USER MEDIA GATEWAY E1, VOIP, GSM, FXS AND FXO
UMG MODULAR 300
Main Characteristics
Modular, according to the scenary which will be used
2 Ethernet Giga ports
VoIP channels: 1 SIP channel for each TDM channel
adding up to the maximum of 46 SIP channels.
Modularity: 3 slots for the desired combination, not
exceeding 46 channels:
• 1 E1 (30 channels)
• 2 GSM (up to 6 GSM channels) 2G or 3G
• 4 FXO (up to 12 FXO)
• 8 FXS (up to 24 FXS)
Typical Applications
Gateway and routing between the TDM and SIP
interfaces.
Ideal for VoIP carriers in the process of expansion.
Application for the corporate market.
Ideal for call routing between branch and headquarter
via IP network.
Ideal for VoIP operators selling minutes for professional
services.
Overview
UMG Modular 300 is an user media gateway of the Khomp gateway lineup. This intermediate device is able to
translate the telephony signaling protocols E1 (ISDN and R2) and SIP while supporting the GSM, FXS and FXO technologies,
thus interconnecting the digital, analogical, mobile and IP networks to the telephony and communication unified platforms,
based on SIP.
Developed to be used in small-sized scenarios in the expansion process, with high-performance assurance, this
modular equipment makes available 46 channels, divided in 3 slots in order to combine the interfaces which are more
convenient to the model of business in which it will be applied. Moreover, its has a size that makes it easy to install as well as
an user friendly web interface for its configuration and monitoring
With a robust architecture based on DSP dedicated to handling telephony critical tasks, as well as features for
signaling and cancelling echoes, resulting in high quality audio, the UMG Modular 300 can be seen as an extremely effective
gateway. It also features transcoding support in all channels as well as support to the main signaling and CODEC system in the
industry, in addition to providing call control and routing, according to the programmed rules.

Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | [email protected]
UMG MODULAR 300
Characteristics and Benefits
Trunk support
E1
1 link (30 channels. Usage may be fragmented.)
ISDN or R2 signalling
Limit of 30 E1 channels
GSM
2 channels per module
3G Six Band: 800/850/900/1700/1900/2100 MHz
OR
2G Quad Band: 850/900/1800/1900 MHz
Limit of 6 GSM channels
FXO
4 channels per module
RJ11 connector
Ring Min Sensor 12 VRMS@ 14Hz-70Hz
Limit of 12 FXO channels
FXS.
8 channels per module
RJ45 connector
Ring voltage 54Vpp / 25Hz
Limit of 24 FXS channels
VoIP.
1 VoIP channel for each TDM channel adding up to
the maximum of 46 VoIP channels
SIP signalling
Support for up to 10 SIP accounts
Transcoding
Software specifications
SNMP support and monitoring
oCall routing per prefix
oFidelization per carriers
Ticketing per customizable CDR (Call Detail
Record)
Generation of logs for diagnosis purpose
Status of E1 link
Detailed diagnostics of the E1 link
Configuration Interface
Supported protocols
oSession Initiation Protocol (SIP)
oSimple Network Management Protocol
(SNMP)
Supported CODECs
oG.711 (A-law & µ-law)
oG.729A (Maximum limit of 30 channels)
Voice quality
oEcho canceling
oSIP-dedicated processing
Support to FAX in pass-through mode
Web Portal
Monitoring
oDashboard
oE1 Link
oPhysical channels
oVoIP channels
Configuration
oRouting by prefix
oAdvanced routing by regular expressions
oE1 Link
oVoIP accounts
oGSM accounts
oFXS accounts
oFXO accounts
oCustomizable CDR
System diagnosis and debugging by means of log
messages
Management
oSystem maintenance.
oDevice configuration provisioning (exporting
and importing)
oDevice restart
oAdmin user password change
oSystem date and time setting
oDevice network configuration
Physical characteristics
Power Source:
oInput: 100-240V 50/60 Hz
oOutput 12V/2.5A
Dimensions: 4.5 (height) x 21.1 (width) x 18.2 (length)
Connections
o2 Gigabit network ports: 100/1000 Base-T
network port
oPolarized power source connector 12VCC
o3 slots which may contain VOIP, GSM, FXS
and FXO channels according to the
modularity.
Equipment status LED
E1 Link status LED
Error warning LED
Reset/restore button
OLED graphic display (optional)
Warranties and Certifications
Factory warranty 3 years
ISO 9001:2008-certified company

Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | [email protected]
UMG MODULAR 300
Friendly web interface
UMG Modular 300 has a friendly web interface for system monitoring, configuration, diagnosis and management. This allows for
time optimization and greater autonomy for the user.
Generation of logs for diagnosis
Logs may be accessed through the web interface, expediting the problem diagnosis and, consequently, the solution.
Routing and Fidelization
Increased cost control with the possibility of routing configuration by prefix and/or by carrier fidelization.
Efficient Architecture
UMG Modular 300 is a compact and efficient system, which can be broken down into three basic parts.
A CPU board, responsible for routing calls, for providing access to the configuration and monitoring portal, and for to
all the high level resources of the equipment.
Three telephony modules, responsible for the access to the telephony interfaces, according to its modularization, and
also for performing the real-time critical tasks.
Two Ethernet Giga network ports, responsible for the integration of the system and for all management of IP traffic,
including VoIP.
Fitting your business
With UMG Modular 300 you can decide which technologies will be part of your composition, according to the business the
device will be applied to, with a limit of 46 SIP channels. There are 3 available slots. Considering that, for instance, 1 slot is
used for E1 (30 channels), the two remaining ones can be used for the GSM technology (with 4 channels), or they can also be
used for FXO (with 8 channels), or 2 FXS (adding up to16 channels).
Additional product images
UMG Modular 300 DY -
with optional display.

Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | [email protected]
UMG MODULAR 300
Examples of system screens
Rear view without telephony interfaces.
Monitoring screen.
Rear view with 1 E1, 8 FXS, and 4 FXO.

Rua Joe Collaço, 253, Florianópolis, SC | CEP 88037-010 | Brasil (+55 48) 3722.2900 | [email protected]
UMG MODULAR 300
Configuration screen
Diagnostics screen
