VM-ELEC Chassis Electronics
Assembly Installation Sheet
Description
The VM-ELEC Chassis Electronics Assembly provides the mounting,
internal power, and audio and data distribution for the VM-CPU main
board, user interface, and supporting cards.
Installation
WARNING: Electrocution hazard. To avoid personal injury or death
from electrocution, remove all sources of power and allow stored
energy to discharge before installing or removing equipment.
Caution: Circuit boards are sensitive to electrostatic discharge (ESD).
To avoid damage, follow ESD handling procedures.
Note: Install the PS10-4B power supply board and any cabinet
backbox-mounted options before installing the VM-ELEC.
To install the VM-ELEC:
1. Connect one end of the data ribbon cable to J17 on the VM-CPU.
Refer to Figure 2 for the VM-CPU location on the assembly.
Refer to the VM-CPU Main Board Installation Sheet (P/N 3101798-
EN) received in the instruction sheet bag with the VM-ELEC for
additional information.
2. Connect one end of the power supply cable to J15 on the
VM-CPU.
3. Connect the other end of the data ribbon cable to J1 on the
PS10-4B. See Figure 1.
Refer to the PS10-4B Power Supply Board Installation Sheet
(P/N 3101774-EN) received with the board for additional
information.
4. Connect the other end of the power supply cable to J2 on the
PS10-4B.
5. Attach the VM-ELEC to the four screws on the backbox using the
hardware provided. See Figure 1.
Wiring
Connect VM-CPU field wiring as described on the VM-CPU Main
Board Installation Sheet (P/N 3101798-EN).
Maintain 0.25 in. (6 mm) separation between power-limited and
nonpower-limited wiring at all times. Keep nonpower-limited wiring in
the shaded area shown in Figure 3. Secure the wiring to the cabinet
using nylon cable ties.
Figure 1: Installing the VM-ELEC assembly
(1)PS10-4B power supply protective cage is installed here for ULC applications
(2)Data ribbon cable (P/N 250189-01)
(3)Power supply cable (P/N 250187-01)
(4)#8-32 K-nuts (4X)
(4)
PS10-4B
(1)
(2)
(3)

2 / 2 P/N 3101780-EN • REV 03 • ISS 16FEB16
Figure 2: VM-ELEC exploded view
(1)Chassis
(
2)VM-CPU main board
(3)VM-LCD user interface
(4)Filler plates
(5)Mounting frame
Figure 3: Power-limited and nonpower-limited wiring
(1)Nonpower-limited wiring area
(2)Power-limited wiring area
(3)Battery area
Specifications
VM
-CPU Refer to the VM-CPU Main Board
Installation Sheet (P/N 3101798-EN)
VM
-LCD Refer to the VM-LCD User Interface
Installation Sheet (P/N 3101781-EN)
Operating environment
Temperature
Relative humidity
32 to 120°F (0 to 49°C)
0 to 93% noncondensing
Regulatory information
FCC compliance
This device complies with part 15 of the
FCC Rules. Operation is subject to the
following two conditions: (1) This device may
not cause harmful interference, and (2) this
device must accept any interference
received, including interference that may
cause undesired operation.
Environmental class
UL: Indoor dry
