KitchenAid KECC500WBL0 User manual

NOTE: The screws and nuts required to attach a part are listed immediately
following that part.
1 Trim Ring, Cooktop
3150305 Black
3150306 White
3182346 Screw (14)
2 Cooktop, Glass
3181662 Black
3181663 White
4 3150328 Bracket, Switch Mounting
5 Element, Surface
3148829 1400W Left Rear
3148830 1700W Right Front
3148831 2100W Right Rear
3148832 2400W Left Front
6 3149191 Spring Locator (8)
246119 Screw (8)
7 Switch, Infinite
3148962 Use W/1400W Left Rear & 1700W Right Front Burner
3148961 Use W/2100W Right Rear Burner
3148963 Use W/2400W Left Front Burner
155023 Screw (8)
8 309839 Seal, Switch Shaft
9 3149978 Light, Indicator
10 Knob, Control (4)
3150100 Black
3150096 White
11 3150317 Cover, Bottom
3148107 Screw (6)
12 3150316 Element Support (2)
3148107 Screw (4)
13 3150318 Cover, Service
3148107 Screw (5)
15 3182435 Seal, Switch (4)
16 Switch, Limiter
3149121 Use W/3148829 Element
3149122 Use W/3148830 Element
3149128 Use W/3148831 Element
3149124 Use W/3148832 Element
17 Rail, Side
3150325 Right Hand
3150326 Left Hand
18 3150327 Rail, Front & Rear
19 Seal, Silicone
3181645 Small (3)
3181644 Large (2)
20 3181973 Reflector, Heat
21 3150321 Bracket, Hot Surface Indicator
22 3150304 Lamp, Hot Surface Indicator
3148107 Screw (2)
FOLLOWING PARTS NOT ILLUSTRATED
LITERATURE PARTS
LIT3181199 Installation Instructions
LIT3181198 Use & Care Guide

LIT4174121 Repair Parts List
Miscellaneous Mounting Screws
161463 10A X 2 (4)
309029 8-15 X 1/2 (3)
3150320 Clamp (2)
FOLLOWING PARTS NOT ILLUSTRATED
SPLICING WIRES--25FT. LENGTH
242828 Wire, Black 12 Ga. 150~ C
242820 Wire, Black 14 Ga. 150~ C
242822 Wire, Blue 14 Ga. 150~ C
242830 Wire, Brown 14 Ga. 200~ C
242823 Wire, Green 14 Ga. 150~ C
242824 Wire, Orange 14 Ga. 150~ C
242829 Wire, Red 12 Ga. 150~ C
242825 Wire, Red 14 Ga. 150~ C
242831 Wire, Red 14 Ga. 200~ C
242826 Wire, White 14 Ga. 150~ C
242827 Wire, Yellow 14 Ga. 150~ C
242832 Wire, Yellow 14 Ga. 200~ C
ACCESSORY PARTS
814009 Cleaner, Glass

1 3181503 Wiring Harness Surface Unit
2 3181502 Wiring Harness Infinite Switch
4 3149157 Cable Tie
5 313438 Clip, Harness
3148107 Screw (4)
6 3149964 Jumper, Infinite Switch
