Kingsman OFP42N Specification sheet

OUTDOOR FIREPLACE MANUAL
Models: OFP42N, OFP42LP, OFP42NS, OFP42LPS
Certified For USA & Canada
Standards: CSA 4.96 US 2nd Edition, CGA CR97-003, CGA 2.17-M91
Outdoor Gas Fireplaces
Owner’s Operation and Installation Manual
Warning
If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury, or
loss of life.
-Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
-An LP-cylinder not connected for use shall not be stored in the
vicinity or this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your
building.
•Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
•If you cannot reach your gas supplier, call the fire department.
-Installation and service must be performed by a qualified installer,
service agency, or the gas supplier.
This manual must be used for installation and retained by the homeowner for
operation and maintenance. Save this manual for future reference. Please contact
your dealer for any questions or concerns.
2340 Logan Ave., Winnipeg, MB, Canada, Phone: [phone] –Printed in Canada- PART #42OFP-MAN Oct. 10/08
Warning
Improper installation,
adjustment, alteration,
service, or maintenance
can cause injury or
property damage. Read
the installation, operating
and maintenance
instructions thoroughly
before installing or
servicing this equipment.
Warning
DO NOT LEAVE
FIREPLACE
UNATTENDED WHEN
IN USE
Warning
FOR OUTDOOR USE
ONLY.
Warning
DO NOT USE FOR
COOKING.
Warning
The OFP42N and OFP42LP
Fireplace are to be used only
with the Logs/Rock Kits as
specified in this manual. Do
not burn wood or other
materials in this appliance.
IMPORTANT: Read all instructions
carefully before starting installation.
Failure to follow these installation
instructions may result in a possible
fire hazard and will void the warranty.
Installer: Leave this manual with the appliance.
Consumer: Retain this manual for future reference

2
Table of Contents
SECTION PAGE
Table of Contents…………………………………………………………………………………………. 2
Introduction………………………………………………………………………………………………… 3
Pre-Installation Questions and Answers……………………………………………………………….. 4
Fireplace Dimensions and Framing Specifications………………………………………………........ 5
Installation Clearances……………………………………………………………………………..…….. 6
Screened Porch Installation……………………………………………………………………………… 6
Gas Line Installation and Gas Specifications……………………………………………………......... 7
Brick Panel Installation …………………………………………………………………….…………….. 8
Curtain and Hood Installation………………………………………………………………..…….…….. 8
Installing Stainless Steel Surround……………………………………………………………………… 9
Log Placement…………………………………………………………………………………….………. 10
MQ Rock Setup…………………………………………………………………………………………… 11
MQ Rock and Glass Setup…………………………………………………………….………………… 12
Lighting Instructions…………………….………………………………………………………………… 13
Gas Conversion -Valve-……………………………….………………………………………………… 14
Gas Conversion –Burner and Pilot-..…………………………………………………………………… 15
Troubleshooting…………………………………………………………………………………………… 16
Cleaning……………………………………………………………………………………………………. 16
Electronic Spark Assist…………………………………………………………………………………… 17
Weather Cover Installation………………………………………………………………………………. 18
Parts List …………………………………………………………………………………………………... 19
Warranty…………………………………………………………………………………………………… 20

