Kia Carens 2022 User manual

FOREWORD
Dear Customer,
Thank you for selecting your new Kia vehicle.
As a global car manufacturer focused on building high-quality vehicles with excep
-
tional value, Kia is dedicated to providing you with a customer service experience that
exceeds your expectations.
An authorised Kia dealership where factory-trained technicians, recommended spe
-
cial tools, and genuine Kia replacement parts are provided can help if you need tech -
nical assistance.
This Owner's Manual will acquaint you with the operation of features and equipment
that are either standard or optional on this vehicle, along with the maintenance needs
of this vehicle. Therefore, you may find some descriptions and illustrations not appli -
cable to your vehicle. You are advised to read this publication carefully and follow the
instructions and recommendations. Please always keep this manual in the vehicle for
your, and any subsequent owner's, reference.
All information contained in this Owner's Manual was accurate at the time of pu blica
-
tion. However, as Kia continues to make improvements to its products, the company
reserves the right to make changes to this manual or any of its vehicles at any time
without notice and without incurring any obligations.
Please drive safely, and enjoy your Kia vehicle!
© 2022 Kia India Private Limited
All rights reserved. May not be reproduced or translated in whole or in part without the written consent of Kia
India Private Limited (formerly known as Kia Motors India Private Limited).
Printed in India
KYi
_
STD
_
India
.
book
Page
1
Thursday
,
January
6
,
2022
8:35
PM

KYi
_
STD
_
India
.
book
Page
2
Thursday
,
January
6
,
2022
8:35
PM

3
1
1
How to use this manual
We want to help you get the greatest
possible driving pleasure from your
vehicle. Your Owner's Manual can assist
you in many ways.
We strongly recommend that you read
the entire manual. In order to minimise
the chance of death or injury, you must
read the WARNING and CAUTION sec
-
tions in the manual.
Illustrations complement the words in
this manual to best explain how to enjoy
your vehicle. By reading your manual,
you learn about features, important
safety information, and driving tips
under various road conditions.
The general layout of the manual is pro
-
vided in the Table of Contents. Use the
index when looking for a specific area or
subject, it has an alphabetical listing of
all information in your manual.
Chapters: This manual has nine
chapters plus and index and the "Kia
Warranty Policy". Each chapter begins
with a brief list of contents so you can
tell at a glance if that chapter has the
informa - tion you want.
You will find various WARNINGS, CAU -
TIONS, and NOTICES in this manual.
These WARNINGS were prepared to
enhance your personal safety. You
should carefully read and follow ALL
procedures and recommendations pro -
vided in these WARNINGS, CAUTIONS
and NOTICES.
WARNING
A WARNING indicates a situation in
which harm, serious bodily injury or
death could result if the warning is
ignored.
CAUTION
A CAUTION indicates a situation in
which damage to your vehicle could
result if the caution is ignored.
NOTICE
A NOTICE indicates interesting or helpful
information is being provided.
KYi
_
STD
_
India
.
book
Page
3
Thursday
,
January
6
,
2022
8:35
PM

KYi
_
STD
_
India
.
book
Page
4
Thursday
,
January
6
,
2022
8:35
PM

Table of Contents
1
2
3
4
5
6
7
8
A
I
Introduction
Your vehicle at a glance
Safety features of your vehicle
Features of your vehicle
Driving your vehicle
What to do in an emergency
Maintenance
Specifications & Consumer information
Abbreviation
Index
Kia Warranty Policy
KYi
_
STD
_
India
.
book
Page
5
Thursday
,
January
6
,
2022
8:35
PM
w

KYi
_
STD
_
India
.
book
Page
6
Thursday
,
January
6
,
2022
8:35
PM

1Introduction
Introduction
Fuel requirements ..........................................................................1-2
Vehicle modifications.................................................................... 1-4
Vehicle break-in process .............................................................. 1-5
Risk of burns when parking or stopping vehicle ...................... 1-5
Vehicle handling instructions ...................................................... 1-6
Open Source Software Notice ..................................................... 1-6
KYi
_
STD
_
India
.
book
Page
1
Thursday
,
January
6
,
2022
8:35
PM

