GETTING TO KNOW YOUR SORENTO
Congratulations on Your New Kia Purchase!
Your new Kia vehicle has been designed, engineered and manufactured to provide you with years of comfortable and dependable
driving. Kia is committed to quality, innovation, safety and — above all — your satisfaction.
Using This Guide
The information contained in this guide is a brief overview that will help you become familiar with the operation and features of your
new Kia vehicle. The flipbook format facilitates information access, while the detailed illustrations help to ensure the instructions are
easy to follow.
This Features & Functions Guide, and the specific operational and safety information it provides, is not a substitute for your Owner’s
Manual. In the interest of your safety and that of your family, and to help you avoid risks that may result in death or serious injury,
Kia reminds you to carefully read your Owner’s Manual in order to fully familiarize yourself with the important information it contains.
While Kia endeavors to ensure that the information contained in this guide is accurate at the time of printing, Kia may change vehicle
specifications without notice in advance or after the fact, and assumes no liability in connection with such changes.
www.kia.com
Consumer - Roadside Assistance†17
1-800-333-4KIA (4542)
See Back Pages for Vehicle
Maintenance Schedule
Always check the Owner’s Manual for complete operating information and safety warnings. †LEGAL DISCLAIMERS ON BACK INSIDE COVER

VIDEOS & QR CODES . . . . . . . . . . . . . . . . . . . 2
INSTRUMENT CLUSTER
Instrument Cluster Overview . . . . . . . . . . . . . . . . . 3
Indicators & Warning Lights . . . . . . . . . . . . . . . . . 4
Tire Pressure Monitoring System (TPMS) . . . . . . . . . . 5
Fuel Economy. . . . . . . . . . . . . . . . . . . . . . . . . 5
LCD Instrument Cluster Modes . . . . . . . . . . . . . . . 6
Trip Modes / Trip Computer. . . . . . . . . . . . . . . . . . 6
User Settings . . . . . . . . . . . . . . . . . . . . . . . . . 7
Service Interval Mode . . . . . . . . . . . . . . . . . . . . 7
Drive Mode Integrated Control System . . . . . . . . . . . . 8
ECO Mode (Active ECO)* . . . . . . . . . . . . . . . . . . . 8
DRIVER’S PANEL
Electronic Stability Control (ESC) . . . . . . . . . . . . . . . 9
Hill-Start Assist Control (HAC) . . . . . . . . . . . . . . . . 9
Instrument Cluster Control . . . . . . . . . . . . . . . . . . 9
AC Inverter*. . . . . . . . . . . . . . . . . . . . . . . . . . 9
Blind-Spot Collision Warning (BCW)* . . . . . . . . . . . . . 10
Lane Keeping Assist (LKA)* . . . . . . . . . . . . . . . . . 11
Forward Collision-Avoidance Assist-Pedestrian (FCA-Ped)* /
Forward Collision Warning (FCW)*. . . . . . . . . . . . . 11
Power Windows, Window Lock & Central Door Lock . . . . . 12
Power Folding Outside Mirrors* . . . . . . . . . . . . . . . 12
Power/Heated Outside Mirrors* . . . . . . . . . . . . . . . 12
Automatic Door Lock / Unlock . . . . . . . . . . . . . . . . 12
Fuel Filler LId Release Button . . . . . . . . . . . . . . . . 12
Reverse Parking Aid Function* . . . . . . . . . . . . . . . . 13
Engine Start/Stop Button* . . . . . . . . . . . . . . . . . . 13
STEERING WHEEL CONTROLS
Tilt / Telescoping Steering Wheel. . . . . . . . . . . . . . . 14
Headlights & High Beams. . . . . . . . . . . . . . . . . . . 14
Turn Signals & Fog Lights* . . . . . . . . . . . . . . . . . .15
Windshield / Rear Wipers & Washers . . . . . . . . . . . . . 15
Bluetooth®Wireless Technology . . . . . . . . . . . . . . . 16
Audio Controls . . . . . . . . . . . . . . . . . . . . . . . . 18
