Kidde RBUN User manual

1
Part Number: RBUN
TRIGGER INPUT & RELAY MODULE
USER GUIDE
IMPORTANT: READ INSTRUCTIONS CAREFULLY AND
COMPLETELY BEFORE INSTALLING
This is an AC mains powered battery backup surface mounting relay module. The alarms
do NOT mount directly onto this relay; it links into their circuit via hardwiring.
Compatible models: Smoke / Heat Alarms: Firex KF10, KF10LL, KF10R, KF20, KF20LL,
KF20R, KF30, KF30LL, KF30R, Slick 1SFW, 1SFWR, 2SFW, 2SFWR, 3SFW, 3SFWR.
CO alarms: 4MCO and 4MDCO.
Operational features:
‘Trigger’
Causes the interlinked Smoke / Heat / CO alarm(s) to sound alarm in the temporal three
(smoke alarm pattern) and the relay to activate when the interconnected sprinkler system
is activated.
‘Relay’
a. Operates (activating the relay) when interlinked
Smoke / Heat Alarm(s) sound an alarm. (The installer
MUST preselect the Selector switch on relay module
selected to ‘SMOKE’).
OR
b. Operates (activating the relay) when the interlinked
Carbon Monoxide Alarm(s) sound an alarm. (The
installer MUST preselect the Selector switch on relay
module selected to ‘CO’).
a
b
Selector switch
1202-7202-01

2
!IMPORTANT SAFETY DESIGN NOTE: Relay will NOT operate when the CO alarms
sound when the selector switch is set to ‘SMOKE’ or when the Smoke / Heat alarm(s)
sound when selected to ‘CO’.
The input extra low voltage power supply portion is designed primarily to be connected
to suitable sprinkler flow switches.
The relay module can be used for signalling to suitable compatible equipment or to
activate auxiliary warning devices such as external bells and sirens, hallway or stairwell
lighting. It provides isolated, (no internal connection to 230 volts AC) normally open, and
normally closed contacts.
!WARNING! Alarm and relay module wiring installation must comply with the
current edition of BS 7671 Wiring Regulations and all appropriate prevailing local
regional / national building regulations / codes of practice.
All wiring should be performed by a competent, qualified electrician. Failure to install
this product correctly may expose the user to electric shock or fire risk hazards. This
relay module is not rated as waterproof and must not be exposed to dripping or
splashing. The relay module must be installed correctly in order to function. The
electrical circuit used to power the alarms and the relay module must be a permanent
supply being a 230 volt AC 50Hz circuit which cannot be turned off by a switch. This relay
module has an alkaline battery backup to allow it to function in mains outages.
!WARNING: This product cannot be operated from power derived from a square
wave, modified square wave or modified sine wave inverter. These type of inverters are
sometimes used to supply power to the structure in ‘off grid’ installations, such as solar
or wind derived power sources. These power sources produce high peak voltages that
can damage the device.
!IMPORTANT: Whenever alarms and relay modules are interconnected they
must be powered on a single circuit.

3
133.5mm
31.5mm
AC
FLASHING = ALARM
1 FLASH = LOW BATTERY
INSTALLATION INSTRUCTIONS:
This relay module should be installed in an appropriate suitable location. Site and select
alarm type(s) in accordance with manufacturer literature/user guide shipped with the
alarms. Also refer to applicable Building Regulation requirements and codes of practice
such as BS 5839 Pt 6 and / or BS EN 50292.
!Isolate mains power before commencing work.
Refer to the below diagrams
1. Remove cover screws to allow access to wire connections. Remove cover and 9V
battery.
Front and side view of
relay module unit

4
L L N N IO IO SW 9V NC NO C E E
Mains 230 Volts AC Alarm Int Sprinkler Int Relay CPC Connections
Tighten terminal screws to 0.8 N.m max.
2. Connect wires to appropriate terminals.
Selector switch
Battery compartment

5
3. The relay module can be connected anywhere in the circuit to suit the application.
See diagram below.
Neutral
I/O
Live
SW
9V DC/
Vbat
NO
NC
Common
CPC omitted for clarity
Sprinkler
Flow Switch
Kidde
Smoke
alarm
Kidde
CO
alarm
Relay
module

6
Slide battery compartment
5. Insert battery into battery compartment, and slide it into product. Insert and
tighten the screw that holds the battery compartment closed.
4. Replace relay module cover and tighten screws after all wire connections are
complete.

