Kingfisher FPHT26-4 User manual

Petrol Hedge
Trimmer (26 cm3)
Original Instructions – FPHT26-4__V20721
WARNING: Read the instructions before using the machine!
FPHT26-4
EAN: 5059340124377
BX220IM

2
FPHT26-4
Let’s
get started...
These instructions are for your safety. Please read through
them thoroughly before use and retain them for future
reference.
Getting Started... 02
Safety information 03
Your equipment 12
Before you start 14
Quick start 18
In more detail... 21
Equipment functions 21
Operation 22
Care and maintenance 27
Troubleshooting 35
Recycling and disposal 36
Guarantee 37
EC declaration of conformity 38

3
FPHT26-4
Getting Started . . .
Safety warnings
IMPORTANT
READ CAREFULLY BEFORE USE
KEEP FOR FUTURE REFERENCE
1. This equipment is not intended for use by children and persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge.
2. Children should be supervised to ensure that they do not play with the equipment.
WARNING! Your safety and the safety of others is very important. Of course,
it is not practical or possible to warn you about all the hazards associated with
operating or maintaining this equipment. At all times you must use your own
good judgment.
Training
Read the instructions carefully. Become familiar with the instructions before attempting
to operate the equipment.
Preparation
1. THIS HEDGE TRIMMER CAN CAUSE SERIOUS INJURIES. Read the instructions
carefully for the correct handling, preparation, maintenance, starting and stopping
of the hedge trimmer. Become familiar with all controls and the proper use of the
hedge trimmer.
2. Never allow children to use the hedge trimmer.
3. Beware of overhead power lines.
4. Avoid operating while people, especially children, are nearby.
5. Dress properly! Do not wear loose clothing or jewellery, which can be caught in moving
parts. Use of sturdy gloves, non-slip footwear and safety glasses is recommended.
6. Use the following personal protective equipment (PPE) when operating the
equipment:
• Wear ear protection (compliant to EN 352-1)
• Wear eye protection (compliant to EN 166)
• Protective gloves (compliant to EN ISO 21420 Class 0)
• First Aid Kit in case of injury
• Dry powder re extinguisher readily available
Safety information

4
FPHT26-4
Getting Started . . .
7. Use extra care when handling fuels. Fuel is ammable and the vapours are
explosive. The following points should be observed.
• Use only an approved container.
• Never remove the fuel cap or add fuel with the power source running. Allow
engine and exhaust components to cool down before refuelling.
• Do not smoke.
• Never refuel indoors.
• Never store the hedge trimmer or fuel container inside where there is an open
ame, such as near a water heater.
• If fuel is spilled, do not attempt to start the power source, but move the hedge
trimmer away from the spillage before starting.
• Always replace and securely tighten the fuel cap after refuelling.
• If the fuel tank is drained, this should be done outdoors.
8. If the cutting mechanism strikes any foreign object or the hedge trimmer starts
making any unusual noise or vibration, shut off the power source and allow the
hedge trimmer to stop. Disconnect the spark plug wire from the spark plug and
take the following steps.
• Inspect for damage.
• Check for, and tighten, any loose parts.
• Have any damaged parts replaced or repaired with parts having equivalent
specications.
9. In an emergency: stop the engine by immediately releasing the throttle control
and set the stop switch to "STOP" position.
Operation
1. Stop the engine before:
• cleaning or when clearing a blockage;
• checking, carrying out maintenance or working on the hedge trimmer;
• adjusting the working position of the cutting device;
• leaving the hedge trimmer unattended.
2. Ensure that the hedge trimmer is correctly located in a designated working
position before starting the engine.
3. While operating the hedge trimmer, always ensure that the operating position is
safe and secure, especially when using steps or a ladder.
4. Do not operate the hedge trimmer with a damaged or excessively worn cutting
device.
5. To reduce re hazards, keep the engine and silencer free of debris, leaves and
excessive lubricant.
6. Always ensure that all handles and guards are tted when using the hedge
trimmer. Never attempt to use an incomplete hedge trimmer or one tted with an
unauthorized modication.
7. Always use two hands to operate a hedge trimmer.
Safety information

