King Pigeon RTU5024 User manual

GSM Gate, Barrier, Shutter, Garage
Door and Door opener
Open gate or garage door with a FREE
call from your mobile phone!
Remote switching machines with a
FREE call from your mobile phone!
New version with a battery inside to
V2019 Support power failure alert
GSM Gate Opener
Remote Relay Switch
User Manual
For V2019 and V2017
RTU5024 V2.0
Date Issued: 2019-01-08
All rights reserved
SEMENOVIP.RU
1
Приобрести на SEMENOVIP.RU:

Тех поддержка:
[phone] (на этом же номере WhatsApp)
On-line чат на сайте semenovip.ru
E-mail: [e-mail]
Skype, TeamViewer по запросу
Контроллер RTU5024 в магазине
https://semenovip.ru/index.php?route=product/searc
h&search=RTU5024
Инструкция на русском к RTU5024
(v 1.0 rv1)
https://semenovip.ru/manuals/RTU/RTU5024_manual
_RUS_v1_0_rv1_semenovip.ru.pdf
Приложение для Android Play Маркете для RTU5024
https://play.google.com/store/apps/details?id=com.ji
nge.gsmgateopener_rtu5024
Видеоистуркция по настройке RTU 5024 со
смартфона
https://youtu.be/1PmG5IRJfQQ
Инструкция на английском к RTU5024
(v 1.6)
https://semenovip.ru/manuals/RTU5024_manual_EN
G_v1_6.pdf
Программное обеспечение и драйвера для
RTU5024 RED 2017
https://semenovip.ru/manuals/RTU/RTU5024_RED_2
017_Drv_Cnfg_Exmpl_Mnl_v1_semenovip.ru.zip
SEMENOVIP.RU
2

RTU5024 RED 2017 Настройка через USB
видеоинструкция
https://youtu.be/jhFXNK9bmjE
Этот лист в PDF
https://semenovip.ru/manuals/RTU/RTU5024/RTU5
024_Hyperlink_and_QR_v5.pdf
Приложение для Android для RTU5024 с
интерфейсом на русском языке
https://semenovip.ru/manuals/RTU/RTU5024/RTU5
024_14_RUS.apk
SEMENOVIP.RU
3

Table of contents
1. Product details --------------------------------------------------------------------------3
1.1 Features------------------------------------------------------------------------------------------------------- 3
1.2 Specifications------------------------------------------------------------------------------------------- 3
1.3 Dimensions---------------------------------------------------------------------------------------------- 3
1.4 Standard Packing List-----------------------------------------------------------------------------------------4
1.5 Applications------------------------------------------------------------------------------------------ 4
2. Safety Directions -----------------------------------------------------------------------4
3. Diagram -----------------------------------------------------------------------------------5
4. Typical Wiring Connection-----------------------------------------------------------------5
5. Installation and SMS command settings ----------------------------------------------6
5.0 Start(Verify time)-- ------ ---------- --------- -------- ---------- --------- -------- ---------- ------- 7
5.1 C hange password-------------------------------------------------------------------------------7
5.2 Authorized number managerment--------------------------------------------------------------- 7
5.3 Relay control parameters-------------------------------------------------------------------------- 8
5.4 Self-check report/inquiry status/IMEI code and firmware version/RESET----------------------------------9
6. Important information ----------------------------------------------------------------10
7. Maintenance----------------------------------------------------------------------------10
8. Warranty --------------------------------------------------------------------------------10
9. Authorized users list paper--------------------------------------------------------------11
This handbook has been designed as a guide to the installation and operation of V2017 / V2019 RTU5024
Gate Opener. Statements contained in the handbook are general guidelines only and in no way are designed to
supersede the instructions contained with other products.
We recommend that the advice of a registered electrician be sought before any Installation work commences.
Huobei Electronics & Technology Co.,LTD. its employees and distributors, accept no liability for any loss or
damage including consequential damage due to reliance on any material contained in this handbook.
Huobei Electronics & Technology Co.,LTD. its employees and distributors, accept no liability for GSM
Network upgrading or SIMCard upgrading due to the technology specifications contained in this handbook.
Caution!
Please read this user manual carefully before install/operate the Gate
Opener,basicelectronic acknowledges required.
SEMENOVIP.RU
4

