Genesis EG1 Series Signaling
Appliance Installation Sheet
Description
Genesis EG1 Series horns, strobes, and horn-strobes are compact,
wall-mounted, fire alarm signaling appliances designed for indoor dry
applications. See Table 1 through Table 3 for a list of models.
Table 1: Horn models
Number Description
EG1ARF Compact wall horn, red, FIRE
EG1ARN Compact wall horn, red, no marking
EG1AWF Compact wall horn, white, FIRE
EG1AWN Compact wall horn, white, no marking
Table 2: Strobe models
Number Description
EG1VRF Compact wall strobe, red, FIRE
EG1VRN Compact wall strobe, red, no marking
EG1VWF Compact wall strobe, white, FIRE
EG1VWN Compact wall strobe, white, no marking
Table 3: Horn-strobe models
Number Description
EG1AVRF Compact wall horn-strobe, red, FIRE
EG1AVRN Compact wall horn-strobe, red, no marking
EG1AVWF Compact wall horn-strobe, white, FIRE
EG1AVWN Compact wall horn-strobe, white, no marking
Genesis EG1 Series signaling appliances feature:
• Field-configurable horn and strobe outputs. See Figure 2.
• Enhanced synchronization circuitry to comply with the latest
requirements of UL 1638 and CAN/ULC-S526.
• Input wiring test points on the front of the appliance when the
cover is removed.
Note: Synchronized operation requires a separately installed
synchronization device. See the control unit or remote booster/auxiliary
power supply compatibility list for compatible synchronization devices.
Configuration
Caution: Equipment damage hazard. Using excessive force when
removing the appliance cover may damage the cover and prevent it
from latching in place.
To configure the signaling appliance:
1. Remove the appliance cover. See Figure 1.
Insert a small, flat-bladed screwdriver into the slot at the bottom of
the appliance.
Gently pull up on the screwdriver to pry the bottom of the
appliance cover down and away from the appliance.
Lift the bottom of the cover out and over the top of the appliance.
2. Set the light and sound output switches. See Figure 2.
3. Replace the appliance cover.
Figure 1: Removing and replacing the cover

2 / 4 P/N 3102550-EN • REV 002 • ISS 03APR18
Figure 2: Light and sound output settings
(1) Constant, low dB
(2) Constant, high dB
(3) T3 temporal, low dB
(4) T3 temporal, high dB
(5) 75 candela
(6) 30 candela
(7) 15 candela
Installation
Install and wire this device in accordance with applicable national and
local codes, ordinances, and regulations.
Caution: Electrical supervision requires that you break the wire run at
each terminal. Do not loop the signaling circuit field wires around the
terminals.
Note: Do not use Genesis EG1 Series strobe and horn-strobe
signaling appliances in applications where signal power is cycled on
and off, such as coded or private mode signaling systems.
To install the appliance:
1. Remove the appliance cover.
2. Connect the field wiring. Observe signal polarity for the appliance
to operate properly. See Figure 3.
3. Attach the appliance and, if used, the trim ring backplate to the
electrical box. Do not overtighten the screws. See Figure 4.
4. Replace the cover by hooking it to the top of the appliance, and
then snapping the bottom into place. See Figure 1.
5. Test the unit for proper operation.
Figure 3: Wiring
(1) Horn/strobe circuit in (signal polarity shown in the active condition)
(2) Horn/strobe circuit out
Figure 4: Mounting on a 1-gang electrical box
(1) Electrical box
(2) EG1 Series signaling appliance
(3) Captive screw (2X)
(4) Appliance cover
Note: Using a trim ring is optional except when installing the signaling
appliance on electrical boxes greater than three inches wide. For
installation instructions when using a trim ring, see Genesis EG1
Series Trim Ring Installation Sheet (P/N 3102552-EN).
Maintenance and testing
Caution: Equipment damage hazard. To maintain the required agency
listings, do not change factory-applied finishes.
This unit is not serviceable or repairable. Should the unit fail to
operate, contact the supplier for replacement.
Perform a visual and operational inspection in accordance with
applicable codes and standards or as directed by the local authority
having jurisdiction.
Input wiring test points are available on the front of the appliance when
the cover is removed. The test points let you easily spot-check the field
circuit wiring without the need to remove the appliance from the wall.
See Figure 5.
Figure 5: Test points
Note: Marking indicates signal polarity when the circuit is active.
