS/TP networks must be terminated to ensure
proper operation. A network should be terminated twice,
once at the beginning and once at the end. Termination
helps reduce reections and noise. The terminating can
be done with a 100 ohm resistor across the + and - lines.
Termination can also be done via software using the
Keystone BACnet Flow Controller. For more information
see the BACnet Service Menu section of this manual.
Tech Tip: The BACnet MS/TP to IP Router supplied by
Keystone has built in termination and it is enabled by
default (since the router is typically the beginning of the
entire MS/TP network). Now you only have to go and nd/
terminate that last device.
Electrical Noise
Electrical noise can affect both analog signal and digital
communications such as BACnet. Therefore do not route
high voltage lines next to the BACnet network! Avoid
noisy electrical sources such as:
•Variable Frequency Drives
•High current power lines
(main panel feeds)
•Fluorescent light xtures
If you must pass near noisy electrical lines cross at right
angles. This will help reduce the amount of noise coupled
to the network wires.
Electrical Noise Example
High voltage/
current line
BACnet
network

For more information visit KeystoneCleanAir.comv001
15
BACnet Flow Controller for Fan Filter Units | Networking & Setup
Use Keystone supplied CAT-5 cables for BACnet
whenever possible. If not possible to use Keystone
supplied cables, follow these wire specications.
Network Wire Specications
For the BACnet MS/TP network specic wire is required.
Do not use standard power or “thermostat” wire. This
wire does not have the necessary requirements for
digital communications. While it’s possible it may work
(temporarily) the network will be unreliable and not
operating at optimal performance.
BACnet MS/TP Wire type recommendations
•Use 2 balanced twisted pairs, one for + and -, one for
NET COM
•Low capacitance (17pF or less)
•Plenum rated (FT6, CMP ratings)
•100-120 ohm, Balanced
•(CAT5, CAT5E, CAT6 network cable has excellent
specifications and will work in almost any BACnet
MS/TP application.)
•Keystone controllers use the Orange Compliment
for (+), the Orange for (-), and the Brown and Brown
Compliment together for the (NETCOM)
connections. These are paired in a standard CAT5E
cable. Pre-terminated CAT5 cables are available from
Keystone (35 ft plenum rated cable, terminated with
RJ45 plugs, 568-B standard).
PIN 1
PIN 3
PIN 5
PIN 7
PIN 2
PIN 4
PIN 6
PIN 8
Wiring
Use RJ45 jacks for BACnet connection, or 3 position
terminal block for 3-wire connection (+, -, NET COM) NET
COM must be wired.
Pre-terminated CAT5 cable

For more information visit KeystoneCleanAir.com v001
16
BACnet Flow Controller for Fan Filter Units | Networking & Setup
BACnet Service Menu
Each controller’s MAC address, Device Instance, and Baud rate are set in the BACnet sub-menu of the service menu accessed
through the LCD screen on the face of the BFC. For information on how to select a MAC address and Device instance for any
controller on a network, see following pages.
To set the controller’s BACnet settings, enter the Service Menu and adjust settings as follows:
NOTE: When the screen displays a ashing value, that value is ready to be changed and can be adjusted by pressing the
arrow keys. Pressing Menu will save the value.
Hold down the Menu button on the LCD Thermostat for
5 seconds until prompted for a passcode; use and
to enter the passcode; DOWN, UP, UP, DOWN.
The screen will now display “SERVICE MENU: FAN”
Scroll down to the BACnet sub-menu.
Press the Menu button to enter this menu.
Screen will now show “MAC ADDRESS = 1”. This is the
default setting and can be programmed between 1 and 99
by pressing Menu and using the UP and DOWN arrows
( ).
Use to scroll to whatever MAC you are intending to
set this controller to, once you arrive at the number, press
Menu to save
Note: By default, the MAC address will appear as the last
2 digits of the device instance.
5 SECONDS
THEN
SERVICE MENU:
FAN
THEN
SERVICE MENU:
BACNET
MAC ADDRESS THEN
The device instance defaults to 100, but will be displayed
with the last 2 digits as the MAC if the previous screen
was set to enabled. Press Menu then use the arrow keys
to change the device instance.
NOTE: Each Menu press will change allow changes in
different tiers of the device instance (so that you don’t
have to scroll for extended periods to get into the millions
range – supposing that’s where you need to set your
device instance)
The baud rate is the speed that the MS/TP network runs
at. EVERY device on the network must run at the same
speed. Keystone controllers are defaulted to a baud rate
of 76800, but can be changed to 38400, 19200, or 9600.
For a network segment with all Keystone controllers, it’s
recommended that the baud rate be left at 76800.
*Choose lower baud rates only when integrating with
devices by other manufacturers whose maximum speed
is lower than 76800 (eg. 38400).
THEN
THEN
OR
OR
DEVICE INST.
101
BAUD RATE
76800
Once all settings are made scroll down to the ‘Press Menu to Exit’ screen and press Menu. The controller will then re-start
which will save these values.

