COOKTOP PARTS
1
For Models: KECC507RSS04
(STAINLESS)
1−08 Litho in U.S.A.(amd) Part No. W10183544 Rev. A
30" ELECTRIC
CERAN
COOKTOP
COOKTOP PARTS
2
For Models: KECC507RSS04
(STAINLESS)
W10183544
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Installation
Instructions
8286066 Cooktop
8304571 Undercounter Oven
8286447 Wiring Diagram
W10162162
Use & Care Guide
Safer Cooking Tips
9762761 English
W10065852
French
2 8286959 Cooktop, Glass
3 246119 Screw
4 8285935 Bracket, Switch
Mounting
5 8286535 Bracket, Bottom
6 9759094 Spring Locator (8)
7 Switch, Infinite
9763763 Single (2)
9763764 Dual
9763765 Triple
8 3183956 Seal, Switch Shaft
9 8286577 Wall, Inside
10
8286096BL
Knob, Control (4)
11 8286554 Box, Burner
12 4455917 Bracket, Mounting
13 8285240 Seal, Heat
14 3196537 Screw
15 4449868 Block ,Terminal
16 8285469 Seal, Switch
17 311865 Screw
18 3196163 Screw
19 3400093 Screw
20 9763517 Rail, Element
21 8286344 Rail, Element
22 8286055 Lamp, Hot
Surface Indicator
23
W10142240
Frame, Cooktop
24 Element, Surface
8523698 1200W LR
8523697 1500W RF
8285937 2000/1000W RR
8286187 2500/1800/900W LF
25
W10180228
Box, Control
26 8285426 Seal, Heat Shield
27 112432 Nut
28 8286599 Inside Wall,
Insulation
29 8286607 Grommet,
Flexible (2)
30 3192439 Seal, Limiter
OPTIONAL PARTS
3
For Models: KECC507RSS04
(STAINLESS)
W10183544
Illus. Part
No. No. DESCRIPTION
Miscellaneous
OPTIONAL PARTS
8286642 Tape, Foam
FOLLOWING PARTS
NOT ILLUSTRATED
SPLICING WIRES−−25FT.
LENGTH
4456028 Wire, Jumper
242828 Wire, Black
12 Ga. 150 C
242820 Wire, Black
14 Ga. 150 C
242822 Wire, Blue
14 Ga. 150 C
242830 Wire, Brown
14 Ga. 200 C
242823 Wire, Green
14 Ga. 150 C
242824 Wire, Orange
14 Ga. 150 C
242829 Wire, Red
12 Ga. 150 C
242825 Wire, Red
14 Ga. 150 C
242831 Wire, Red
14 Ga. 200 C
242826 Wire, White
14 Ga. 150 C
242827 Wire, Yellow
14 Ga. 150 C
242832 Wire, Yellow
14 Ga. 200 C
ACCESSORY PARTS
WIRING HARNESS PARTS
8286467 Wiring Harness
8286382 Clip, Harness
3400015 Screw
8286338 Conduit, Harness
8286238 Thermostat
