Kirby Morgan SuperMask MOD-1 User manual

Kirby Morgan Dive Systems, Inc.®
1430 Jason Way Santa Maria, California 93455
Phone: [phone] Fax: [phone]
www.KirbyMorgan.com email: [email protected]
K
I
R
B
Y
M
O
R
G
A
N
D
I
V
E
S
Y
S
T
E
M
S
,
I
n
c
.
© MMXX Kirby Morgan Dive Systems, Inc. All Rights Reserved Document #200821001 Page 1 of 4
Part #815-060
SuperMask®/MOD-1
Communications Assembly
PART # DESCRIPTION QTY
815-060 SuperMask®/MOD-1 Communications Assembly 1
Tools Required:
• Scissors
• Tie Wrap Gun or Diagonal Cutters
POD should be removed from Mask when installing or removing communication assembly. Mask strap DOES
NOT need to be removed for installation or removal or communications assembly.
Procedures for installing assembly into mask is the same for both the right and left communications ports.
1) Using a sharp pair of scissors cut off the end of one
of the communications ports, located below the bottom
edge of the mask frame.
2) Push the microphone into the port. (The microphone
will appear to be too large, but the seal easily stretches.)
Ensure the main body is fully inserted into the com-
munications ports with the leading edge of the cut port
resting on the upraised edge on the main body of the
communications assembly.
Confirm solid black side of the microphone is facing to-
wards diver’s mouth

Kirby Morgan Dive Systems, Inc.®
1430 Jason Way Santa Maria, California 93455
Phone: [phone] Fax: [phone]
www.KirbyMorgan.com email: [email protected]
K
I
R
B
Y
M
O
R
G
A
N
D
I
V
E
S
Y
S
T
E
M
S
,
I
n
c
.
© MMXX Kirby Morgan Dive Systems, Inc. All Rights Reserved Document #200821001 Page 2 of 4
3) Use the included tie wrap P/N 520-038 to secure the
communications assembly to the mask. Position the end
or termination of the tie wrap so it won’t be touching the
diver’s face.
If the mask strap is installed, ensure the earphone wires
are routed on the inside of the strap NOT THE OUTSIDE.
4) Bend the lens body away from the jaw frame and
route the longer earphone wire across the front of the
mask. Ensure the wire is pushed down into the gap found
between these two parts of the mask. When the mask is
released the wire should fit snugly into the groove.

Kirby Morgan Dive Systems, Inc.®
1430 Jason Way Santa Maria, California 93455
Phone: [phone] Fax: [phone]
www.KirbyMorgan.com email: [email protected]
K
I
R
B
Y
M
O
R
G
A
N
D
I
V
E
S
Y
S
T
E
M
S
,
I
n
c
.
© MMXX Kirby Morgan Dive Systems, Inc. All Rights Reserved Document #200821001 Page 3 of 4
5) Insert the earphone into the earphone pocket, gray shiny side facing diver’s ear
Operating considerations
Microphone
The microphone is supplied with a “flexible contacts protective band”. The band prevents interaction of the
mouth with the connectors.
The dynamic microphone is encapsulated and protected by a hydrophobic membrane. The microphone is
waterproof and is designed to handle operating under pressure. If the POD is removed underwater the micro-
phone WILL NOT suffer any damage. However, continuing to descend WITHOUT the POD sealed to the mask
of a distance greater than 33 fsw/10m may damage the microphone.
Ascending at a rate greater than 33 FSW/10m with an exposed microphone (POD not on the mask) can also
cause damage to the microphone. An ascent rate of 33 FSW/10m or slower will allow the expanding gas to
vent properly through the membrane, causing no damage to the microphone element.
Earphones
It is designed to work underwater so the best quality is achieved when the unit is submerged.
Post Dive
The communicator and microphone should be rinsed with fresh water (immersed, not a strong “flow of water”)
after each dive and should be placed in a well-ventilated area that is not exposed to direct sunlight to dry. D-
Mic does not have a polarity restriction when assembled on the PTT contacts. Be careful to unscrew the two
screws before removing it. Clean the contacts and lubricate them on a timely base.
