Kia LNN2010IWUM User manual

Car Navigation System
OWNER’S MANUAL
LAN4200EKUM
Please read this manual carefully before operating your set and retain it for future reference.
Designs and specifications are subject to change without prior notice.
ENGLISH
DEUTSCH
FRANÇAIS
ESPAÑOL
ITALIANO
NEDERLANDS
РУССКИЙ
SVENSKA
PORTUGUÊS
DANSK
Čeština
POLSKI
SLOVENČINA
KOREAN
TÜRKÇE

2
Thank you for purchasing this Car Navigation system.
This user’s manual explains how to use the KIA Motor Car Navigation system.
Before using the product, read the contents of this user’s manual carefully and use this product safely.
• The screens shown in this manual may dier with the actual screens of the product.
• The design and specication of this product may change without prior notication for product improvement.
• When transferring the vehicle to another individual, include this user’s manual so that the next driver can
continue its use.

3
Safety notes
CAUTION
RISK OF ELECTRIC
SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE THE
COVER (OR BACK). NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
The lightning ash with the arrowhead symbol
within an equilateral triangle is intended
to alert the user about the presence of
uninsulated dangerous voltage within the
product’s enclosure that may be of sucient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral
triangle is intended to alert the user to
the presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
Always operate the vehicle in a safe manner.
Do not become distracted by the vehicle while
driving and always be fully aware of all driving
conditions. Do not change settings or any
functions.
Pull over in a safe and legal manner before
attempting such operations.
To promote safety, certain functions are
disabled unless the hand brake is on.
To reduce the risk of electric shock, do not
remove the cover or back of this product.
There are no user-serviceable parts inside.
Refer servicing to qualied service personnel.
To reduce the risk of re or electric shock,
do not expose this product to dripping or
splashing water, rain, or moisture.
When driving your vehicle, be sure to keep the
volume of the unit low enough to allow you to
hear sounds coming from the outside.
Do not drop it and avoid heavy impacts at
anytime.
The driver should not watch the monitor while
driving. If the driver watches the monitor while
driving, it may lead to carelessness and cause
an accident.
Precautions for safety
Precautions for safety

4
Precautions for safety
WARNING:
• Don’t use a cellular phone when you are
driving. You must stop at a safe place to use
a cellular phone.
• The use of the navigation radio by no means
relieves the driver of his/her responsibilities.
The highway code must always be observed.
Always observe the current trac situation.
• The applicable trac regulations and the
prevailing trac situation always take
precedence over the instructions issued by
the navigation system if they contradict one
another.
• For trac safety reasons, use the navigation
system menus only before starting a journey
or when the vehicle is stationary.
• In certain areas, one-way streets and turn
o and entry prohibitions (e.g. pedestrian
zones) are not recorded. In areas such as
these the navigation system will issue a
warning. Pay particular attention to one-way
streets and turn o and entry restrictions.
• The navigation system does not take the
relative safety of the suggested routes into
consideration.
Road blocks, building sites, height or weight
restrictions, trac or weather conditions
or other inuences which aect the route
safety or travel time are not taken into
consideration for the suggested routes. Use
your own discretion in order to decide on
the suitability of the suggested routes.
• The current legal road trac speed limit
always takes priority over the values saved
on the data. It is impossible to provide an
assurance that the speed values of the
navigation system will always match those
of the current trac regulations in every
situation.
• Always observe the applicable legal speed
limits the trac regulations. The vehicle
speedometer must always be given priority
for display of the vehicle speed.
• Do not rely exclusively on the navigation
system when attempting to locate an
emergency service (hospital, re service
etc.). It cannot be guaranteed that all
available emergency services in your vicinity
are saved in the database. Use your own
discretion and abilities to secure help in
such situations.