Introduction
21
Fuel requirements
Introduction
Fuel requirements
Petrol engine
Your new Kia vehicle is designed to use
only unleaded fuel having an Octane
Rating of RON (Research Octane Num
-
ber) 91/AKI (Anti- Knock Index) 87 or
higher. (Do not use methanol blended
fuels.)
Your new vehicle is designed to obtain
maximum performance with unleaded
fuel, as well as minimise exhaust emis
-
sions and spark plug fouling.
WARNING
僅 Do not "top off" after the nozzle auto -
matically shuts off when refuelling.
僅 Always check that the fuel cap is
installed securely to prevent fuel spill
-
age in the event of an accident.
CAUTION
Never use leaded fuel. The use of leaded
fuel is detrimental to the catalytic con
-
verter and will damage the engine con -
trol system's oxygen sensor and affect
emission control.
Never add any fuel system cleaning
agents to the fuel tank other than what
has been specified. (Kia recommends to
consult an authorised Kia dealer/service
partner for details.)
Petrol containing alcohol and
methanol
Gasohol, a mixture of petrol and ethanol
(also known as grain alcohol), and petrol
or gasohol containing methanol (also
known as wood alcohol) are being mar
-
keted along with or instead of unleaded
petrol.
Do not use gasohol containing more
than 10% ethanol, and do not use petrol
or gasohol containing any methanol.
Either of these fuels may cause drivabil
-
ity problems and damage to the fuel
system, engine control system and emis
-
sion control system.
Discontinue using gasohol of any kind if
drivability problems occur.
Vehicle damage or drivability problems
may not be covered by the manufac
-
turer's warranty if they result from the
use of:
1. Gasohol containing more than 10%
ethanol.
2. Petrol or gasohol containing metha
-
nol.
3. Leaded fuel or leaded gasohol.
CAUTION
Never use gasohol which contains meth -
anol. Discontinue use of any gasohol
product which impairs drivability.
Other fuels
Using fuels such as
僅 Silicone (Si) contained fuel,
僅 MMT (Methylcyclopentadienyl Man
-
ganese Tricarbonyl), Manganese (Mn)
contained fuel,
僅 Ferrocene (Fe) contained fuel, and
僅 Other metallic additives contained
fuels,
may cause vehicle and engine damage
or cause plugging, misfiring, poor accel
-
eration, engine stalling, catalyst melting,
abnormal corrosion, life cycle reduction,
etc.
KYi
_
STD
_
India
.
book
Page
2
Thursday
,
January
6
,
2022
8:35
PM

3
1
1
Introduction Fuel requirements
Also, the Malfunction Indicator Lamp
(MIL) may illuminate.
NOTICE
Damage to the fuel system or perfor -
mance problem caused by the use of
these fuels may not be covered by your
New Vehicle Limited Warranty.
Use of MTBE
Kia recommends avoiding fuels contain -
ing MTBE (Methyl Tertiary Butyl Ether)
over 15.0% vol. (Oxygen Content 2.7%
weight) in your vehicle.
Fuel containing MTBE over 15.0% vol.
(Oxygen Content 2.7% weight) may
reduce vehicle performance and pro
-
duce vapour lock or hard starting.
CAUTION
Your New Vehicle Limited Warranty may
not cover damage to the fuel system
and any performance problems that are
caused by the use of fuels containing
methanol or fuels containing MTBE
(Methyl Tertiary Butyl Ether) over 15.0%
vol. (Oxygen Content 2.7% weight.)
Do not use methanol
Fuels containing methanol (wood alco -
hol) should not be used in your vehicle.
This type of fuel can reduce vehicle per
-
formance and damage components of
the fuel system, engine control system
and emission control system.
Fuel additives
Kia recommends that you use unleaded
petrol which has an octane rating of
RON (Research Octane Number) 95/AKI
(Anti Knock Index) 91 or higher (for
Europe) or Octane Rating of RON
(Research Octane Number) 91/AKI (Anti-
Knock Index) 87 or higher (except
Europe).
For customers who do not use good
quality petrols including fuel additives
regularly, and have problems starting or
the engine does not run smoothly, one
bottle of additives should be added to
the fuel tank when the engine oil is
replaced.
Additives are available from a profes
-
sional workshop along with information
on how to use them. Kia recommends to
visit an authorised Kia dealer/service
partner.
Operation in foreign countries
If you are going to drive your vehicle in
another country, be sure to:
僅 Observe all regulations regarding reg
-
istration and insurance.
僅 Determine that acceptable fuel is
available.
Diesel engine
Diesel fuel
Diesel engines must be operated only on
commercially available diesel fuel that
complies with EN 590 or comparable
standard. (EN stands for "European
Norm"). Do not use marine diesel fuel,
heating oils, or non-approved fuel addi
-
tives, as this will increase wear and
cause damage to the engine and fuel
system. The use of non-approved fuels
and/or fuel additives will result in a lim
-
itation of your warranty rights.
Diesel fuel of above cetane 51 is used in
your vehicle. If two types of diesel fuels
are available, use summer or winter fuel
KYi
_
STD
_
India
.
book
Page
3
Thursday
,
January
6
,
2022
8:35
PM