Cruise Control . . . . . . . . . . . . . . . . . . . . . . . . 18
Smart Cruise Control (SCC) with Stop and Go* . . . . . . . . 19
AUDIO SYSTEMS
Android Auto™/ Apple CarPlay®Setup . . . . . . . . . . . .20
UVO eServices Activation* . . . . . . . . . . . . . . . . . .20
Standard Audio System* . . . . . . . . . . . . . . . . . . .21
UVO eServices*. . . . . . . . . . . . . . . . . . . . . . . . 22
UVO eServices with Premium Navigation* . . . . . . . . . .23
CENTER PANEL
Surround View Monitor (SVM)* . . . . . . . . . . . . . . . 24
Automatic Gear Shift with Sportmatic®Shifting . . . . . . 25
AWD (All-Wheel Drive) Lock* . . . . . . . . . . . . . . . . 27
Automatic Climate Control*. . . . . . . . . . . . . . . . . 26
Manual Climate Control* . . . . . . . . . . . . . . . . . . 28
Digital Clock . . . . . . . . . . . . . . . . . . . . . . . . 29
Aux / USB / iPod®Ports, Power Outlets,
USB Charger & AC Inverter* . . . . . . . . . . . . . . . 29
Wireless Smartphone Charging System*. . . . . . . . . . 30
Electronic Parking Brake (EPB)* . . . . . . . . . . . . . . 31
Auto Hold* . . . . . . . . . . . . . . . . . . . . . . . . . 31
Heated Steering Wheel* . . . . . . . . . . . . . . . . . . 32
Seat Warmers / Ventilated Seats* . . . . . . . . . . . . . 32
SEATING
Front Seat Headrest Adjustment . . . . . . . . . . . . . . 33
Driver Position Memory System* . . . . . . . . . . . . . . 33
Power Adjustable Driver's Seat* / Power Lumbar* . . . . . 34
Manual Adjustable Driver's Seat*. . . . . . . . . . . . . . 34
2nd-Row Folding Seat . . . . . . . . . . . . . . . . . . . 35
2nd-Row Auto-Folding Seat*. . . . . . . . . . . . . . . . 35
3rd-Row Folding Seat* . . . . . . . . . . . . . . . . . . . 36
OTHER KEY FEATURES
Sunvisor . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Sunglasses Holder . . . . . . . . . . . . . . . . . . . . . 37
Remote Keyless Entry (Folding Key)* . . . . . . . . . . . . 37
Double-Turn Lock / Unlock All . . . . . . . . . . . . . . . 37
Smart Key* . . . . . . . . . . . . . . . . . . . . . . . . . 38
PowerLiftgate* . . . . . . . . . . . . . . . . . . . . . . . 39
Smart Power Liftgate* . . . . . . . . . . . . . . . . . . . 40
Driver Attention Warning (DAW)* . . . . . . . . . . . . . . 41
HomeLink®with Auto-Dimming Rearview Mirror* . . . . . 42
Map/Room Lamps . . . . . . . . . . . . . . . . . . . . . 43
Panoramic Sunroof with Power Sunshade*. . . . . . . . . 43
Parking Distance Warning-Forward* and Reverse . . . . . 44
Rear-Camera Display . . . . . . . . . . . . . . . . . . . . 44
Hood Release Lever and Latch . . . . . . . . . . . . . . . 45
Fuel Cap / Malfunction Indicator (Check Engine Light) . . . 45
Child-Protector Rear Door Locks . . . . . . . . . . . . . . 45
SAFETY FEATURES
Occupant Detection System (ODS) /
Passenger Airbag Off Indicator . . . . . . . . . . . . . . . 46
Seat Belts. . . . . . . . . . . . . . . . . . . . . . . . . . 46
Seat Belt Retractor Locks . . . . . . . . . . . . . . . . . 46
LEGAL DISCLAIMERS . . . See Back Inside Cover Page
ESSENTIAL FEATURES
SORENTO FEATURES & FUNCTIONS GUIDE
Air Conditioning / Automatic Climate Control* . . . . . . 26
Android Auto™/ Apple CarPlay®Setup . . . . . . . . . . 20
Audio System – Standard Audio System* . . . . . . . . 21
Audio System – UVO eServices* . . . . . . . . . . . . . 22
Audio System – UVO eServices / Premium Navigation* . 23
Audio System – UVO eServices Activation . . . . . . . . 20
Aux/USB/iPod®Ports, Power Outlets & AC Inverter*. . . 29
Bluetooth®Wireless Technology . . . . . . . . . . . . . 16
Cruise Control . . . . . . . . . . . . . . . . . . . . . . 18
Digital Clock . . . . . . . . . . . . . . . . . . . . . . . 29