3
OFP42N/OFP42LP Introduction
Models OFP42N/OFP42LP are for outdoor use only.
This appliance MUST NOT be used for cooking.
WARNING: This appliance shall be used ONLY
outdoors in a well-ventilated space and shall NOT be
used inside a building, garage, or any other enclosed
area.
WARNING: THIS UNIT IS NOT FOR USE WITH SOLID
FUEL.
The installation must conform with local codes or in the
absence of local codes, to the National Fuel Gas Code
ANSI Z223.1/NFPA 54, the Natural Gas and Propane
Installation Code, CSA B149.1, or International Fuel Gas
Code.
The appliance and its individual shut off valve must be
disconnected from the gas supply piping system during
any pressure testing of the system at test pressures in
excess of ½ psi (3.5 kPa).
The appliance must be isolated from the gas supply
piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply
piping system at test pressures equal to or less than ½
psi (3.5 kPa).
Always keep the appliance clear and free from
combustible materials, gasoline, and other flammable
vapors and liquids.
Warning
Do not locate appliance where it can
get excessively wet. Do not use this
appliance if any part has been under
water. Immediately call a qualified
service technician to inspect the unit
and to replace any part of the control
system and any gas control which
gas been under water.
•Children and adults should be alerted to the
hazards of high surface temperatures and should
stay away to avoid burns or clothing ignition.
•Young children should be carefully supervised
when they are in the area of the appliance.
•Clothing or other flammable materials should not
be hung from the appliance or placed on or near
the appliance.
•Any guard or other protective device removed for
servicing the appliance must be replaced prior to
operating the appliance.
•Installation and repair should be done by a
qualified service person. The appliance should be
inspected by a qualified service person. More
frequent cleaning may be required as necessary. It
is imperative that control compartment, burners
and circulating air passageways of the appliance
be kept clean.
•Inspect the fuel supply connection (including the
hose for LP models) before each use of the
appliance. See p11-Lighting Instructions for
removal of Access Panel.
•If it is evident there is excessive abrasion or wear,
or the hose is damaged, it must be replaced prior
to the appliance being put into operation.
•The LP gas supply cylinder used with LP models
must be constructed and marked in accordance
with the Specifications for LP-Gas Cylinders of the
US Department of Transportation (D.O.T.), or the
Standard for Cylinders, Spheres, and Tubes for
Transportation of Dangerous Goods and
Commission, CAN/CSA-B339* as applicable.
•Cylinders must be stored outdoors in a well
ventilated area out of the reach of children.
Disconnected cylinders must have threaded valve
plugs tightly installed and must not be stored in a
building, garage or any other enclosed area.
•Storage of this appliance indoors is permissible
only if it has been disconnected from its fuel
supply (natural gas line or LP gas cylinder).
•The LP gas cylinder supply system must be
arranged for vapor withdraws.
•The LP gas cylinder used must include a collar to
protect the cylinder valve.
•When an LP model is not in use, the LP gas must
be turned off at the supply cylinder.
For the state of Massachusetts a T-handle gas shut-off valve must be
used on a gas appliance. This T-handle gas shut-off valve must be
listed and approved by the state of Massachusetts.
This is in reference to the State of Massachusetts state code
CMR238.

4
OFP42N/OFP42LP Pre-Installation Questions and Answers

5
OFP42N/OFP42LP Framing Specifications
-Fireplace and Framing Dimensions-
*Attention: Top & Rear Standoffs must be folded into position & fastened with Screws before installation.
(Dimensions allow for ½” in front of framing tabs for finishing materials.)
Framing Clearances to Fireplace and Standoffs(Unless otherwise noted):Bottom: 0”/ Sides: 0” /
Adjacent side wall: 3-1/2” /Floor of fireplace to ceiling: 7’ /Low Profile Enclosure: 43-1/2”Minimum. Back: 0” /
Top: 0”.

6
OFP42N/OFP42LP Installation Clearances
Mantel Clearances
Installation Clearances
Carefully follow the instructions below. This will ensure safe
installation.
Minimum Wall and Ceiling Clearances
A. Clearances from the firebox to adjacent wall should not
be less than 3-1/2 inches.
B. Clearance from the top of the fireplace front to the ceiling
should not be less than 47 inches.
C. Clearance from the bottom of the firebox to the floor is 0
inches.
D. Clearance from the side of the fireplace to the enclosure
is 0 inches.
E. Clearance from the top of the fireplace standoffs is 0
inches.
Minimum Clearances- Side Walls
OFP42N / OFP42LP Screened Porch Installation
The OFP42N and OFP42LP can be installed safely in a screened porch area within the following guidelines:
Minimum porch area………………………..….….. 96sq. feet
Minimum ceiling height ……………………….…….92” inches
A minimum of two (2) walls can be screened, but must be open to outside ventilation, with a minimum screen area of 64
sq. feet, and a minimum side wall height of 78” inches.
Warning
Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Read the
installation, operating and
maintenance instructions
thoroughly before installing or
servicing this equipment.
Notice
A qualified service person must install
firebox. Follow all local codes.
Warning
Maintain the minimum clearances. If you can, provide greater
clearances from the floor
,
ceilin
g,
and ad
j
oinin
g
wall.
Warning
Ensure the minimum clearances shown are maintained.
Left and right clearances are determined when facing the
front of the unit.