1. Product details
The RTU5024 is an powerful remote relay controller, it is a very simple device which can be used for authorized door access, controlling gates,
switching of remote equipments, car parking systems. Actually the RTU5024 can be used in places which require to turn ON/OFF your system,
machines, equipments remotely with a FREE call from your mobile phone.
Just dial from Authorized User number at the specified time then the Barrier and doors are opened, or the machine are turn on or off by the RTU5024.
There are no call costs, the RTU5024 rejects the call from authorized number then carries out the turn ON/OFF action.
Moreover, the user can be authorized at the specified time to operate it, after timeout, will automatically change to unauthorized type.
1.1 Features:
Advantages
Quad-band GSM or Optional 3G or 4G version can work in the worldwide mobile Networks;
No call charges. the GSM GPRS Relay Switch rejects the call from authorized number then carries out the turn ON/OFF action
on the first 'ring';
Multiple applications. (gates, bollards, barriers, garage doors, shutters and access doors or machines);
Secure - Using caller-ID for identification, unknown callers are ignored;
Can be operated from anywhere, no distance limit;
Add or remove users by SMS Text command;
No need to provide a remote control or keys for different users;
Up to 1000 authorized phone numbers can be configured at the specified time;
One output with relay rating 3A/240VAC for connecting the switch of the door or machines;
The relay action will return a SMS confirmation to the owner or authorized call-in number, this function is editable by user;
The relay close or open time is programmable;
Multiple applications. (gates, bollards, barriers, garage doors, shutters and access doors or machines);
Support customized SMS command to control the relay output
Optional inside rechargeable battery for normal power supply failure alarm (2019 version supported)
V2019 can support the rechargeable battery inside for power failure alarm, but V2017 doesn’t support this function
Setting
SMS command and PC software
Operate from anywhere anytime, no distance limitation;
1.2 Specifications 1.3 Dimensions
GSM Frequency Quad-band 850/900/1800/1900MHz
Digital Output
NC/NO dry contact, 3A/240VAC
DC Power supply 9~24VDC/2A
Power consumption 12V input Max. 50mA/Average 25mA
SIM Card Supporting 3V SIM Card
Antenna 50Ω SMA Antenna interface
Temperature range -20~+60 ° C
Humidity range Relative humidity 90%
Exterior dimension W102mm*D76mm*H27mm
Net Weight 180 g
1.4. Standard Packing List
Gate Opener Controller, Antenna, User Manual, Packing size: 17*9.5*4 cm, Gross Weight: 0.30kg
SEMENOVIP.RU
5

1.5 Applications:
Remote open/close swing/sliding gates, doors, shutters, garage doors,locks with a free call!
Residential: Door,gate,garage access control, electronic fan,microwave,air-conditioner control.
Industry: Remote switch equipment, for example: street lights, solar power, motor, inverter, PLC, pumps, fans, etc.
Agriculture: Remote control pumps, etc.
Business: Remote control electronic boxes,bright billboards,LED signs,etc.
2.Safety Directions
Safe Startup
Do not use Gate Opener when using GSM equipment is prohibited or might bring disturbance or
danger.
Interference
All wireless equipment might interfere network signals of Gate Opener and influence its
performance.
Avoid Use at Gas Station
Do not use Gate Opener at a gas station. Power off Gate Opener when it near fuels or chemicals.
Power it off near Blasting Places
Please follow relevant restrictive regulations. Avoid using the device in blasting places.
Reasonable Use
Please install the product at suitable places as described in the product documentation. Avoid signal
shielded by covering the mainframe.
Use Qualified Maintenance Service
Maintenance can be carried out only by qualified maintainer.
SEMENOVIP.RU
6