5
Precautions for safety
CAUTION:
• Do not keep the navigation system running
with the engine stopped. Doing so may
discharge the vehicle battery. When you
use the navigation system, always keep the
engine running.
• When the driver wants to operate the
navigation system, rst park the vehicle in
a safe location and set the parking brake.
Operating the system while driving can
distract the driver and may result in a serious
accident.
• Do not disassemble or modify this system.
If you do, it may result in accidents, re, or
electrical shock.
• Some states/provinces may have laws
limiting the use of video screens while
driving. Use the system only where it is legal
to do so.
• Do not use your phone in private mode
when you are driving. You must stop at a
safe location to use it.
Disposal of your old appliances
1. When this crossed-out wheeled bin
symbol is attached to a product, it
means the product is covered by the
European Directive 2002/96/EC.
2. All electrical and electronic products
should be disposed of separately
from the municipal waste stream via
designated collection facilities appoint-
ed by the government or the local
authorities.
3. The correct disposal of your old appli-
ance will help prevent potential nega-
tive consequences for the environment
and human health.
4. For more detailed information about
disposal of your old appliance, please
contact your city office, waste disposal
service or the shop where you pur-
chased the product.
Disposal of waste batteries/
accumulators
1. When this crossed-out wheeled bin sym-
bol is attached to batteries/accumulators
of Your product it means they are covered
by European Directive 2006/66/EC.
2. This symbol may be combined with
chemical symbols for mercury(Hg),
cadmium(Cd) or lead(Pb) if the battery
Contains more that 0.0005% of mer-
cury,0.002% of cadmium or 0.004% of
lead.
3. All batteries/accumulators should be
disposed separately from the municipal
waste stream via designated collection
facilities appointed by the government or
the local authorities.
4. The correct disposal of Your old batteries/
accumulators will help to prevent potential
negative consequences for the environ-
ment, animal and human health.
5. For more detailed information about
disposal of Your old batteries/accumula-
tors, please contact Your city office, waste
disposal service or the shop
where You
purchased the product.

6
Precautions for safety 3
Safety notes . . . . . . . . . . . . . . . . . . . . . . 3
Table of contents 6
General information 10
About USB . . . . . . . . . . . . . . . . . . . . . . 10
MP3 file Information. . . . . . . . . . . . . . . .11
Image file Information . . . . . . . . . . . . . .11
Video file Information . . . . . . . . . . . . . . .11
Using iPod Devices . . . . . . . . . . . . . . . . .11
Precautions upon using iPod.............. 11
Supported iPod devices ....................... 11
Cautions upon using SD Cards . . . . . . 12
Ejecting and Inserting SD Cards....... 12
Usage of SD Cards............................... 12
Name of each component 13
Head unit. . . . . . . . . . . . . . . . . . . . . . . . 13
Steering wheel remote control . . . . . . . 15
Basic operation 16
Start-up screen . . . . . . . . . . . . . . . . . . . 16
Turning the system on . . . . . . . . . . . . . 16
Turning the system off . . . . . . . . . . . . . 16
Adjusting the volume . . . . . . . . . . . . . . 16
Using the Touch screen. . . . . . . . . . . . . 16
Radio operation (FM/AM) 17
Listening to FM/AM radio. . . . . . . . . . . 17
Viewing station list . . . . . . . . . . . . . . . . 17
Autostore (AM only) . . . . . . . . . . . . . . . 17
Presetting FM/AM . . . . . . . . . . . . . . . . 18
Saving FM/AM preset .......................... 18
Deleting FM/AM preset ....................... 18
Setting the FM/AM option . . . . . . . . . . 18
Scan .......................................................... 18
TA............................................................... 19
Region (FM only) ................................... 19
Sound settings ....................................... 19
Radio operation (DAB) 20
Listening to DAB. . . . . . . . . . . . . . . . . .20
Viewing station list . . . . . . . . . . . . . . . .20
Presetting DAB . . . . . . . . . . . . . . . . . . .20
Saving DAB preset...............................20
Deleting DAB preset............................20
Setting the DAB option . . . . . . . . . . . .20
Scan .........................................................20
TA............................................................... 21
Service Following ................................... 21
L-Band ...................................................... 21
Sound settings ....................................... 21
USB Operation 22
Playing USB music . . . . . . . . . . . . . . . .22
Pause ....................................................... 22
Skip........................................................... 22
Search...................................................... 22
Seek ......................................................... 22
List ............................................................ 22
Setting USB music option................. 23
Scan ......................................................... 23
Repeat ..................................................... 23
Shuffle ..................................................... 23
Sound settings ...................................... 23
Viewing USB image . . . . . . . . . . . . . . . 24
Switching to menu screen or full
screen ...................................................... 24
Skip........................................................... 24
Zoom in/out ........................................... 24
Rotating image...................................... 24
List ............................................................ 25
Setting USB image option . . . . . . . . . . 25
File Info.................................................... 25
Display Settings ....................................25
Slideshow settings................................25
iPod Operation 26
Playing iPod . . . . . . . . . . . . . . . . . . . . . 26
Pause ....................................................... 26
Skip........................................................... 26
Table of contents
Table of contents

