MODULARM®75LC MULTI-MONITOR
INSTALLATION AND OPERATING MANUAL
A KITCHEN BRAINS BRAND
TM

NOTICE
Before installing, please thoroughly read these instructions so that you can fully benet
from all of the capabilities offered by the Modularm®75LC Multi-Monitor.
CONTENTS
PRODUCT OVERVIEW 3
PRODUCT ACCESSORIES 4
MC-1 MAGNETIC DOOR CONTACTS (INCLUDED) 4
IP-1 LIGHT CONTROL AND PANIC ALARM (OPTIONAL) 4
MD-1/MD1+2 MOTION DETECTOR (OPTIONAL) 4
PRODUCT FEATURES 5
PRODUCT OPERATION 6
LIGHTING CONTROL OPERATION WITHOUT ACCESSORIES 6
LIGHTING CONTROL OPERATION WITH MC-1 MAGNETIC DOOR CONTACTS 6
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1 INSTALLED 7
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1 AND MC-1 INSTALLED 8
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1, MC-1 AND MD-1 OR MD-1+2 INSTALLED 9
CONFIGURATION MO0DE 10
ALARM OPERATION MODE 10
PREVENTIVE MAINTENANCE REMINDER 10
PAS-PRO™ PASSWORD PROGRAMMING INSTRUCTIONS 11
OPERATION PASSWORD EXAMPLES 12
PARAMETER LIST 12
PROBE CALIBRATION (PASSWORD 51) 13
RINGBACK DELAY (PASSWORD 56) 13
LIGHTS OFF DELAY (PASSWORD 57) 13
LIGHTS OPERATION (PASSWORD 58) 13
ALARM RELAY (PASSWORD 59) 13
INSTALLATION 14
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS 14
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS 15
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS 16
FLUSH MOUNT CUTOUT TEMPLATE 17
MD-1 AND MD-2 CONNECTIONS 18
MD-1 CONNECTIONS DIAGRAM 19
MD-2 CONNECTIONS DIAGRAM 20
MODULARM 75LC WIRING DIAGRAM REV 3 21
SPECIFICATIONS 22
USE THE 75LC TO 23
CONTACT INFORMATION 24
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 2 of 24 kitchenbrains.com
1-800-327-8766

The Kitchen Brains®Modularm®75LC Multi-Monitor is the standard in walk-in monitoring. The 75LC
provides temperature, door ajar, AC failure and panic alarms. Using Autoset™ technology, the Modularm
75LC automatically adjusts alarm set points, thus eliminating the need for manual programming.
The system saves energy, improves eciency, reduces coil icing, lowers maintenance costs and helps to
maintain product integrity.
The 75LC offers the following functions: (Patented Operation, other Patents Pending)
• Built in battery back-up with recharging circuitry
• Patented energy act compliant light control activates by motion sensors
• HI & LO Temperature Alarm with Patented Autoset Technology.
• AC Failure Alarm with built-in rechargeable battery and built-in recharging circuitry
• Door Ajar Alarm (Requires include magnetic contacts)
• Panic (Entrapment) Alarm (Requires optional IP-1 Illuminated Button)
• Timed Light Control
• HACCP monitoring (Additional equipment required)
• Remote notication (Additional equipment required)
• Built-in audible alarm
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 3 of 24 kitchenbrains.com
1-800-327-8766
PRODUCT OVERVIEW
75LC

OR
MC-1 MAGNETIC DOOR CONTACTS (INCLUDED)
• Senses door status
• Provides door ajar and lights on switches based on status
• Runs on low voltage
• One set included with each 75LC purchase
IP-1 LIGHT CONTROL AND PANIC ALARM (OPTIONAL)
• Mounts inside the cooler/freezer
• Controls the cooler/freezer interior light
• Provides visual and audio panic alarms
• Runs on low voltage
• Optional purchase
MD-1/MD1+2 MOTION DETECTOR (OPTIONAL)
• Mounts inside the cooler/freezer
• Detects motion to control the cooler/freezer interior light
• Runs on low voltage
• Optional purchase
PRODUCT ACCESSORIES
The accessories listed below connect directly to, and are powered by, the 75LC. These accessories may
be used individually, or in combination, to meet the unique requirements of each installation.
AUTODETECT TECHNOLOGY selects the right alarm temp setpoints for monitoring a cooler or a freezer
automatically, virtually eliminating the need for manual programming.
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 4 of 24 kitchenbrains.com
1-800-327-8766

PRODUCT FEATURES
AC POWER FAILURE ALARM
• 75LC “chirps” every 30-seconds
• “Power Failure” displays on screen
• For power failures less than one-minute:
• Normal operation restores automatically
• Incident is ignored
• If power failure continues after one-minute:
• Alarm relay activates for remote notication
• The 75LC will go dark to conserve battery life
• Pressing the screen will wake the darkened unit
• Status will again be displayed on screen
VISUAL ALARM ANNUNCIATION
TABLE 1. STATUS OF THE 75LC FOR ABNORMAL & ALARM CONDITIONS SCREENS
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 5 of 24 kitchenbrains.com
1-800-327-8766
THREE BUTTON USER INTERFACE
ALARM TYPE ABNORMAL CONDITION ALARM CONDITION
PANIC ALARM [Non applicable] “HLP” +“HLP”
DOOR AJAR Door Light On “Dor” + Temp
TEMP OUT OF RANGE “HI” or “LO” + Temp “HI” or “LO” + “AL” + Temp
TEMPERATURE AC POWER FAILURE “PF” + Temp A single dot will display
TEST (UP) LIGHTS (Prog) SILENCE (Down)
WHILE IN RUN OR ALARM MODE:
TEST: Press to test and view alarm parameter settings
LIGHTS: Press to manually activate and deactivate compartment
SILENCE: Press to acknowledge an alarm
WHILE IN PROGRAM MODE:
UP: Press to increase and alarm parameter values
LIGHTS: Press to select PAS-PRO™ preset and program menu options
DOWN: Press to decrease alarm parameter values

