KingsBox Ring Vest Hacker User manual

KingsBox
Ring Vest Hacker
EN

2
Table of content
Manufacturer information....................................3
Equipment Identification..........................................3
Field of application......................................................4
Equipment positioning..............................................5
Correct use of the equipment.............................6
Exercise instructions...............................................7
Technical information...............................................8
Care and maintenance..............................................10
List of tools required................................................11
Assembly elements....................................................12
Assembly instructions.............................................13

3
Manufacturer information
Equipment identification
TNG oprema d.o.o.
Bazoviška cesta 7a, 6210 Sežana
Slovenia
Costumer service
Telephone: [phone]
Email: [e-mail]
Address: Bazoviška cesta 7a, 6210 Sežana
Slovenia
WARNING
PINCH POINT
WATCH YOUR FINGERS

4
Field of application
Product classification:
EN ISO 20957-1:2013 Class S
The free area shall not be less than 0,6 m
greater han the training area in the
directions from which the equipment is
accessed. The free area must also include the
area for emergency dimount. Where
equipment is positioned adjacent to each
other the value of the free area may be
shared.
The possibility of users not being able to exist
the equipment when using it according to this
manual shall be avoided.

5
Equipment positioning
Total surface area (foot print):
600
600
600
600
Free area
Training area
600
600 600
600

6
Correct use of the equipment
unsupervised children should be kept
away from the equipment!

7
Exercise instructions
injuries to health may result from
incorrect or excessive training!
muscle up

8
Technical information
Total mass: 15 KG
Maximum user body weight: 100 KG
Maximum loading mass: 250 KG
warning!
if any of the adjustment
devices are left projecting, they could
interfere with the user’smovement!
warning!
free standing equipment shall be in-
stalled on astable and levelled base!

9
warning!
If the structure is not secured to the ground
and / or to the wall, it may overturn and / or
cause damage to person or
object in the immediate vicinity.
The fixing bolts for wall and/or floor are not
included in the pack-age, since different types
of anchor bolts must be used for differ-ent
wall/floor types.
Dimensions

10
Care and maintenance
warning!
The safety of the equipment is assured only
on condition that it is carefully inspected
for signs of damage and/or wear every two
weeks.
Replace defective and worn components im-
medeately, or alteranively remove the equip-
ment from service.
warning!
Be careful not to rub with excessive force on
the drawings and instructions shown on the
labels.
The equipment should always be kept clean
and free of dust, in compliance with good
hygiene practice, especially if it is used in a
gym or by more than one person.
To clean the padded parts, use a moist cloth
or a sponge and mild soap.
Every week, clean the outer parts of the
equipment using a damp sponge.

11
List of tools required
2x
19 mm Wrench

12
Assembly elements
QTY.
2x
2x
2x
1x
4x
position
position 3
name
NOT INCLUDED
M12x120
NOT INCLUDED
Mighty Iron Hand
NOT INCLUDED
Nut M12
KB Ring
Vest Hacker
NOT INCLUDED
Washer M12
position 2
position 5
position 1
position 4
SAMPLE

13
Assembly instructions
3
4
4
5
3
4
4
5
2
1
2
STEP 1
iron hands are
not included
in the box!

KingsBox
Ring Vest Hacker
I TA

15
Indice contenuti
Dati produttore............................................................16
Identificazione articolo.............................................17
Utilità...................................................................................18
Collocamento articolo...............................................19
Utilizzo corretto dell’articolo...............................20
Istruzioni per l’esecuzione degli
esercizi..............................................................................21
Informazioni tecniche................................................22
Cura e manutenzione...............................................23
Elenco attrezzi necessari......................................24
Elenco componenti.....................................................25
Istruzioni per l’assemblaggio................................26

16
WARNING
PINCH POINT
WATCH YOUR FINGERS
Dati produttore
Identificazione articolo
TNG oprema d.o.o.
Bazoviška cesta 7a, 6210 Sežana
Slovenia
Servizio clienti
Telefono: [phone]
E-mail: [e-mail]
Indirizzo: Bazoviška cesta 7a, 6210 Sežana
Slovenia

17
Utilità
Classificazione articolo:
EN ISO 20957-1:2013 Class S
L’area libera attorno all’area d’allenamento
dovrebbe essere di almeno 0,6m tutt’attorno
all’area di utilizzo. L’area libera deve includere
anche un’area per l’evacuazione o altre emer-
genze. Nel caso di più attrezzi posizionati uno
accanto all’altro, questi possono condividere
l’area libera.

18
600
600
600
600
Free area
Training area
600
600 600
600
Collocamento articolo
Planimetria articolo (foot print):

19
Utilizzo corretto dell’articolo
non permettere ai bambini di giocare e/o
allenarsi sull’apparecchio senza la su-
pervisione di un adulto.

20
Istruzioni per l’esecuzione
degli esercizi
muscle up
l’allenamento inadeguato oesagerato
può portare ad infortuni.
