Kicker KMC50 User manual

KMC
MEDIA CENTER
Owner’s Manual
KMC50
KMC MULTI-MEDIA RECEIVER WITH USB,
BLUETOOTH and AUX Input.

2
KMC50
Owner’s Manual
Media Center
Multi-Media Receiver w/ USB, Bluetooth and AUX Input
Thank you for purchasing the KMC50 Media Center. We recommend read-
ing through the entire manual for detailed instructions on how to install and
operate the unit. For support please call: 1-800-844-2774
Purchase Date:
Serial Number:
ITEMS INCLUDED:
(1) KMC50 (1) Trim Ring (1) Wiring Harness (1) UV Cover
(1) Mounting Gasket (1) Owner’s Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide more reasonable protection against harmful interference
in a residential installation.
Operation is subjected to the following two conditions: (1) This device may
not cause harmful interference, and (2) the device must accept any interference re-
ceived, including interference that may cause undesired operation.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turn-
ing the equipment off and on, you are encouraged to try to correct the interference by
one of the following measures:
t3FPSJFOUPSSFMPDBUFUIFSFDFJWJOHBOUFOOB
t*ODSFBTFUIFTFQBSBUJPOCFUXFFOUIFFRVJQNFOUBOESFDFJWFS
t$POOFDUUIFFRVJQNFOUJOUPBOPVUMFUPOBDJSDVJUEJGGFSFOUGSPNUIBUUPXIJDIUIF
receiver is connected.
t$POTVMUUIFEFBMFSPSBOFYQFSJFODFESBEJP57UFDIOJDJBOGPSIFMQ
$IBOHFTPSNPEJýDBUJPOTOPUFYQSFTTMZBQQSPWFECZUIFQBSUZSFTQPOTJCMFGPSDPNQMJ-
ance could void the user’s authority to operate the equipment.
The equipment should be installed and operated with minimum distance 20cm between
the radiator & your body.
CE
Operation temperature: (-25°C~55°C )
Bluetooth: 2402-2480MHz
Bluetooth transmitter power: 3.01dBm
Hereby declares that this equipment is in compliance with essential requirements and
other relevant provisions of Directive 2014/53/EU.
All radio frequencies can be used in all EU member safe without restrictions.

3
KMC50
Installation Overview
3” Hole Cutout
Main Harness
1- Red, Switched 12V+
2- White/Blk, Left Front Spkr, Negative
3- White, Left Front Spkr, Positive
4- Orange, Dimmer
5- Grey/Blk, Right Front Spkr, Negative
6- Grey, Right Front Spkr, Positive
7- Blue, Amp Turn-on
8- Green/Blk, Left Rear Spkr, Negative
9- Green, Left Rear Spkr, Positive
10- Black, Ground
11- Purple/Blk, Right Rear Spkr, Negative
12- Purple, Right Rear Spkr, Positive
1
2
3
4
5
6
7
8
9
1. Main Harness
2. USB Port
3. Antenna Input
4. Remote Port
5. AUX Input
6. Front RCA Output
7. Rear RCA Output
8. Sub RCA Output
9. Zone 2 RCA Output
5.5”
3.5”
e
n

4
OPERATION
The button layout below will give you a quick overview of the button functionality.
BUTTONS:
1 - Source
2 - Favorites
3 - Menu
4 - Sub/Zone 2
5 - Seek/Tune Down
6 - Play/Pause
7 - Seek/Tune Up
8 - Volume Knob
Function: How To:
Power On Press the Source (1) button.
Power Off Hold the Source (1) button for 2 seconds.
Volume Up Turn the knob (8) clockwise.
Volume Down Turn the knob (8) counter-clockwise.
Seek Up Press Seek Up (7) once.
Seek Down Press Seek Down (5) once.
Tune Up Hold down Seek Up (7).
Tune Down Hold down Seek Down (5).
Enter/Select Press the Knob (8) inward once.
Play/Pause Press Play/Pause (6) once.
Mute Press Play/Pause (6) once.
Subwoofer Level Press Sub/Zone (4) once.
Zone 2 Level Hold Sub/Zone (4) for 1 second.
1
2
3
84567
DISPLAY
KMC50 Settings MENU
To enter the Settings Menu : Hold the MENU (3) button for 2 seconds.
Press the Menu (3) button to scroll between menu items and rotate the
knob (7) to adjust the Menu setting.
Available Settings are:
Beep:
Turns the audible key press on and off. Default is off.
Loud:
Turns the loudness function on and off. Default is off.
Area:
Changes the FM/AM Tuner region from USA to Europe. Default is USA.
Zone 2:
Turns Zone 2 volume control on and off. Default is off.
Z2VOL:
The Absolute and Relative setting for Zone 2 change the behavior of the
Zone 2 volume control with regard to the main zone volume.
a. Relative- When the main zone volume is increased or decreased, Zone
2 volume will adjust up or down accordingly.
b. Absolute- When the main zone volume is increased or decreased, Zone
2 volume will remain at the same level until adjusted independently.
HPF:
Adjusts the high-pass crossover for internal channels and Front, Rear, Zone
2 RCA outputs.
Your available options: OFF, 50Hz, 80Hz, 120Hz.
Dimmer:
The Dimmer allows you to adjust the brightness of the screen, and buttons.
You can adjust the brightness from 0 to 10.