LIGHTING CONTROL OPERATION WITHOUT ACCESSORIES
THERE ARE TWO OPTIONS FOR CONTROLLING LIGHTS:
• Regular Timed Lighting (default):
• To turn lights on and activate the lights-off timer, press the “Light” button on the 75LC
• The lights will turn off when the lights-off timer expires
• To manually turn lights off before the lights-off timer expires, press the “Light” button again
• Untimed, Manual Light Control (replaces light switches):
• To turn lights on, press the “Light” button on the 75LC
• To turn lights off, press the “Light” button again
LIGHTING CONTROL OPERATION WITH MC-1 MAGNETIC DOOR CONTACTS
THERE ARE TWO OPTIONS FOR CONTROLLING LIGHTS:
• Regular Timed Lighting (default):
•Open door to turn lights on
•The lights will turn off when the lights-off timer expires
•To manually turn lights off before the lights-off timer expires, close door
• Untimed, Manual Light Control (replaces light switches):
•Open door to turn lights on
•Close door to turn lights off
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 6 of 24
PRODUCT OPERATION
kitchenbrains.com
1-800-327-8766
OR

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 7 of 24
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1 INSTALLED
THERE ARE TWO OPTIONS FOR CONTROLLING LIGHTS:
Patented Timed Lighting with AutoPanic (default):
• To turn lights on and activate the lights-off timer and AutoPanic alarm, press the “Light” button on the
75LC
•The IP-1 beeps and blinks for 40-seconds
•Press the IP-1 within 40-seconds to:
•“Check in” and keep the lights on for as long as the door remains closed
•Lock out the 75LC “Light” button and prevent the light from being turned off from outside the walk-in
•Activate the 20-minute AutoPanic timer
• If the IP-1 is not pressed within 40-seconds, the lights will turn off
• After 20-minutes, the IP-1 beeps and blinks again for 40-seconds
• Press the IP-1 to “check in“ and restart the AutoPanic timer
• The 20-minute alarm cycle will repeat for as long as a person remains in the walk-in without opening the door
• If the IP-1 is not pressed within 40-seconds, the 75LC will automatically sound a panic alarm
Untimed, Manual Light Control (replaces light switches):
• To turn lights on, press the “Light” button on the 75LC
• To turn lights off, press the “Light” button again
PRODUCT OPERATION
kitchenbrains.com
1-800-327-8766

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 8 of 24
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1 AND MC-1 INSTALLED
THERE ARE TWO OPTIONS FOR CONTROLLING LIGHTS:
Patented Timed Lighting with AutoPanic (default)
• Open door to turn lights on
•When door is closed, the lights-off and AutoPanic timers activate
•The IP-1 beeps and blinks for 40-seconds
•. Press the IP-1 within 40-seconds to:
• “Check in” and keep the lights on for as long as the door remains closed
• Lock out the 75LC “Light” button and prevent the lights from being turned off
from outside the walk-in
•Activate the 20-minute AutoPanic timer
If the IP-1 is not pressed within 40-seconds, the lights will turn off
• After 20-minutes, the IP-1 beeps and blinks again for 40-seconds
•Press the IP-1 to “check in “ and restart the AutoPanic timer
•The 20-minute alarm cycle will repeat for as long as a person remains in the walk-in without opening the door
•If the IP-1 is not pressed within 40-seconds, the 75LC will automatically sound a panic alarm
Untimed, Manual Light Control (replaces light switches):
• To turn lights on, press the “Light” button on the 75LC
• To turn lights off, press the “Light” button again
PRODUCT OPERATION
kitchenbrains.com
1-800-327-8766
OR

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 9 of 24
THERE ARE TWO OPTIONS FOR CONTROLLING LIGHTS:
Patented Timed Lighting with AutoPanic (default)
• Open door to turn lights on
• When door is closed, the lights-off and AutoPanic timers activate
•The IP-1 beeps and blinks for 40-seconds
•Press the IP-1 within 40-seconds to:
• “Check in” and keep the lights on for as long as the door remains closed
•Lock out the 75LC “Light” button and prevent the lights from being turned off from outside
the walk-in
•Activate the 20-minute AutoPanic timer
•If the IP-1 is not pressed within 40-seconds, the lights will turn off
• After 20-minutes, the IP-1 beeps and blinks again for 40-seconds
•Press the IP-1 to “check in “ and restart the AutoPanic timer
•The 20-minute alarm cycle will repeat for as long as a person remains in the walk-in without
opening the door
•If the IP-1 is not pressed within 40-seconds, the 75LC will automatically sound a panic alarm
Untimed, Manual Light Control (replaces light switches)
• To turn lights on, press the “Light” button on the 75LC
• To turn lights off, press the “Light” button again
PRODUCT OPERATION
LIGHTING AND PANIC CONTROL OPERATION WITH IP-1, MC-1 AND MD-1 OR MD-1+2 INSTALLED
kitchenbrains.com
1-800-327-8766
OR

