KitchenAid KECC501GAL2 User manual

COOKTOP PARTS
1
For Models: KECC501GBL2, KECC501GWH2, KECC501GAL2
(Black) (White) (Almond)
30" ELECTRIC
BUILT−IN
COOKTOP
10−02 Litho in U.S.A. (RS) Part No. 8177487

COOKTOP PARTS
2
For Models: KECC501GBL2, KECC501GWH2, KECC501GAL2
(Black) (White) (Almond)
8177487
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT3191771 Installation
Instructions
LIT3191793 Wiring Diagram
LIT3191524 Use & Care Guide
LIT3191638 Safer Cooking Tips
2 Cooktop, Glass
4455296 Black
4455294 White
4455295 Almond
3 246119 Screw
4 4455421 Bracket, Switch
Mounting
6 3191791 Spring Locator (8)
7 Switch, Infinite
4454541 Use W/2400W
Left Front Burner
3191050 Use W/1700W
Right Rear Burner
3191049 Use W/1400W
Left Rear Burner
3191049 Use W/1200 W
Right Front Burner
8 3192439 Seal, Switch Shaft
9 3191945 Light, Indicator
10 Knob, Control (4)
9750372FF Black
9750372FW White
9750372FT Almond
11 4456401 Box, Burner
13 3192477 Bumper, Silicone
14 3196537 Screw
15 3182435 Seal, Switch (4)
17 311865 Screw
20 3191515 Rail, Element (2)
21 3192268 Rail, Element (1)
22 3191343 Lamp, Hot
Surface Indicator
24 Element, Surface
(Includes # 16)
8272565 2500W Left Front
8272567 1200W Right Front
8272566 1800W Right Rear
8272564 1500W Left Rear
3192737 Seal, Heat
3183956 Seal, Switch
Cover

MISCELLANEOUS PARTS
3
For Models: KECC501GBL2, KECC501GWH2, KECC501GAL2
(Black) (White) (Almond)
8177487
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3172515 Hardware, Mounting
3191239 Tape, Foam
4455364 Bracket,
Support (4)
3192408 Bracket,
Support (2)
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
3191048 Cleaner, Glass
WIRING HARNESS PARTS
4455271 Wiring Harness
Surface Unit
313438 Clip, Harness
3400015 Screw, Ground
3192220 Conduit
