Kicker PSM3 User manual

PSM3 Weather-proof Mini System
Wiring: Attach the included wiring to your source unit or amplifier. If you
require more length, splice the exposed wiring from the insulated cable to your
source unit or amplifier using 18 gauge wire. KICKER recommends protecting
the splice with heat shrink tubing. Attach the Rear Badge over the M5x40
Screw.
Specifications
Woofer [in, mm] 3, 75
Frequency Response [Hz] 100 - 15,000
Power Handling [PEAK/RMS] 100/50
Sensitivity [1W, 1m] 85 dB
Nominal Impedance [Ω] 2 or 4
Weight [oz, g] 20, 570
Height [in, mm] 4-3/4, 120
Width [in, mm] 3-3/8, 86
Depth [in, mm] 3-7/8, 98
Fits Handle Bar Sizes [in,mm]
1-1/4, 32
1, 25
7/8, 22
Contains:
(2) PSM Speaker
(2) PSM Enclosure
(2) Upper Clamp
(2) Lower Clamp
(2) Speaker Mount
O-Ring
(2) M5 O-Ring
(2) Washer
(2) M5x40 Screw
(2) M8X20 Screw
(4) M5x16 Screw
(2) Rear Badge
(4) Small Adapter
(4) Large Adapter
Frost Clear: Negative Frost Blue - Positive
3

Enclosure Mounting: Remove the M5x16 Screws and Lower Clamp
using a 4mm hex key, then position the Upper Clamp along the bar you wish
to mount the enclosure to. Use the Large & Small Adapters for smaller
bar-mounting applications. Attach the Lower Clamp to the Upper Clamp with the
M5x16 Screws using a 4mm hex key.
Speaker Orientation: Slightly loosen the M8X20 Screw using a 6mm hex
key and the M5x40 Screw using a 4mm hex key. Aim the speaker enclosure
at the listener’s head and orient the logo as desired. Do not rotate the speaker
too far (± 45°) and damage the internal wiring. Retighten the screws.
No Adapter: 1-1/4 inches (32mm)
Large Adapter: 1 inch (25mm)
M5x40 Screw
M8x20 Screw
Small Adapter: 7/8 inch (22mm)
Use with Large Adapter
12