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 10 of 24
CONFIGURATION MODE
ALARM OPERATION MODE
The 75LC has four modes of operation: Sleep, Run, Test, and Program.
SLEEP MODE:
The 75LC ships from the factory in Sleep Mode. (The rechargeable battery is connected physically but is
not connected electrically until AC power is applied)
To restore Sleep Mode if the alarm has been powered up:
1. Disconnect from AC power. Press and hold Lights (Prog) button for 3 seconds. Display reads
“con” (conrm)
2. Press Test (Up). Display reads “bye”, all functions shut off and the alarm goes into Sleep Mode (Ready to ship)
3. The battery automatically reconnects electrically the next time AC Power is applied
RUN MODE:
All 75LC monitoring functions take place in RUN Mode
Note the following:
1. You must press Silence to clear a Temp or Power Failure alarm, even if the condition has corrected
itself. This informs the operator if these alarm conditions happened, even if no one was present
during the alarm.
2. If door is being monitored, close the door to clear a Door Ajar alarm.
3. Open and close the door or press Silence to clear a Panic Alarm.
TEST MODE:
Press Test to perform simple test procedures and to view alarm parameter settings.
The following occurs:
1. All visual indicators light (LEDS)
2. Software version rE (revision) is displayed
3. Program Menu parameters and settings are sequentially displayed (See Parameter List below)
4. Horn sounds and alarm relay activates
5. Pressing Silence at any time during the Test procedure restores Run Mode (normal operation)
6. Run Mode is automatically restored 10 seconds after Test is complete, if Silence isn’t pressed
PROGRAM MODE:
Use PAS-PRO™ password programming to select or customize a factory preset mode of operation
(See pg. 13). The 10 available program parameters with symbols and ranges are shown on following pages.
PREVENTIVE MAINTENANCE REMINDER
PROGRAMMING REMINDER TO CLEAN CONDENSER AND INSPECT COIL:
1. While pressing and holding Silence, press Test. Display reads “???”, then “0”
2. Press and hold Test (Up) to scroll up or Silence (Down) to scroll down to the desired operation
password
a. For Clean Condenser Feature, scroll up to Password (70) to activate and password (80) to clear
b. For Inspect Coil Feature, scroll up to Password (71) to activate and password (81) to clear
c. Each number shown under menu option (70 & 71) represents 1 week. If selected to annunciate, it will
sound a reminder to perform Inspection
3. Press Lights (Prog). Displays initially reads “Set” and then the password for the selected operation
4. 75LC returns to Run Mode, operating in accordance with selected operation password
kitchenbrains.com
1-800-327-8766