3. Diagram
INDICATORS
Relay ON: Relay closed(ON). OFF: Relay open(OFF)
I III
Flash per 0.8 second(quickly): registering to cellular network.
Flash per 2 seonds: Normal status.
OFF:
can’t connect to SIM card or unregistered to the cellular network
Connection Terminals
Power
+ Power supply input,Positive wire(Red).
_ Power supply input,Negative wire(Black).
Relay
Output
NO Normally Open port
COM Common port
NC Normally Close port
ANT Connect to GSM antenna.
4. Typical wiring connection:
1. RTU5024 for Gate opener:
Power up the RTU5024 and electronic lock by same DC source,the
lock switched ON/OFF by phone call.
2. RTU5024 for remote switch:
The pump switched ON/OFF by phone call. Pump power up by the
grid/electrocity, and RTU5024 power up by AC/DC adaptor.
SEMENOVIP.RU
7

5. Installation and Settings
Notice:
1. The default Password is 1234.
2. You can program the RTU5024 with SMS commands using your phone. It is safe to do so because in
addition to the fact that other people may not know the number of the SIM inserted in it, we also use a
Password that makes it impossible for others who doesn't know it, to access the system by chance, and
all the action will be recorded.
3. The relay output will change the close or open status by every call in, please note it. Means the first time
call it, it will close the relay to switch on the lock, if the second call in is in the setting time, then the unit
will ignore the setting time, and open the relay, to switch off the lock.
4. Remember that commands must be CAPITAL LETTERS. It is AA not aa, EE not Ee etc. Don't add
spaces or any other character on the SMS commands.
5. The pwd in the command means the password,like 1234 or 5678 if you have changed.
6. If the RTU5024 used for gate access only,all you need to do is to change the default password and add
the authorized numbers.
7. If you cannot call to control the RTU5024 or cannot send or receive any SMS message from it.please try
to add 00 with your country code in front of the phone numbers:
For example:
In China, the country code is 0086The user cell phone number is 13570810212 and has been assigned as
the SMS Alert number, the simcard number in the panel is 13512345678.
Problem 1: Alarm but the user hasn’t received the SMS Alert.
Solution: Please plus the country code while you setup the 13570810254 as SMS Alert number, means setup
008613570810212 instead of the 13570810212.
Problem 2: The user number can receive the SMS Alert message from alarm panel, but the alarm panel can
not receive the commands from the user number.
Solution: Please add country code to the simcard number in the alarm panel. Means send sms commands to
008613512345678 instead of 13512345678.
Solution 3: Use mobile phone A to call mobile phone B, the number displayed on B is which you should set
as the dial number; Use mobile phone A send SMS to mobile phone B, the number displayed on B is which
you should set as the SMS alert number; sometimes you may need to use the 00 to replace the + or use the +
to replace the 00 on front of the country code.
8. Fo security purpose, the RTU5024 will NOT return any SMS if command error,so please make sure and
check the SMS Commands, or add the country code before the telephone number or check the input is
in ENGLISH INPUT METHOD and CAPS LOCK.
9. For RTU5024 V2019,If you want to receive the power failure alert SMS,must setup the 1st authorized
number,that is the only number that can receive the alarm SMS.
10. The relay switch is only a switch, no voltage output and also no current output, just a switch.
11. The SMS commands that you will certainly use in the RTU5024 are the following:
SEMENOVIP.RU
8

