COOKTOP PARTS
1
30" ELECTRIC
BUILT−IN
COOKTOP
For Models: KECC508MBL01, KECC508MWW01, KECC508MSS01, KECC508MBB01
(Black) (Designer White) (S.Steel) (Pure Biscuit)
10−04 Litho in U.S.A. (cre) Part No. 8186150

COOKTOP PARTS
2
For Models: KECC508MBL01, KECC508MWW01, KECC508MSS01, KECC508MBB01
(Black) (Designer White) (S.Steel) (Pure Biscuit)
8186150
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
LIT8285316 Installation
Instructions
LIT8285627 Tech Sheet
LIT8285368 Use & Care Guide
LIT3191638 Safer Cooking Tips
COOKTOP PARTS
2 Cooktop, Glass
8285313 Black
8285387 Designer White
8285389 Stainless Steel
8285388 Pure Biscuit
3 246119 Screw
4 8284627 Frame, Cooktop
(Stainless Steel
model only)
6 3191791 Spring Locator (8)
9 8285571 Wall, Inside
3196160 Screw
10 8285534 Bracket, Bottom
3196160 Screw
11 8285172 Box, Burner
12 3192439 Seal, Switch Shaft
13 8285617 Board, Control
14 3196537 Screw
15 8285346 Board, Power
4449745 Screw
17 4456923 Box, Touch Control
3196160 Screw
18 8285319 Cable Ass’y
20 8285104 Rail, Element (2)
21 3192268 Rail, Element (1)
23 8285568 Cover, Harness
3196160 Screw
24 Element, Surface
8285230 1200W RF − LR
8285468 1800W RR
8285233 1000/2400W LF
25 4449868 Block, Terminal
26 3196163 Screw, 10−16 x 7/8
28 112432 Nut, #10−32 Hex
29 4456921 Support, Module
30 4455917 Bracket, Mounting
3400093 Screw

MISCELLANEOUS PARTS
3
For Models: KECC508MBL01, KECC508MWW01, KECC508MSS01, KECC508MBB01
(Black) (Designer White) (S.Steel) (Pure Biscuit)
8186150
Illus. Part
No. No. DESCRIPTION
FOLLOWING PARTS
NOT ILLUSTRATED
Miscellaneous
3172515 Mtg. Hardware Kit
3192408 Bracket,
Support (2)
MISCELLANEOUS PARTS
SPLICING WIRES−−25FT.
LENGTH
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
4456147 Cleaner, Glass
WIRING HARNESS PARTS
8285470 Wiring Harness
Surface Unit
FE02313 Bushing
3400015 Screw, Ground
8285599 Conduit Assy.