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 11 of 24
CONFIGURATION MODE
USING PAS-PRO™ TO SELECT AN OPERATION PASSWORD PROGRAMMING (50 – 59)
See passwords and corresponding program menu parameters in tables on previous page.
NOTE: Parameter passwords “50” thru “59” are “entry points” into the programming menu. The programming
menu is an “endless loop” and the entire menu can be accessed from any entry point.
1. While pressing and holding Silence, press Test. Display reads “???” then “0”.
2. Press Test (Up) to scroll to the password for the desired parameter you wish to change. Silence (Down)
may be used to lower the number if you overshoot.
3. Press Lights (Prog). Display reads “Prg”, then the selected parameter symbol, then the present parameter
setting. (Example: HI SETPT SYMBOL = “HI” + “ALr”, default setting = “42o”).
4. Use the Test (Up) switch or the Silence (Down) to change parameter setting if necessary
5. Once the desired parameter setting is selected, momentarily press Lights (Prog) to advance to the next
parameter and continue in the same manner for each setting you wish to change.
6. Exit from Program Mode occurs automatically if no buttons are pressed for 5 seconds. Display reads
“SEt” and the 75LC returns to Run Mode, operating in accordance with new settings. To manually exit,
HOLD Lights (Prog) Switch for 2 seconds until Display reads “SEt”. (75LC returns to run mode, operating in
accordance with new settings.) It is not necessary to complete the menu to change selected parameters.
ANY CHANGES MADE PRIOR TO EXITING WILL BE STORED AS NEW OPERATING PARAMETERS.
If desired, once programming is complete, press the “TEST” switch to verify new parameter settings.
OPERATION PASSWORD EXAMPLES
kitchenbrains.com
1-800-327-8766
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 20 21 22 23 24
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL F F F F F
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10)
53 LOSETPOINT(box1&2) LO+Alr
COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20)
COOLER30(FRZR-20)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 25 26 27 28 29
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL C C C C C
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12)
COOLER6(FRZR-12)
53 LOSETPOINT(box1&2) LO+Alr
COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29)
COOLER-1(FRZR-29)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
WITHAUTOPANIC
WITHOUTAUTOPANIC
OPERATIONPASSWORDS,INFAHRENHEIT
LIGHTOPERATION
OPERATIONPASSWORDS,INCENTIGRADE
LIGHTOPERATION
Toclearusepassword80
Toclearusepassword81
Toclearusepassword80
Toclearusepassword81
WITHAUTOPANIC
WITHOUTAUTOPANIC
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 20 21 22 23 24
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL F F F F F
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10)
53 LOSETPOINT(box1&2) LO+Alr
COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20)
COOLER30(FRZR-20)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 25 26 27 28 29
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL C C C C C
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12)
COOLER6(FRZR-12)
53 LOSETPOINT(box1&2) LO+Alr
COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29)
COOLER-1(FRZR-29)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
WITHAUTOPANIC
WITHOUTAUTOPANIC
OPERATIONPASSWORDS,INFAHRENHEIT
LIGHTOPERATION
OPERATIONPASSWORDS,INCENTIGRADE
LIGHTOPERATION
Toclearusepassword80
Toclearusepassword81
Toclearusepassword80
Toclearusepassword81
WITHAUTOPANIC
WITHOUTAUTOPANIC
EXAMPLE: USE PASSWORDS [20-29]
TO CHOOSE SELECTED OPERATION
EXAMPLE: USE PASSWORDS [50-59]
TO CHOOSE SELECTED OPERATION
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 20 21 22 23 24
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL F F F F F
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10)
53 LOSETPOINT(box1&2) LO+Alr
COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20)
COOLER30(FRZR-20)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 25 26 27 28 29
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL C C C C C
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12)
COOLER6(FRZR-12)
53 LOSETPOINT(box1&2) LO+Alr
COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29)
COOLER-1(FRZR-29)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
WITHAUTOPANIC
WITHOUTAUTOPANIC
OPERATIONPASSWORDS,INFAHRENHEIT
LIGHTOPERATION
OPERATIONPASSWORDS,INCENTIGRADE
LIGHTOPERATION
Toclearusepassword80
Toclearusepassword81
Toclearusepassword80
Toclearusepassword81
WITHAUTOPANIC
WITHOUTAUTOPANIC
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS 20 21 22 23 24
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL F F F F F
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10) COOLER42(FRZR10)
53 LOSETPOINT(box1&2) LO+Alr
COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20) COOLER30(FRZR-20)
COOLER30(FRZR-20)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
(DEFAULT)
COMPLIANT15MIN.
TIMEDLIGHTINGWITH
AUTOPANIC
ON-OFFLIGHTSWITCH,
NOTIMEDLIGHTING
WITHAUTOPANIC
COMPLIANT15MIN.
TIMEDLIGHTING
WITHOUTAUTOPANIC
NON-COMPLIANT150
MIN.TIMEDLIGHTING
WITHOUTAUTOPANIC
ON-OFFLIGHT
SWITCH,WITHOUT
AUTOPANIC
PASSWORDS
25 26 27 28 29
PROGRAMMENUPARAMETERS SYMBOL
50 SCALE SCL C C C C C
51 CALIBRATION(box1&2) Prb+CAL 0 0 0 0 0
52 HISETPOINT(box1&2) HI+Alr
COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12) COOLER6(FRZR-12)
COOLER6(FRZR-12)
53 LOSETPOINT(box1&2) LO+Alr
COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29) COOLER-1(FRZR-29)
COOLER-1(FRZR-29)
54 TEMPALARMDELAY(box1&2) Alr+dLy
60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.) 60(MIN.)
55 DOORAJARDELAY(box1&2) dor+dLy
20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.) 20(MIN.)
56 RINGBACKDELAY rnG+dLy
0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback) 0(NoRingback)
57 LIGHTSOFFDELAY(box1&2) LtS+dLy
14(MIN.) Infinate(tOG)14(MIN.) 150(MIN.) Infinate(tOG)
58 LIGHTSOPERATIONMODE Lts+OPr Aut Aut tL tL tL
59 ALARMRELAYMODE Alr+rLy
UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched) UnL(Unlatched)
70 CLEANCONDENSER Cln+Con
71 INSPECTCOIL Ins+Col
AUTOSETENABLED? YES YES YES YES YES
AUTODETECTENABLED? YES YES YES YES YES
WITHAUTOPANIC
WITHOUTAUTOPANIC
OPERATIONPASSWORDS,INFAHRENHEIT
LIGHTOPERATION
OPERATIONPASSWORDS,INCENTIGRADE
LIGHTOPERATION
Toclearusepassword80
Toclearusepassword81
Toclearusepassword80
Toclearusepassword81
WITHAUTOPANIC
WITHOUTAUTOPANIC
EXAMPLE: USE PASSWORDS [20-29]
TO CHOOSE SELECTED OPERATION
EXAMPLE: USE PASSWORDS [50-59]
TO CHOOSE SELECTED OPERATION

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 12 of 24
CONFIGURATION MODE
OPERATION PASSWORD EXAMPLES
kitchenbrains.com
1-800-327-8766
PASSWORD PROGRAM MENU PARAMETER
61 FACTORY SETTING TO REMOVE ACCESSORIES
10 LOCKING THE KEYPAD
105 UNLOCKING THE KEYPAD
20 FACTORY DEFAULTS
PARAMETER LIST
PASSWORD PARAMETER SYMBOL RANGE
50 SCALE SCL F or C
51 PROBE CALIBRATION (1) Prb + CAL -5 to +5
52 HI ALARM TEMP SETPt HI + ALr -40F to 125F
53 LO ALARM TEMP SETPT LO +ALr -40F to 125F
54 TEMP ALARM DELAY Alr + dLy 0 to 150 Min.
55 DOOR AJAR DELAY dor + dLy 0 to 60 Min.
56 RINGBACK DELAY (2) rng + dLy 0 to 60 Min.
57 LIGHTS OFF DELAY (3) LtS + dLy 0 to 150 Min.
58 LIGHTS OPERATION (4) LtS + OPr Aut or tL
59 ALARM RELAY (5) Alr + rLy Unlatch (UnL) or Latch (LCH)
70 REMINDER Cln+Con 1=1 Week
71 REMINDER Ins+Col 1=1 Week