7
OFP42N / OFP42LP Gas Line Installation
This gas appliance should be installed by a qualified installer in accordance with local building codes and with current CAN/CGA
- B149.1 or .2 installation codes for Gas Burning appliances and equipment in Canada and the National Fuel Gas Code ANSI
Z223 in the U.S.A.
1. The gas pipeline can be brought in through either the left side or the bottom of the appliance. A knockout is provided at
either location to allow for the gas pipe installation and testing of any gas
connection.
2. The gas control inlet is 3/8” NPT. Typical installation layout for rigid pipe is shown
at right.
3. When using copper or flex connector, use only approved fittings. Always provide
a union so that gas line can be easily disconnected for burner or fan servicing.
See gas specification for pressure details and ratings.
4. When a vertical section of gas pipe is required for the installation, a condensation
trap is needed. See CAN/CGA-B149.1 or .2 for code details.
5. For natural gas, a minimum of 1/2” iron pipe with gas minimum pressure of 5.5” w.c. must be used for supply from the gas
meter. Consult with the local gas utility if any questions arise concerning pipe sizes.
6. Ports are accessible for test gauge connection both on the inlet and outlet of the gas valve.
7. Turn the gas supply ON and check for leaks. DO NOT USE OPEN FLAME FOR THIS PURPOSE. Use an approved leak
testing solution.
8. The appliance and its individual shutoff valve must be disconnected from the gas supply piping system during any pressure
testing of that system at test pressures in excess of 1/2psig [3.5 KPa].
9. The appliance must be isolated from the gas supply piping system by closing its individual shutoff valve during any pressure
testing of the gas supply piping system at test pressures equal to or less than 1/2psig [3.5 KPa].
Note: The gas line connection may be made of 1/2” rigid pipe, 1/2” copper pipe or an approved flex connector. Since some
municipalities have additional local codes, it is always best to consult your local authorities and the current CAN/CGA - B149.1 or
.2 installation code in Canada or the National Fuel Gas code ANSI Z223.1 in the U.S.A.
-Gas Specifications-
Models OFP42N OFP42LP
Fuel Natural Gas Propane
Gas Control Millivolt Adjustable Millivolt Adjustable
Maximum Input 38,000Lo / 55,000Hi 44,000Lo / 55,000Hi
Orifice Size (0-4500ft) #20 #42
Air Shutter 1/4” Open Fully Open
Gas Inlet Size S.I.T. 820 Nova, 3/8” NPT
Gas Supply Pressure Minimum Normal Maximum
Natural Gas 5.5” 7” 10”
Liquid Propane 11” 11” 13”
Manifold Pressure High 3.5” w.c. [0.87KPa] NG 10” w.c. [2.61KPa] LP
Manifold Pressure Low 1.6” w.c. [0.40KPa] 6.3” w.c. [1.57KPa]
For the state of Massachusetts a T-handle gas shut-off valve must be used on a gas appliance. This T-handle gas shut-off valve must
be listed and approved by the state of Massachusetts. This is in reference to the state of Massachusetts state code CMR238.
IMPORTANT: Always check for gas leaks with a soap and water solution. DO NOT USE OPEN FLAME FOR LEAK TESTING.

8
OFP42N/OFP42LP Installing Brick Panels
Installing Brick Panels
1. Remove Brick Clips and Screws from inside
Firebox Top. Remove Log Support.
Do not discard these items.
2. Place Rear Brick Panel up against the back
of the Firebox.
3. Tilt and slide Side Brick Panels into position
in the sides of the Firebox. The Side Brick
Panels should be against the face of the
Rear Brick Panel, and behind the Inner Lip
of the Firebox.
4. Re-insert the Brick Clips and Screws in the
Firebox Top. Replace Log Support.
*Note: Brick Panels can also be installed
reversed, with the brick pattern against the
firebox wall. This will give a dark, Textured
Stone look to the inside of the firebox.
OFP42N/OFP42LP Installing Curtain and Hood
Curtain
1.Slide Curtain onto Rods.
2.Slide round end of Rod into hole in Frame.
3.Mount flattened end of Rod onto Rod Hanger
Bracket with a DT Screw. Repeat for opposite
side.
Hood
1.Remove DT Screws from inside top of Firebox.
2.Slide Hood Tabs into slots in Firebox top.
3.Re-insert DT screws through hood and into
firebox top.