7
Seek ......................................................... 26
List ............................................................ 26
Setting iPod option. . . . . . . . . . . . . . . .26
Setting audiobook playback speed. 26
Repeat ..................................................... 27
Shuffle ..................................................... 27
Sound settings ...................................... 27
Auxiliary device operation 28
Playing an AUX source . . . . . . . . . . . . .28
Switching to menu screen or full
screen ......................................................28
Display Settings ....................................28
Sound settings ......................................28
Bluetooth audio 29
Playing Bluetooth audio . . . . . . . . . . . . 29
Before playing the Bluetooth audio.29
Starting the Bluetooth audio............. 29
Pause ....................................................... 29
Skip........................................................... 29
Sound settings ...................................... 29
Getting started with navigation 30
Precautions for safe driving . . . . . . . . .30
What is GPS? . . . . . . . . . . . . . . . . . . . .30
About satellite signals. . . . . . . . . . . . . .30
Acquiring satellite signals. . . . . . . . . . .30
Operating Navigation Screen . . . . . . . . 31
Map screen.............................................. 31
Zoom In / Zoom Out .......................... 33
Map scale ............................................... 33
Scrolling map ........................................ 33
Traffic information list.......................... 33
Navigation volume................................34
General operations of quick menu..34
General operations of [Nav] menu. . . .34
Searching for destination of navi-
gation 35
Address Search . . . . . . . . . . . . . . . . . . .35
Last destinations. . . . . . . . . . . . . . . . . .36
POI . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Searching for POI by category ......... 36
Searching for POI by name............... 36
Searching for POI by phone number
....................................................................37
Address book . . . . . . . . . . . . . . . . . . . . 37
Deleting Address book ........................37
Editing Address book..........................38
Hyundai service. . . . . . . . . . . . . . . . . . .38
Near current position...........................38
Service name.........................................38
Service phone number ....................... 39
Load tour. . . . . . . . . . . . . . . . . . . . . . . . 39
Coordinates . . . . . . . . . . . . . . . . . . . . . .40
Home, Office, Favourite (1~6) . . . . . . .40
Registering Home, Office, or Favourite
(1~6)..........................................................40
Finding your Home, Office, or
Favourite place ......................................40
Using the route menu 41
Route menu overview . . . . . . . . . . . . . . 41
Stop guidance/ Resume guidance . . . . 41
Route option . . . . . . . . . . . . . . . . . . . . . 41
Plan tour . . . . . . . . . . . . . . . . . . . . . . . .42
Avoid street . . . . . . . . . . . . . . . . . . . . . .43
Route overview . . . . . . . . . . . . . . . . . . .43
Route information. . . . . . . . . . . . . . . . .43
Route scan . . . . . . . . . . . . . . . . . . . . . .44
Bluetooth® Wireless Technology 45
Before Using the Bluetooth Handsfree 45
What is Bluetooth Wireless
Technology? ...........................................45
Precautions for Safe Driving.............. 45
Cautions upon Connecting Bluetooth
Phone....................................................... 45
Pairing and connecting the unit and a
Bluetooth phone . . . . . . . . . . . . . . . . . .46
When no phones have been paired 46
When a phone is already paired ...... 47
Disconnecting the connected phone
Table of contents