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 13 of 24 kitchenbrains.com
1-800-327-8766
CONFIGURATION MODE
PROBE CALIBRATION (PASSWORD 51)
The 75LC comes pre-calibrated to read proper temperature with Automatic Scale Conversion from F to C. Calibration
parameter provides a means for offsetting the displayed temperature by +/-5 if so desired. NOTE: CALIBRATING offset doesn’t
change setpoints
RINGBACK DELAY (PASSWORD 56)
Ringback generates timed repeat audible alarms during an ongoing temperature or power failure alarm condition. Select
desired time interval for this to occur.
LIGHTS OFF DELAY (PASSWORD 57)
The lights will turn OFF after the pre-programmed time. Factory default time is 14 minutes - Field programmable
LIGHTS OPERATION (PASSWORD 58)
“Aut” operation provides Timed Lighting with Auto panic. "tL” operation provides regular timed lighting.
ALARM RELAY (PASSWORD 59)
Normally Open (N/O) and Normally Closed (N/C) dry contacts are provided for low voltage of 28-30VDC at 1 amp. For main
voltages, 120/240VAC, an external relay will be required with 28-30VDC at 1A. To control main voltages, 120/240VAC, an
external relay will be required.
The two Relay Modes are:
UNLATCHED: Default Setting. Relay activates when alarm occurs and deactivates when Silence is pressed. Typical Application:
Controlling a remote buzzer or light.
LATCHED: Relay activates when alarm occurs and deactivates when alarm condition has been cleared and Silence has
been pressed. Typical Application: Connection to a building management system where relay remains activated until alarm
condition clears and is acknowledged.

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 14 of 24 kitchenbrains.com
1-800-327-8766
• This product (“Product”) must be installed by a licensed electrician experienced in working in the types of environments
for which this Product is intended to be utilized; specically, commercial Cooler/Freezer coolers and freezers (“Equipment”).
• Personnel installing the Product must carefully and completely read the Operating and Installation Instructions
(“Instructions”), and instructions and specications of the Equipment manufacturers, before attempting to operate and
install the Product. Failure to comply with the Instructions, and the instructions and specications of the Equipment
manufacturers, may result in personal injury and/or property damage and may void the warranty of the Product. Retain
the Instructions for future reference.
• The Product shall only be used for the purposes described in the Instructions.
• During installation of the Product, all applicable laws, regulations and industry rules, including local electrical and safety
codes, the National Electric Code (NEC) and the Occupational Safety and Health Act (OSHA), must be strictly followed.
Consistent therewith, follow applicable electrical codes regarding running of low voltage wiring and high voltage wiring
in separate conduits and use appropriately rated wire (insulation type, voltage rating and wire gauge) for all connections.
Supply connection wiring must be rated at least 90°C. Use copper conductors only.
• Conrm that the power source conforms to the requirements of the Product before connecting.
• Do not exceed the rated limits of the Product. Refer to the Product specications for suitability of the Product to
the application.
• The Product is not suitable for use in wet locations. Do not expose the Product to water, moisture or condensation.
In no event should the Product be exposed to environments where sudden temperature changes with high humidity may
result in the formation of condensation.
• Any openings in the walls, ceiling or oor of the Equipment for wiring or other reason must be sealed (made
airtight and watertight) with appropriate materials (e.g., silicone, caulk or foam), both on the outside and inside of the
Equipment, to prevent moisture or condensation from entering the compartment of the Equipment and forming
and accumulating on the interior walls of the compartment and the contents of the compartment, including
the Product. Failure to properly seal such openings may (i) result in damage to the Equipment and contents of the
compartment (ii) pose a safety hazard and (iii) void the warranty of the Product.
•To prevent moisture or condensation from entering or forming in the enclosure used for the Product, any openings in
this enclosure (for wiring access or other purpose) must be appropriately sealed with materials such as silicone, caulk
or foam.
• Installation of the Product should be inspected and the Product tested by qualied personnel to ensure the Product
performs safely and in accordance with the Product specications. Periodic testing of the Product should be performed
on an ongoing basis (at least quarterly) to ensure the Product continues to perform properly.
• All personnel operating, maintaining, repairing or interfacing with the Product must be instructed in the use of the Product
and provided with the Instructions, which are accessible on the Kitchen Brains website at www.kitchenbrains.com.
• WARNING: Hazard of electric shock! Power sources must be turned off or otherwise disconnected prior to installation
or servicing of the Product. Lock and tag power disconnects to prevent an unexpected application of power.
INSTALLATION
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 15 of 24 kitchenbrains.com
1-800-327-8766
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS
Mounting the
Enclosure For
The 75LC
Any enclosure used for 75LC mounting must provide multiple wire access hubs for running line voltage
wiring and low voltage wiring in separate conduits. Determine the wire access hubs to be utilized for
the installation and plug and seal any remaining unused openings with hardware and/or sealant. The
75LC will t into a typical outdoor, single gang outlet box.
Surface Mount: A typical outdoor, single gang outlet box may be used for surface mounting. Mount
the enclosure vertically onto the desired surface. If fastening the enclosure with screws directly
through the back wall of the enclosure, use two screws, centered vertically above and below the
opening in the rear of the enclosure.
Flush Mount: (See ush mount cutout template, pg 17). Make the cutout and the mounting holes
into the compartment door frame or compartment wall as shown on the cutout template. Once the
cutout and mounting holes have been made, screws in the mounting holes may be used to hold the
selected enclosure in place during the foaming process.
Mounting the IP-1 The IP-1 may be ush mounted into a standard J-Box. A typical outdoor type single gang outlet box
may be used for surface mounting. (NOTE: The IP-1 is a low voltage device. Wiring to the IP-1 must
not be installed in the same conduit as line voltage wiring. An 8’ length of color coded wiring for
connecting the IP-1 is provided.) Typical mounting location for the IP-1 is inside of the walk-in adjacent
to the door. Any wire pathways or other openings leading into the enclosure for the IP-1 from outside
of the walk-in must be sealed both on the outside and on the inside of the walkin to prevent a pathway
for condensation.
Mounting the MD-1
or MD-1+2 The MD-1 or MD-1+2 may be ush mounted into a standard J-Box. A typical outdoor type single
gang outlet box may be used for surface mounting. (NOTE: The MD-1 or MD-1+2 is a low voltage
device. Wiring to the MD-1 or MD-1+2 must not be installed in the same conduit as line voltage wiring.
A 6’ length of color coded installation wiring is pre-connected to the MD-1 or MD-1+2). Typical
mounting location for the MD-1 or MD-1+2 is inside of the walk-in above the door. There is no need
to open or access the motion detector itself. Mount the MD-1 or MD-1+2 horizontally with the white
oval lens facing down. The red light inside of the MD-1 or MD-1+2 will illuminate whenever the MD-1
or MD-1+2 is activated.
WIRING: See Wiring Diagrams, page 18. Keep wiring relatively short inside of the enclosure for the
75LC. Make sure that wiring openings into all enclosures are sealed properly to prevent a pathway
for condensation.
Line Voltage Wiring
on the 75LC The line voltage terminal block will accept up to 12AWG wire. Wire the 3 line voltage connections in
accordance with the accompanying 75LC Connections diagram. Connections are also marked on
the 75LC.The stripped end of the line voltage wire connections should be kept short, approximately
¼” long. Insert the wire ends into the appropriate terminal block openings and tighten the screws
securely to clamp the wires into place. With stranded wire, make sure that all strands are captured
in the terminal block openings. Tug on wire to make sure connections are secure. MAKE SURE THE
SCREWS ARE TIGHT! Supply connection wiring must be rated at least 90°C. Use copper conductors
only. Make sure that the green wire from the 75LC faceplate is properly grounded. If a metal enclosure
is used for mounting the 75LC, make sure that the enclosure is also properly grounded.