Introduction
41
Vehicle modifications
properly according to the following tem -
perature conditions.
僅 Above -5°C (23°F) ... Summer type die
-
sel fuel.
僅 Below -5°C (23°F) ... Winter type diesel
fuel.
Watch the fuel level in the tank very
carefully: If the engine stops through
fuel failure, the circuits must be com
-
pletely purged to restart.
CAUTION
僅 It is recommended to use the regu -
lated automotive diesel fuel for diesel
vehicle equipped with the DPF sys -
tem. (if equipped)
僅 If you use diesel fuel including high
sulfur (more than 50 ppm sulfur) and
unspecified additives, it can cause the
DPF system to be damaged and white
smoke can be emitted. (if equipped)
僅 Do not let any petrol or water enter
the tank. This would make it neces
-
sary to drain it out and to bleed the
lines to avoid jamming the injection
pump and damaging the engine.
Vehicle modifications
This vehicle should not be modified.
Modification of your vehicle could affect
its performance, safety or durability and
may even violate governmental safety
and emissions regulations.
In addition, damage or performance
problems resulting from any modifica
-
tion may not be covered under warranty.
僅 If you use unauthorised electronic
devices, it may cause the vehicle to
operate abnormally, wire damage,
battery discharge and fire. For your
safety, do not use unauthorised elec
-
tronic devices.
KYi
_
STD
_
India
.
book
Page
4
Thursday
,
January
6
,
2022
8:35
PM

5
1
1
Introduction Vehicle break-in process
Vehicle break-in process
By following a few simple precautions
for the first 1,000 km (600 miles) you
may increase the performance, econ
-
omy and life of your vehicle.
僅 Do not race the engine.
僅 Whilst driving, keep your engine
speed (rpm, or revolutions per min
-
ute) within 3,000 rpm.
僅 Do not maintain a single speed for
long periods of time, either fast or
slow. Varying engine speed is needed
to properly break-in the engine.
僅 Avoid hard stops, except in emergen
-
cies, to allow the brakes to seat prop -
erly.
僅 Fuel economy and engine perfor
-
mance may vary depending on vehi -
cle break-in process and be stabilized
after 6,000 km (4,000 miles). New
engines may consume more oil during
the vehicle break-in period.
Risk of burns when parking or
stopping vehicle
僅 Do not park or stop the vehicle near
flammable items such as leaves,
paper, oil, and tyre. Such items placed
near the exhaust system can become
a fire hazard.
僅 When an engine idles at a high speed
with the rear side of the vehicle touch
-
ing the wall, heat of the exhaust gas
can cause discolouration or fire. Keep
enough space between the rear part
of the vehicle and the wall.
僅 Be sure not to touch the exhaust/cata
-
lytic systems whilst engine is running
or right after the engine is turned off.
There is a risk of burns since the sys -
tems are extremely hot.
KYi
_
STD
_
India
.
book
Page
5
Thursday
,
January
6
,
2022
8:35
PM

Introduction
61
Vehicle handling instructions
Vehicle handling instructions
As with other vehicles of this type, failure
to operate this vehicle correctly may
result in loss of control, an accident or
vehicle rollover.
Specific design characteristics (higher
ground clearance, track, etc.) give this
vehicle a higher centre of gravity than
other types of vehicles. In other words
they are not designed for cornering at
the same speeds as conventional 2-
wheel drive vehicles.
Avoid sharp turns or abrupt manoeu
-
vres. Again, failure to operate this vehi -
cle correctly may result in loss of control,
an accident or vehicle rollover.
Be sure to read the "Reducing the risk
of a rollover" on page 5-47.
Open Source Software Notice
This vehicle contains software with open
source licenses.
Open source software information
including the source code, copyright
notices and referred license terms may
be obtained on the website http://
worldwide.kia.com/int/opensource
Kia Corporation will provide the open
source code to you in storage medium
such as CD-ROM for minimum charge
covering the cost of performing source
distribution upon email request to
[email protected]
within a period of 3 years from the date
of product purchase.
KYi
_
STD
_
India
.
book
Page
6
Thursday
,
January
6
,
2022
8:35
PM

