These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...
32
33
35
31
27
23
19
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical
Declaration of conformity
19
02
03
15
16
Getting started...
Safety information
Your product
Before you start
37
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 2 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
03
Safety information
Safety warnings
General safety warnings
General power tool safety warnings
WARNING! Read all safety warnings,
provided with this power tool. Failure to follow
all instructions listed below may result in electric
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
2. Do not operate power tools in explosive
liquids, gases or dust. Power tools create sparks
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 3 9/16/21 6:28 PM
Never allow children, persons with reduced physical, sen-
sory or mental capabilities or lack of experience and
knowledge or people unfamiliar with these instructions to
use the machine, local regulations may restrict the age of
the operator.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children.

EN
04
NMGT18-Li
Getting started...
Safety information
Safety warnings
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 4 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
05
Safety information
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A
moment of inattention while operating power tools
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source and/or battery pack, picking up or carrying
the tool.
switch or energising power tools that have the switch
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 5 9/16/21 6:28 PM

EN
06
NMGT18-Li
Getting started...
Safety information
Safety warnings
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 6 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
07
Safety information
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
Battery tool use and care
1.
manufacturer. A charger that is suitable for one type
2.
battery packs. Use of any other battery packs may
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
contacts eyes, additionally seek medical help.
5. Do not use battery pack or tool that is damaged or
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 7 9/16/21 6:28 PM

EN
08
NMGT18-Li
Safety information
Getting started...
Safety information
Safety warnings
6.
or excessive temperature.
7. Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
Charging
range may damage the battery and increase the risk
Service
1.
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
Electricallypoweredgrasstrimmersafetywarnings
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
Training
1. Read the instructions carefully. Be familiar with the
controls and the correct use of the machine.
2. Never allow children or people unfamiliar with these
instructions to use the machine. Local regulations can
restrict the age of the operator.
3. Keep in mind that the operator or user is responsible
for accidents or hazards occurring to other people or
their property.
Getting started...
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 8 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
09
Safety information
Preparation
1. Before use check the supply and extension cord
for signs of damage or aging. If the cord becomes
damaged during use, disconnect the cord from the
supply immediately. DO NOT TOUCH THE CORD
BEFORE DISCONNECTING THE SUPPLY. Do not
use the machine if the cord is damaged or worn.
2. Before use, always visually inspect the machine for
damaged, missing or misplaced guards or shields.
3. Never operate the machine while people, especially
children, or pets are nearby.
Operation
1. Keep supply and extension cords away from cutting
means.
2. Wear eye protection and stout shoes at all times while
operating the machine.
3. Avoid using the machine in bad weather conditions
especially when there is a risk of lightning.
4.
5. Never operate the machine with damaged guards or
shields or without guards or shields in place.
6. Switch on the motor only when the hands and feet are
away from the cutting means.
7. Always disconnect the machine from the power supply
(i.e. remove the plug from the mains, remove the
disabling device or removable battery)
1)whenever the machine is left unattended;
2)before clearing a blockage;
3)before checking, cleaning or working on the machine;
4)after striking a foreign object;
5)whenever the machine starts vibrating abnormally.
8. Take care against injury to feet and hands from the
cutting means.
EN
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 9 9/16/21 6:28 PM

EN NMGT18-Li
Safety information
Getting started...
10
Safety information
Safety warnings
9. Always ensure that the ventilation openings are kept
clear of debris.
Maintenance and storage
1. Disconnect the machine from the power supply (i.e.
remove the plug from the mains, remove the disabling
device or removable battery) before carrying out
maintenance or cleaning work.
2. Use only the manufacturer’s recommended
replacement parts and accessories.
3. Inspect and maintain the machine regularly. Have the
machine repaired only by an authorized repairer.
4. When not in use, store the machine out of the reach
of children.
Additional safety warnings for battery pack
1. Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge it
2. Remove the battery pack from the product when
not in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery pack
several times to obtain the maximum performance.
5. Longer life and better performance can be obtained
if the battery is charged when the air temperature
is between 18°C and 24°C. Do not charge the battery
important as it can prevent serious damage to the
6. Do not charge battery in a damp or wet location.
Following this rule will reduce the risk of electric shock.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 10 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
Safety information
11
Safety information
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh air
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and
these insstructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure
they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 11 9/16/21 6:28 PM