Passenger Airbag Off Indicator. . . . . . . . . . . . . . 46
Service Mode. . . . . . . . . . . . . . . . . . . . . . . . 7
Smart Cruise Control (SCC) with Stop & Go* . . . . . . . 19
Smart Key* . . . . . . . . . . . . . . . . . . . . . . . . 38
Tire Pressure Monitoring System (TPMS) . . . . . . . . . 5
Trip Modes / Trip Computer . . . . . . . . . . . . . . . . 6
User Settings . . . . . . . . . . . . . . . . . . . . . . . . 7
Windshield/Rear Wipers & Washers . . . . . . . . . . . 15
*IF EQUIPPED
Driving while distracted can result in a loss of vehicle control
that may lead to an accident, severe personal injury and death.
The driver’s primary responsibility is in the safe and legal
operation of a vehicle, and use of any handheld devices, other
equipment or vehicle systems which take the driver’s eyes,
attention and focus away from the safe operation of a vehicle
or that are not permissible by law should never be used during
operation of the vehicle.

SORENTO FEATURES & FUNCTIONS GUIDE
2*IF EQUIPPED
VIDEOS & QR CODES - SMARTPHONES, TABLETS AND COMPUTERS
Kia provides a number of video resources to assist you with becoming familiar with the features and functions found in your
Kia vehicle. You can access these resources by snapping the QR Codes with your smartphone/
tablet (mobile devices) or by visiting the following website: www.youtube.com/KiaFeatureVideos. Continue reading
for a more in-depth look at QR Codes and for instructions on how to use them.
REMINDER: When accessing videos
on your mobile device, standard
cellular data rates may apply.
One-Click Fuel Cap Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
www.youtube.com/KiaFeatureVideos
What are QR Codes?
A QR Code is a square, 2-dimensional barcode that can
be read by mobile devices loaded with an appropriate
barcode or QR Code Reader App. The app reads the
barcode image and then launches/uploads the specific
information the code contains, such as URLs, text,
photos, videos and so much more.
How to Use QR Codes
If you have a mobile device with a QR Code Reader App,
you can snap the code with your phone and you’ll be
provided a video with additional information pertaining
to the topic. For example, in the Fuel Cap section, if you
would like additional information, just snap the code with
your mobile device to view the selected Kia Features &
Functions Video.
How to snap a QR Code
1. With your mobile device, download a QR Code Reader
App. With many devices, you can do this through an
app store or marketplace
2. Open the QR Code Reader App on your mobile device
3. The app will utilize your device’s camera. Center the
code in the camera viewing area:
•With some apps, as soon as the app recognizes
the code, it will launch the corresponding video
•With other apps, you will have to snap or take a
picture of the code. The app will then launch the
corresponding video
•For operation specifics, refer to the instructions
that come with the QR Code Reader App
QR CODE
1. If you’re having trouble scanning codes, check the following:
•The code should be centered and focused in your mobile device’s camera screen
•Consider moving your device closer to or farther away from the code
•The code should be well lit, without significant shadow
2. After scanning, if a “connecting” message appears and then nothing happens or there’s a “connection error” message, this typically indicates that your device is having
trouble connecting to the Internet
3. When accessing videos on your mobile device, standard cellular data rates will apply
QUICK TIPS
•Avoid scanning from a significant angle
•Confirm that the device’s app supports 2D QR Code scanning.