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 16 of 24 kitchenbrains.com
1-800-327-8766
Magnetic Contacts
Mounting Mounting method will vary depending on the type of contacts utilized. Make sure that the operating
gap between the magnet part and the switch part of the contacts accurately detects a door open or
door closed condition. (The DOOR light is on constantly when the door is open. This light may be utilized
to assist in proper switch and magnet placement.) NOTE: For compartments with more than one
door, multiple sets of contacts, wired in series, may be utilized to monitor the status of multiple doors.
Mounting the 75LC
onto the enclosure Mount the 75LC onto the enclosure with the provided mounting screws. If the 75LC is mounted
onto an outdoor type single gang outlet box, route all wiring away from the battery when the 75LC is
inserted. Inspect the installation for compliance with electrical codes, safety and sealing against
moisture and condensation. Test to conrm that the Product is installed and are operating properly
in accordance with these instructions. Periodic testing is recommended to ensure continued
proper operation.
INSTALLATION GENERAL SAFETY MEASURES AND PRODUCT LIMITATIONS
Locking the Keypad Enter programming menu, select password “10” and press Lights (Prog) switch. Display reads
“Set” then returns to run mode. The keypad is locked. To unlock, proceed as above, using password
“105”. The keypad is unlocked. Use password “61” for deleting any accessory that is no longer
needed in the circuit.
Resetting the 75LC
to Factory Defaults
Enter programming menu, select password “20” and press LIGHTS Button. Display reads “Set” then
returns to run mode. The 75LC is now in factory mode.
Temperature
Probe Mounting
Run the probe into the monitored compartment and locate the sensor in a spot which will typify the
average ambient temperature. Recommended location is in the center of the ceiling. Fasten the
sensor with the provided clamp. Make sure sensor and sensor wire are positioned and/or protected,
so as not to be damaged by products or items in the monitored area. Seal any openings made for
passage of the probe wire into the Cooler/Freezer on the inside and the outside of the Cooler/Freezer
to prevent a pathway for condensation.
Low Voltage Wiring The low voltage terminal blocks will accept wire from 24-16AWG. Accessories and sensors are
typically provided with 24-22AWG wire. General Accessories and sensor connections are shown on
the accompanying 75LC Connections diagram. Connections are also marked on the 75LC. See the
diagrams labeled “IP-1 Connections”, “MD-1 or MD-1+2 Connections”, and “IP-1 & MD-1or MD-1+2
Connections” for wiring specic to your application. The stripped end of the low voltage wire
connections should be kept short, approximately ¼” long. To connect wires, press down on the
respective plunger on the top of the terminal block, insert the wire into the respective hole and
release the plunger. Tug on wires to make sure connections are secure and that they are grabbing
bare wire and not insulation. NOTE: If the IP-1 and the MD-1or MD-1+2 will both be installed, use
the enclosure for the IP-1 as a junction box for connecting the MD-1 in accordance with the “IP-1
& MD-1 or MD-1+2 Connections” diagram. Connect the green wires together in the IP-1 enclosure
with a wire nut or other connector. Strip the 2 black wires approximately 3/8”, twist together and
insert both into the IP-1 block, in accordance with the diagram. Do the same with the two red wires.
Again, tug gently on all wires to make sure connections are secure.
(The stripped end of the
low voltage wire
connections should
be kept short,
approximately ¼” long.
To connect wires, press
down on the respective
plunger on the top of the
terminal block, insert the
wire into the respective
hole and release the
plunger. Tug on wires to
make sure connections
are secure and that they
are grabbing bare wire
and not insulation.)

