These instructions are for your safety. Please read through them
thoroughly before use and retain them for future reference.
Let’s
get started...
24
25
27
23
21
19
18
In more detail...
Product functions
Operation
Care and maintenance
Troubleshooting
Recycling and disposal
Guarantee
Technical
Declaration of conformity
18
02
03
14
15
Getting started...
Safety information
Your product
Before you start
29
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 2 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
03
Safety information
Safety warnings
General power tool safety warnings
WARNING! Read all safety warnings,
provided with this power tool. Failure to follow
all instructions listed below may result in electric
Save all warnings and instructions for future
reference.
The term “power tool” in the warnings refers to
your mains-operated (corded) power tool or
Work area safety
1. Keep work area clean and well lit. Cluttered or dark
2. Do not operate power tools in explosive
liquids, gases or dust. Power tools create sparks
3. Keep children and bystanders away while
operating a power tool. Distractions can cause you
Electrical safety
1. Power tool plugs must match the outlet. Never
modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 3 9/13/21 1:09 PM

EN
04
NMHT18-Li
Getting started...
Safety information
Safety warnings
2. Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
3. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
4. Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
5. When operating a power tool outdoors, use an
extension cord suitable for outdoor use. Use of
a cord suitable for outdoor use reduces the risk of
6. If operating a power tool in a damp location is
unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of
Personal safety
1. Stay alert, watch what you are doing and use
common sense when operating a power tool. Do
not use a power tool while you are tired or under
A
moment of inattention while operating power tools
2. Use personal protective equipment. Always wear
eye protection. Protective equipment such as dust
mask, non-skid safety shoes, hard hat, or hearing
protection used for appropriate conditions will reduce
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 4 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
05
Safety information
3. Prevent unintentional starting. Ensure the switch
is in the off-position before connecting to power
source, picking up or carrying the tool. Carrying
4. Remove any adjusting key or wrench before
turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result
5. Do not overreach. Keep proper footing and balance
at all times. This enables better control of the power
6. Dress properly. Do not wear loose clothing or
jewellery. Keep your hair and clothing away from
moving parts.
7. If devices are provided for the connection of dust
extraction and collection facilities, ensure these
are connected and properly used. Use of dust
8. Do not let familiarity gained from frequent use of
tools allow you to become complacent and ignore
tool safety principles. A careless action can cause
Power tool use and care
1. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
2. Do not use the power tool if the switch does not
turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 5 9/13/21 1:09 PM

EN
06
NMHT18-Li
Getting started...
Safety information
Safety warnings
3. Disconnect the plug from the power source and/
or remove the battery pack, if detachable, from
the power tool before making any adjustments,
changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of
4. Store idle power tools out of the reach of children
and do not allow persons unfamiliar with the
power tool or these instructions to operate the
power tool. Power tools are dangerous in the hands
5. Maintain power tools. Check for misalignment or
binding of moving parts, breakage of parts and
any other condition that may affect the power
tool’s operation. If damaged, have the power tool
repaired before use. Many accidents are caused by
6. Keep cutting tools sharp and clean. Properly
maintained cutting tools with sharp cutting edges are
7. Use the power tool, accessories and tool bits etc.
in accordance with these instructions, taking into
account the working conditions and the work to
be performed. Use of the power tool for operations
different from those intended could result in a
8. Keep handles and grasping surfaces dry, clean
and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 6 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
07
Safety information
Battery tool use and care
1.
manufacturer. A charger that is suitable for one type
2.
battery packs. Use of any other battery packs may
3. When battery pack is not in use, keep it away from
other metal objects, like paper clips, coins, keys,
nails, screws or other small metal objects that can
make a connection from one terminal to another.
Shorting the battery terminals together may cause
4. Under abusive conditions, liquid may be ejected
from the battery; avoid contact. If contact
contacts eyes, additionally seek medical help.
5. Do not use battery pack or tool that is damaged or
6.
or excessive temperature.
7. Follow all charging instructions and do not charge
the battery pack or tool outside the temperature
Charging
range may damage the battery and increase the risk
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 7 9/13/21 1:09 PM