9
OFP42N/OFP42LP Installing Stainless Steel Surround
-Part Number OFP42SS-
A Stainless Steel Surround is available as an option for the OFP42N/OFP42LP.
(Install before finishing with decorative material on facing of enclosure.)
Part 1: Preparing the Fireplace
1. Remove the 2 DT Screws inside the Firebox
Top and remove the Deflector Hood from
the top of the unit.
2. Lift Access Panel and remove.
Set these 2 items aside as they will be
replaced by parts of the Surround.
3.Remove Access Panel Brackets by
removing DT Screws. These Brackets will
be reused with the Surround.
Part 2: Installing the
Surround (See Surround
Drawing above for reference.)
1. Place Firebox Ledge Cap(3)
and Bottom Cover(4) into
position on the Fireplace.
2. Slide Surround Top(7) onto
Surround Sides(5&6).
Place Surround Top and
Sides onto fireplace.
3. Insert Screws into holes in
the inside edge of the
Surround Top, and into
Sides just above the Curtain
Rod.
4.Replace the Deflector Hood
and Access Panel removed
in Part 1 with the Stainless
Steel Surround parts.

10
LOGF37 INSTALLATION FOR OFP42
#1: 1 Bag of Small 1/4” Lava Rock - Supplied with Unit
#2: 1 Bag of Large 3/4" Lava Rock – Supplied
#3: LOGF37 – Outdoor 7 Piece Burnt Oak
Step #1 – Place 1/4” Lava Rock onto and around outer
Perimeter of the Pan Burner as shown. Leave the Log
Placement Pins exposed.
Step #2 – Place Log 1 onto Rear Log Holder and up
to Brick Panel.
Step #3 – Place Logs 2-3 on top of Log 1, Locate holes
On bottom of logs 4-5 and place these onto Log Place-
ment Pins as shown in the Photograph above.
Step #4 – Locate holes on Logs 6-7 and place these
onto Locating Pins of Logs 2-5, place Large Lava
Rock around and in front of Log Set as shown.

11
Marquis (MQ) products are available through Marquis Dealers.
Parts List
#1: 1 Bag of MQSS11 Silica Sand – Optional (Not Used for this Set-up)
#2: 1 Bag of Small 1/4” Lava Rock – Supplied with Unit
#3: MQROCK 2 or 3 – Box of 30 Rocks (MQROCK 3 shown below)
#4: MQG10W or MQG10B – Decorative Glass White or Black (Not Shown)
NOTE: Silica Sand and 1/4” Lava Rock maybe substituted with MQG10W-B
Step #1-.Place 1/4” Lava Rock Onto and around Burner
Pan as shown, Do Not place lava rock into pilot shield
assembly area.
Step #2 – Suggested MQROCK Placement.
Position rocks 1 and 3 as shown.
Step #3 – Position rock 4 as shown.
Step #4 – Position rock 6 as shown. Step #3 –Position remaining rock 4 as shown. Place Silica
Sand around the rocks and in front, do not put silica sand
onto the Burner Pan as this may cause clogging of burner
porting.
MQROCK Set-up OFP42

12
Marquis (MQ) products are available through Marquis Dealers.
Parts List
#1: 1 Bag of MQSS11 Silica Sand – Optional (Not Used for this Set-up)
#2: 1 Bag of Small 1/4” Lava Rock – Supplied with Unit (Not Used for this Set-up)
#3: MQROCK 2 or 3 – Box of 30 Rocks (MQROCK3 shown below)
#4: MQG10W or MQG10B – Decorative Glass White or Black
Step #1-.Remove Rear Log Holder.
Step #2 – Place Glass onto and around Burner Pan as
shown, do not place glass into the Pilot Shield assembly
area. NOTE: It is not necessary to place rocks over
glass.
Step #3 – Position Rocks as per MQROCK Set-up or
position randomly as shown.
MQG10(W-B) and MQROCK Set-up OFP42

13
OFP42NG/OFP42LP Lighting Instructions
1. Remove Front Panel in order to access
Igniter and valve controls.
(To remove Access Panel, simply lift upward,
and then pull forward.)
2. Refer to Millivolt Lighting Instructions
below.
Recommended Maximum Lead Length (Double Wire)
When Using Wall Switch
Wire Size Max. Length
14ga 100ft.
16ga 64ft.
18ga 40ft.
20ga 25ft.
22ga 16ft.
Pilot Burner Adjustment
Adjust pilot screw to
provide
proper sized flame.
Caution: Do not wire 120
Volt Power to millivolt
switches o
r
thermostat.