For more information visit KeystoneCleanAir.comv001
17
BACnet Flow Controller for Fan Filter Units | Networking & Setup
BACnet Networking and Setup
Setting the MAC Address:
MAC (media access control) must be UNIQUE on an MS/TP network segment within building. An installer setting up an MS/
TP segment must ensure each device has a UNIQUE MAC Address (Range 1-99). The MAC Address is set through the LCD
thermostat or LCD setup tool.
NOTE: Each device on a network segment must be set to run at the same speed or baud rate.
Network segment #1
Network segment #2
TECH TIP
NET COM
NET COM
NET COM
NET COM
TECH TIP
24 VAC power HOT and COMMON polarities are critical and must not be reversed on ANY devices! Reverse polarity will stop
communication on that MS/TP segment. All 24 VAC transformers must be grounded on their secondary side for BACnet to
work.
NET COM wire must be connected at each device and is critical for BACnet network reliability.
Use one twisted pair for + and -, and another twisted pair for NET COM for optimal noise cancellation.

For more information visit KeystoneCleanAir.com v001
18
BACnet Flow Controller for Fan Filter Units | Networking & Setup
Setting the Device Instance (Coupled MAC and DI)
Device Instance:
A Device Instance number identies a device within an entire building, therefore giving it a unique number or Address,
much like a telephone ext. number. A building can have one telephone number, but all the extensions have a unique
number to identify them. A Device Instance number would work the same way and must be unique throughout the building.
Below is a table dening how a Device Instance number is obtained.
NOTE: Each device on a network segment must be set to run at the same speed or baud rate.
Description Default Value (Factory) Notes
MAC Address 6 Value: limited to 1-99
Tier 1 (x100) 58 Value: limited to 0-99
Tier 2 (x10,000) 1Value: limited to 0-99
Tier 3 (x1,000,000) 0 Value: limited to 0-4
Example Device Instance setup with Default settings:
• MAC Address = 6 (6 x 1 = 6) – Set through software
+
TIER 1 = 58 (58 x 100 = 5800) – Set through software
+
TIER 2 = 1 (1 x 10,000 = 10,000) – Set through software
+
TIER 3 = 0 (0 x 1,000,000 = 1,000,000) – Set through software
=
Final Device Instance = 0,015,806
0 01 58 06
Tier3
Multiplier
Tier2
Multiplier
Tier1
Multiplier
MAC
Address

For more information visit KeystoneCleanAir.comv001
19
BACnet Flow Controller for Fan Filter Units | Networking & Setup
Setting the Device Instance (De-coupled MAC and DI)
Device Instance:
A Device Instance number identies a device within an entire building, therefore giving it a unique number or Address, much
like a telephone ext. number. A building can have one telephone number, but all the extensions have a unique number to
identify them. A Device Instance number would work the same way and must be unique throughout the building.
Below is a table dening how a Device Instance number is obtained.
NOTE: Each device on a network segment must be set to run at the same speed or baud rate.
Description Example Value Notes
Tier 1 (x01) 4 Value: limited to 1-99
Tier 2 (x100) 58 Value: limited to 0-99
Tier 3 (x10,000) 1Value: limited to 0-99
Tier 4 (x1,000,000) 0 Value: limited to 0-4
Example Device Instance setup with Default settings:
• TIER 1 = 4 (4 x 1 = 4) – Set through software
+
TIER 2 = 58 (58 x 100 = 5800) – Set through software
+
TIER 3 = 1 (1 x 10,000 = 10,000) – Set through software
+
TIER 4 = 0 (0 x 1,000,000 = 1,000,000) – Set through software
=
Final Device Instance = 0,015,806
0 01 58 04
Tier4
Multiplier
Tier3
Multiplier
Tier2
Multiplier
Tier1
Multiplier

For more information visit KeystoneCleanAir.com v001
20
BACnet Flow Controller for Fan Filter Units | Networking & Setup
Network Layout
The BFC can be connected over BACnet MS/TP and added to an existing BAS front end system. Keystone also offers its own
mini front-end system known as Krown-CS which acts as a graphics package. The Keystone WEB Server allows the user to
view variables such as lter status, CFM, etc. for each Krown Fan Filter unit and modify setpoints as needed.
Devices
Webserver: Provides the graphical web interface, plugs into IP Router. 2000 node capacity.
IP Router: Acts as interface between Internet and internal system. 5 ports. 1 Port for Building WAN (Internet/Building
Network – You cannot plug a BACnet Router or IP Switch into this port). 4 LAN Ports available (Used for BACnet Routers and
IP Switches).
BACnet Router: Interfaces between BACnet MS/TP system and IP Router (internet). Supports 30 Krown Fan Filter Units.
IP Switch: Expands available connections for BACnet router. 5 ports.
Connection example (less than 30 units)
BACnet MS/TP
to BACnet IP
Router
Krown 1 Krown 2 Krown 3
Krown 30 Krown 4
Network
Connection
IP Router
Webserver Interface
FFU 1
CFM- 312
FIlterHours - 1280
FilterStatus - Clean
ANTEROOM
FFU 2
CFM- 310
FIlterHours - 1125
FilterStatus - Clean
FFU 3
CFM- 312
FIlterHours - 1225
FilterStatus - Replace
FFU 4
CFM- 310
FIlterHours - 1300
FilterStatus - Clean
FFU 5
CFM- 312
FIlterHours - 1430
FilterStatus - Clean
FFU 6
CFM- 315
FIlterHours - 1400
FilterStatus - Replace
FFU 7
CFM- 312
FIlterHours - 1350
FilterStatus - Clean
Webserver