EN NMGT18-Li
Safety information
Getting started...
12
Safety warnings
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
2. Switch the product off and remove the battery pack
if there are malfunctions. Have the product checked
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3.
objects.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 12 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
Safety information
13
WARNING! This product produces an
may under some circumstances interfere with
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
/min or min-1 Per minute °C Degree Celsius
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimeter m/s² Metres per second squared
dB(A) Decibel (A-rated)
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction manual. Note / Remark.
Caution / Warning.
xxWyy Manufacturing date code; year of manufacturing (20xx) and week
of manufacturing (Wyy)
Wear hearing protection. Wear a dust mask.
Wear eye protection. Wear protective
gloves.
Wear protective, slip-resistant footwear.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 13 9/16/21 6:28 PM

EN NMGT18-Li
Getting started...
14
Safety information
Symbols
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class III.
Do not expose the product to rain or wet conditions (moisture).
Objects thrown by the product could hit the user or other
bystanders. Always ensure that other people and pets remain at a
safe distance from the product when it is in operation. In general,
children must not come near the area where the product is.
Inspect the area where the product is to be used and remove all
objects which can be thrown by the product. If objects are hidden
while operating stop the motor and remove the object.
Keep other people out of working area during operation. A distance
of at least 15 m must be observed.
Contact of the guide bar tip with any object should be avoided.
Guaranteed sound power level value in 96 dB.
WEEE symbol. Waste electrical products should not be disposed
of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be
disposed of with household waste. Please recycle where facilities
exist. Check with your Local Authority or local store for recycling
advice.
Do not dispose of battery packs in rivers or immerse in water.
cause injury.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 14 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
15
Safety information / Your product
Do note expose battery packs to heat in excess of 40 ºC. Do not
charge or store the battery pack in temperatures below 5 °C
(41 °F) and above 40 °C (104°F).
The product complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
UK Conformity Assessed.
Your product
1
2
3
4
5
15a
15
6
7
8
9
10
13
14
11
12 16b16a
16
17
12a
12b
12c
12d
12e
12h 11b
12g
16c
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 15 9/16/21 6:28 PM

EN NMGT18-Li
Getting started...
16
Your product / Before you start
Your product
1. Main handle
2. On/off switch
3. Rear safeguard
4. Battery docking port
5. Upper pole
6. Unlock button for
angle adjustment
7. Locking sleeve for
length adjustment
8. Lower pole
9. Pole support
10. Unlock button for tilt
adjustment
a. Indicator triangle*
11. Guard
a. Screw*
b. Knife
c. Screw hole*
d. Knife protector*
12. Trimmer head
a. Cover
b. Release latch (x2)
c. Trimming spool
d. Trimming line
e. Housing
f. Sliding slot (x2)*
g. Release push
button
h. Eyelet
i. Screw hole*
13. Plant protector
14. Air vents
15. Auxiliary handle
a. Lock button
16. Battery pack
a. Battery capacity
indicators
b. Battery capacity
button
c. Release button
17. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
Unpacking
1.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING!
You will need
(items not supplied)
Suitable personal protective equipment
Suitable crosshead screwdriver
(items supplied)
Guard (11)
Screw (11a)
Battery pack (16)
Charger (17) and its manual
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 16 9/16/21 6:28 PM

EN
NMGT18-Li
Getting started...
Before you start
17
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING!
Do not use a product that is only partly assembled or assembled with
Follow the assembly instructions step-by-step and use the pictures
Do not connect the battery pack (16) to the product before it is
NOTE: Take care of small parts that are removed during assembly or
when making adjustments. Keep them secure to avoid loss.
Guard
1. Turn the trimmer head (12) upside down.
2. Align two tips of the guard (11) with the sliding slots (12f) of the trimmer head
(12) (Fig. 1, step 1). Fully insert the guard (11) and make sure that the screw
holes (11c, 12i) are well aligned.
3. Secure the guard (11) with the screw (11a) in clockwise (Fig. 1, step 2).
12
11c 11c
11a
11
11
12i
12f
12f
1.
2.
Fig. 1
WARNING! Never use the trimmer head (12) without the guard (11)
NOTE: Always remove knife protection (11d) before use.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 17 9/16/21 6:28 PM