(1) (2) (3) (4)
(6)
(7)
(5)
+
–+
–
(1) (2)
(1)
(2)
(3) (4)

P/N 3102550-EN • REV 002 • ISS 03APR18 3 / 4
Specifications
Operating voltage 16 to 33 VDC, 16 to 33 VFWR
Operating current See Table 4 to Table 6
Horn signal type Constant or T3 temporal
Sound output See Table 7
Sound pattern See Table 8
Light output 15, 30, or 75 candela
Strobe flash rate 1 fps (flash per second) approx.
Light distribution See Figure 6
Synchronization 20 Ωmax. between any two devices.
To determine allowed wire resistance, refer to
these specifications, and the specifications
for the synchronized signal source.
Wire size 12 to 18 AWG (0.75 to 2.50 mm²)
Screw torque
Mounting screws
Terminal screws
15 lbf-in (1.8 N-m) max.
12 lbf-in (1.4 N-m) max.
Dimensions (W×H×D) 3 × 4-5/8 × 1-1/8 in. (7.62 × 11.75 × 2.86 cm)
See Figure 7
Strobe-to-box center
offset
-0.71 inches (-1.8 cm)
Compatible electrical
boxes [1]
1-gang, 2-gang, 4-inch octagon,
4-inch square
Trim rings EG1TR, EG1TW
Replacement covers See Table 9 to Table 11.
Operating environment
Temperature
Relative humidity
32 to 122°F (0 to 50°C)
0 to 93% noncondensing
Storage temperature -40 to 158°F (-40 to 70°C)
[1] Electrical boxes must be at least 1-1/2 in. (3.81 cm) deep. Electrical
boxes greater than three inches wide require a trim ring.
Table 4: Operating current (horn models)
Sound setting 16 to 33 VDC 16 to 33 VFWR
C-LOW, T-LOW 13 mA 15 mA
C-HIGH, T-HIGH 23 mA 29 mA
Table 5: Operating current (strobe models)
Strobe setting 16 to 33 VDC 16 to 33 VFWR
15, 30, 75 24 mA 32 mA
Table 6: Operating current at 16 to 33 VDC (horn-strobe models)
Strobe
setting Sound setting 16 to 33 VDC 16 to 33 VFWR
15, 30, 75 C-LOW, T-LOW 35 mA 43 mA
C-HIGH, T-HIGH 45 mA 55 mA
Table 7: Sound output (horn and horn-strobe models)
Sound setting Reverberant
(UL 464)
Anechoic
(CAN/ULC-S525)
C-LOW, T-LOW 80 dBA 86 dBA
C-HIGH, T-HIGH 86 dBA 92 dBA
Table 8: Sound pattern (ULC)
Axis Angle Change in output
Horizontal 45° and 115° –3 dBA
5° and 130° –6 dBA
Vertical 65° and 135° –3 dBA
45° and 140° –6 dBA
Table 9: Horn replacement covers
Model Description
EG1ARN-CVR Cover, compact wall horn, red, no marking
EG1AWA-CVR Cover, compact wall horn, white, ALERT
EG1AWN-CVR Cover, compact wall horn, white, no marking
Table 10: Strobe replacement covers
Model Description
EG1VRN-CVR Cover, compact wall strobe, red, no marking
EG1VWA-CVR Cover, compact wall strobe, white, ALERT
EG1VWN-CVR Cover, compact wall strobe, white, no marking
Table 11: Horn-strobe replacement covers
Model Description
EG1AVRN-CVR Cover, compact wall horn-strobe, red, no marking
EG1AVWA-CVR Cover, compact wall horn-strobe, white, ALERT
EG1AVWN-CVR Cover, compact wall horn-strobe, white, no
marking
Figure 6: Light distribution
(1) Horizontal left
(2) Horizontal right
(3) Vertical bottom
─
─────── Measured
─
────UL minimum
Note: Figure 6 shows the light distribution for 75 cd output. For 30 cd
output, multiply point by 0.40. For 15 cd output, multiply point by 0.20.
20
40
60
80
100
120
140
160
0510 15 20 25 30 35 4045
50
55
60
65
70
75
80
85
90
5
10
15
20
25
30
35
40
45
50
55
60
65
70
75
80
85
90
90
85
80
75
70
65
60
55
50
4540 35 30 25 20 15 10 5
(1) (2)
(3)