Installation: Open the SIM card cover on the back side of RTU5024,insert your SIM Card.
Reset the password: Press and hold the RESET button(closed to the SIM card holder), then power ON,after
3 seconds later,MCU LED will start to flash 5 times, the RTU5024 will only reset password to 1234. This
operation will reset the password to default 1234 and other parameters, but the authorized users numbers will
remain on the memory.
And if still hold the button for more than 10 seconds until the LED start to flash again and then release the
button,that will reset device working parameters and delete all authorized numbers and TEL number.
( For V2017 controller. No inside battery and switch )
5.0 Auto clock adjust with received SMS (This is necessary if need to use the
time-authorization enablement number):
Send pwdTELphone number of the RTU5024# to the RTU5024 for adjust the device clock.
E.g.: 1234TEL[phone]# if the SIM card number inside the RTU5024 is 00861351015.
RTU5024 Reply: TEL IS 00861351015
Then later every time after powered on,device will send an SMS to it self to adjust the clock
5.1 Change Password
1234Pnew password E.g.: 1234P6666 for change the new password to 6666.
RTU5024 return: “Password changed to“new password”, please remember it carefully.”if sucessfully.
5.2 Authorized number managerment
5.2.0 Add authorized number:
pwdAserial number#authorized number#start time#end time#
A:command code.
serial number: the authorized number’s position, from 001~200.
start time:yy(year)mm(month)dd(day)hh(hour)mm(minute).the start time of this number can call in to control.
end time: yy(year)mm(month)dd(day)hh(hour)mm(minute).the end time of this number can call in to control.
Without start time and end time means: Always can call in to control.
E.g.: 1234A003#123456# to set the phone no.123456 at the 3rd position and always can call in to control.
E.g.: 1234A016#123456#1502050800#1502051000# to set the phone number 123456 at the 16th position,
this number can call in to control during Feb 5th 8:00a.m.(1502050800) to Feb 5th 10:00a.m.(1502051000).
Note: 1. The authorized number means the one who can dial the RTU5024 to control the relay.
2. The Serial Number is the position to store the authorized users, from 001~1000.
SEMENOVIP.RU
9

5.2.1 Inquiry the Authorized number’s position(serial):
pwdAserial number#
E.g.: 1234A002# to check the number on the 2nd position(serial number2).
5.2.2 Inquiry batch users number
pwdALserial number start#serial number end#
E.g.: 1234AL002#050# to inquiry the authorized numbers from the 2nd to the 50th,RTU5024 return serval
SMS with the numbers list(10 numbers on each SMS).
5.2.3 Delete the Authorized Number(or you can overwrite this postion with another number).
pwdAserial number##
E.g.: 1234A002## to delete the 2nd authorized number.
5.3 Relay Control setting
5.3.1 Allow all numbers can call in to control:
pwdALL#
5.3.2 Allow only the authorized numbers can call in to control(Caller-ID for security,default):
pwdAUT#
5.3.3 How long time the relay keep close(ON) after phone call in (unit: second)
pwdGOTclose time#
close time=000~2000. Unit:Second
close time=000: relay close 0.5 second then open (use the relay as Latch).
close time=2000: relay will always keep close(ON) after call in untill the next call in.
Eg: 1234GOT030# to set relay close 30 seconds(ON) and then open(OFF) after call in.
5.3.4 Who will receive the confirmation SMS when the relay is ON/OFF
pwdGONab#content# for relay ON, pwdGOFFab#content# for relay OFF.
ab: the ID code of the 1st number(a) and the caller number(b), =0 means disable, =1 means enable.
content: confirmation SMS content.
ID code
RTU5024 send notify SMS to
a
b
The 1st number
Caller number
0
0
0
1
√
1
0
√
1
1
√ √
Eg: 1234GON11#Door Open#
The 1st number & the caller number receive confirmation SMS when relay is ON(door opened).
Eg: 1234GOFF00#Door Close#
The 1st number & the caller number will not receive confirmation SMS when relay is OFF(door closed)..
SEMENOVIP.RU
10

