KitchenAid KGCS166GAL1 User manual

COOKTOP, BURNER AND GRATE PARTS
1
For Models: KGCS166GBL1, KGCS166GWH1, KGCS166GAL1, KGCS166GBT1, KGCS166GSS1
(Black) (White) (Almond) (Biscuit) (Stainless Steel)
12−99 Litho in U.S.A. (RS) Part No. 8177469
36" GAS COOKTOP

COOKTOP, BURNER AND GRATE PARTS
2
For Models: KGCS166GBL1, KGCS166GWH1, KGCS166GAL1, KGCS166GBT1, KGCS166GSS1
(Black) (White) (Almond) (Biscuit) (Stainless Steel)
8177469
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Cooktop
3191256 White
3191255 Black
3191257 Almond
3191295 Biscuit
3191258 Stainless Steel
2 Collar, Knob
3192165 White
3192164 Black
3192166 Almond
3192167 Biscuit
3 3193091 Seal, Foam
4 Nameplate
3191516 White
3191514 Black
3191517 Almond
3191920 Biscuit
6 Cap, (RF)(LR)
3191729 White
3191728 Black
3191730 Biscuit
3192486 Use w/Stainless
Steel Model
7 Cap, (CR)
3191732 White
3191731 Black
3191733 Biscuit
3192487 Use w/Stainless
Steel Model
8 Cap, (RR)
3191735 White
3191734 Black
3191736 Biscuit
3192488 Use w/Stainless
Steel Model
9 Cap, (LF)
3191738 White
3191737 Black
3191739 Biscuit
3192489 Use w/Stainless
Steel Model
10 Grate, Burner
3191486 White
3191485 Black
3191487 Biscuit
3192485 Use w/Stainless
Steel Model
11 Grate, Filler
3191281 White
3191280 Black
3191282 Biscuit
3192483 Use w/Stainless
Steel Model
12 Knob, Control (4)
3191923 White
3191922 Black
3191924 Almond
3191925 Biscuit
13 9754215 Ignitor
14 Orifice
3192528 RF −LR
3192523 Center
3192524 RR
3192525 LF
15 Holder, Orifice
9754182 RF −LR
9754188 LF
9754187 RR
9754186 Center
16 Head, Burner
8273216 RF −LR
9754181 LF
8273214 RR
8273215 Center
18 4449809 Screw
20 3368921 Screw

BURNER BOX, GAS VALVES, AND SWITCHES
33
For Models: KGCS166GBL1, KGCS166GWH1, KGCS166GAL1, KGCS166GBT1, KGCS166GSS1
(Black) (White) (Almond) (Biscuit) (Stainless Steel)
8177469

BURNER BOX, GAS VALVES, AND SWITCHES
4
PARTS NOT ILLUSTRATED
For Models: KGCS166GBL1, KGCS166GWH1, KGCS166GAL1, KGCS166GBT1, KGCS166GSS1
(Black) (White) (Almond) (Biscuit) (Stainless Steel)
8177469
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 3191557 Rail, Burner
2 3191317 Pipe, Manifold
3 3191292 Valve, Gas Burner
Burner, (RF)(LR)
4 3191387 Seal, Shaft
5 3191293 Valve, Gas Burner
(RR & CR)
6 3192157 Valve, Gas
Burner (LF)
7 3192819 Rail, Center
8 307630 Bolt, Gas Valve
9 3177991 Screw
10 3192491 Bracket, Mainfold
11 3196160 Screw
12 3191336 Harness & Switches
14 3191324 Tubing, Gas
Burner (RF)
15 3191326 Tubing, Gas
Burner (LF)
16 3191325 Tubing, Gas
Burner (RR)
17 3191327 Tubing, Gas
Burner (LR)
18 3191462 Shield, Heat (2)
19 3191332 Tubing, Gas
Burner (CR)
21 3177120 Regulator, Pressure
22 3192498 Burner Box
27 3190700 Module Spark
LITERATURE PARTS
LIT3191827 Installation
Instructions
LIT3193071 Use & Care Guide
LIT3192099 Wiring Diagram
LIT3191638 Tips−Safer Cooking
LIT3192742 LP Conversion
Instructions
Illus. Part
No. No. DESCRIPTION
Following Parts Not Illustrated
3192231 Cord, Power
4173634 Bushing
3179557 Screw
3183401 Bracket, Mounting
4167077 Tinnerman Nut
Miscellaneous
3188310 Hardware, Mounting
3192741 Conversion Kit
Natural Gas To L.P.
WIRING HARNESS PARTS
3192229 Harness,
Ignitor 15" (2)
3191417 Wire, Ground
3192230 Harness,
Ignitor 28" (2)
