KING3301 User Guide
Kingslide 3301 User Guide.
Introduction
Overview
•T e ‘Kingslide 3301 Package’ from Solid Setup adds t e Kingslide 3301 runners to Cabinet Vision Solid.
•It provides drilling in t e drawer/rollout sides and cabinet ends for CNC output.
•T e runners are added as a separate parts and materials for reporting purposes.
•All material descriptions contain t e Kingslide order number after t e # symbol.
Included in This Package
Drawer Guide chedule:
•Kingslide 3301
Drawer Guide Materials:
User Created tandards
T e Following UCS’s are provided
•{ DRAWS } -- Kingslide 3301 Runners Adds t e drawer box drilling intellij and drawer side dado.

Page 2 of 2
Solid Setup Pty Ltd
www.solidsetup.com
KING3301 User Guide
3301 Usage
Menu elections.
To use t e 3301 drawers in a job you must make t e following selections:
•In t e Construction tab s ould ave t e Drawer Box and Rollouts set to any applicable 4 or 5 piece drawer.
•In t e Hardware tab, c oose t e Kingslide 3301 guide sc edule:
•In t e Materials tab, you can c oose any of t e Drawer Box or Roll Out sc edules you ave set up for ot er
drawers as long as t e materials selected are suitable for Kingslide 3301.
Drilling etup
UC Public Variables
T ere are 3 Public Variables in t e “{ DRAW } -- Kingslide 3301 Runners “ UCS
•To c ange t ese variables go to t e Utilities – Edit User Created Standards from t e Plan or Elevation views
•T en click on t e “{ DRAW } -- Kingslide 3301 Attributes” UCS
•On t e top rig t and side of t e screen you will see t e Public Variables lists:
Guide Box Holes Depth = Dept of Holes in t e sides of t e Drawer or Rollout.
Guide Box Holes DIA = Diameter of Holes in t e sides of t e Drawer or Rollout.
Guide Box Holes Position = Distance to t e front Hole in t e sides of t e Drawer or Rollout.
Package Exclusions
Some of t e drawer drilling s own in various images contained in t is document are not included in t e Kingslide 3301
Visual Package, but come from ot er packages w ic are sold separately.
Any ot er items s own in any images suc as cabinet screw oles, benc top brackets, plastic legs etc are also part of
our ot er packages w ic are sold separately.
See our website for more detailed information on t ese packages.
