Kirstein MV-CD3SUP User manual

MV-CD3SUP
Anti Shock CD / USB / SD Card Reader / Speed Control / Remote Control Player
)2/'(5
&'
03
5(3($7 $// 352* 5$ 06+ <))/(
%$
IDENTIFICATIONS OF CONTROLS :
zPOWER : ON : Press Power to switch on the power. OFF：Press and hold Power to
switch off the power
zLCD DISPLAY：Display CD status including track number and playing time.
zSD / USB / CD : Press this key will changed to USB, SD or CD mode.
zFB : Select backward. Then press “ PLAY / PAUSE “ back to normal playing.
zFF : Select forward. Then press “ PLAY / PAUSE “ back to normal playing.
zFOLDER : Select files. Available for playing MP3 format. Press each FOLDER key a
time, it will change to next catalogue.
zREV : Press to desired previous track number.
zF.WD : Press to desired next track number.
zPLAY / PAUSE : Press once stat to play, press again pause to stop.
zSTOP/ EJECT : Press to stop playing and press to disk ejected gradually.
zInfrared window：Pick up signal from the remote controller.
zUSB Connector
zSD Connector : Accepts SD Card and MMC Card.
zLO - PITCH: To adjust slow-speed play. Press once, the screen will indicate PITCH: -1,
press one time, it will be -1. It has 10 steps of speed variation.
zHI – PITCH : To adjust high speed play. Press once, the screen will indicate PITCH: 1,
press one time, it will be +1. It has 10 steps of speed variation.
zNOR – PITCH : To adjust the speed to zero. Press NOR/PITCH key, the speed will be
zero to back to normal play.

LCD Display :
zMP3：When being MP3 mode, the display panel shows MP3.
zCD：When being CD mode, the display panel shoes CD.
zWhen in playing mode, it display , when pausing, the panel shows .
zWhen repeatedly playing the single track, it shows REPEAT 1.
zWhen all songs at the folders are playing repeatedly, it shows REPEAT ALL .
zWhen it appears REPEAT FOLDER, it refers to playing the tracks repeatedly from a
specific folder.
zSHUFFLE : When Random playback.
zPROGRAM : When playback program tracks.
zMEMORY : When playback memory tracks.
zA→B：When repeat playing between A and B.
z：Under the MP3 mode, it will appear the folder numbers.
z：Display the current playing track.
z：Display the time for the current playing track.
zVOLUME : Turning to adjust & control the desired volume.
PLAYING :
zThis player can accepts 12 cm discs like CD, CD-R, CD-RW , MP3 disks and USB and
SD / MMC reader playing, but please do not intend to play the CD-ROM / CD-I / CDV,
8 cm discs or computer CD.
zThis player can accepts format MP3 and WMA
zInsert a disc into disc slot with the playback side down and playback starts automatically.
Track number and playing time will be displayed.
zTo pause playback or normal playback, press PLAY/PAUSE or press on the remote
controller,
zPressREV,F.WD,or ontheremote controller, for desired next or previous
track number. CD player will continue playback while display selected tracks.

zTo stop playback, press STOP/EJECT or press once on the remote controller.
Press STOP/EJECT once to stop playback, LCD will show total track numbers
and total time played. Press again to stop CD play. Press 3rd disc will quietly eject.
Press fourth disc will be inserted again.
zPress FB, FF or or on the remote controller, to activate fast forward or reverse
Until desired section is located.
z: Play the catalogue with MP3 file to change the select catalogue,
Toselectthecatalogue with MP3 form in playing program, may use
key in the face plate or remote controller to select next catalogue.
Press each key a time; it will change to next catalogue.
zPressLO,HI,NOR/PITCHor ontheremotecontroller.
To adjust high / low / normal speed play.
Note :
zWhen inserts the disk into CD player or takes out the disk, it is necessary to let CD
player insert disk and return automatically. It is prohibited to push or take out the disk
by hand before the disk completely return from CD player, thus will cause the machine
to be broken down and unable to operate normally.
SD / MMC Card
zInsert SD Card or MMC Card into the insert hole of SD/MMC CARD in the face plate.
Pull the card to get stuck with the tenon. It then finished the assembly. When taking
out the card, please push the card to the bottom and then release to shout it out.
Please don’t use the force to pull it out. If so, it will damage the card and the machine.
zPress SD / USB / CD or SD / USB / CD on the remote controller. Selects SD then press
PLAY / PAUSE or on the remote controller to playing.
As for other playing operation way, please refer to the operation way in PLAYING and
THE FUNCTIONS RESPECTIVELY ON THE REMOTE CONTROLLER.
USB
zInsert USB into the insert hole of USB in the face plate. If don't need to use USB, may take it
off directly.
zPress SD / USB / CD or SD / USB / CD on the remote controller. Selects USB then
press PLAY / PAUSE or on the remote controller to playing.
FOLDER
FOLDER
FOLDER
LOW HIGH NOR