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 17 of 24 kitchenbrains.com
1-800-327-8766
3 1/4" 2 7/8"
2 1/2"
FLUSH MOUNT
CUTOUT TEMPLATE
1 5/8"
1 1/4"
FLUSH MOUNT CUTOUT TEMPLATE
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
1A@120VAC
C NC NO
SUPPLY
POWER
120 VAC
LIGHTS
8.3A@120VAC
1000W
NEUTRAL
LINE
LIGHTS
N/C
CONTACTS
TEMP.
PROBE
MD-1
MOTION
DECTECTOR IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
IMPORTANT!!
MOUNT THE 75LC
ENCLOSURE WITH THE
GROUND LUG TO THE LEFT
SO THAT THE BATTERY
GROUND LUG WHEN THE
ALARM IS INSTALLED
GROUND
LUG TO
LEFT!!
75LC ENCLOSURE POSITION
DOES NOT CONTACT THE
(WHITE)*
(BLACK)*
(RED)*
*COLORS INDICATED ARE TYPICAL
75LC TERMINAL
BLOCK
LINE VOLTAGE CONNECTIONS
75LC CONNECTIONS
CONNECT THE GROUND WIRE
TO GROUND LUG BEFORE
INSERTING 75LC

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 18 of 24 kitchenbrains.com
1-800-327-8766
MD-1 AND MD-2 CONNECTIONS
STANDARD ACCESSORIES AND BUILDING CONNECTION SCHEMATIC

MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 19 of 24 kitchenbrains.com
1-800-327-8766
MD-1 CONNECTION
STANDARD ACCESSORIES AND BUILDING CONNECTION SCHEMATIC
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
C NC NO SUPPLY
POWER
120 VAC
LIGHTS
NEUTRAL
LINE
LIGHTS
N/C
CONTACTS
TEMP. PROBE
MD-1
MOTION
DECTECTOR
IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
(WHITE)*
(BLACK)*
(RED)*
*COLORS INDICATED ARE TYPICAL
BLOCK
LINE VOLTAGE CONNECTIONS
MODULARM 75LC WIRING DIAGRAM Rev 2
TEMP B R Y DOOR
MD W
G
B
R
(GREEN)
B
W
R
Y
1000W
8.3A@120VAC
*75LC MUST
BE GROUNDED
GREEN WIRE
75LC TERMINAL
75LC
FROM
BACK
PR
REVISION 2
REVISION 3
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
C NC NO
SUPPLY
POWER
120 VAC
LIGHTS
LIGHTS
NEUTRAL
LINE
N/C
CONTACTS
TEMP. PROBE
MD-1
MOTION
DECTECTOR
IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
BW R Y
BW R Y
BW R Y
MD-1
CONNECTION
B=BLACK
R=RED
G=GREEN
LOW
VOLTAGE!!
IP-1
CONNECTION
B=BLACK
R=RED
LOW
VOLTAGE!!
W=WHITE
Y=YELLOW
IP-1
TERMINAL
BLOCK
BW RY
BW R Y
IP-1 / MD-1
CONNECTION
B=BLACK
R=RED
LOW
VOLTAGE!!
W=WHITE
Y=YELLOW
MD-1
MOTION
DETECTOR
G=GREEN
USE IP-1 ENCLOSURE
AS A JUNCTION BOX
FOR CONNECTING MD-1
WIRE NUT OR OTHER
APPROPRIATE SPLICING
75LC TERMINAL
BLOCK
DOOR
TEMP MD
TEMP DOOR
TEMP DOOR
(RED)*
(WHITE)*
(BLACK)*
*COLORS INDICATED ARE TYPICAL
BLOCK
LINE VOLTAGE CONNECTIONS
MODULARM 75LC WIRING DIAGRAM Rev 3
IP-1 CONNECTIONS
MD-1 CONNECTIONS
IP-1 & MD-1 CONNECTIONS
TEMP B R Y DOORMD W
G
B
R
(GREEN)
B
W
R
Y
1000W
8.3A@120VAC
MD
MD
GB R
METHOD
IP-1 ENCLOSURE
(GREEN)
GB R
(GREEN)
MD-1
MOTION
DETECTOR
IP-1
TERMINAL
BLOCK
75LC TERMINAL
BLOCK
75LC TERMINAL
BLOCK
*75LC MUST
BE GROUNDED
GREEN WIRE
75LC TERMINAL
75LC
FROM
BACK
PR
[e-mail]
MODULARM
WWW.KITCHENBRAINS.COM
[e-mail]
MODULARM
WWW.KITCHENBRAINS.COM
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
BOARD LABELS
PLEASE FOLLOW THE
WIRE PLACEMENT AS
INDICATED BY THE
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
MD-1
MAGNETIC
CONTACT (MC-1)
TMP
MD
BWRYDOOR
TEMP
SENSOR
GREEN
B
W
R
Y
B
W
R
Y
75LC # 1 CONNECTIONS
DOOR # 1
ILLUMINATED PUSHBUTTON
DOOR # 2
DOOR # 3
MAGNETIC
CONTACT (MC-1)
MAGNETIC
CONTACT (MC-1)
(IP-1)
ILLUMINATED PUSHBUTTON
(IP-1)
ILLUMINATED PUSHBUTTON
*
(IP-1)
TMP
MD
BWRYDOOR
TEMP
SENSOR 75LC # 2 ONLY READS TEMP
TMP
MD
BWRYDOOR
TEMP
SENSOR 75LC # 3 ONLY READS TEMP
CONNECT ALL LIGHTS TO THIS ALARM'S TERMINAL
OF COMPARTMENT, DOOR AJAR,
MC-1 CONTACTS CAN CONNECT INSIDE IP-1
WIRING DIAGRAM
IP-1'S & MAGNETIC CONTACTS.
MOTION DETECTOR (MD-1)
FUNCTION: TO PROVIDE 3 AND 4 WAY
AND AUTOMATIC "LIGHTS-ON" AT
EACH DOOR.
*NOTE: ALL CONNECTIONS SHOWN ARE LOW
VOLTAGE USING RECOMMENDED INTER-CONNECT
WIRE: [22AWG,MULTI-CONDUCTOR,STRANDED]
PROVIDE SEPARATE CONDUIT FOR LOW VOLTAGE WIRING.
- 75LC WITH MULTIPLE
ALSO SHOWN
LIGHT SWITCHING INSIDE