pwdDD
pwdTOG-TEXT=wsd1gg
pwdGOTclose time#
pwdQUE-TEST?
5.3.5 Need or No need confirmation SMS when the relay is ON/OFF.
pwdGON## pwdGOFF##
5.3.6 Control the relay ON/OFF by SMS command
pwdCC
pwdCD
Return SMS: Relay Toggled for 02 seconds (or the SMS content which you modified before)
Return SMS: Relay ON (or the SMS confirmation content which you modified before)
Return SMS: Relay OFF (or the SMS confirmation content which you modified before)
The relay close timer according to the before setting 6.3.3:
5.3.7 Control the relay ON/OFF by Customized SMS command
pwdON-TEXT=wsd1on
pwdOFF-TEXT=wsd1off
After defined,wsd1on can be send directly to control the relay to ON
After defined,wsd1on can be send directly to control the relay to OFF
After defined,wsd1gg can be send directly to toggle the relay
User can change the above text “wsd1on”,”wsd1off”,”wsd1gg” to their own text that is easy remembered
( Custom command make it easy to authorize people who don’t need to know the password to use the device. )
This is used to read back the customized SMS command setting
5.4 About the battery for power failure alarm (Only V2019 has this function)
When main power supply failure,Device will send the alarm SMS to the 1st number
Battery is only for power failure alert, not for relay working.
(Firstly slide the “battery switch” to ON postion to check if already has the battery mounted inside box )
5.5 Others:
5.5.1 Self-check auto report SMS to the 1st number. (unit:hour)
pwdT#xxx#
xxx=000~999
xxx=000, default,no self-check auto
report. Auto report SMS including:
Relay status;
GSM signal value(full is 31,cellular signal weak if lower than 14)
Inquiry the self-check and auto-report time
pwdT#
5.5.2 Inquiry current status
pwdEE
5.5.3 Inquiry the GSM modules’ IMEI code and firmware version
pwdIMEI#
SEMENOVIP.RU
11

5.6 About the PC software:
1. Download the software from our website QA page: http://www.waferlife.com/en/QA-RTU5024.html
2. Download the USB driver from the QA page: http://www.waferlife.com/en/QA-RTU5024.html
3. All in one. Driver, software, examples, manuals:
https://semenovip.ru/manuals/RTU/RTU5025/RTU5025_APP_EXMPL_PRJ_MNL_DRV.zip
4. Connect the USB programmer to PC and plug another end to RTU5024 three pin connector
5. Check the Virtual COM Number which is created in the PC Windows “Device Manager ”
6. Then Run the RTU5024 PC software and press the “open” to open the right com port.
7. Input the right password and Press the next "Login" button to connect to the RTU5024
(Device default password is : 1234)
Software :
SEMENOVIP.RU
12

6. Important information
1) Please read the User Manual carefully before you install and control the RTU5024.
2) Install the RTU5024 in a hidden place.
3) Avoid getting water into the RTU5024.
4) Have a secure connection to the main power supply.
7. Maintenance
1) In case of failure, please contact the distributor or manufacturer.
2) If the RTU5024 works but fail to send SMS texts, switch the power off and on again after one minute. Test it
after few minutes later,or ensure and check the settings are correct and the cellular signal strong enough.
3) If the RTU5024 works well with sensors but cannot send SMS texts, please change a SIM Card from another
Mobile Operator’s, and then testing again.
4) Whe first time start to use,should power on with normal power supply for more than 20 minutes and then can
test the battery with power failure alert SMS
5)Please contact the distributor or manufacturer if the problem can’t solved.
8. Warranty
1) Device has been carefully checked and are in perfect working condition before shipping.And it isalso
warranted for a period of one year from the date of purchase..
2) The warranty covers any malfunction in materials and workmanship during the warranty period of
your device. Your device will be repaired free of charge with the presentation of the warranty
certificate or your order link.Any damage resulting from inappropriate use is excluded from the
warranty.
3) Whenever shipping your device across any international border, you must indicate "returning product
to manufacturer for repair & return only. Value for customs purposes only. No commercial value." You
are responsible for allduties, taxes, freight or other fees associated with shipping your device to our
Service Centers and the return cost from Service Centers.Failure to do so may result in refusal of the
package.
9. Alarm input. Added by SEMENOVIP.RU 15.04.201
Thealarminput isinside the box.
Alarm Input Settings:
Preset the alarm Text:
1234TEXT1O:wsd1Openalarm#
1234TEXT1C:wsd1Closealarm#
Setup the alarm working mode:
1234M1# (when alarm input closed,will send the alert SMS)
1234M2# (when alarm input status changed,will send the alert SMS)
SEMENOVIP.RU
13