5
FPHT26-4
Getting Started . . .
8. Always be aware of your surroundings and stay alert for possible hazards of
which you might not be aware due to the noise of the hedge trimmer.
9. Keep all parts of the body away from the cutting blade. A moment of inattention
while operating the hedge trimmer may result in serious personal injury.
Maintenance and storage
1. When the hedge trimmer is stopped for servicing, inspection or storage, shut off the
power source, make sure all moving parts have come to a stop and disconnect the
spark plug wire from the spark plug. Allow the hedge trimmer to cool before making
any inspections, adjustments, etc.
2. Store the hedge trimmer where the fuel vapour will not reach an open ame or spark.
Always allow the hedge trimmer to cool down before storing.
3. When transporting or storing the hedge trimmer, always t the cutting device transport
guard.
4. Empty the fuel tank after every use. Run the product dry of fuel in idle before storage.
5. Dispose of waste oil and fuel at a local petrol station, local authority centre or where
facilities exist.
Additional fuel handling tips
1. Always switch the equipment off, disconnect the spark plug wire and let the equipment
cool down before refuelling it.
2. Fuel and fuel vapour are highly ammable. Take care when handling fuel.
3. Always use suitable aids such as funnels and ller necks. Do not spill any fuel on
the equipment or its exhaust system. There is a risk of ignition. Remove spilled fuel
carefully from all parts of the equipment. Any residue which may be present must
have completely volatilised, before the equipment is put into operation!
4. Never use the equipment in environments where there is a risk of explosion. Exhaust
gases and fuel fumes are noxious. Fuel fumes can ignite.
5. Avoid skin contact with petrol.
6. Do not eat or drink, while you are refuelling the equipment. If you have swallowed
petrol or oil, or if petrol or oil has got into your eyes, then seek the advice of a doctor
immediately.
7. Fuel vapour pressure may build up inside the fuel tank depending on the fuel used,
weather conditions and the tank venting system. To reduce the risk of burns and
other personal injuries, remove the fuel tank cap carefully to allow any pressure
build up to release slowly.
8. Ensure the spark plug wire is secure. Loosen wire may cause electrical arcing that
could ignite combustible fumes and cause a re or explosion.
9. Use caution when handling fuel. To avoid any accidental res, move the equipment
at least 3 metres from the fuelling point before starting the engine.
10. Do not operate the equipment if it is leaking fuel.
11. Do not remove the fuel tank cap while the engine is running.
Safety information

6
FPHT26-4
Getting Started . . .
12. Do not store cans of fuel or rell the fuel tank in any place where there is a boiler,
stove, wood re, electrical sparks, welding sparks, or other sources of heat or re
which might ignite the fuel.
13. If any fuel spillage occurs during refuelling, use a dry rag to wipe up spills and allow
remaining fuel to evaporate before starting the engine on again.
14. If you have spilt fuel on yourself or on your clothes, change your clothes and wash
any part of your body that has come in contact with fuel before turning the engine
on again.
15. If fuel has ignited, put out the re with a dry powder re extinguisher.
16. Never breathe in any fuel fumes, when you are refuelling the equipment.
17. Keep fuel fresh (less than 30 days) or add fuel stabiliser.
Vibration and noise reduction
To reduce the impact of noise and vibration emission, limit the time of operation, use
low-vibration and low-noise operating modes as well as wear personal protective
equipment.
Take the following points into account to minimise the vibration and noise exposure risks:
1. Only use the equipment as intended by its design and these instructions.
2. Ensure that the equipment is in good condition and well maintained.
3. Use correct attachments for the equipment and ensure they in good condition.
4. Keep a tight grip on the handles/gripping surfaces.
5. Maintain this equipment in accordance with these instructions and keep it well
lubricated (where appropriate).
6. Plan your work schedule to spread any high vibration tool use across a longer period
of time.
Safety information

7
FPHT26-4
Getting Started . . .
Emergency
Familiarise yourself with the use of this equipment by means of this instruction
manual. Memorise the safety directions and follow them to the letter. This will help
to prevent risks and hazards.
1. Always be alert when using this equipment, so that you can recognise and
handle risks early. Fast intervention can prevent serious injury and damage to
property.
2. Stop the engine and disconnect the spark plug wire if there are malfunctions.
Have the equipment checked by a qualied professional and repaired, if necessary,
before you operate it again.
3. In case of re stop the engine and disconnect the spark plug wire. Take re-
extinguishing measures immediately if the equipment switch is no longer accessible.
WARNING! Never use water to extinguish the equipment on re. Burning
fuel must be extinguished with special extinguishing agents! We recommend
that you keep a suitable re extinguisher within reach in your work area! We
recommend to have dry powder re extinguisher always available.
Residual risks
Even if you are operating this equipment in accordance with all the safety
requirements, potential risks of injury and damage remain. The following dangers
can arise in connection with the structure and design of this equipment:
1. Health defects resulting from vibration emission if the equipment is used over long
periods of time or not adequately managed and properly maintained.
2. Injuries and damage to property due to broken application tools or the sudden impact
of hidden objects during use.
3. Danger of injury and property damage caused by ying objects.
4. Burns, if touching hot surfaces.
WARNING! This equipment produces an electromagnetic eld during operation!
This eld may under some circumstances interfere with active or passive
medical implants! To reduce the risk of serious or fatal injury, we recommend
persons with medical implants to consult their doctor and the medical implant
manufacturer before operating this equipment!
Safety information