This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 20 of 24
MD-2 CONNECTIONS
STANDARD ACCESSORIES AND BUILDING CONNECTION SCHEMATIC
kitchenbrains.com
1-800-327-8766
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
C NC NO SUPPLY
POWER
120 VAC
LIGHTS
NEUTRAL
LINE
LIGHTS
N/C
CONTACTS
TEMP. PROBE
MD-1
MOTION
DECTECTOR
IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
(WHITE)*
(BLACK)*
(RED)*
*COLORS INDICATED ARE TYPICAL
BLOCK
LINE VOLTAGE CONNECTIONS
MODULARM 75LC WIRING DIAGRAM Rev 2
TEMP B R Y DOOR
MD W
G
B
R
(GREEN)
B
W
R
Y
1000W
8.3A@120VAC
*75LC MUST
BE GROUNDED
GREEN WIRE
75LC TERMINAL
75LC
FROM
BACK
PR
REVISION 2
REVISION 3
EXPANSION
PORT
TX RX SHLD
DRY
CONTACTS
C NC NO
SUPPLY
POWER
120 VAC
LIGHTS
LIGHTS
NEUTRAL
LINE
N/C
CONTACTS
TEMP. PROBE
MD-1
MOTION
DECTECTOR
IP-1
PUSH
BUTTON
9V,NI-MH
RECHARGEABLE
BATTERY
MAGNETIC
BW R Y
BW R Y
BW R Y
MD-1
CONNECTION
B=BLACK
R=RED
G=GREEN
LOW
VOLTAGE!!
IP-1
CONNECTION
B=BLACK
R=RED
LOW
VOLTAGE!!
W=WHITE
Y=YELLOW
IP-1
TERMINAL
BLOCK
BW RY
BW R Y
IP-1 / MD-1
CONNECTION
B=BLACK
R=RED
LOW
VOLTAGE!!
W=WHITE
Y=YELLOW
MD-1
MOTION
DETECTOR
G=GREEN
USE IP-1 ENCLOSURE
AS A JUNCTION BOX
FOR CONNECTING MD-1
WIRE NUT OR OTHER
APPROPRIATE SPLICING
75LC TERMINAL
BLOCK
DOOR
TEMP MD
TEMP DOOR
TEMP DOOR
(RED)*
(WHITE)*
(BLACK)*
*COLORS INDICATED ARE TYPICAL
BLOCK
LINE VOLTAGE CONNECTIONS
MODULARM 75LC WIRING DIAGRAM Rev 3
IP-1 CONNECTIONS
MD-1 CONNECTIONS
IP-1 & MD-1 CONNECTIONS
TEMP B R Y DOORMD W
G
B
R
(GREEN)
B
W
R
Y
1000W
8.3A@120VAC
MD
MD
GB R
METHOD
IP-1 ENCLOSURE
(GREEN)
GB R
(GREEN)
MD-1
MOTION
DETECTOR
IP-1
TERMINAL
BLOCK
75LC TERMINAL
BLOCK
75LC TERMINAL
BLOCK
*75LC MUST
BE GROUNDED
GREEN WIRE
75LC TERMINAL
75LC
FROM
BACK
PR
[e-mail]
MODULARM
WWW.KITCHENBRAINS.COM
[e-mail]
MODULARM
WWW.KITCHENBRAINS.COM
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
BOARD LABELS
PLEASE FOLLOW THE
WIRE PLACEMENT AS
INDICATED BY THE
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
PLEASE FOLLOW THE
WIRE PLACEMENT AS
BOARD LABELS
INDICATED BY THE
MD-1
MAGNETIC
CONTACT (MC-1)
TMP
MD
BWRYDOOR
TEMP
SENSOR
GREEN
B
W
R
Y
B
W
R
Y
75LC # 1 CONNECTIONS
DOOR # 1
ILLUMINATED PUSHBUTTON
DOOR # 2
DOOR # 3
MAGNETIC
CONTACT (MC-1)
MAGNETIC
CONTACT (MC-1)
(IP-1)
ILLUMINATED PUSHBUTTON
(IP-1)
ILLUMINATED PUSHBUTTON
*
(IP-1)
TMP
MD
BWRYDOOR
TEMP
SENSOR 75LC # 2 ONLY READS TEMP
TMP
MD
BWRYDOOR
TEMP
SENSOR 75LC # 3 ONLY READS TEMP
CONNECT ALL LIGHTS TO THIS ALARM'S TERMINAL
OF COMPARTMENT, DOOR AJAR,
MC-1 CONTACTS CAN CONNECT INSIDE IP-1
WIRING DIAGRAM
IP-1'S & MAGNETIC CONTACTS.
MOTION DETECTOR (MD-1)
FUNCTION: TO PROVIDE 3 AND 4 WAY
AND AUTOMATIC "LIGHTS-ON" AT
EACH DOOR.
*NOTE: ALL CONNECTIONS SHOWN ARE LOW
VOLTAGE USING RECOMMENDED INTER-CONNECT
WIRE: [22AWG,MULTI-CONDUCTOR,STRANDED]
PROVIDE SEPARATE CONDUIT FOR LOW VOLTAGE WIRING.
- 75LC WITH MULTIPLE
ALSO SHOWN
LIGHT SWITCHING INSIDE
MODULARM®75LC MULTI-MONITOR | OPERATING MANUAL
This document contains confidential information. Dissemination, publication, copying, or duplication of this document or software described herein without prior written authorization is strictly prohibited.
Page 10 of 24 kitchenbrains.com
1-800-327-8766