8
Table of contents
...................................................................48
Deleting Bluetooth Devices................48
Making a call by entering phone number
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
Making a call by redialing . . . . . . . . . . .48
Making a call with speed dial numbers 49
Answering/Rejecting a call . . . . . . . . . . 49
Switching call to the mobile phone . . .49
Using the menu during a phone call . .50
Call history . . . . . . . . . . . . . . . . . . . . . .50
Making a call from call history..........50
Downloading call history.....................50
Deleting call history............................... 51
Contacts . . . . . . . . . . . . . . . . . . . . . . . . 51
Downloading mobile phone contacts
.................................................................... 51
Searching for contacts........................ 52
Adding as a Favourite ......................... 52
Favourites . . . . . . . . . . . . . . . . . . . . . . . 52
Calling Favourites.................................. 52
Adding as a Favourite ......................... 53
Deleting favourites................................ 53
Setting Bluetooth Connection . . . . . . .53
Settings 54
Settings menu overview . . . . . . . . . . . . 54
Navigation . . . . . . . . . . . . . . . . . . . . . . . 54
General ....................................................54
Display .....................................................54
Guidance.................................................54
Route........................................................55
Traffic ....................................................... 55
Sound . . . . . . . . . . . . . . . . . . . . . . . . . .56
Volume control ......................................56
Fader/Balance........................................56
Treble/Middle/Bass..............................56
Surround effect ..................................... 57
Speed Dependent Vol......................... 57
Touch Tone ............................................. 57
Reset ........................................................ 57
Display. . . . . . . . . . . . . . . . . . . . . . . . . . 57
Set Video image ................................... 57
Set LCD Brightness .............................58
Illumination Settings............................58
Ratio.........................................................58
Reset ........................................................ 59
Bluetooth. . . . . . . . . . . . . . . . . . . . . . . .59
Bluetooth connection .......................... 59
Auto connection priority..................... 59
Auto download ......................................60
Audio Streaming ..................................60
Device Information ...............................60
Voice recognition . . . . . . . . . . . . . . . . . 61
Clock . . . . . . . . . . . . . . . . . . . . . . . . . . .62
GPS time ................................................ 62
Time Settings ........................................ 62
Daylight Savings Time......................... 62
Clock Type .............................................. 63
Time Format........................................... 63
General . . . . . . . . . . . . . . . . . . . . . . . . .63
Language................................................ 63
Keyboard.................................................64
Frame.......................................................64
Agreement Screen...............................64
Lock Rear Controls .............................. 65
E-Manual . . . . . . . . . . . . . . . . . . . . . . . . 65
Skip........................................................... 65
Zoom In/Out.......................................... 65
Search...................................................... 66
Go to page ............................................. 66
System Info . . . . . . . . . . . . . . . . . . . . . .66
Version ..................................................... 66
Jukebox Info ..........................................66
Update......................................................67
Reset All...................................................67
Using rear camera - Option 68
About Rear Camera . . . . . . . . . . . . . . .68
Turning on the rear camera...............68
Using PGS (Parking Guide
System) - Option 69
About PGS (Parking Guide System) . . 69
PGS screen ............................................ 69
Normal View ........................................... 69
Top View .................................................. 69
Rear view angle conversion ............... 69

9
Table of contents
AVM (Around View Monitor) -
Option 70
About AVM (Around View Monitor) . . . 70
Operating front AVM . . . . . . . . . . . . . . 70
Operating rear AVM . . . . . . . . . . . . . . . 70
AVM setting . . . . . . . . . . . . . . . . . . . . . 71
Warning display. . . . . . . . . . . . . . . . . . . 71
Driver's door open indicator ............... 71
Front passenger's door open indicator
.................................................................... 71
Trunk open indicator ........................... 71
Side mirror folding indicator............... 71
Climate Mode 72
Operating Climate Mode . . . . . . . . . . . 72
Before thinking there is a product
defect 73
Troubleshooting 76
Trademarks and Licenses 78
DivX®......................................................... 78
Bluetooth® Wireless Technology ....... 78
iPod®......................................................... 78
Specification 79

10
General information
About USB
Connect the USB device after turning on the
engine. The USB device may become damaged
if it is already connected when the ignition is
turned on.
• Files that are not standard format les will
not be played.
• For MP3/WMA les, only music les with
compression rates between 8 Kbps ~ 320
Kbps can be played.
• Heed caution to static electricity when
connecting/disconnecting external USB
devices.
• Encoded MP3 Players will not be recognized
when connected as an external device.
• When connecting an external USB device,
the device may not properly recognize the
USB is in some states.
• Only USB devices formatted as FAT 12/16/32
are supported, and NTFS le system is not
supported.
• Some USB devices may not be supported
due to compatibility issues.
• Avoid contact between the USB connector
with bodily parts/foreign objects.
• Repeated connecting/disconnecting of USB
devices within short periods of time may
result in product malfunction.
• Insert USB device after starting the car. If the
car is started while USB device is inserted, it
may damage USB device.
• The amount of time required to recognize
the external USB device may dier
depending on the type, size, or le formats
stored on the USB. Such dierences
in required time are not indications of
malfunction.
• The device may not recognize the USB
device if separately purchased USB hubs and
extension cables are being used. Connect
the USB directly with the multimedia
terminal of the vehicle.
• When application programs are installed to
specic USBs, les may not properly play.
• The device may not operate normally if MP3
Players, cellular phones, digital cameras,
or other electronic devices (USB devices
not recognized as portable disk drives) are
connected with the device.
• Charging through the USB may not work for
some mobile devices.
• The device may not support normal
operation when using a USB memory type
besides Metal Cover Type USB Memory.
• The device may not support normal
operation when using formats such as HDD
Type, CF, or SD Memory.
• The device will not support les locked by
DRM (Digital Rights Management).
• USB memory sticks used by connecting an
Adaptor (SD Type or CF Type) may not be
properly recognized.
General information