As for other playing operation way, please refer to the operation way in PLAYING and
THE FUNCTIONS RESPECTIVELY ON THE REMOTE CONTROLLER.
THE FUNCTIONS RESPECTIVELY ON THE REMOTE CONTROLLER
zEJECT : Press to stop playing and press to disk ejected gradually.
zcan memorize the self-set playing procedure.
1) Play the ordinary CD ROM, press key a time, and then select the number
0~9 from the combination key, for example: press 2 and 3, then LCD will display "23",
then press Confirm key to complete memory setup; LCD will display "23:01".
If press "5" again, and press key, LCD will display "05:02", and so it has set "23"
and "05" as memorized songs. And press play key, it will play all of the
memorized songs. Meanwhile, LCD indicator will display "MEMORY" and the playing
song numbers. If want to cancel all of the memorized songs, press key for 2
times repeatedly.
2) To play MP3 form, press key once, and select the song numbers 0~9 from the
catalogue of combination key, for example: press 2 and then press Confirm key,
and then press 3, and then press key, then LCD will display 02 03:01", so it has
set up 02 as memorized in the catalogue, 03 is the song in the catalogue and 01 is the
first memorized song. Repeat this way to operate and memorized more songs. After
confirmation the memorized playing songs, then press play key to play all the
PROG
PROG
PROG
PROG
PROG

memorized songs. Meanwhile, LCD indicator will display "MEMORY" and the playing
song number. If want to cancel all of the memorized songs, press key for 2
times repeatedly
z: A random selection is played from alive labile tracks. Press and LCD
it shows SHUFFLE. Then press or can selection from alive labile
tracks.
z: Repeat mode.
1) Play the ordinary CD ROM. Press once LCD it shows REPEAT ALL : Repeat by the
songs in all. Press again LCD it shows REPEAT 1 : Repeat by the song in the folder.
Press the 3rd time, LCD display will eliminate the word REPEAT, and cancel
Repeat Playing function.
2) To play MP3 form. Press each key a time; it will change to〝REPEAT ALL 〞,
〝REPEAT FOLDER 〞,〝REPEAT 1 “, the last to cancel Repeat Playing function.
〝REPEAT FOLDER 〞: Repeat all the songs in the folder.
zNumeral 0 ~ 9 : Select numerals. Selects the track from numerals.
z: Play the catalogue with MP3 file to change the select catalogue,
and LCD display will show catalogue item. Press one
time can change one catalogue item.
z: PLAY / PAUSE. Press once is pause and LCD it shows . Press again to
play and LCD it shows .
z：Stop to play。
z: Skip to the former track.
z:Tonexttrack.
z: Press once to activate fast reverse. Presses again cancel fast reverse. Then
Press , back to normal play.
z: Press once to activate fast forward. Presses again cancel fast forward. Then
Press , back to normal play.
z: Selection USB, SD or CD. Then press to start playing.
z: It is the zone memory function. During Playing State, press
A point will start to memorize. Press again to memorize B point, and
RANRAN
REP
FOLDER
CD
USB / SD
A→B A→B
A→B
FOLDER
REP

stop memorizing at the same time, and start repeating playing point A - B
Memory Zone. Press again to cancel A→B Function.
z: ON / OFF Mute.
zconfirmation : Execution.
.
zPITCH To adjust slow – speed, high -speed or normal play. To adjust high
speed play. To adjust slow-speed play. They each have 10 bands of speed
variation. Back to normal play.
zWhen using the remote controller, the remote controller shall be appointed to the
receiving hole of face plate. The optimal receiving distance is 3 meters. (the
available distance is 5 meters.) The batteries ( model CR2025 3V) shall be put into
the remote controller.
zBattery installation of remove controller
1. Press and hold the tenon located on lower left-hand corner of the rear remote
controller, pull out the battery set by the slot at the right.
2. Place the battery〈positive electrode faces upwards〉according to its correct
polarity.
3. Push the battery compartment back to the fixed position.
HIGH
LOW
NOR