•Try another QR Code Reader App; not all apps are created equal

3
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
Instrument Cluster Overview
This illustration is for demonstration purposes only.
Some indicators and warning lights may not appear in
illustration. On the vehicle, they may appear in the LCD.
Your vehicle’s instrument cluster & indicator light
locations may differ from those in the illustrations.
For more information on the instrument cluster and
the function of all indicator and warning lights,
please refer to the Owner’s Manual.
ATachometer
BTurn Signal Indicators
CSpeedometer
DEngine Temperature Gauge
EIndicators & Warning Lights
FGear Shift Position Indicator
GOdometer/Trip Computer/Tripmeter
HFuel Gauge 0
1
2
345
6
7
8
20
40
60 80 100
120
140
160
0
MPH
km/h
0
20
40
60
80
100 120 140 160
180
200
220
240
260
x1000rpm
EPB
AUTO
HOLD
EF CH
AUTO
N
(Type A Cluster)
A C
BB
F
D
E
H
G
INSTRUMENT CLUSTER

SORENTO FEATURES & FUNCTIONS GUIDE
4*IF EQUIPPED
Indicators & Warning Lights
Your vehicle’s instrument cluster & indicator
light locations may differ from those in the
illustrations. For more information on the
instrument cluster and the function of all
indicator and warning lights, please refer
to the Owner’s Manual.
Engine Oil Pressure Warning Light
Malfunction Indicator Light
Electric Parking Brake (EPB) Warning Light*
Seat Belt Warning Light
Light ON Indicator Light
High Beam Indicator Light
Low Beam Assist-Dynamic (LBA-D) Warning Light*
Front Fog Light Indicator Light
High Beam Assist Indicator Light*
Parking Brake & Brake Fluid Warning Light
Forward Collision-Avoidance Assist -
Pedestrian (FCA-Ped) Warning Light*
All-Wheel Drive (AWD) Warning Light*
All-Wheel Drive (AWD) Lock Indicator Light*
Electronic Power Steering (EPS) Warning Light
Charging System Warning Light
Airbag Warning Light
Low Fuel Level Warning Light
Immobilizer Indicator Light*
Engine Coolant Temperature Warning Light
Icy Road Warning Indicator Light*
Low Tire Pressure Light / Tire Pressure Monitoring
System (TPMS) Malfunction Indicator Light
Anti-Lock Braking System (ABS) Warning Light
x1000rpm
0
0
20
20
40
60
80
100
120
140
160
40
60
80
100
120
140
160
180
200
220
240
260
0
1
2
3
4
5
6
78
AUTO
EPB F
C
H
E
MPH km/h
AUTO
Electronic Stability Control (ESC) OFF Indicator Light
Electronic Stability Control (ESC) Warning Indicator Light
AUTO HOLD Indicator*
Cruise Control SET Indicator*
Cruise Control ON Indicator*
Washer Fluid Warning Light*
Master Warning Light
Electronic Brake Force Distribution (EBD) System Warning
Light (two separate indicators on Instrument Cluster lit at
same time)
Lane Keeping Assist (LKA)* ON/OFF Indicator Light
LED Headlamp Warning Indicator*
(Type B Cluster)
This illustration is for demonstration purposes
only. Some indicators and warning lights may
not appear in illustration. On the vehicle, they
may appear in the LCD.
INSTRUMENT CLUSTER

5
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS *IF EQUIPPED †LEGAL DISCLAIMERS ON BACK INSIDE COVER

The TPMS indicator functions as both Low Tire Pressure Light
and TPMS Malfunction Indicator.