7
Earth terminal is provided to facilitate wiring termination of the CPC wire, which plays no part in
the safety protection of the relay module itself.
After all connections are made, replace the cover and test operation.
Do not exceed the total number of devices allowable in the interconnected system, refer to the
individual alarm’s user guide for the maximum number of units allowed when interconnecting.
Avoid locations where the temperature or humidity limits might be exceeded, such as garages
and unfinished attics. See Technical Specifications.
!ATTENTION: Turn off power when replacing battery. Do not remove main relay
module cover. Replace battery please refer to section 5.
6. Test Relay Module operation.
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste.
Please recycle where facilities exist. Check with your local authority or retailer
for recycling advice.

8
Relay Module Operation and Indications Table
Status Red LED Green LED Smoke relay CO relay
Normal Operation On – when AC mains
power present
Off - when AC mains
power not connected
No operation No operation
Relay module
receiving Smoke
signal from
attached units
Note: Selector
switch must be set
to SMOKE
T3 pattern- Flash
3 times, same
as Smoke/Heat
alarm unit NA
Red LED Flash 3
times, same as
Smoke/Heat alarm
pattern.
Relay activates.
No operation
Relay module
receiving CO
signal from
attached units
Note: Selector
switch must be set
to CO
T4 pattern- Flash
4 times, same as
CO alarm unit NA
No operation Red LED Flash
4 times, same
as CO alarm
pattern.
Relay activates.
Low battery
backup in relay
module
Flashes every 40
seconds
NA Flashes every 40
seconds
Flashes every
40 seconds
Sprinkler activated
with signal from
flow switch.
Note: Selector
switch must be set
to SMOKE
T3 pattern- Flash
3 times, same
as Smoke/Heat
alarm unit
NA Red LED Flash 3
times, same as
Smoke/Heat alarm
pattern.
Relay activates.
NA

9
Technical Specifications
Supply Voltage: 230VAC 50Hz, 50mA Max
Battery Backup: Alkaline Battery
Replacement Batteries: Energizer 522, DURACELL MN1604 or MX1604
Battery Lifespan: 1 Year
Alarm Connection: Via Hard wire Circuit with models listed (see diagram)
Output Relay Contacts: Contact ratings 230V AC @ 3Amps
24V DC @ 3Amps
Fixing:
Remote fixing separate to alarm units hardwired circuit connection
Temperature Range: 0°C to 40°C
Humidity Range: 0% to 90% RH, non-condensing
Dimensions: 133.5 mm diameter by 31.5 mm depth
Weight: 222 gram
Guarantee: 5 year limited warranty
Approvals:

10
Guarantee
Kidde Safety Europe Ltd
Ash House, Littleton Road, Ashford, TW15 1TZ, UK
Telephone: [phone]
www.kiddesafetyeurope.co.uk
Made in China
Kidde guarantees to you as a purchaser that the enclosed unit will be free of defects
in material, workmanship or design under normal use and service for a period of 5 years
(from the date of purchase), excluding any loose battery supplied. The Guarantee is not
assignable. Our liability to you, under this guarantee is limited to repairing or replacing any
part which we find to be defective in material, workmanship or design (part replacement
only, no installation), free of charge to the customer, who is situated within the UK, upon
sending the unit with proof of date of purchase, postage prepaid, to Kidde Safety Europe,
Ash House, Littleton Road, Ashford, TW15 1TZ, UK. The terms of this guarantee will not
apply in the following circumstances: If unit has been damaged, modified, neglected,
dismantled, contaminated, abused or altered after the date of purchase, or if it fails to
operate due to incorrect selection, siting, installation, maintenance or inadequate AC or DC
electrical power, or damage caused by failure to abide by the instructions supplied. The
liability of Kidde, arising from the sale of this alarm or under the terms of this guarantee shall
not in any case exceed the cost of replacement of the unit, in no case, shall be liable for
consequential loss or damaged resulting from the failure of the alarm or for the breach of this
or any other guarantee, express or implied, or for damages caused by failure to abide by the
instructions supplied. This guarantee does not affect your statutory rights. Kidde makes no
guarantee, express or implied, written or oral, including that of satisfactory quality or fitness
for any particular purpose, with respect to the battery.