8
FPHT26-4
Getting Started . . .
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to reduce
hazards like personal injuries and damage to property.
kW Kilowatt l Litre
cm3Cubic centimetre ml Millilitre
min-1 Per minute °C Degree Celsius
m Metre dB(A) Decibel (A-rated)
mm Millimetre m/s2Metres per second squared
cm Centimetre kg/h Kilogram per hour
kg Kilogram g/kWh Gram per kilowatt per hour
yyWxx
Manufacturing date code; year of manufacturing (20yy) and week of
manufacturing (Wxx)
Description of signal words:
DANGER! The signal word that indicates a hazard with a high level of risk
which, if not avoided, will result in death or serious injury.
WARNING! The signal word that indicates a hazard with a medium level of
risk which, if not avoided, could result in death or serious injury.
CAUTION! The signal word that indicates a hazard with a low level of risk
which, if not avoided, could result in minor or moderate injury.
NOTE! Indicates a practical tip, advice or practice not related to personal
injury.
Caution/Warning.
Read the instruction
manual.
Note/Remark.
Wear ear protection
(compliant to EN 352-1)
Protective gloves (compliant to
EN ISO 21420 Class 0)
Wear eye protection
(compliant to EN 166)
Do not expose the equipment to rain or wet conditions.
Safety information

9
FPHT26-4
Getting Started . . .
Open ames in the work area, around the equipment and in the vicinity
of ammable materials are prohibited!
Do not smoke in the work area, around the equipment and in the vicinity
of ammable materials!
Risk of re/ammable materials.
Hot surface, do not touch! High temperatures on the equipment’s
surfaces and structural parts that could cause burns, if they are touched.
The equipment can also stay hot for a longer period of time after the
operation!
Petrol engines produce toxic carbon monoxide exhaust fumes. Breathing
carbon monoxide can cause nausea, fainting or even death. Do not
operate the engine indoors!
Stop the engine before refuelling. Never refuel the equipment while
the engine is running.
40:1
Only refuel unleaded petrol and oil mixture in ratio 40:1. Do not use
any other mixture ratio.
Stop the engine and disconnect the spark plug wire before assembly,
cleaning, adjustments, maintenance, storage and transportation.
Blades are sharp. Risk of cuts.
Keep ngers away from the moving cutting device.
Press the primer 6 times before starting the cold engine.
Choke – Start (CLOSE position).
Choke – Run (OPEN position).
Safety information

10
FPHT26-4
Getting Started . . .
Safety information
Guaranteed sound power level value in dB.
FPHT26-4
Designation of the tool
(FP_Brand Name; HT_Hedge Trimmer; 26_Engine size in cc)
The equipment complies with the applicable European directives and
an evaluation method of conformity for these directives was done.
Technical specications
General
> Dimensions: approx. 116 x 25 x 26 cm
> Weight: approx. 5.3 kg
> Fuel tank capacity: 460 cm3(ml)
> Petrol type: #95, unleaded
> Engine oil type: 2-stroke motor oil
> Fuel-oil ratio: 40:1
> Max. cutting length: 550 mm
> Max. cutting capacity 27 mm
> Handle adjustment 3 positions (90°/ 0°/ -90°)
Engine
> Engine model: SL34G
> Engine displacement: 26 cm3 (55 cm)
> Maximum engine power
(in accordance with ISO 8893): 0.75 kW
> Maximum speed at maximum power
(rotational frequency): 8000 min-1
> Maximum operating engine speed
(rotational frequency): 10000 min-1
> Idle speed: 3000 min-1
> Fuel consumption (in accordance with
ISO 8893) at max. engine performance: 400 g/h
> Specic fuel consumption (in accordance
with to ISO 8893) at max. engine
performance: 533 g/kWh
> Spark plug type: TORCH L8RTC/CHAMPION RCJ6Y
> Spark plug gap: 0.6 – 0.7 mm