14
OFP42NG/OFP42LP Gas Conversion –Valve

15
OFP42N / OFP42LP Gas Conversion -Burner-
Warning!
This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s
instructions and all applicable codes and requirements of the authority having jurisdiction. If the information
in these instructions is not followed exactly, a fire, explosion, or production of carbon monoxide may result in
causing property damage, personal injury or loss of life. The qualified service agency is responsible for the
proper installation of this kit. The installation is not proper and complete until the operation of the converted
appliance is checked as specified in the manufacturer’s instructions supplied with the kit.
-Burner Conversion-
1. Shut off and Disconnect the gas supply to the
appliance.
2. Remove Burner Pan Assembly from the
Fireplace bottom by removing the screws in
each corner of the firebox.
3. Invert Burner Pan.
4. Adjust Air Shutter opening to appropriate size:
NG ¼”Open – LP Fully Open.
5. Remove existing Orifice and replace with new
one: NG #20 – LP #42.
6. Replace Burner Pan.
OFP42N / OFP42LP Gas Conversion -Pilot-
1.Shut off the gas supply to the appliance.
2.Allow the pilot burner to cool to room temperature.
Warning: Touching a hot pilot burner can result in injury.
3.Using a 10mm wrench, remove the pilot tube from the pilot burner assembly. The
olive and injector can now be removed from the bottom of the pilot hood.
4.Verify that the new injector is proper for the application. LPG injectors have a RED
top surface, while NG injectors do not. Refer to the Parts List in this manual for
the proper injector.
5.Insert new injector into bottom of pilot hood. Replace olive and reconnect pilot
tube.
Warning!
This conversion kit must only be applied as part of a
conversion kit supplied by the appliance
Manufacturer for the specific appliance, and type of
gas being converted.
Installer Notice: These instructions must be left with
a
pp
liance.

16
OFP42N/OFP42LP Troubleshooting the Gas Control System
NOTE: Before troubleshooting the gas control system, be sure external gas shut off is in the “ON” position.
Problem Possible Causes Corrective Action
Spark igniter will not
light
Defective or misaligned electrode at
pilot.
Check for spark at electrode and pilot: if no spark and electrode
wire is properly connected, replace igniter.
Defective igniter
(push-button)
Using a match, light pilot, If pilot lights, turn off pilot and push
the red button again. If pilot will not light, check gap at electrode
and pilot- gap should be 1/8” to 1/4” to have a strong spark.
Pilot will not stay lit
after carefully following
lighting instructions.
Defective Valve Magnet Turn valve knob “ON”, place wall switch “ON”. Millivolt meter
should read greater than 100mv. If the reading is okay and the
burner does not come on, replace the gas valve.
Pilot burning, no gas to
burner, Valve knob
“ON”, Wall Switch “ON”
Wall Switch or wires defective Check wall switch and wires for proper connections. Jumper
wire across terminals at wall switch. If burner comes on, replace
defective wall switch. If okay, jumper wire across wall switch
wires at valve. If burner comes on, wires are faulty or
connections are bad.
Generator may not be generating
sufficient voltage
Check generator with millivolt meter. Take reading at generator
terminals of gas valve. Should read 325 millivolts minimum
while holding valve knob depressed in pilot position and wall
switch “OFF”. Replace faulty generator if reading is below
specified minimum.
Plugged burner orifice Check burner orifice for stoppage and remove.
Defective automatic valve operator Remove all switch wires from gas valve. Install jumper wires
from TPTH and TH terminals of gas valve. Turn valve “ON”. If
main burner does not light, replace valve.
Frequent Pilot outage
problem
Pilot flame may be too low or blowing
(high) causing the pilot safety to drop
out.
Clean and/or adjust pilot flame for maximum flame impingement
on generator .
Windy Conditions. Close Pullscreens
OFP42N/OFP42LP -Cleaning -
It is recommended to annually inspect and clean the unit to prevent malfunction and / or sooting. This operation
should be performed by your dealer or a qualified technician.
-Carefully remove contents of firebox (log set, Rocks, Glass, etc.). Gloves are recommended.-
Annual Cleaning / Inspection
•Do not use cleaning fluids to clean logs.
•Use a soft bristle brush or a vacuum with brush
attachment.
•Vacuum loose particles and dust from burner and
valve
•Inspect Burner Plate, Pilot, Valve, and Mixing Sleeve
for spider webs or other blockages.
•Replace contents of firebox. Refer to the
appropriate page in this manual for proper
placement of contents, such as logs.
Warning
Turn off Unit and allow to cool before cleaning. Only a
qualified service technician should service and repair
appliance.
(Burner Assembly shown removed for clarity.)

