Kidco Safeway G2000 Manual

Fits openings 24.75”– 43.5”
G2000
USER GUIDE
®
HARDWARE MOUNTINSTALLATION
G2001
Safeway
®
A
B
I-J K
L N O PM
DC E F G H
Parts list
AHinge side template
BLocking side template
C Lower hinge bottom
DLower hinge spindle
ESpring
FLower hinge cap
GUpper hinge
HUpper hinge spindle
I-J Screw/Screw socket
KWood screws
LLocking latch bracket
MLower latch bracket
NLocking latch spindle
OStop pin
PWrench

USER GUIDE
4
1
2
1Important: Gate must be installed in a
structurally sound opening. The hinge side
of gate must be mounted to a rigid surface.
Ensure mounting surface (wall, door frame,
stairposts, etc.) is strong, rigid and has an
even surface.
2If using gate on a stairway, it must be
placed either on top stair or on lowest stair
at the bottom.
3The correct width will be achieved by
adjusting gate sections and all four corner
spindles. Each spindle adjusts individually
and may be extended varying lengths to
allow for molding, uneven walls, etc.
Spindles may be extended a minimum of
1 ¼” (hinge side) or 1” (on locking side)
and a maximum of 3”.
Installation
3
G2000/G2001
Safeway
®
4Finding appropriate width of gate
Adjust sections until gate is approximately
the correct width and adjustment holes are
aligned and overlap in two places on both
the top and bottom rail (maximum overlap
is 5 bars).
Sections should fit without any distance
between rails or bars.
5Place screws (I) and screw sockets (J)
in top and bottom sets of overlapping
adjustment holes nearest hinge and locking
sides of gate.
Do not fully tighten yet.
6Screw upper hinge spindle (H) into top
rail of one gate section. Screw lower hinge
spindle (D) into bottom rail of same side.
Extend spindles equally.
4
6
5
H
D
J
J
I
I

N
N
USER GUIDE
6
7Screw locking latch spindles (N) into
top and bottom rails of second gate
section. Extend spindles equally. Final
spindle adjustments will be made later.
8Hinge side mounting
Screws provided are for mounting
directly into wood. If mounting into
brick, drywall or other surfaces, use
appropriate hardware. If installing into
hardwood (i.e. oak), drilling a pilot
hole may be necessary. Cut out
templates along all dotted lines, separating
template (A) from (B). Hold template (A)
vertically and completely outstretched
against mounting surface with the end
marked ” ” even with the floor. Mark screw
hole positions. Remove the template.
9Use longer screws for mounting
into studs behind drywall. Using
2 wood screws (K), mount upper hinge (G)
(with hole pointing up) in top 2 screw
hole positions.
10 Using 2 wood screws (K), mount lower
hinge bottom (C) (with post pointing up) in
bottom 2 screw hole positions.
A
8
7
G2000/G2001
Safeway
®
G
9
C
10
M
11 Locking Side Mounting
Screws provided are for mounting
directly into wood. If mounting into
brick, drywall or other surfaces, use
appropriate hardware. If installing into
hardwood (i.e. oak), drilling a pilot hole
may be necessary. Hold template (B)
vertically and completely outstretched
against mounting surface with the end
marked ” ” even with the floor. Mark 4
screw hole positions. Remove the template.
12 Determine which direction the gate
should open. For the top of stairways,
gate should never open out over stairs.
Insert stop pins (O) from behind in holes of
locking latch bracket (L) and lower latch
bracket (M) opposite desired opening
direction.
Important: The gate cannot open to the
stop pinside.
13 Use longer screws for mounting
into studs behind drywall. Using 2 wood
screws (K) mount locking latch bracket (L) in
top 2 screw hole positions.
14 Using 2 wood screws (K) mount lower
latch bracket (M) in bottom 2 screw hole
positions.
13
B
11
O
L
M
12
L
14

USER GUIDE
8
15 Center gate in opening. Adjust upper
hinge spindle (H) so post fits into upper
hinge hole (G).
16 Adjust lower hinge spindle (D) so end
fits over lower hinge post (C).
Space between end of gate and mounting
surface on hinge side may be no less than
1 ¼” and not more than 2 1/2”.
17 Adjust locking latch spindles (N) until
they fit securely into both latch brackets.
Top spindle must click under locking latch
when in the closed position.
Space between end of gate and mounting
surface on locking side may be no less
than 1” and not more than 2 3/4”.
D
C
16
N
17
H
G
15
G2000/G2001
Safeway
®
H
G
H
G
Min: 1 1/4”
Max: 3”
A
Min: 1”
Max: 3”
B
18 If adjusting the spindles does not
achieve the correct length, it may be
necessary to lift gate off hinges and
readjust the sections (see step 3).
Check that gate can be smoothly
opened and closed.
19 Place spring (E) on lower hinge post.
20 Place lower hinge cap (F) on lower
hinge and push down until it clicks into
locked position.
IMPORTANT: ENSURE HINGE CAP CANNOT
BE PUSHED UP AND IS LOCKED IN PLACE.
18
E
19
20

USER GUIDE
10
G2000/G2001
Safeway
®
21 Using Phillips head screwdriver,
tighten all screws and screw sockets.
With wrench (P), securely tighten all 4 lock
nuts toward the gate.
22 Operation
To open gate, press down on locking latch
with thumb and lift gate out of upper and
lower brackets. To lock gate, top locking
latch spindle must click under locking latch
and bottom latch spindle must rest in bottom
bracket as shown in figure 17.
NOTE: GATE SHOULD ALWAYS BE IN
THE LOCKED POSITION. IF GATE IS OPEN
AND EXCESSIVE PRESSURE IS APPLIED,
(SUCH AS STANDING OR SWINGING
ON THE GATE) STRUCTURAL DAMAGE
MAY OCCUR.
23 Temporary removal
The gate may be removed by pressing back
on the locking tab on top of lower hinge
bottom while sliding the hinge cap up.
Remove spring and lift gate off top and
bottom hinges. FOR SAFETY REASONS,
RETURN SPRING AND HINGE CAP ONTO
HINGE POST, MAKE SURE CAP IS
LOCKED IN PLACE.
P
21
22
23
Intended for use with children
from 6 months through 24 months
Check the stability of the gate
and tighten all hardware and
mountings regularly
To prevent serious injury or death,
securely install gate or enclosure
and use according to
manufacturer’s instructions
Install according to the
manufacturer’s instructions
Never use with a child able to
climb over or dislodge/open the
gate or enclosure
Never use if gate is less than
¾ of child’s height
Do not use if any part of the gate
is broken or missing
This product will not necessarily
prevent all accidents. Never leave
child unattended
Use only spare parts available
from KidCo®
Never allow child to climb or
swing on gate
Use only with the locking/latching
mechanism securely engaged
Discontinue use if any part of
the gate is damaged
Never climb over the gate
Never hang or tie toys, etc,
to any part of the gate
•
•
•
•
•
•
•
•
•
•
•
•
•
•
WARNING
Important Information
FOLLOW THESE INSTRUCTIONS CAREFULLY AND KEEP THEM
FOR FUTURE REFERENCE
This gate is designed for children from 6 months to 24 months. Since each child’s skills develop at different
ages, these parameters should be monitored against your child’s own development.
When installed in as instructed, between two clean, structurally sound surfaces, this gate conforms to
applicable ASTM standards.
No part of the gate requires lubrication. Clean using warm, soapy water or a damp cloth. Do not use abrasive
cleaners or bleach. Once installed the gate should be checked periodically to ensure a safe and secure fit
and to maintain proper working order.
Maintenance