EN
08
NMHT18-Li
Safety information
Getting started...
Safety information
Safety warnings
Service
1.
repair person using only identical replacement
parts. This will ensure that safety of the power tool is
2. Never service damaged battery packs. Service
of battery packs should only be performed by the
Hedge trimmer safety warnings:
1. Keep all parts of the body away from the blade. Do
not remove cut material or hold material to be cut
when blades are moving. Blades continue to move
while operating the hedge trimmer may result in serious
2. Carry the hedge trimmer by the handle with the
blade stopped and taking care not to operate any
power switch. Proper carrying of the hedge trimmer
will decrease the risk of inadvertent starting and
3. When transporting or storing the hedge trimmer,
Proper handling of the
4. When clearing jammed material or servicing the
unit, make sure all power switches are off and the
power cord is disconnected. Unexpected actuation
Getting started...
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 8 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
09
Safety information
5. Hold the hedge trimmer by insulated gripping
surfaces only, because the blade may contact
hidden wiring or its own cord. Blades contacting a
"live" wire may make exposed metal parts of the hedge
trimmer "live" and could give the operator an electric
6. Keep all power cords and cables away from cutting
area. Power cords or cables may be hidden in hedges
7. Do not use the hedge trimmer in bad weather
conditions, especially when there is a risk of
lightning. This decreases the risk of being struck by
Additional safety warnings for battery pack
1. Battery pack needs to be charged before use.
Always refer to the charger’s instruction and charge it
2. Remove the battery pack from the product when
not in use.
3. Don’t maintain the battery pack on the charger
when not in use.
4. After extended periods of storage, it may be
necessary to charge and discharge the battery pack
several times to obtain the maximum performance.
5. Longer life and better performance can be obtained
if the battery is charged when the air temperature
is between 18°C and 24°C. Do not charge the battery
important as it can prevent serious damage to the
6. Do not charge battery in a damp or wet location.
EN
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 9 9/13/21 1:09 PM

EN NMHT18-Li
Safety information
Getting started...
10
Safety information
Safety warnings
7. Do not disassemble the battery and avoid
mechanical damage to the battery. Risk of short
circuit and fumes may be emitted. Ensure fresh air
8. When disposing of battery pack, keep the battery
pack of different electrochemical systems separate
from each other.
Vibration and noise reduction
To reduce the impact of noise and vibration emission,
limit the time of operation, use low-vibration and
low-noise operating modes as well as wear personal
protective equipment.
Take the following points into account to minimise the
vibration and noise exposure risks:
1. Only use the product as intended by its design and
these instructions.
2. Ensure that the product is in good condition and well
maintained.
3. Use correct attachments for the product and ensure
they are in good condition.
4. Keep tight grip on the handles/grip surface.
5. Maintain this product in accordance with these
instructions and keep it well lubricated (where
appropriate).
6. Plan your work schedule to spread any high vibration
tool use across a longer period of time.
7. Prolonged use of the product exposes the user
to vibrations that can cause a range of conditions
collectively known as hand-arm vibration syndrome
diseases such as carpal tunnel syndrome. To reduce
this risk when using the product, always wear protective
gloves and keep your hands warm.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 10 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
Safety information
11
Safety information
Emergency
Familiarise yourself with the use of this product by
means of this instruction manual. Memorise the
safety directions and follow them to the letter. This
will help to prevent risks and hazards.
1. Always be alert when using this product, so that
you can recognise and handle risks early. Fast
2. Switch the product off and remove the battery pack
if there are malfunctions. Have the product checked
Residual risks
Even if you are operating this product in accordance
with all the safety requirements, potential risks of
injury and damage remain. The following dangers
can arise in connection with the structure and design
of this product:
1. Health defects resulting from vibration emission if the
product is being used over long periods of time or not
adequately managed and properly maintained.
2. Injuries and damage to property due to broken
attachments or the sudden impact of hidden objects
during use.
3.
objects.
WARNING! This product produces an
may under some circumstances interfere with
the risk of serious or fatal injury, we recommend
persons with medical implants to consult their
doctor and the medical implant manufacturer
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 11 9/13/21 1:09 PM