The indicator is designed to illuminate if it detects one or more tires is
significantly underinflated, the vehicle has a spare tire installed without
TPMS or the outside temperature becomes significantly lower.
Inflate tire(s) to specifications using an
accurate tire pressure gauge to turn off
Low Tire Pressure Indicator . See front
driver’s door jamb for PSI specification.
The Low Tire Pressure Position Indicator
Ais displayed on the LCD screen in the
Instrument Cluster when the tire(s) are
underinflated.
When there is a problem with the TPMS, the TPMS Malfunction Indicator
will blink for approximately one minute and then illuminate. See dealer
for service.
Tire Pressure Monitoring System (TPMS)†26
REMINDERS:
• Check the recommended tire pressure label located
on the left side of driver's door jam, visible when the
door is opened.
• Consult your dealer for service if Low Tire Pressure
Light remains illuminated after inflating your tire(s).
• Personal electronic devices (such as laptops,
wireless chargers, remote start systems, etc.)
which has electronic noise may interfere with TPMS
system, which may cause the Malfunction Warning
Indicator (Check Engine Light) to illuminate.
Fuel Economy
There are several factors that contribute to your vehicle’s fuel economy, including maintenance of your vehicle, driving style,
environmental conditions, vehicle weight and vehicle aerodynamics. Below are tips on how to help improve fuel economy:
For more information on Fuel
Economy, you can snap the QR Code
above to view a video or refer to the
Owner's Manual.
•Keep your vehicle in good condition with regular
maintenance
•Don’t let the engine idle longer than necessary
•Drive at a moderate speed, accelerating smoothly and at
a moderate rate
•Keep tires inflated to the recommended pressure
•Travel lightly, without carrying unnecessary weight in
your vehicles
•Avoid placing large or heavy items on roof racks
•Avoid hilly, winding or poorly maintained roads
To view these videos on
your mobile device, snap
these QR codes or visit the
listed website.
Refer to page 2 for more
information.
Tire Pressure Monitoring
System Video
Fuel Economy Video
www.youtube.com/KiaFeatureVideos
www.youtube.com/KiaFeatureVideos
25
35 35
35
psi
Low Tire Pressure
A
QR CODES
•Even with TPMS, tire pressure should be
checked manually at least once a month.
Only adjust tire pressure on “cold tires”
•For proper maintenance and optimal fuel
economy, maintain recommended tire
inflation pressures and stay within the load
limits and weight distribution recommended
for your vehicle
•In winter or cold weather, the TPMS light
may illuminate if the tire pressure was
adjusted to the recommended tire inflation
pressure during warm weather
QUICK TIPS
INSTRUMENT CLUSTER

SORENTO FEATURES & FUNCTIONS GUIDE
6*IF EQUIPPED
Trip Modes / Trip Computer
The Trip Computer is a driver information system
that displays information related to driving on the
display when the Engine Start/Stop button is in the
ON position.
To cycle through the LCD Instrument Cluster modes,
press the Mode button A.
To select and enter Trip Computer mode ,
press the Move button Bup/down and then press
Set/Reset (OK) Cto enter. To cycle through and
select the different screens (Fuel Economy, Trip A,
Trip B), press the Move button Bup/down again and
then press OK button C. When displaying TRIP A or
TRIP B screens, press and hold the OK button Cto
reset the Tripmeter to zero.
Press the OK button Cto go back to the previous
mode/item
REMINDERS:
•Appearance of Trip Computer display may differ as equipped
•All stored driving information (except Odometer and Range)
is reset if the battery is disconnected
LCD Instrument Cluster Modes
Press the Mode button Ato cycle through different LCD
Instrument Cluster Modes:
Your vehicle’s steering wheel
buttons may differ from those
in the illustrations.
Trip Computer Mode: Displays driving
information for tripmeter, fuel economy, etc.
