King Canada KAC-650 User manual

AIR CLEANER
WITH REMOTE CONTROL
INSTRUCTION MANUAL
COPYRIGHT 2000 ALL RIGHTS RESERVED BY KING CANADA TOOLS INC.
C
MODEL: KAC-650
IMPORTANT INFORMATION
2-YEAR
LIMITED WARRANTY
FOR THIS AIR CLEANER
KING CANADA TOOLS
OFFERS A 2-YEAR LIMITED WARANTY
FOR NON-COMMERCIAL USE ONLY.
PROOF OF PURCHASE
Please keep your dated proof of purchase for warranty and servicing purposes.
REPLACEMENT PARTS
Replacement parts for this tool areavailable at our authorized KING CANADA
service centers across Canada. For servicing, contact or return to the retailer where
you purchased your product along with your proof of purchase.
LIMITED TOOL WARRANTY
KING CANADA makes every effort to ensure that this product meets high quality
and durability standards. KING CANADA warrants to the original retail consumer
a2-year limited warranty as of the date the product was purchased at retail and that
each product is free from defects in materials. Warranty does not apply to defects
due directly or indirectly to misuse, abuse, negligence or accidents, repairs or
alterations and lack of maintenance. KING CANADA shall in no event be liable for
death, injuries to persons or property or for incidental, special or consequential
damages arising from the use of our products. Totake advantage of this warranty,
the product or part must be returned for examination by the retailer. Shipping and
handling charges may apply. If a defect is found, KING CANADA will either repair
or replace the product.
PARTS DIAGRAM & PARTS LISTS
Refer to the Parts section of the King Canada web site for the most updated parts
diagram and parts list.

SPECIFIC SAFETY RULES
FOR AIR CLEANERS
1. FOR YOUR OWN SAFETY, READ
INSTRUCTION MANUAL BEFORE
OPERATIONG THE TOOL. Learn the
tool’s application and limitations as well
as the specific hazards peculiar to it.
2. DO NOT ATTEMPT TO REMOVE OR
REPLACE THE FILTER(S) WHILE THE
MACHINE IS IN OPERATION. MAKE
CERTAIN AIR CLEANER IS
DISCONNECTED FROM THE POWER
SOURCE.
3. DO NOT OPERATE THE CLEANER
WITHOUT THE FILTER IN PLACE TO
AVOID EXPOSURE TO ROTATING
PARTS AND OVERLOADING THE
MOTOR.
4. THE USE of filters and attachments
which are not recommended may result
in product damage or the risk of
personal injury.
5. When suspending the Air Cleaner from
the ceiling MAKE CERTAIN the
hardwareis securely anchored into a
wood structure. Always keep a
minimum of 7 feet between bottom of Air
Cleaner and the floor surface to allow for
adequate head clearance. Also, use only
properly sized chain to prevent the tool
from falling.
6. TO REDUCE THE RISK OF
ELECTRICAL SHOCK, do not expose to
water or rain, and do not lift the Air
Cleaner by the power cord. DO NOT use
the power cord as a hanging device.
7. When used in the portable application,
MAKE CERTAIN the Air Cleaner is
adequately supported, or securely
clamped to the work surface to eliminate
any potential for movement or damage
from falling.
8. ALWAYS WEAR ADEQUATE EYE
PROTECTION.
9. WHEN NOT IN USE, BE CERTAIN TO
STORE AIR CLEANER IN A SAFE
LOCATION TO ELIMINATE THE
POTENTIAL OF DAMAGE TO THE
POWER CORD OR TRIPPING
HAZARDS.
10. MAKE WORKSHOP CHILDPROOF
by unplugging tools from power source,
using padlocks, or by using a master
switch.
11. MAINTAIN TOOLS IN TOP
CONDITION. Keep filters clean for
optimum performance. Follow
instructions for changing and cleaning
filters.
12. DANGER: DO NOT use this machine
to filter any metal dust. Combining wood
and metal dust can create an explosive
hazard. This Air Cleaner is intended to be
used to filter non-explosive atmospheres
only.
13. IF YOU ARE NOT thoroughly familiar
with the operation of the Air Cleaner,
obtain advice from your supervisor,
instructor or other qualified person.
14. WARNING: DO NOT operate your Air
Cleaner until it is completely assembled
and installed according to the instruction
manual.
15. PLACE POWER CORD IN A SAFE
LOCATION TO ELIMINATE
TRIPPING HAZARDS.
16. USE FACE OR DUST MASK AND
EYE PROTECTION. WARNING: The
dust generated by certain woods and
wood products can be hazardous to your
health. Always operate machinery in
well-ventilated areas and provide for
proper dust removal.
17. WARNING: TO AVOID A
POTENTIALLY DANGEROUS
SITUATION, DO NOT USE AIR
CLEANER TO DISSIPATE FUMES OR
SMOKE. This Air Cleaner is intended for
use in non-explosive, non-metallic
atmospheres where only dry airborn
dust is present.
18. SA
VE THESE INSTRUCTIONS. Refer
to them frequentely and use them to
instruct other users.
PRODUCT SPECIFICATIONS
&
ELECTRICAL CONNECTIONS
Specifications
Outer filter..........................................................................................................5 Microns
Inner filter ............................................................................................................1 Micron
Overall dimensions (LxWxH) ........................................30-1/4” x 24-1/8” x 12-1/8”
Sound rating @ 3ft...............................................................................High speed- 60db
........................................................................................................Medium speed- 53 db
................................................................................................................Low speed- 50 db
Air flow. ........................................................................................High speed- 650 CFM
..................................................................................................Medium speed- 550 CFM
..........................................................................................................Low speed- 450 CFM
Motor ................................................................................................115V, 60Hz, 1 Phase
RPM’s ....................................................................................................High speed- 1700
..........................................................................................................Medium speed- 1300
..................................................................................................................Low speed- 1000
Net weight ................................................................................................................44 lbs.
Shipping weight ......................................................................................................50 lbs.
ELECTRICAL CONNECTIONS
GROUNDING
This air cleaner must be grounded. If it
should malfunction or breakdown,
grounding provides a path of least
resistance for electric current, to reduce
the risk of electric shock. This air cleaner
is equipped with a cord having an
equipment-grounding conductor and
grounding plug. The plug must be
plugged into an appropriate outlet that is
properly installed and grounded in
accordance with all local codes and
ordinances.
WARNING: TO MAINTAIN PROPER
GROUNDING, DO NOT REMOVE OR
ALTER THE GROUNDING PRONG IN
ANY MANNER.
As received from the factory, your air
cleaner is ready to run for 110V operation.
This air cleaner is intended for use on a
circuit that has an outlet and a plug
which looks like the one illustrated in
Fig.1.
A separate electrical circuit should be
used for your tools. This circuit should be
no less than than #12 wire and should be
protected with a 20 amp fuse. Make sure
the electric current is of the same
characteristics as stamped on the
machine nameplate. Running on low
voltage will damage the motor.
The air cleaner has three speeds and runs
at 2.4A/1700RPM in High speed,
0.8A/1300RPM in Medium speed and
0.6A/1000RPM in Low speed.
Figure 1
Current
carrying
prongs
Grounded outlet
Grounding
blade