5
OPERATION
Sources Sources Cont.
To change any of the sources, press the Source (1) button on the KMC50.
FM Source:
AM Source:
Weatherband (WX) Source:
Function: How To:
Seek Up: Press the Seek Up (7) button once.
Seek Down: Press the Seek Down (5) button once.
Tune Up: Hold the Tune Up (7) button for 2 seconds. Then press (7) once.
Tune Down: Hold the Tune Down (5) button for 2 seconds. Then press (5) once.
Mute: Press the Play/Pause (6) button.
Function: How To:
Seek Up: Press the Seek Up (7) button once.
Seek Down: Press the Seek Down (5) button once.
Tune Up: Hold the Tune Up (7) button for 2 seconds. Then press (7) once.
Tune Down: Hold the Tune Down (5) button for 2 seconds. Then press (5) once.
Mute: Press the Play/Pause (6) button.
Function: How To:
Seek Up: Press the Seek Up (7) button once.
Seek Down: Press the Seek Down (5) button once.
Tune Up: Hold the Tune Up (7) button for 2 seconds. Then press (7) once.
Tune Down: Hold the Tune Down (5) button for 2 seconds. Then press (5) once.
Mute: Press the Play/Pause (6) button.
USB Source:
Function: How To:
/FYU5SBDL1SFTTUIF4FFL6QCVUUPOPODF
Previous Track: Press the Seek Down (5) button once.
Fast Forward: Hold the Tune Up (7) button.
Rewind: Hold the Tune Down (5) button.
Pause: Press the Play/Pause (6) button.
Quick Browse:
Press the Favorites (2) button to enter the quick browse menu. This
Displays all les/folders available for playback. Rotate the knob to scroll
through the items and press knob (8) to begin playback of selected track.
Repeat/Shufe:
Press and Hold the Favorites (2) button to turn on and off the Repeat and
Shufe function. Each Press and Hold will cycle through Repeat ON,
Repeat OFF, Shufe ON, Shufe OFF

6
OPERATION
FAVORITES
The Favorites button will allow you to view and set your favorite station from the
following sources: FM - AM - WX 10 favorites can be set for each source.
Setting a Favorite
1. Select the station you wish to add to the favorites list.
2. Press the Favorites button and select the Favorites preset you wish to set.
3. Press and Hold the knob (8) button for 2 seconds to set.
Audio Settings
Audio Menu: Press the Menu (3) button from any source screen to enter the
Audio Settings Menu. Pressing the Menu (3) button will scroll between the
available settings. Rotate the knob (8) to adjust the setting.
Bass: Rotate the knob left and right to adjust the Bass. Pressing Menu (3)
XJMMNPWFUPUIFOFYUJUFN"EKVTUNFOUJTGSPNUP
Treble: Rotate the knob left and right to adjust the Treble. Pressing Menu (3)
XJMMNPWFUPUIFOFYUJUFN"EKVTUNFOUJTGSPNUP
Balance: Rotate the knob left and right to adjust the Balance. Pressing
.FOVXJMMNPWFUPUIFOFYUJUFN"EKVTUNFOUJTGSPN-FGUUP3JHIU
Fader: Rotate the knob left and right to adjust the Fader. Pressing Menu (3)
XJMMNPWFUPUIFOFYUJUFN"EKVTUNFOUJTGSPN'SPOUUP3FBS
Equalizer: When the EQ is ON, Bass & Treble controls are not acces-
sible. The KMC50 has the following preset options for the EQ:
OFF - FLAT - CLASSICAL - POP - ROCK - CUSTOM. Rotating the
knob left and right to scroll between the options. When CUSTOM is
selected press Menu (3) to enter the custom frequency adjustment
below. To enable Bass, Mid & Treble controls, EQ must be set to OFF.
When using the CUSTOM EQ you can adjust the following frequencies:
60Hz - 250Hz - 250Hz - 1kHz - 3kHz - 8kHz
Rotate the knob (8) to adjust the value. In each of these frequencies
you can adjust the values from -6 to 6.
Sources Cont.
AUX Input Source:
Function: How To:
Mute: Press the Play/Pause (6) button.
Bluetooth Source:
Function: How To:
/FYU5SBDL1SFTTUIF4FFL6QCVUUPOPODF
Previous Track: Press the Seek Down (5) button once.
Pause: Press the Play/Pause (6) button.
Bluetooth Device Name: Media Center. There is no password required.
When the KMC50 is not paired with a device, “In Pairing Mode” will appear
on the screen until a device is paired. Press and Hold Favorites (2) button
for 2 seconds to manually disconnect from a paired device and reenter
pairing mode. Press and Release Favorites (2) button to reconnect last
known device.
T
Y
A
W
W
Y
t