EN NMGT18-Li
Before you start
18
Before you start
Battery pack
Attaching / releasing the battery pack
1. Align the battery pack (16) with the sliding slots of the battery docking port (4)
under the rear safeguard (3) and slide the battery pack in to attach it. Ensure
it clicks in place (Fig. 2).
2. Press the release button (16c) and remove the battery pack (16) from the
battery docking port (4) (Fig. 3).
4
3
16
Fig. 2
416
16c
1.
2.
Fig. 3
Charging the battery pack
The battery pack (16) for this product has been shipped in a low charge condition.
Refer to the charger instruction manual (NMBA18-2) for the details.
Battery capacity indicators
The battery pack (16) is equipped with the battery capacity indicators (16a) which
are used to give an indication of the battery pack’s remaining capacity. Press the
battery capacity button (16b) to check battery capacity (Fig. 4). The LEDs will
stay lit for approximately 2 seconds.
16a 16b 16
Battery capacity status
indicators (16a)
Battery
capacity
70-100%
31-69%
5-30%
Fig. 4
Getting started...
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 18 9/16/21 6:28 PM

EN
19
EN
In more detail...
NMGT18-Li Product functions
Intended use
This cordless grass trimmer NMGT18-Li is designated with a rated voltage of
18 V . It is designed only to be used with the battery pack which is listed in
The product is intended for cutting weed, grass or similar soft vegetation in areas
that are hard to reach, e. g. under bushes, on slopes and edges. It may not be
used to work on unusual thick, dry or wet grass, e. g. pasture grass, or to shred
leaves.
operation and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
Auxiliary handle adjustment
Adjust the angle of the auxiliary handle
1. Lossen the lock button (15a) in
clockwise (Fig. 5, step 1), then rotate
the auxiliary handle (15) forward or
backward to adjust the angle (Fig. 5,
step 2).
2. Tight the lock button (15a) in anti-
clockwise to secure the auxiliary
handle (15) in position (Fig. 5,
step 3).
15
15a
2. 3. 1.
Fig. 5
Length adjustment
height.
1. Loosen the locking sleeve (7) in
clockwise (Fig. 6, step 1).
2. Pull the lower pole (8) out or push it
together to adjust the desired length
(Fig. 6, step 2).
3. Tighten the locking sleeve (7) in
anticlockwise (Fig. 6, step 3).
7
8
1.
3.
2.
Fig. 6
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 19 9/16/21 6:28 PM

EN
20
EN Product functions
In more detail...
NMGT18-Li
Main handle angle adjustment
Adjust the main handle (1) to either 0° for trimming or 180° for edging.
1. Press down the unlock button (6) and turn the main handle (1) clockwise
while holding lower pole (8) to adjust the trimmer head (12) to an angle of
180° (Fig. 7). Release the unlock button (6) and keep turning the main handle
(1) until it locks in place. Ensure the unlock button (6) snaps into place.
2. Press down the unlock button (6) and turn the main handle (1) anticlockwise
while holding lower pole (8) to adjust the trimmer head (12) to an angle of 0°
(Fig. 8). Release the unlock button (6) and keep turning the main handle (1)
until it locks in place. Ensure the unlock button (6) snaps into place.
1
6
8
1.
2.
Fig. 7 (initial position 0)
1
6
8
1.
2.
Fig. 8 (initial position 180°)
WARNING! Always ensure that the unlock button (6) snaps into place
Trimmer head tilt adjustment
edging use by aligning the indicator triangle (10a) on unlock button (10) with one
of three indicators of the pole support (9) (Fig. 9).
1. Push the unlock button (10) and hold it in position (Fig. 10, step 1).
2. Move the lower pole (8) slightly up or downward (Fig. 10, step 2).
3. Release the unlock button (10) and keep moving the lower pole (8) until it
locks in place.
MNL_NMGT18-Li_18V 23cm Grass Trimmer_V2_210916.indd 20 9/16/21 6:28 PM