UNPACKING
&
ASSEMBLY
UNPACKING
The Air Cleaner is shipped complete in one
container. Carefully unpack the Air Cleaner
and all loose items from the shipping
container. WARNING: DO NOT LIFT
THE AIR CLEANER BY POWER
CORD.
Contents of shipping container;
A- Air cleaner unit (1)
B- Remote control (1) with 2 AA
Batteries
C- Mounting brackets (4)
D- Hooks and nuts (4 ea.)
E- Hex. bolts (8)
F- Lock washers (8)
G- Velcropiece (1)
Tools required for assembly;
-No. 2 Cross point screwdriver
-10mm Wrench
Assembly
•This unit will work best if it is located
away from corners and heating/cooling
vents.
•This unit is specifically designed to
circulate and filter non-metalic dust, which
is generated thoughout the work area.
1) The air cleaner unit can be hung from the
ceiling. Remove the four screws (A, Fig.3)
from the cabinet top.
2) Hang the unit using four hooks and lock
nuts provided.
3) Make sure the lock nut is threaded half
way up the hook. Screw the hook into the
hole and tighten lock nut against the
cabinet top. You will need to hold the
hook so it doesn’t spin while tightening
the lock nut.
4) Repeat steps for the remaining three
hooks.
Note: Make sure the chain and ceiling
hooks areproperly rated for hanging this
unit. Hang unit with a 7ft. clearance from
the floor.
WARNING! Mounts must be anchored to
the building structure, which will support a
minimum of at least 100 pounds. Never
mount to dry wall or false ceiling grids.
Figure 2
C
E
F
D
G
A
B
Figure 3
A
Assembly
1) Four brackets can also be used for
mounting to a ceiling or wall.
2) Place one end of bracket underneath the
lip of the cabinet.
3) Attach the bracket (A, Fig.4) with two
hex. bolts (B) and two lock washers (C).
4) Repeat steps for the remaining three
brackets.
CONTROLS & FEATURES
Remote control;
Timer button:(A, Fig.5) controls the three
different settings which are:
2H-will light up on the back of the unit
with one press of the timer button. The air
cleaner will operate for 2 hours and then
will shut off automatically.
4H-will light up on the back of the unit by
pressing the timer button twice. The air
cleaner will operate for 4 hours and then
will shut off automatically.
8H-will light up on the back of the unit by
pressing the timer button three times. The
air cleaner will operate for 8 hours and
then will shut offautomatically.
Speed button:(B, Fig. 5) contols the three
different speed settings (low, medium,
high). Thereis also a manual speed button
(A, Fig.6) on the backside of the unit which
allows you to sellect the desired speed.
On/Offbutton:(C, Fig.5) turns the unit on
&off. There is also a manual on/off button
(B, Fig.6) on the backside of the unit.
Fuse switch:(C, Fig.6) will pop out in case
of an overload. Wait 3-5 minutes and push
the fuse in.
Exhaust:The exhaust vent is adjustable by
moving it to the desired angle.
Changing filters
WARNING! To reduce the risk of injury,
disconnect the air cleaner from the power
source before servicing or changing filters.
Failure to comply may cause serious
injury!
There are two filters that need to be
changed. The outer filter can easily be
removed by disengaging the two clips of
the cabinet. Pull the filter out or use a
screwdriver to pop the filter out.
The filtration bag can now be pulled out of
the unit. The filters should be replaced
depending on the amount of usage and the
environment of your shop. Clogged filters
will reduce the amount of air circulation.
Replacement filters are availlable at your
nearest KING CANADA retailer.
ASSEMBLY, CONTROLS
&
CHANGING FILTERS
Figure 4
Figure 5
Figure 6
A
B
C
C
B
A