11
FPHT26-4
Getting Started . . .
Sound emission level
> Sound pressure level LpA:94.6 dB(A)
> Uncertainty K: 3 dB(A)
> Measured sound power level LWA:105.6 dB(A)
> Guaranteed sound power level LWA:108 dB(A)
> Uncertainty K: 2.04 dB(A)
Vibration emission level
> Hand-arm vibration ahw:7.152 m/s2(front handle)
3.378 m/s2(rear handle)
> Uncertainty K: 1.5 m/s2
The sound values have been determined according to noise test code given in ISO 10517,
using the basic standards ISO 11201 and ISO 3744.
Wear hearing protection, especially when sound pressure is over 80 dB(A).
The declared vibration value has been measured in accordance with a standard test
method (according to EN ISO 10517) and may be used for comparing one equipment
with another. The declared vibration value may also be used to evaluate the exposure
for the user caused by vibration in advance.
WARNING! Depending on the actual use of the equipment the vibration values
can differ from the declared total. Adopt proper measures to protect yourself
against vibration exposures. Take the whole work process including times
the equipment is running under no load or switched off into consideration!
Proper measures include among others regular maintenance and care of the
equipment and accessories, keeping hands warm, periodical breaks and proper
planning of work processes!
Safety information

12
FPHT26-4
Getting Started . . .
Your equipment
Gettin
134
5
6
7
8
9
101112
13
14
16 15
17
18
19
20
21
22
23
24
25
2

13
FPHT26-4
Getting Started . . .
1. Cutting device
2. Cutter blade
3. Front handle
4. Front hand barrier
5. Recoil starter handle
6. Rear handle
7. Throttle control lock-out
8. Rear hand barrier
9. Throttle control
10. Rear handle adjustment lever
11. Stop switch
12. Fuel tank
13. Fuel tank cap
14. Primer
15. Choke lever
16. Fixing screw
17. Air lter case
18. Cutting device transport guard
19. Spark plug wire
20. Exhaust outlet
21. Ventilation openings
22. Gear box
23. Lubricator
24. Fuel mixing bottle
25. Multi-tool (Socket wrench/cross-head
screwdriver)
Unpacking
1. Unpack all parts and lay them on a at, stable surface.
2. Remove all packing materials and protective shipping materials, if applicable.
3. Make sure the delivery contents are complete and free of any damage. If you nd
that parts are missing or show damage do not use the equipment and contact your
dealer. Using an incomplete or damaged equipment represents a hazard to operators
and property.
4. Ensure that you have all the accessories and tools needed for assembly and operation.
This also includes suitable personal protective equipment.
WARNING! The equipment and the packaging are not children’s toys! Children
must not play with plastic bags, sheets and small parts! There is a danger of
choking and suffocation!
You will need
(items not supplied)
> Suitable personal protective equipment
> Sharpening set
> Fuel funnel with lter
> Suitable 2-stroke motor oil
> Suitable fuel (#95, unleaded petrol)
> Container to collect fuel
> Lubricating gun and lubricant for cutting
device
> First aid kit
> Dry powder re extinguisher readily
available
(items supplied)
> Fuel mixing bottle (24)
> Multi-tool (25)
Your equipment

14
FPHT26-4
Getting Started . . .
Before you start
Set up
Removing the cutting device transport guard
CAUTION! Risk of cuts! Cutter blades (2) are very sharp. Wear protective
gloves when handling cutter blades (2).
Remove the cutting device transport guard (18) carefully from the cutting device (1) (Fig. 1).
118
1
NOTE: Always attach the cutting device transport guard (18) back onto
the cutting device (1) when the equipment is not in use, and for storage or
transportation.
Adjusting the rear handle
CAUTION! Risk of loss of balance! Only adjust the handle position when
the engine is switched off.
1. Press and hold the rear handle adjustment lever (10), then rotate the rear handle (6)
to the desired position (90°/ 0°/ -90°) (Fig. 2, 3, 4 and 5).
2
6
10

15
FPHT26-4
Getting Started . . .
Before you start
2. Release the rear handle adjustment lever (10) to lock the position in place (Fig. 6).
NOTE: The rear handle (6) can only be locked at 3 positions. Make sure it
snaps securely into place before operating the equipment.
34
Right position (90°)Initial position (0°)
56
Left position (-90°)
10