EN NMHT18-Li
Safety information
Getting started...
12
Symbols
others the following symbols and abbreviations. Familiarise yourself with them to
reduce hazards like personal injuries and damage to property.
V Volt, (direct current voltage) mAh Milliampere per hour
/min or
min-1
Per minute °C Degree Celsius
g Gram kg Kilogram
mm Millimetre m Metre
cm Centimeter m/s² Metres per second squared
dB(A) Decibel (A-rated)
Lock / to tighten or secure. Unlock / to loosen.
Read the instruction manual. Note / Remark.
Caution / Warning.
xxWyy
manufacturing (Wyy)
Wear hearing protection.
Wear eye protection.
Wear a dust mask.
Wear protective gloves.
Wear protective, slip-resistant footwear.
Switch the product off and remove battery pack before assembly,
cleaning, adjustments, maintenance, storage and transportation.
This product is of protection class III.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 12 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
Safety information
13
Do not expose the product to rain or wet conditions (moisture).
Objects thrown by the product could hit the user or other bystanders.
Always ensure that other people and pets remain at a safe distance
from the product when it is in operation. In general, children must not
come near the area where the product is.
Guaranteed sound power level value in 96 dB.
WEEE symbol. Waste electrical products should not be disposed of
with household waste. Please recycle where facilities exist. Check with
your Local Authority or local store for recycling advice.
Crossed out dust bin. Batteries and battery packs should not be
disposed of with household waste. Please recycle where facilities exist.
Check with your Local Authority or local store for recycling advice.
Do not dispose of battery packs in rivers or immerse in water.
injury.
Do note expose battery packs to heat in excess of 40 ºC.
Do not charge or store the battery pack in temperatures below 5 °C
(41 °F) and above 40 °C (104°F).
The product complies with the applicable European directives and an
evaluation method of conformity for these directives was done.
UK Conformity Assessed.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 13 9/13/21 1:09 PM

EN NMHT18-Li
Getting started...
14
Your product
Your product
1
2
3
4
5
6
7
8
9
10
11
12c
12
13
12a 12b
1. Cutting device (blade)
2. Front safeguard
3. Safety switch
4. Front handle
5. Air vents
6. Rear handle
7. On/off switch
8. Rear safeguard
9. Battery docking port
10. Housing
11. Blade cover
12. Battery pack
a. Battery capacity indicators
b. Battery capacity button
c. Release button
13. Charger
NOTE: Parts marked with * are not shown in this overview. Please
refer to the respective part in the instruction manual.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 14 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
15
Before you start
Unpacking
1.
2. Remove all packing materials and shipping devices if applicable.
3. Make sure the delivery contents are complete and free of any damage. If
contact your dealer. Using an incomplete or damaged product represents a
hazard to people and property.
4. Ensure that you have all the accessories and tools needed for assembly and
operation. This also includes suitable personal protective equipment.
WARNING!
You will need
(items not supplied)
Suitable personal protective equipment
Suitable cross-head driver
Lubricant for blade
(items supplied)
Blade cover (11)
Battery pack (12)
Charger (13) and its manual
NOTE: The accessories required depend on the intended application.
Ask your dealer for advice.
Setup
WARNING! Before using the product, familiarise yourself with the
operating features read the entire instruction manual paying particular
attention to the safety rules and operating procedures.
Do not connect the product to battery pack (12) before it is completely
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 15 9/13/21 1:09 PM

EN NMHT18-Li
Before you start
Getting started...
16
Setup
Front safeguard
The front safeguard (2) is already pre-installed on the housing (10) (Fig. 1).
2
10
Fig. 1
Blade cover
1. Remove the blade cover (11) from the cutting device (blade) (1) before
operation (Fig. 2).
2. Keep the blade cover (11) safely.
11
1
Fig. 2
NOTE: Always attach the blade cover (11) when the product is not
in use, for storage and transportation.
To attach the blade cover (11), align and push the blade cover onto
the cutting device (blade) (1).
Battery pack
Attaching / releasing the battery pack
1. Align the battery pack (12) with the sliding slots of the battery docking port
(9) under the rear safeguard (8) and slide the battery pack (12) in to attach it.
Ensure it clicks in place (Fig. 3).
2. Press the release button (12c) and remove the battery pack (12) from the
battery docking port (9) (Fig. 4).
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 16 9/13/21 1:09 PM