2Your vehicle at a glance
Your vehicle at a glance
Exterior overview .......................................................................... 2-2
Interior overview ...........................................................................2-4
Instrument panel overview ..........................................................2-6
Engine compartment.....................................................................2-8
KYi
_
STD
_
India
.
book
Page
1
Thursday
,
January
6
,
2022
8:35
PM

Your vehicle at a glance
22
Exterior overview
Your vehicle at a glance
Exterior overview
Front view
* The actual features in your vehicle may not necessarily be available due to the
selected options or regions.
1. Bonnet 4-22
2. Head lamp 4-47, 7-50
3. Wheel and tyre 7-30, 8-5
4. Outside rear view mirror 4-31
5. Sunroof 4-25
6. Front windscreen wiper blades 4-50, 7-26
7. Windows 4-19
8. Front ultrasonic sensor 5-42
9. Front fog lamp 7-50
10.Roof rack 4-75
OKYI011001
KYi
_
STD
_
India
.
book
Page
2
Thursday
,
January
6
,
2022
8:35
PM

3
2
2
Your vehicle at a glance Exterior overview
Rear view
* The actual features in your vehicle may not necessarily be available due to the
selected options or regions.
1. Doors 4-12
2. Fuel filler door 4-23
3. Rear combination lamp 7-50, 7-52
4. High mounted stop lamp 7-50
5. Tailgate 4-16
6. Antenna 4-76
7. Rear view camera 5-36
8. Rear ultrasonic sensor 5-39, 5-42
9. Rear wiper 4-50, 7-26
10.Backup lamp 7-50
OKYI011002
KYi
_
STD
_
India
.
book
Page
3
Thursday
,
January
6
,
2022
8:35
PM

Your vehicle at a glance
42
Interior overview
Interior overview
* The actual features in your vehicle may not necessarily be available due to the
selected options or regions.
1. Inside door handle 4-13
2. Outside rearview mirror folding switch 4-31
3. Outside rearview mirror control switch 4-32
4. Central door lock/unlock switch 4-14
5. Power window switches (Front) 4-20
6. Power window switches (Rear) 4-20
7. Steering wheel tilt lever 4-29
8. Steering wheel 4-29
9. Headlight levelling adjustment switch 4-49
10.ESC OFF button 5-27
11.Bonnet release lever 4-22
12.Instrument panel fuse 7-38
13.Seat 3-3
OKYI011003
KYi
_
STD
_
India
.
book
Page
4
Thursday
,
January
6
,
2022
8:35
PM

5
2
2
Your vehicle at a glance Interior overview
14.Shift lever 5-11, 5-13, 5-15
15.ENGINE START/STOP button 5-7
KYi
_
STD
_
India
.
book
Page
5
Thursday
,
January
6
,
2022
8:35
PM

Your vehicle at a glance
62
Instrument panel overview
Instrument panel overview
* The actual features in your vehicle may not necessarily be available due to the
selected options or regions.
1. Audio remote control button 4-76
2. Driver's front air bag 3-34
3. Horn 4-30
4. Driving Assist button 5-32, 5-34
5. Instrument cluster 4-33
6. Light control/turn signals lever 4-47
7. Wiper and washer control lever 4-50
8. Infotainment system 4-42
9. Hazard warning flasher switch 6-3
10.Climate control system 4-60, 4-62
11.DBC button 5-28
12.Front seat air ventilation seat button 4-69
13.Drive mode integrated control system 5-31
OKYI011005
KYi
_
STD
_
India
.
book
Page
6
Thursday
,
January
6
,
2022
8:35
PM

7
2
2
Your vehicle at a glance Instrument panel overview
14.Parking Safety button 5-39, 5-42
15.Parking/View button 5-36
16.Wireless smartphone charging system 4-72
17.Centre console storage box 4-66
18.Passenger's front air bag 3-34
19.Glove box 4-66
20.Rear USB charger 4-70
KYi
_
STD
_
India
.
book
Page
7
Thursday
,
January
6
,
2022
8:35
PM