16
FPHT26-4
Getting Started . . .
Before you start
Filling up fuel and oil
WARNING! This equipment is not supplied with petrol-oil mixture in the engine!
Before operating this equipment it is essential to ll it with petrol-oil mixture!
This equipment is equipped with a 2-stroke engine. The fuel and oil tank are combined
and it is essential to ll a fuel-oil mixture before operating this equipment. Observe the
technical specications for suitable fuel and engine oil.
WARNING! Fuel and oil are highly inammable! Fumes will explode if lit!
Ensure that there are no naked ames around the equipment! Do not smoke
while lling fuel and oil!
NOTE: To avoid spillage and to lter out debris, use a funnel with lter to ll
the fuel mixing bottle (24) and the fuel tank (12).
1. Place the equipment on a stable, level surface with the fuel tank cap (13) facing
upwards. We recommend laying a non-ammable sheet under the equipment.
2. Pour a regular-grade unleaded petrol and a quality engine oil for air cooled 2-stroke
engines in the supplied fuel mixing bottle (24) respectively via the 2 openings. Use
the scale markings on different sides for the desired ratio for petrol:oil. For example,
this indicates a correct ratio of 40:1 when using the scale 40:1.
3. Tilt and shake the bottle thoroughly to mix the fuel.
NOTE: Use an anti-oxidant added quality oil expressly labelled for air-cooled
2 stroke engine use (JASO FC GRADE OIL or ISO EGC GRADE). Do not use
BIA or TWC (2 stroke water-cooling type) mixed oil. The recommended mixing
ratio for petrol:oil is 40:1.
CAUTION! Risk of equipment damage. Never mix fuel and oil directly in the
fuel tank (12).

17
FPHT26-4
Getting Started . . .
Before you start
=
100 ml + 2.5 ml =
40:1
200 ml + 5 ml =
300 ml + 7.5 ml =
400 ml + 10 ml =
4. Unscrew and remove the fuel tank cap (13) (Fig. 7).
5. Fill the fuel into the fuel tank (12). Leave approximately 5 mm of space between
the top of the fuel and the inside edge of the tank to allow for expansion. Do not
overll (Fig. 8).
6. Wipe up spilled fuel with a soft cloth. Ret and screw the fuel tank cap (13) rmly
(Fig. 7).
713
12
8
5 mm
NOTE: Fuel and oil deteriorate over time. It may be difcult to start the engine
if you use fuel which has been kept for more than 30 days. Towards the end of
the season, it is advisable to put only as much fuel in the tank as you need for
each use, since it should be completely used up before storing the equipment.
Empty remaining fuel from the tank after each use.

18
FPHT26-4
Getting Started . . .
Operating controls
Primer
CLOSE
OPEN
ON
OFF
Stop
switch
Choke
lever
Recoil starter handle
Throttle
control
lock-out
Throttle control
Unlock lever
Quick start

19
FPHT26-4
Getting Started . . .
Quick start
Preparation
Assemble Adjust Add fuel and oil
mixture
Starting (Cold engine)
1 2 3 4 5
Set stop switch
to I
Press primer
6 times
Set the choke
to CLOSE
Pull recoil
starter handle
3-4 times
(If engine
already
started, skip
step 6)
Set the choke
to OPEN
6 7 8 2
1
9
Pull recoil
starter handle
until the engine
starts
Run idle for
1-2 minutes
Press the
throttle control
lock-out and
throttle control
Operate

20
FPHT26-4
Getting Started . . .
Starting (Warm engine)
1 2 3 4 2
1
5
Set stop switch
to I
Set the choke
to OPEN
Pull recoil
starter handle
until the engine
starts
Press the
throttle control
lock-out and
throttle control
Operate
Stopping
Release throttle control and
throttle control lock-out Set stop switch to STOP
Storage
Empty fuel tank Empty oil Clean and maintain Store
WARNING! This quick start provides only a short overview of how to start and
stop the equipment! For safe use it is essential to read the entire instruction
manual before rst use!
Intended use
This petrol hedge trimmer FPHT26-4 is designated with a maximum power output of
0.75 kW. This equipment intended for trimming hedges, bushes and shrubs with a
maximum diameter of 27 mm. Do not use the equipment for any other purpose.
Quick start