EN
NMHT18-Li
Getting started...
Before you start
17
8
912
Fig. 3
9 12
12c
2.
1.
Fig. 4
Charging the battery pack
The battery pack (12) for this product has been shipped in a low charge condition.
Refer to the charger’s instruction manual (NMC18) for the details.
Battery capacity indicators
The battery pack (12) is equipped with the battery capacity indicators (12a) which
are used to give an indication of the battery pack’s remaining capacity. Press the
battery capacity button (12b) to check battery capacity (Fig. 5).
The LEDs will stay lit for approximately 2 seconds.
12a 12b 12
Battery capacity status
indicators (12a)
Battery
capacity
70-100%
31-69%
5-30%
Fig. 5
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 17 9/13/21 1:09 PM

EN
18
EN
In more detail...
NMHT18-Li
Product functions
Intended use
This cordless hedge trimmer NMHT18-Li is designated with a rated voltage of
18 V . It is designed only to be used with the battery pack which is listed in
The product is intended for cutting and trimming of hedges, bushes and shrubs in
domestic gardens. The maximum cutting capacity must be observed. Do not cut
branches exceeding the stated maximum capacity.
The use of this product in case of rain or humid environment is prohibited.
operation and to observe all the instructions therein.
This product is intended for private domestic use only, not for any commercial
trade use. It must not be used for any purposes other than those described.
Switching on/off
1. Ensure the cutting device (blade) (1) does not touch any objects. Remove
the blade cover (11) from the cutting device (blade) (1) before switching the
product on.
2. Hold the product with one hand on the front handle (4) and the other hand on
the rear handle (6).
3. Squeeze the safety switch (3) and hold it in position (Fig. 6, step 1).
4. Squeeze the on/off switch (7) to switch the product on (Fig. 6, step 2).
5. Release either the on/off switch (7) or the safety switch (3) to switch the
product off.
1
3
46
7
1.
2.
Fig. 6
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 18 9/13/21 1:09 PM

EN
19
EN
In more detail...
NMHT18-Li Operation
General operation
1. Check the product, its battery pack and charger as well as accessories for
damage before each use. Do not use the product if it is damaged or shows
2.
3. Always hold the product on its handles. Keep the handles dry to ensure safe
support.
4. Ensure that the air vents are always unobstructed and clear. Clean them if
necessary with a soft brush. Blocked air vents may lead to overheating and
damage the product.
5. Switch the product off immediately if you are disturbed while working by other
people entering the working area. Always let the product come to complete
stop before putting it down.
6. Do not overwork yourself. Take regular breaks to ensure you can concentrate
on the work and have full control over the product.
Trimming times
green leaf hedges June to October
evergreens April and August
conifers and other fast growing shrubs every 6 - 8 weeks
Trimming
NOTE: Try to keep the cutting device angled at approximately 15°
to the cutting surface.
1. Make sure that the blade cover (11) is removed, and the battery pack (12) is
assembled before operation.
2. Ensure that no people or animals are in the work area.
3. Cut and remove branches exceeding the cutting capacity of this product
using a proper pruner before operation.
4.
handle (6). Never operate this product using only one hand.
5. Do not rush and do not attempt to cut too much with one stroke of the cutting
device.
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 19 9/13/21 1:09 PM

EN
20
EN Operation
In more detail...
NMHT18-Li
Trimming
6. First cutting both sides from the bottom upwards to the top. This will prevent
any of the cuttings falling into the path of the area still to be cut (Fig. 7).
7. After cutting the sides proceed to the top. Try to keep the cutting device
angled at approximately 15° to the cutting surface (Fig. 8).
Fig. 7
0-15˚
Fig. 8
8. When cutting wide hedges with the cutting area in sight move the cutting
blade lightly through the cutting surface in a sweeping motion following the
shape of the hedge or shrub. A slight tilt downwards of the cutting blade in the
direction of motion is recommended for optimum cutting performance.
9. Cut in a number of stages to achieve a better result rather than trying to cut
allow for easy composting.
NOTE: When shaping it is advisable to achieve a trapezoidal shape
(Fig. 10). A trapezoidal cut corresponds to the natural growth of
plants and results in optimal hedge growth, as it will expose more
light to the lower end of the hedge.
Fig. 9 Fig. 10
MNL_NMHT18-Li_18V 50cm Hedge Trimmer_V1_210913.indd 20 9/13/21 1:10 PM