7
TROUBLESHOOTING
The following checklist will help you remedy problems you may encounter with your unit. Before going through the checklist below, check the connection and
operating procedures. If the problem is not solved, please contact your local KICKER retailer or call 1-800-844-2774.
General
Radio Reception
No power is being supplied to the unit- Check to ensure 12V is being supplied to the red wire and the black wire has a good ground.- Check the fuse - Press the Source button.
No Sound- Check to ensure ampliers (if applicable) are on.- Check to ensure fader and balance is in the middle (0) position.
The buttons will not function- Perform Master Reset by holding the Play/Pause button down for 10 seconds.
Stations cannot be received- Check Antenna for proper connection.- The broadcast signal is too weak.- Ensure Tuner in Settings Menu is set to proper region.
RDS Information is not displayed- The current station is not an RDS station.- RDS data has not been received.
USB playback
You cannot play back items via a USB hub.- This unit cannot recognize USB devices via a USB hub.
A USB device takes longer to play back.- The USB device contains les with a complicated tree structure or contains a large amount of les.
The sound is intermittent.- The sound may be intermittent at a high-bit-rate of more than 320 kbps.
WARRANTY
Electronics Limited Warranty (including KICKER Accessories)
When purchased from an Authorized KICKER Dealer, CPS warrants this product to be free from defects in material and workmanship under normal use for a period of ONE (1)
YEAR from date of original purchase with receipt. If this product is identied as “Refurbished” or “B Goods”, the warranty is limited to a period of THREE (3) MONTHS from the
date of original purchase. In all cases you must have the original receipt. Should service be necessary under this warranty for any reason due to manufacturing defect or malfunc-
tion during the warranty period, CPS will repair or replace (at its discretion) the defective merchandise with equivalent merchandise. Warranty replacements may have cosmetic
TDSBUDIFTBOECMFNJTIFT%JTDPOUJOVFEQSPEVDUTNBZCFSFQMBDFEXJUINPSFDVSSFOUFRVJWBMFOUQSPEVDUT8BSSBOUZJTWBMJEPOMZGPSUIFPSJHJOBMQVSDIBTFSBOEJTOPUFYUFOEFEUP
PXOFSTPGUIFQSPEVDUTVCTFRVFOUUPUIFPSJHJOBMQVSDIBTFS"OZBQQMJDBCMFJNQMJFEXBSSBOUJFTBSFMJNJUFEJOEVSBUJPOUPBQFSJPEPGUIFFYQSFTTXBSSBOUZBTQSPWJEFEIFSFJOCFHJO-
OJOHXJUIUIFEBUFPGUIFPSJHJOBMQVSDIBTFBUSFUBJMBOEOPXBSSBOUJFTXIFUIFSFYQSFTTPSJNQMJFETIBMMBQQMZUPUIJTQSPEVDUUIFSFBGUFS
© 2019 CPS Distributors, Inc. 6024 Parretta Dr. Kansas City, MO 64120 800-844-2774

IC WARNING
This device contains licence-exempt transmitter(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt
RSS(s). Operation is subject to the following two conditions:
(1) This device may not cause interference.
(2) This device must accept any interference, including interference that may cause undesired operation of the device.
L’émetteur/récepteur exempt de licence contenu dans le présent appareil est conforme aux CNR d’Innovation, Sciences et Développement
économique Canada applicables aux appareils radio exempts de licence. L’exploitation est autorisée aux deux conditions suivantes:
1. L’appareil ne doit pas produire de brouillage;
2. L’appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement.
This equipment meets the exemption from the routine evaluation limits in section 2.5 of RSS-102. It should be installed and operated with a
minimum distance of 20cm between the radiator and any part of your body.
Cet équipement est conforme à l'exemption des limites d'évaluation habituelle de la section 2.5 de la norme RSS-102. Il doit être installé et
utilisé à une distance minimale de 20 cm entre le radiateur et toute partie de votre corps.
KMC50
Owner’s Manual

KMC50 v1.0
