KitchenAid KECC506RSS05 User manual

COOKTOP PARTS
1
For Models: KECC506RSS05
(Stainless)
10−08 Litho in U.S.A. (amd) (psw) Part No. W10240396 Rev. A
30" ELECTRIC
CERAN
COOKTOP

COOKTOP PARTS
2
For Models: KECC506RSS05
(Stainless)
W10240396
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8286066 English/French
8304571 Canadian
8286073 Wiring Diagram
W10162162 Use & Care Guide
Safer Cooking Tips
9762761 English
W10065852 French
2 8286946 Cooktop, Glass
3 246119 Screw
4 8285935 Bracket, Switch
Mounting
5 9759094 Spring Locator (8)
6 Switch, Infinite
3191049 LR − RF
4456027 RR
8286070 LF
7 3183956 Seal, Switch Shaft
8
8286096BL Knob, Control (4)
9 8285862 Box, Burner
10 4455917 Bracket, Mounting
11 3400093 Screw
12 3196537 Screw
13 8285469 Seal, Switch
14 311865 Screw
15 9763517 Rail, Element (2)
16 8286344 Rail, Element (1)
17 8286055 Lamp, Hot
Surface Indicator
18
W10142240 Frame, Cooktop
19 Element, Surface
8523698 1200W LR
8523697 1500W RF
8285937 2000/1000W RR
8285846 2500/1800/900W
LF
20 4455468 Shield−Heat,
Control
21 Seal, Heat Shield
3191839 8.74"
8286426 6.41"
22 8286607 Grommet, Flexible

OPTIONAL PARTS
3
For Models: KECC506RSS05
(Stainless)
W10240396
Illus. Part
No. No. DESCRIPTION
Miscellaneous
8286642 Tape, Foam
WIRING HARNESS PARTS
8286417 Harness, Main
3400015 Screw
8286421 Harness, Conduit