17
OFP42N / OFP42LP -Electronic Spark Assist-
(Part Number OFP42SA)
A Battery powered module is available to assist in lighting the pilot burner. See below for installation.

18
OFP42WC -Weather Cover-
An optional Weather Cover is available to protect the inside of the unit when not in use.
Assembly Instructions
1. Insert Carriage Bolts through handles and into front
of Fireplace Cover.
2. Place washer and nut onto bolts on the back side
of the Fireplace Cover.
3. Tighten nuts with a 7/16” wrench.
Installation Instructions
1. Turn off unit and wait until cool.
2. Open Curtains approximately 24” apart, allowing a
½” space between curtain and frame sides (See
fig.1 below).
3. Slide the Weather Cover up behind the top lip of
the firebox (See fig.2 below).
4. Push the bottom of the Weather Cover into the
firebox and allow it to drop into place.
Fig.1
Fig.2

19
Parts List for Models OFP42N/OFP42LP
Part No. Description Fireplace Accessories
Fireplace Part Numbers OFP42SS Surround Stainless Steel
Coverage (37”H x 42-3/16” W)
OFP42N Outdoor Fireplace Black 55,000BTU OFP42WCSS Weather Cover (Stainless Steel)
OFP42LP Outdoor Fireplace Black 55,000BTU OFP42WCBL Weather Cover (Black)
OFP42NS Outdoor Fireplace Stainless 55,000BTU OFP42SA Spark Assist
OFP42LPS Outdoor Fireplace Stainless 55,000BTU GFRC Remote Control On/Off
Replacement Burner Assembly ZIRC Remote Control Millivolt (On/Off with LED)
(Model I)
42OFP-BNGSI Burner Assembly- Natural Gas
c/w Valve System
DCHS Remote Control Heatshield
42OFP-BLPSI Burner Assembly- Liquid Propane
c/w Valve System Liners
Valve System Parts OFP42RLT Refractory Liner Traditional /Reversible
1001-P640SI Valve NGTMV OFP42RLH Refractory Liner Herringbone /Reversible
1001-P639SI Valve LPTMV Miscellaneous and Replacement Parts
1001-P503SI Pilot NG 42OFP-126 Stainless Steel Pullscreens – 2 Each
1001-P504SI Pilot LP 42VFU-125 Pullscreen Rods – 2 Each
1001-P136WR Thermopile 42OFP-108 Deflector Hood
1001-P132SI Pilot Orifice NG 42OFP-108SS Deflector Hood
1001-P150SI Pilot Orifice LP 1000-214 #Piezo Igniter 1244-17 MARK 21
1000-220 Pilot Tube ¼” 1000-215 #Pal Nut (18MMXI.5MM)BLK(1364.03)
1001-P069SI Electrode Sparker 915.069 TC SIT 1000-218 #Switch Ivory (1451/001)
Fireplace Requirements 1000-255 #Orifice Brass – (State Size)
Log Sets or Rock Kits required for Fireplace Conversion Kit (SIT Valve Only)
LOGF37 Log Set -7pce. Burnt Oak 42OFP-CKNG NG Conversion Kit
MQROCK1 Rock Set Tan 42OFP-CKLP LP Conversion Kit
MQROCK2 Rock Set Natural
MQROCK3 Rock Set Multi-Color
MQG10W Decorative Glass ½” White 10lbs.
MQG10B Decorative Glass ¼” Black 10lbs.
MQSS11 Silica Sand 11lbs.

20
OFP42N/OFP42LP -- Limited Warranty