Turn-by-Turn Mode*: Displays the state of
the navigation system
User Settings Mode: Change settings of the
doors, lamps and other features
Master Warning Mode: Informs on low tire
pressure warnings, Blind-Spot Collision Warning
(BCW)*†system malfunction and other systems.
Assist Mode*: Displays the state of the SCC
with S&G†, Lane Keeping Assist, TPMS†; In AWD
AUTO MODE, the cluster displays the traction
force distribution status of the front and rear
wheels. In AWD LOCK MODE, the cluster doesn’t
display the status.
(Type B Cluster)
TRIP
• Average MPG
• Instant MPG
ACCUMULATED INFO
• Tripmeter
• Average MPG
• Elapsed Time (E/T)
DRIVE INFO
• Tripmeter
• Average MPG
• Elapsed Time (E/T)
SMART SHIFT*
MODE
RES
SET
CRUISE
CANCEL
OK
A
B
C
(Type A; Controls located on Steering Wheel)
DIGITAL SPEEDOMETER
Fuel Economy
N
Average 12.4 MPG
0 5025
INSTRUMENT CLUSTER
Driving while distracted is dangerous and should be avoided. Drivers should
remain attentive to driving and always exercise caution when using the
steering wheel mounted controls while driving.

7
ALWAYS CHECK THE OWNER’S MANUAL FOR COMPLETE OPERATING INFORMATION AND SAFETY WARNINGS. *IF EQUIPPED
To enter Service Interval Mode,
press the Mode button A, scroll
to User Settings and enter by
pressing the OK button C.
Scroll to Service Interval by
pressing the OK button B, then
press the OK button Cto enter.
System will display number of
miles remaining until next service
is due, as well as the type of
service due.
When service is required, the
following will be displayed:
Service Required D.
To reset the Service Interval Mode system, press and
hold the OK button Cfor more than 1 second.
Press the OK button Cto go back to the previous
mode/item
To turn Service In OFF E, go to User Settings.
Service Interval Setting F
To set the service interval in User Settings mode:
•Press the Mode button Ato cycle to User
Settings and press the OK button Cto enter
•If Service Interval is OFF, press the OK button Cto turn ON
•Press the Move button Bto select/change the interval setting
•Press the OK button Cto select the interval
To enter the User Settings mode in the LCD Instrument Cluster
Modes, press the Mode button Awhen the vehicle is at a
stand-still and with the Engine/Start Stop button in the ON
position and select User Settings by pressing the Move
button Bup/down.
You can navigate the selections on the display by pressing the
Move button B, and then selecting the item by pressing the
OK button C.
Press the OK button Cto go back to the previous mode/item.
User Settings mode:
Driving Assist
•Lane Safety*
•Driver Attention Warning (DAW)
•Smart Cruise Control with Stop & Go*
•Forward Collision-Avoidance Assist-
Pedestrian (FCA-Ped)*
•Forward Collision Warning (FCW)*
•Blind-Spot Collision Warning Sound*
•Rear Cross Traffic Collision Warning Sound*
•Speed Limit Information Function*
Door/Liftgate (Tailgate)
•Automatically Lock
•Automatically Unlock
•Two Press Unlock*
•Power Liftgate*
•Smart Liftgate*
Lights
•One-Touch Turn Signal
•Ambient Light*
•Headlamp Delay*
Sound
•Parking Distance Warning-Forward* and
Reverse System Volume*
•Welcome Sound*
User Settings
Convenience
•Seat-Easy Access*
•Welcome Mirror/Light*
•Wireless Charging System*
•Wiper/Lights Display*
•Gear Position Pop-up*
Service Interval
•Service Interval
•Adjust Interval
•Reset
Other Features
•Fuel Economy Auto Reset
•Speedometer Subscale*
•Fuel Economy Unit
•Temperature Unit
•Tire Pressure Unit
Language
•Choose the language
Reset
•Reset the User Settings
menus (except language
and service interval)
Service Interval Mode
(Images are for illustration
purposes only and may vary)
Service Interval
-30000 mi. -3365 days
Hold : Reset
OK
Service required
-20 mi
-5 day
Service Interval
Off
Service Interval
-30000 mi. -3365 days
Hold : Reset
OK
Service required
-20 mi
-5 day
Service Interval
Off
Service Interval
-30000 mi. -3365 days
Hold : Reset
OK
Service required
-20 mi
-5 day
Service Interval
Off
D
E
F
To view a video on your
mobile device, snap these
QR Codes or visit the listed
website.
Refer to page 2 for more
information.
LCD Display Video
LCD Display:
Maintenance Video
www.youtube.com/KiaFeatureVideos
QR CODES
INSTRUMENT CLUSTER

SORENTO FEATURES & FUNCTIONS GUIDE
8*IF EQUIPPED
SMART, COMFORT, SPORT and ECO drive modes Amay be changed according
the driver’s preference or road conditions. To cycle through drive modes, press
the DRIVE MODE button B.
COMFORT Mode – The system’s
default mode is COMFORT mode
and is not displayed on the
instrument cluster nor the audio
system’s screen.
ECO Mode – A green ECO indicator will
illuminate on the instrument cluster. To
deactivate, press the DRIVE MODE button B
again to change the selection to another setting.
SPORT Mode – A yellow SPORTindicator
will illuminate on the instrument cluster. To
deactivate, press the DRIVE MODE button B
again to change the selection to another setting.
SMART Mode – When SMART mode is activated, the system automatically
selects the drive mode best suited to the current driving style (economic,
average, aggressive). A SMART indicator will illuminate on the instrument
cluster. The color of the
SMART indicator (green,
white, red) depends on
the current driving style.
To deactivate, press the
DRIVE MODE button B
again to change the
selection to another
setting.
Drive Mode Integrated
Control Video
To view a video on your
mobile device, snap this
QR Code or visit the listed
website.
Refer to page 2 for more
information.
www.youtube.com/KiaFeatureVideos
ECO Mode (Active ECO)*
The Active ECO system is designed
to help improve fuel economy
by controlling several vehicle
components. When activated, it
optimizes drivetrain operations such
as engine power and transmission to
help improve fuel economy.
To turn ON, press the DRIVE MODE
button Band scroll through options
until in the ECO mode. The ECO mode
indicator in the instrument cluster will
illuminate, indicating that the vehicle
is in ECO mode and Active ECO is
operating. The Active ECO system will
remain on even when the ignition
is cycled.
To turn the Active ECO system OFF,
press the DRIVE MODE button B
again and change to another mode.
For more information on Active ECO, refer to your Owner’s Manual or contact your local
dealership.
Drive Mode Integrated Control System*
REMINDERS:
•When ECO mode is selected, the following may occur to
improve fuel economy:
– Acceleration may be slightly reduced even when the
accelerator is fully depressed
– Air conditioner performance may be limited
– Shift pattern of the automatic transmission may change
– Engine noise may increase
– System’s power will be limited when driving uphill
•When SPORT mode is selected, fuel economy may decrease.
•The system is turned ON and in COMFORT mode when
ignition is in the ON position
•Steering effort may be slightly increased in Sport mode
(Appears on LCD in Instrument Cluster)
QR CODE
• When the Engine Start/Stop button is turned off, the system will default to
COMFORT mode and each mode will need to be selected again when the
vehicle restarts.
To help improve your fuel economy:
•Drive at a moderate speed, accelerating smoothly and at a moderate rate
•Keep tires inflated to the recommended pressure
•Be sure the wheels are properly aligned
QUICK TIPS
COMFORT
ECOSMART
SPORT
A
(Located on Center Panel below Gear Shift)*
B
INSTRUMENT CLUSTER
